Digital Projection HIGHlite 660 3D Series User manual

Rev E February 2015
HIGHlite 660 3D Series
High Brightness Digital Video Projector
4INSTALLATION AND QUICK-START GUIDE
4CONNECTION GUIDE
4OPERATING GUIDE
4REFERENCE GUIDE
114-242E

page i
Digital Projection HIGHlite 660 3D Series
Rev E February 2015
About This Document
Follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Keep this manual handy for future reference.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2015 Digital Projection Ltd. All rights reserved.
Notes

page ii
Digital Projection HIGHlite 660 3D Series
Rev E February 2015
Introduction
Congratulations on your purchase of this Digital Projection product.
Your projector has the following key features:
• Support for most 3D standards
• Full range of digital and legacy analog inputs
• Control of most aspects of the projector’s operation via LAN and RS232
• Support for a number of aspect ratios and screen sizes
• Nonlinear warp adjustment by moving points on an interpolated grid
• Ceiling mount and rear-screen installation options
• Simultaneous display of two sources via Picture-In-Picture
• Long lamp life
• Motorized lens mount
A serial number is located on the product label. Record it here:
Notes

page iii
Digital Projection HIGHlite 660 3D Series
Rev E February 2015
CONTENTS
INSTALLATION AND QUICK-START GUIDE ..............................1
WHAT’S IN THE BOX? ................................................................... 3
CONNECTING THE POWER SUPPLY ............................................. 4
PROJECTOR OVERVIEW ............................................................... 5
Front and rear views ............................................................................. 5
Control panel indicators ........................................................................ 6
REMOTE CONTROL....................................................................... 7
Infrared reception.................................................................................. 9
Remote control troubleshooting .......................................................... 10
POSITIONING THE SCREEN AND PROJECTOR........................... 11
Tilting the projector.............................................................................. 12
Pitch................................................................................................. 12
Roll and portrait mode........................................................................... 12
Adjusting the optional rigging frame.................................................... 13
CHANGING THE LENS................................................................. 14
Inserting a new lens ............................................................................ 14
Removing the lens .............................................................................. 15
OPERATING THE PROJECTOR.................................................... 16
Switching the projector on................................................................... 16
Switching the projector off................................................................... 16
Selecting an input signal or test pattern.............................................. 17
Input signal ........................................................................................ 17
Test pattern ........................................................................................ 17
Adjusting the lens................................................................................ 18
Zoom................................................................................................ 18
Focus ............................................................................................... 18
Shift ................................................................................................. 18
Adjusting the image............................................................................. 19
Orientation ......................................................................................... 19
Keystone ........................................................................................... 19
Picture .............................................................................................. 19
CONNECTION GUIDE ............................................................................21
SIGNAL INPUTS AND OUTPUTS.................................................. 23
Analog inputs ...................................................................................... 23
Digital inputs and outputs.................................................................... 24
Low latency inputs............................................................................... 25
DVI connection example ..................................................................... 26
EDID on the DVI and VGA inputs........................................................ 27
Using HDMI/DVI switchers with the projector ..................................... 27
3D connections ................................................................................... 28
3D sources up to 60Hz requiring frame doubling and left/right interleaving.......... 28
3D sources above 60Hz not requiring frame doubling.................................... 28
Dual Pipe 3D ...................................................................................... 28
3D Sync............................................................................................... 29
3D Sync in ......................................................................................... 29
3D Sync out ....................................................................................... 29

page iv
Digital Projection HIGHlite 660 3D Series
Rev E February 2015
CONTROL CONNECTIONS........................................................... 30
HDBaseT/LAN..................................................................................... 30
Wired remote control........................................................................... 30
Service port......................................................................................... 31
RS232 ................................................................................................. 31
Control port ......................................................................................... 31
LAN connection examples .................................................................. 32
RS232 connection example ................................................................ 33
OPERATING GUIDE ................................................................................35
USING THE MENUS ..................................................................... 37
Menus and sub-menus........................................................................ 37
Drop-down lists ................................................................................... 38
Sliders ................................................................................................. 39
Commands.......................................................................................... 39
Editing elds........................................................................................ 40
USING THE PROJECTOR............................................................. 41
Main menu .......................................................................................... 41
Lens menu .......................................................................................... 42
Zoom................................................................................................ 42
Focus ............................................................................................... 42
Center Lens ....................................................................................... 42
Nudge............................................................................................... 43
Lens Presets ...................................................................................... 43
Image menu ........................................................................................ 44
Video Filters ....................................................................................... 44
VGA Setup......................................................................................... 44
Color menu.......................................................................................... 45
Gamut .............................................................................................. 45
Black Level and Gain sliders................................................................... 45
Geometry menu .................................................................................. 46
Aspect Ratio....................................................................................... 46
Overscan........................................................................................... 46
Size & Position.................................................................................... 47
Geometry Engine................................................................................. 48
Edge Blend menu................................................................................ 54
Overview ........................................................................................... 54
Array H Position and V Position............................................................... 55
S-Curve Value .................................................................................... 56
Blending............................................................................................ 58
Segmentation ..................................................................................... 59
Blend Width........................................................................................ 61
Black Level Uplift ................................................................................. 61
Reduce Black Level Uplift Width .............................................................. 62
Blending images from multiple projectors ........................................... 65
Before you start................................................................................... 65
Edge Blend procedure .......................................................................... 66
PIP menu ............................................................................................ 74
3D menu.............................................................................................. 75
3D types............................................................................................ 76
CONTENTS (continued)

page v
Digital Projection HIGHlite 660 3D Series
Rev E February 2015
Some 3D settings explained ............................................................... 78
Dark Time.......................................................................................... 78
Source Dominance............................................................................... 78
Sync Offset ........................................................................................ 78
Frame Rate Multiplier............................................................................ 79
Lamps menu ....................................................................................... 80
Setup menu......................................................................................... 81
Reset Default Settings .......................................................................... 81
Input Conguration............................................................................... 82
Network ............................................................................................ 83
On Screen Display ............................................................................... 84
System ............................................................................................. 85
Setting up an IR address ....................................................................... 86
Information menu ................................................................................ 87
Lamps .............................................................................................. 87
Conguration...................................................................................... 87
REFERENCE GUIDE................................................................................89
THE DMD™.................................................................................. 92
CHOOSING A LENS ..................................................................... 94
Basic calculation ................................................................................. 95
Basic calculation example................................................................... 96
Full lens calculation............................................................................. 97
Introducing TRC .................................................................................. 97
Calculating TRC .................................................................................. 98
Calculating the throw ratio with TRC ......................................................... 99
Full lens calculation example ............................................................ 100
SCREEN REQUIREMENTS......................................................... 101
Fitting the image to the DMD™......................................................... 101
1080p images displayed full width .......................................................... 101
1080p images displayed full height......................................................... 102
WUXGA images displayed full width ....................................................... 103
WUXGA images displayed with a height of 1080 pixels................................ 103
WUXGA images displayed full height ...................................................... 104
Diagonal screen sizes....................................................................... 105
Fitting the image to the screen.......................................................... 106
Positioning the screen and projector................................................. 107
POSITIONING THE IMAGE......................................................... 108
Maximum offset range....................................................................... 110
ASPECT RATIOS EXPLAINED.....................................................111
Aspect ratio examples for DMD™ resolution 1080p ......................... 112
Aspect ratio examples for DMD™ resolution WUXGA...................... 115
Aspect ratio example: TheaterScope................................................ 118
FRAME RATES AND PULLDOWNS EXPLAINED..........................119
Interlaced and progressive scan ....................................................... 119
Frame rates of image sources .......................................................... 119
Pulldowns - conversion into destination formats............................... 120
2:3 (normal) pulldown ......................................................................... 120
2:3:3:2 (advanced) pulldown................................................................. 121
APPENDIX A: LENS PART NUMBERS........................................ 122
CONTENTS (continued)

page vi
Digital Projection HIGHlite 660 3D Series
Rev E February 2015
APPENDIX B: LENS CHARTS .................................................... 123
How to use the lens charts................................................................ 123
How to nd the right lens chart......................................................... 124
1080p (1920 x 1080 pixels) .................................................................. 124
WUXGA (1920 x 1200 pixels)................................................................ 125
DMD™ resolution 1080p / WUXGA, full DMD™ width images......... 126
DMD™ resolution 1080p, 1.25:1 images .......................................... 127
DMD™ resolution 1080p, 1.33:1 images .......................................... 128
DMD™ resolution 1080p, 1.6:1 images ............................................ 129
DMD™ resolution 1080p, 1.66:1 images .......................................... 130
DMD™ resolution WUXGA, 1.25:1 images....................................... 131
DMD™ resolution WUXGA, 1.33:1 images....................................... 132
APPENDIX C: SUPPORTED SIGNAL INPUT MODES .................. 133
2D input modes................................................................................. 133
3D input modes................................................................................. 136
APPENDIX D: MENU MAP.......................................................... 138
APPENDIX E: WIRING DETAILS................................................. 145
Signal inputs and outputs.................................................................. 145
VGA ............................................................................................... 145
HDMI 1 ........................................................................................... 146
Output: SPDIF .................................................................................. 146
DVI 1.............................................................................................. 147
3G-SDI ........................................................................................... 148
CVBS 1 (Composite 1) ........................................................................ 148
S-Video........................................................................................... 148
Component ...................................................................................... 148
CVBS 2 (Composite 2) ........................................................................ 148
DVI 2.............................................................................................. 149
HDMI 2 and 3 ................................................................................... 149
HDBaseT input.................................................................................. 149
Control connections .......................................................................... 150
Update port ...................................................................................... 150
Service port...................................................................................... 150
Wired remote control .......................................................................... 150
RS232 ............................................................................................ 151
LAN connection................................................................................. 151
APPENDIX F: GLOSSARY OF TERMS........................................ 152
TECHNICAL SPECIFICATIONS .................................................. 165
Models............................................................................................... 165
Inputs and outputs............................................................................. 166
Bandwidth ......................................................................................... 166
Remote control and keypad .............................................................. 166
Automation control ............................................................................ 166
Color temperature ............................................................................. 166
Lamps ............................................................................................... 167
Lenses............................................................................................... 167
Lens mount ....................................................................................... 167
Mechanical mounting ........................................................................ 167
Orientation......................................................................................... 167
Electrical and physical specications................................................ 168
Safety & EMC regulations................................................................. 168
Accessories....................................................................................... 168
CONTENTS (continued)

Digital Projection HIGHlite 660 3D Series
This page is intentionally left blank.

Rev E February 2015
HIGHlite 660 3D Series
High Brightness Digital Video Projector
INSTALLATION AND QUICK-START GUIDE
4

Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
IN THIS GUIDE
Rev E February 2015
Adjusting the image..................................................................................................19
Orientation ......................................................................................................................19
Keystone .........................................................................................................................19
Picture.............................................................................................................................19
IN THIS GUIDE
What’s In The Box?............................................................................................. 3
Connecting The Power Supply........................................................................ 4
Projector Overview............................................................................................. 5
Front and rear views ...................................................................................................5
Control panel indicators.............................................................................................6
Remote Control.................................................................................................... 7
Infrared reception........................................................................................................9
Remote control troubleshooting .............................................................................10
Positioning The Screen And Projector....................................................... 11
Tilting the projector ..................................................................................................12
Pitch ................................................................................................................................12
Roll and portrait mode.....................................................................................................12
Adjusting the optional rigging frame ......................................................................13
Changing The Lens........................................................................................... 14
Inserting a new lens..................................................................................................14
Removing the lens ....................................................................................................15
Operating The Projector................................................................................. 16
Switching the projector on.......................................................................................16
Switching the projector off.......................................................................................16
Selecting an input signal or test pattern.................................................................17
Input signal......................................................................................................................17
Test pattern .....................................................................................................................17
Adjusting the lens .....................................................................................................18
Zoom...............................................................................................................................18
Focus ..............................................................................................................................18
Shift.................................................................................................................................18

page 3
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
WHAT’S IN THE BOX?
Rev E February 2015
What’s In The Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
You should save the original box
and packing materials, in case you
ever need to ship your projector.
The projector is shipped without a
lens tted.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
Remote control
(105-023)
4 x AAA cells
User Manual on disc
(115-759)
Important Information (114-243)
Power cable, Europe
(102-163)
Power cable, North America
(102-165)
Projector
Power cable, United Kingdom
(102-180)
Power cable, China
(112-817)

page 4
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
CONNECTING THE POWER SUPPLY
Rev E February 2015
Connecting The Power Supply
Lift the cable lock up, push the mains connector in rmly and
push the lock down to secure the cable.
1AC mains inlet with cable lock
Rear view of the projector
1
Notes
Use only the power cable
provided.
Ensure that the power outlet
includes a ground connection as
this equipment MUST be earthed.
Handle the power cable carefully
and avoid sharp bends. Do not
use a damaged power cable.

page 5
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev E February 2015
Projector Overview
Front and rear views
1Front infrared window
2Lens
3Air outlet
4Adjustable feet
5Control panel
6Rear infrared window
7Connection panel
8Power switch and power connection
9Air inlet
9
5
8
76
Rear view
Front view
4
12 3 Notes

page 6
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev E February 2015
Control panel indicators
1Power indicator
Behavior Meaning
Off The projector is switched off.
On (amber) The projector is in Standby mode.
On (green) The projector is switched on (Normal mode).
2Shutter indicator
Behavior Meaning
On (amber) The shutter is closed.
On (green) The shutter is open.
3Error indicator
Behavior Meaning
On (red) Voltage Error
Flashing Temperature Error
4Lamp 1 and Lamp 2 indicators
Behavior Meaning
On (green) The lamp is switched on (100%).
On (amber) The lamp is switched on (85-99%).
Flashing (green) The lamp is warming up.
Flashing (amber) The lamp is cooling down.
Flashing (red) Lamp Error
5Infrared indicator
Behavior Meaning
Flashing (blue) The projector is receiving input from the remote control.
Notes
During startup all LEDs light up
at the same time to indicate the
projector is carrying out a self-test.
3
1 2
4 5

page 7
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev E February 2015
Remote Control
The remote control is shipped with no battery tted. Remove the back cover and insert the
supplied cells while observing the correct cell polarity.
1Transmit indicator
Flashes when the remote control sends a signal to the projector.
Lights solidly when the projector is in LENS ADJUSTMENT mode.
2Power ON / OFF
3ALT
Acts as a shift key. To use, press and hold this button, then press a green-labeled
button.
4Shutter OPEN / CLOSE
5MENU
Access the projector OSD (on-screen display).
6Navigation
Navigate through the menus with the arrows, conrm your choice with OK.
7Input selection
Select input source.
8Image adjustment
Adjust brightness, contrast and gamma.
Press this button while holding the ALT button down to switch red, green and blue
channels on and off.
9Lens presets
To recall a lens preset, press and hold LOAD, then press a number button 1to 5.
To save a lens preset, press and hold SAVE, then press a number button 1to 5.
10 Remote control backlight ON / OFF
Make the remote control buttons glow in the dark, or switch this feature off.
continues on next page...
Notes
Only the controls shown highlighted
are used on this projector.
For more information about
LENS ADJUSTMENT mode, see
Adjusting the lens further in this
guide.
Input selection buttons:
• 1, 4, 5, 6, 7and 8- as labeled.
• 2selects the HDMI 1 input
• 3selects DVI 1
• ALT + 3 selects DVI 2
• 9selects HDMI 2
• 0selects HDMI 3
• 10+ selects Dual Pipe
• #selects HDBaseT
Presets only contain information
about the lens position. Focus and
zoom information is not kept.
Remote control
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
1
2
6
7
8
10
3
4
5
9

page 8
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev E February 2015
Remote control - continued from previous page
11 Lens controls
Adjust position, zoom and focus.
12 INFO
Open the Information menu.
13 TEST
Switch to test pattern.
14 IR address
Set up an address to match the IR address of a projector.
Notes
Only the controls shown highlighted
are used on this projector.
For more information about IR
addresses, see Setting up an IR
address in the Operating Guide.
Remote control
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
11
14
13
12

page 9
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev E February 2015
Infrared reception
The projector has infrared sensors at the front and back.
The angle of acceptance is 40°. Make sure that the remote control is within the angle of acceptance when trying to
control the projector.
40°
40°
Infrared reception
Notes
Infrared reception is conrmed by
the blue Infrared indicator ashing
on the control panel.
The infrared receivers are disabled
when a remote control is connected
via a cable. For more information,
see Wired remote control in the
Connection Guide.

page 10
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev E February 2015
Remote control troubleshooting
The remote control is shipped with no battery tted. Remove the back cover and insert the
supplied cells while observing the correct cell polarity.
If the projector fails to respond to keypress on the remote control, consider the following checks.
Does the Transmit indicator ash when a button is pressed?
The blue Transmit Indicator 1should be dark when the remote control is not being used and
ash when a button is being pressed.
• If it emits a solid light when a button is not being pressed, the remote control is in LENS
ADJUSTMENT mode. Press EXIT or wait up to ten seconds to exit LENS ADJUSTMENT
mode.
• If the Transmit indicator fails to ash when a key is pressed, it might be time to replace the
battery. Use only Alkaline AAA (LR03) cells for best results.
Does the projector control panel respond when a remote control button is pressed?
When a button is pressed on the remote control, the infrared indicator 2on the control panel
should ash blue. If this does not happen:
• Check that the angle of acceptance is met.
• Check that the projector address matches the remote control address.
• If none of the above xes the problem, it might be time to replace the battery. Use only
Alkaline AAA (LR03) cells for best results.
Notes
The infrared receivers are disabled
when a remote control is connected
via a cable. For more information,
see Wired remote control in the
Connection Guide.
For information about the angle of
acceptance, see Infrared reception
earlier in this guide.
See Setting up an IR address in
the Operating Guide.
Transmit indicator
on the remote control
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
1
2
Infrared indicator
on the control panel

page 11
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev E February 2015
Positioning The Screen And Projector
1. Install the screen, ensuring that it is in the best position for
viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance
from the screen for the image to ll the screen. Set the
adjustable feet so that the projector is level, and perpendicular
to the screen.
The drawing below shows the positions of the feet for table
mounting, and the xing holes for ceiling mounting.
1Four adjustable feet
2Six M6 holes for ceiling mount
The screws should not penetrate more than 15 mm
(0.6 in.) into the body of the projector.
1
2
1
1
1
2
2
2
2
2
Notes
Always allow the projector to
cool for ve minutes before
disconnecting the power or
moving the projector.
Ensure that there is at least
30 cm (12 in.) of space between
the ventilation outlets and any
wall, and 10 cm (4 in.) on all other
sides.
Do not stack more than three
projectors.
When positioning the projector,
do not exceed the roll limits
as this may cause serious
lamp failure, damage the lamp
module and cause extra cost
on replacement. For more
information, see Tilting the
projector further in this guide.

page 12
Digital Projection HIGHlite 660 3D Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev E February 2015
Tilting the projector
Pitch
The projector can be positioned at any angle.
Roll and portrait mode
The projector can be tilted up to 90ºwith the air outlet 1pointing upward.
In the opposite direction the projector can be tilted up to 12º.
360º
Pitch
1
12º
Roll, air outlet downward
1
1
90º
Roll, air outlet upward
1
Notes
Always allow the projector to
cool for ve minutes before
disconnecting the power or
moving the projector.
Ensure that there is at least 30 cm
(12 in.) of space between the
ventilation inlets and outlets and
any wall, and 10 cm (4 in.) on all
other sides.
Do not stack more than three
projectors.
Do not exceed these limits as this
may cause serious lamp failure,
damage the lamp module and
cause extra cost on replacement.
