Digital Projection Titan 930 User manual

Rev J July 2014
USER MANUAL
INSTALLATION AND QUICK-START GUIDE
CONNECTION GUIDE
OPERATING GUIDE
REFERENCE GUIDE
Titan 800 Series
High Brightness Digital Video Projector
Titan Super Quad Series
Titan Quad 2000 Series
Titan Quad Series
Titan 930 Series
112-671J

Digital Projection Titan Quad / 930 / 800 Series
i
Rev J July 2014
i
About This Document
Please follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Keep this manual handy for future reference.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2014 Digital Projection Ltd. All rights reserved.
Notes

Digital Projection Titan Quad / 930 / 800 Series
ii
Rev J July 2014
ii
Introduction
Congratulations on your purchase of this Digital Projection product!
Your projector has the following key features:
• Support for most 3D standards (if your projector is a 3D model)
• Full range of digital and legacy analog inputs
• Control of most aspects of the projector’s operation via LAN and RS232
• Support for a number of aspect ratios and screen sizes
• Nonlinear warp adjustment by moving points on an interpolated grid
• Ceiling mount and rear-screen installation options
• Simultaneous display of two sources via Picture-In-Picture
• Long lamp life
• Motorised lens mount
A serial number is located on the back of the projector. Please record it here:
Notes

Digital Projection Titan Quad / 930 / 800 Series
iii
Rev J July 2014
iii
CONTENTS
INSTALLATION AND QUICK-START GUIDE ..............................1
WHAT’S IN THE BOX? ................................................................... 3
CONNECTING THE POWER SUPPLY ............................................. 4
PROJECTOR OVERVIEW ............................................................... 5
Front and rear views ............................................................................. 5
Control panel indicators ........................................................................ 6
Connection panel indicators.................................................................. 7
REMOTE CONTROL....................................................................... 9
Infrared reception.................................................................................. 9
Remote control 105-023 Rev B........................................................... 10
Remote control 105-023 Rev A ........................................................... 12
POSITIONING THE SCREEN AND PROJECTOR........................... 14
Desktop mount.................................................................................... 14
Ceiling mount ...................................................................................... 14
Adjusting the optional rigging frame.................................................... 15
Adjusting pitch, roll and yaw................................................................ 16
FITTING THE LENS...................................................................... 17
OPERATING THE PROJECTOR.................................................... 18
Switching the projector on................................................................... 18
Switching the projector off................................................................... 18
Selecting an input signal or test pattern.............................................. 19
Input signal ........................................................................................ 19
Test pattern ........................................................................................ 19
Adjusting the lens................................................................................ 20
Zoom................................................................................................ 20
Focus ............................................................................................... 20
Shift ................................................................................................. 20
Adjusting the image............................................................................. 21
Orientation ......................................................................................... 21
Keystone ........................................................................................... 21
Picture .............................................................................................. 21
CONNECTION GUIDE ............................................................................23
SIGNAL INPUTS AND OUTPUTS.................................................. 25
Rear connection panel ........................................................................ 25
Side connection panel on 3D projectors ............................................. 27
Special considerations when using inputs 9-11 .................................. 28
Differences between inputs 9-11 and inputs 1-8 ........................................... 28
Input and processing architecture ............................................................ 28
EDID on the DVI and VGA inputs............................................................. 28
Using HDMI/DVI switchers with the projector ..................................... 29
DVI input connection example................................................................. 30
3D connections ................................................................................... 31
3D sources up to 60Hz requiring frame doubling and left/right interleaving.......... 31
3D sources above 60Hz not requiring frame doubling.................................... 31
Dual Pipe 3D ...................................................................................... 31
3D Sync in ......................................................................................... 32
3D Sync out ....................................................................................... 32
3D connection examples ....................................................................... 33
CONTROL CONNECTIONS........................................................... 34
LAN connection examples .................................................................. 35
RS232 connection example ................................................................ 36

Digital Projection Titan Quad / 930 / 800 Series
iv
Rev J July 2014
iv
OPERATING GUIDE ................................................................................37
USING THE MENUS ..................................................................... 40
Menus and sub-menus........................................................................ 40
Drop-down lists ................................................................................... 41
Sliders ................................................................................................. 42
Commands.......................................................................................... 42
Editing elds........................................................................................ 43
USING THE PROJECTOR............................................................. 44
Main menu .......................................................................................... 44
Lens menu .......................................................................................... 45
Zoom................................................................................................ 45
Focus ............................................................................................... 45
Calibrate Zoom and Calibrate Focus......................................................... 45
Center Lens ....................................................................................... 45
Nudge............................................................................................... 46
Lens Presets ...................................................................................... 46
Image menu ........................................................................................ 47
Video Filters ....................................................................................... 47
VGA Setup......................................................................................... 47
Color menu.......................................................................................... 48
Gamut .............................................................................................. 48
Black Level and Gain sliders................................................................... 48
Geometry menu .................................................................................. 49
Aspect Ratio....................................................................................... 49
Overscan........................................................................................... 49
Size & Position.................................................................................... 50
Blanking ............................................................................................ 50
Geometry Engine................................................................................. 51
Edge Blend menu................................................................................ 57
Overview ........................................................................................... 57
Array H Position and V Position............................................................... 58
S-Curve Value .................................................................................... 59
Blending............................................................................................ 61
Segmentation ..................................................................................... 62
Blend Width........................................................................................ 64
Black Level Uplift ................................................................................. 64
Reduce Black Level Uplift Width .............................................................. 65
Blending images from multiple projectors ........................................... 68
Before you start................................................................................... 68
Edge Blend procedure .......................................................................... 69
PIP menu ............................................................................................ 77
3D menu.............................................................................................. 78
3D types............................................................................................ 79
Some 3D settings explained ............................................................... 81
Dark Time.......................................................................................... 81
Source Dominance............................................................................... 81
Sync Offset ........................................................................................ 81
Frame Rate Multiplier............................................................................ 82
Lamps menu ....................................................................................... 83
CONTENTS (continued)

Digital Projection Titan Quad / 930 / 800 Series
v
Rev J July 2014
v
Setup menu......................................................................................... 84
Reset Default Settings .......................................................................... 84
Input Conguration............................................................................... 85
Network ............................................................................................ 86
On Screen Display ............................................................................... 87
System ............................................................................................. 88
Setting up an IR address ....................................................................... 89
Information menu ................................................................................ 90
Lamps .............................................................................................. 90
Conguration...................................................................................... 91
REFERENCE GUIDE................................................................................93
THE DMD™.................................................................................. 96
CHOOSING A LENS ..................................................................... 98
Basic calculation ................................................................................. 99
Basic calculation example................................................................. 100
Full lens calculation........................................................................... 101
Introducing TRC ................................................................................ 101
Calculating TRC ................................................................................ 102
TRC table ........................................................................................ 102
Calculating the throw ratio with TRC ....................................................... 103
Full lens calculation example ............................................................ 104
SCREEN REQUIREMENTS......................................................... 105
Fitting the image to the DMD™......................................................... 105
SX+ images displayed full width ............................................................ 105
SX+ images displayed full height ........................................................... 105
1080p images displayed full width .......................................................... 106
1080p images displayed full height......................................................... 106
WUXGA images displayed full width ....................................................... 107
WUXGA images displayed with a height of 1080 pixels................................ 107
WUXGA images displayed full height ...................................................... 108
Diagonal screen sizes....................................................................... 109
Fitting the image to the screen.......................................................... 110
Positioning the screen and projector..................................................111
POSITIONING THE IMAGE..........................................................112
Maximum offset range....................................................................... 114
ASPECT RATIOS EXPLAINED.....................................................115
Aspect ratio examples for DMD™ resolution SX+ (SXGA+)............. 116
Aspect ratio examples for DMD™ resolution 1080p ......................... 119
Aspect ratio examples for DMD™ resolution WUXGA...................... 122
Aspect ratio example: TheaterScope................................................ 125
FRAME RATES AND PULLDOWNS EXPLAINED......................... 126
Interlaced and progressive scan ....................................................... 126
Frame rates of image sources .......................................................... 126
Pulldowns - conversion into destination formats............................... 127
2:3 (normal) pulldown ......................................................................... 127
2:3:3:2 (advanced) pulldown................................................................. 128
APPENDIX A: LENS PART NUMBERS........................................ 129
CONTENTS (continued)

Digital Projection Titan Quad / 930 / 800 Series
vi
Rev J July 2014
vi
APPENDIX B: LENS CHARTS .................................................... 130
How to use the lens charts................................................................ 130
How to nd the right lens chart.......................................................... 131
1080p (1920 x 1080 pixels) .................................................................. 131
WUXGA (1920 x 1200 pixels)................................................................ 132
SX+ (1400 x 1050 pixels)..................................................................... 133
DMD™ resolution 1080p / WUXGA, full width images...................... 134
DMD™ resolution 1080p, 1.25:1 images .......................................... 136
DMD™ resolution 1080p, 1.33:1 images .......................................... 138
DMD™ resolution 1080p, 1.6:1 images ............................................ 140
DMD™ resolution 1080p, 1.66:1 images .......................................... 142
DMD™ resolution WUXGA, 1.25:1 images....................................... 144
DMD™ resolution WUXGA, 1.33:1 images....................................... 146
DMD™ resolution SX+, full width images ......................................... 148
DMD™ resolution SX+, 1.25:1 images ............................................. 150
APPENDIX C: SUPPORTED SIGNAL INPUT MODES .................. 152
2D input modes................................................................................. 152
3D input modes................................................................................. 155
CONTENTS (continued)
APPENDIX D: MENU MAP.......................................................... 157
Input Selection .................................................................................. 157
Test Pattern ....................................................................................... 157
Lens .................................................................................................. 157
Image ................................................................................................ 158
Color.................................................................................................. 158
Geometry .......................................................................................... 159
Edge Blend........................................................................................ 160
PIP .................................................................................................... 161
3D...................................................................................................... 161
Lamps ............................................................................................... 161
Setup................................................................................................. 162
Information ........................................................................................ 163

Digital Projection Titan Quad / 930 / 800 Series
vii
Rev J July 2014
vii
CONTENTS (continued)
APPENDIX E: WIRING DETAILS................................................. 164
Signal inputs and outputs.................................................................. 164
Input 1: VGA..................................................................................... 164
Input 2: HDMI ................................................................................... 165
Output: SPDIF .................................................................................. 165
Input 3: DVI...................................................................................... 166
Input 4: 3G-SDI ................................................................................. 167
Input 5: Composite 1 .......................................................................... 167
Input 6: S-Video ................................................................................ 167
Input 7: Component............................................................................ 167
Input 8: CVBS................................................................................... 167
Input 9: MAIN/DVI.............................................................................. 168
Input 10: SUB/HDMI ........................................................................... 169
Control connections .......................................................................... 170
Update port ...................................................................................... 170
Wired remote control .......................................................................... 170
RS232 ............................................................................................ 171
LAN connection................................................................................. 171
APPENDIX F: GLOSSARY OF TERMS........................................ 172
TECHNICAL SPECIFICATIONS .................................................. 185
Models............................................................................................... 185
Inputs and outputs............................................................................. 186
Bandwidth ......................................................................................... 186
Remote control and keypad .............................................................. 186
Automation control ............................................................................ 186
Color temperature ............................................................................. 186
Lamps ............................................................................................... 187
Lenses............................................................................................... 188
Lens mount ....................................................................................... 188
Mechanical mounting ........................................................................ 188
Orientation......................................................................................... 188
Electrical and physical specications................................................ 189
Safety & EMC regulations................................................................. 189
Accessories....................................................................................... 189

Rev J July 2014
INSTALLATION AND QUICK-START GUIDE
Titan 800 Series
High Brightness Digital Video Projector
Titan Super Quad Series
Titan Quad 2000 Series
Titan Quad Series
Titan 930 Series

Digital Projection Titan Quad / 930 / 800 Series IN THIS GUIDE Installation and Quick-Start Guide
Rev J July 2014
IN THIS GUIDE
What’s In The Box?............................................................................................. 3
Connecting The Power Supply........................................................................ 4
Projector Overview............................................................................................. 5
Front and rear views ...................................................................................................5
Control panel indicators.............................................................................................6
Connection panel indicators......................................................................................7
Remote Control.................................................................................................... 9
Infrared reception........................................................................................................9
Remote control 105-023 Rev B ................................................................................10
Remote control 105-023 Rev A.................................................................................12
Positioning The Screen And Projector....................................................... 14
Desktop mount ..........................................................................................................14
Ceiling mount ............................................................................................................14
Adjusting the optional rigging frame ......................................................................15
Adjusting pitch, roll and yaw ...................................................................................16
Fitting The Lens ................................................................................................ 17
Operating The Projector................................................................................. 18
Switching the projector on.......................................................................................18
Switching the projector off.......................................................................................18
Selecting an input signal or test pattern.................................................................19
Input signal......................................................................................................................19
Test pattern .....................................................................................................................19
Adjusting the lens .....................................................................................................20
Zoom...............................................................................................................................20
Focus ..............................................................................................................................20
Shift.................................................................................................................................20
Adjusting the image..................................................................................................21
Orientation ......................................................................................................................21
Keystone .........................................................................................................................21
Picture.............................................................................................................................21

Digital Projection Titan Quad / 930 / 800 Series WHAT’S IN THE BOX? Installation and Quick-Start Guide
3
Rev J July 2014
What’s In The Box?
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
Only one remote will be supplied
with the projector. For more
information, see Remote Control
further in this guide.
You should save the original box
and packing materials, in case you
ever need to ship your projector.
When transporting the projector,
always ensure that the removable
feet are fully wound in.
The projector is shipped without a
lens.
Only one power cable - dependent
on the projector model and
destination territory - will be supplied
with the projector.
Remote control
(105-023) Rev A or B
4x AAA batteries
Power cable, United Kingdom
(102-180 for Titan 800, 112-000
for Quad)
User Manual on disc
(115-759)
Important Information (112-658)
Power cable, Europe
(102-163 for Titan 800,
112-001 for Quad)
Power cable, North America
(102-165 for Titan 800,
112-002 for Quad)
Projector
Remote cable
(102-162)
Power cable for Titan 930,
North America
(114-964)

Digital Projection Titan Quad / 930 / 800 Series CONNECTING THE POWER SUPPLY Installation and Quick-Start Guide
4
Rev J July 2014
Connecting The Power Supply
Lift the cable lock up, push the mains connector in rmly and
push the lock down to secure the cable.
1AC mains inlet with cable lock
Notes
Use only the power cable
provided.
Ensure that the power outlet
includes a ground connection as
this equipment MUST be earthed.
Handle the power cable carefully
and avoid sharp bends. Do not
use a damaged power cable.
Front view of the projector
1

Digital Projection Titan Quad / 930 / 800 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
5
Rev J July 2014
Projector Overview
Front and rear views
1Front infrared window
2 Airinletswithairlters
3Lens
4Lens motor
5Mains input
6Adjustable feet
7Air outlets
8Rear connection panel with infrared window
9Control panel
10 Side connection panel
4 5 63
21
Front view
Rear view
9 10
7
8
Notes
The side connection panel is
available on 3D models only.

Digital Projection Titan Quad / 930 / 800 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
6
Rev J July 2014
Control panel indicators
1Power indicator
Behavior Meaning
Off The projector is switched off.
On (amber) The projector is in Standby mode.
On (green) The projector is switched on (Normal mode).
2Shutter indicator
Behavior Meaning
On (amber) The shutter is closed.
On (green) The shutter is open.
Notes
Only the controls shown highlighted
are used on this projector.
During startup all LEDs light up
at the same time to indicate the
projector is carrying out a self-test.
1 2
CTRL FOCUS
AUTO INFO SHIFT ZOOM
MENU INPUT
OK
EXIT INPUT
OFF
ON
OSD
ON
OFF
POWER
OPEN
CLOSE
SHUTTER
+
_
RPY

Digital Projection Titan Quad / 930 / 800 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
7
Rev J July 2014
Connection panel indicators
1Lamps 1-4 indicators
Behavior Meaning
On (green) The lamp is switched on (100%).
On (amber) The lamp is running on less than full capacity:
80-99% for Titan Quad / Titan 800
86-99% for Titan Super Quad / Titan Quad 2000 / Titan 930
Flashing (green) The lamp is warming up.
Flashing (amber) The lamp is cooling down.
On (red) Projector in standby: Lamp Timer Error (call service)
Projector on: Ballast Comms Error (call service)
Flashing (red) Projector in standby: Lamp Error on previous operation
Projector on: Lamp / Interlock Error
2Error indicator
Behavior Meaning
On (red) Voltage Error
Flashing (red) Fan / System Error
3Infrared indicator
Behavior Meaning
Flashing (blue) The projector is receiving input from the remote control or
keypad.
4Input indicators
Behavior Meaning
On (green) Input selected. Signal detected and in range.
Flashing (green) Input selected, but signal is not detected or out of range.
Notes
For more information about
the connection panels, see the
Connection Guide.
A red LED always indicates an error.
If you receive an error indication,
restart the projector. If the problem
persists, contact your dealer.
The side connection panel is
available on 3D models only.
Side connection panel
1
2
3
4
Rear connection panel

Digital Projection Titan Quad / 930 / 800 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
8
Rev J July 2014
Connection panel indicators - continued from previous page
5Sync in indicator
Behavior Meaning
On (green) Valid sync in.
6Sync out indicator
Behavior Meaning
On (green) Valid sync out.
Notes
For more information about
the connection panels, see the
Connection Guide.
The side connection panel is
available on 3D models only.
56
Side connection panel

Digital Projection Titan Quad / 930 / 800 Series REMOTE CONTROL Installation and Quick-Start Guide
9
Rev J July 2014
Remote Control
The projector is equipped with one of the remote control devices shown here. The device on
the left (105-023 Rev B) was introduced in June 2013; a projector purchased before that date
is equipped with the device on the right, 105-023 Rev A.
Both devices and their functions are described in the following pages.
Infrared reception
The projector has infrared sensors at the front and back.
The angle of acceptance is 40°. Make sure that the remote control is within the angle of
acceptance when trying to control the projector.
Notes
Infrared reception is conrmed by
the blue IR LED ashing on the
control panel.
The infrared receivers are disabled
when a remote control is connected
via a cable. For more information,
see Control Connections in the
Connection Guide.
CTRL FOCUS
AUTO INFO SHIFT ZOOM
MENU INPUT
OK
EXIT INPUT
1 RGB1 3 DVI RED
4 SDI 5 VID 6 SVID GREEN
7 COM 8 9 BLUE
PRESET FUNC ADDR SAVE
LIGHT
BRI
10+ 0 # TEST
OFF
ON
OSD
ON
OFF
POWER
OPEN
CLOSE
SHUTTER
+
_
2 RGB2
PRESET
SAVE
CON SAT MAGNIFY PHASE
A B C D
J K L M
E F G H
N P R S
OSD POS
KEYST PAN ASPECT
RPY
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
Remote (105-023)
Rev A
Remote (105-023)
Rev B
40°
40°
Infrared reception

Digital Projection Titan Quad / 930 / 800 Series REMOTE CONTROL Installation and Quick-Start Guide
10
Rev J July 2014
Remote control 105-023 Rev B
1Transmit indicator
Flashes when the remote control sends a signal to the projector.
Lights solidly when the projector is in LENS ADJUSTMENT mode.
2Power ON / OFF
3ALT
Acts as a shift key. To use, press and hold this button, then press a green-labeled
button.
4Shutter OPEN / CLOSE
5MENU
Access the projector OSD (on-screen display).
6Navigation
Navigate through the menus with the arrows, conrm your choice with OK.
7Input selection
Select input source.
9, 0and 10+ are not used on 2D projectors as they are used for inputs on the side
connection panel.
8Image adjustment
Adjust brightness, contrast and gamma.
Press this button while holding the ALT button down to switch red, green and blue
channels on and off.
9Lens presets
To recall a lens preset, press and hold LOAD, then press a number button 1to 5.
To save a lens preset, press and hold SAVE, then press a number button 1to 5.
10 Remote control backlight ON / OFF
Make the remote control buttons glow in the dark, or switch this feature off.
continues on next page...
Remote control 105-023 Rev B
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
1
2
6
7
8
10
3
4
5
9
Notes
Only the controls shown highlighted
are used on this projector.
For more information about
LENS ADJUSTMENT mode, see
Adjusting the lens further in this
guide.
Input selection buttons:
• 1to 8- as labeled.
• 9selects Main/DVI (input 9, side
connection panel).
• 0selects Sub/HDMI (input 10,
side connection panel).
• 10+ selects Dual Pipe (both
inputs 9 and 10).

Digital Projection Titan Quad / 930 / 800 Series REMOTE CONTROL Installation and Quick-Start Guide
11
Rev J July 2014
Remote control 105-023 Rev B - continued from previous page
11 Lens controls
Adjust position, zoom and focus.
Perform calibration when you change the lens.
12 INFO
Open the Information menu.
13 TEST
Switch to test pattern.
14 IR address
Set up an address to match the IR address of a projector.
Notes
Only the controls shown highlighted
are used on this projector.
For more information about IR
addresses, see Setting up an IR
address in the Operating Guide.
VGA HDMI DVI 3GSDI
CVBS1 SVIDEO
CLOSE
12 3 4
COMP CVBS2
5 6 7 8
9 0 10+ #
MAIN SUB DUAL HD-T
OFF ON
ALT ROLL
PITCH YAW
FOCUS CAL
SHIFT ZOOM
EYE
SWAP
MAIN/PIP
SWAP
BRI CON GAMMA 3D
ON/OFF
PIP
ON/OFF
LOAD SAVE TEST ADDR
BACKLIGHT
RGB
PRESET
SHUTTER
OPEN
POWER
MENU
OK
EXIT INFO
Remote control 105-023 Rev B
11
12
14
13

Digital Projection Titan Quad / 930 / 800 Series REMOTE CONTROL Installation and Quick-Start Guide
12
Rev J July 2014
Remote control 105-023 Rev A
1Transmit indicator
Flashes when the remote control sends a signal to the projector.
Lights solidly when the projector is in LENS ADJUSTMENT mode.
2Power ON / OFF
3INFO
Open the Information menu.
4MENU
Access the projector OSD (on-screen display).
5Navigation
Navigate through the menus with the arrows, conrm your choice with OK.
6Input selection
Select input source.
9, 10+ and #are not used on 2D projectors.
7Settings
These buttons allow you to change various settings directly from the remote,
without opening the OSD:
• BRI, CON, SAT - adjust brightness, contrast and saturation
• PHASE - adjust phase for VGA signals
• MAGNIFY, POS, PAN - access the Size and Position menu
• OSD - edit OSD settings
• ASPECT - change the aspect ratio
8Lens presets
To recall a preset, press and hold PRESET, then press a number button 1to 5.
To save a preset, press and hold SAVE, then press a number button 1to 5.
continues on next page...
CTRL FOCUS
AUTO INFO SHIFT ZOOM
MENU INPUT
OK
EXIT INPUT
1 RGB1 3 DVI RED
4 SDI 5 VID 6 SVID GREEN
7 COM 8 9 BLUE
PRESET FUNC ADDR SAVE
LIGHT
BRI
10+ 0 # TEST
OFF
ON
OSD
ON
OFF
POWER
OPEN
CLOSE
SHUTTER
+
_
2 RGB2
PRESET
SAVE
CON SAT MAGNIFY PHASE
A B C D
J K L M
E F G H
N P R S
OSD POS
KEYST PAN ASPECT
RPY
Remote control 105-023 Rev A
1
2
5
6
7
4
3
8
Notes
Only the controls shown highlighted
are used on this projector.
For more information about
LENS ADJUSTMENT mode, see
Adjusting the lens further in this
guide.
Input selection buttons:
• 1selects VGA (input 1)
• 2selects HDMI (input 2)
• 3selects DVI (input 3)
• 4selects 3G-SDI (input 4)
• 5selects Composite 1 (input 5)
• 6selects S-Video (input 6)
• 7selects Component (input 7)
• 8selects Composite 2 (input 8)
• 9selects Main/DVI (input 9, side
connection panel)
• 10+ selects Dual Pipe (both
inputs 9 and 10, side connection
panel)
• 0selects Sub/HDMI (input 10,
side connection panel)
