Dimplex Lucia LUC20 User manual

EN : This product is only suitable for well insulated rooms or occasional use. DE : Dieses Produkt ist nur für gut isolierte Bereiche oder gelegentli-
che Verwendung geeignet. FR : Ce produit convient uniquement à des endroits bien isolés ou pour un usage occasionnel. IT : Questo prodotto è
adatto solo per spazi ben isolati o per uso occasionale. ES : Este producto sólo es adecuado para espacios bien aislados o un uso ocasional. NL :
Dit product is uitsluitend geschikt voor goed geïsoleerde ruimten of voor sporadisch gebruik. PL : Produkt ten jest odpowiedni wyłącznie do dobrze
odizolowanych miejsc lub do okazjonalnego użytku. NO : Dette produktet egner seg kun for godt isolerte rom eller sporadisk bruk. RO : Acest
produs este adecvat exclusiv spaţiilor bine ventilate sau utilizării ocazionale. CZ : Tento výrobek je vhodný pouze do dobře izolovaných prostor
nebo k příležitostnému použití. DK : Dette produkt er kun egnet til velisolerede rum eller lejlighedsvis brug. PT : Este produto somente é ade-
quado para espaços bem isolados ou uso ocasional. SE : Denna produkt är endast avsedd för välisolerade utrymmen eller tillfällig användning.
FI : Tämä tuote soveltuu ainoastaan hyvin eristettyihin tiloihin tai satunnaiseen käyttöön. SK : Tento výrobok je vhodný len pre dobre izolované
priestory alebo na občasné použitie. SI : Ta izdelek je primeren le za dobro izolirane prostore ali za občasno uporabo. HR : Ovaj proizvod je
pogodan samo za dobro izolirane prostore ili povremenu upotrebu. HU : Ez a termék csak jól szigetelt terekhez vagy eseti használatra alkalmas.
8/54155/0 Issue 1
LUCIA
LUC20
The product complies with the European Safety Standards and the European Standard Electromagnetic Compatibility. These cover the essential
requirements of EEC Directives.
UK

2
1
2
3
I
II
3
4
1508
597
344
min max
OFF
ON
T
econ

Technical Information
with mechanic thermostat room temperature control.
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
- Lucia LUC20
Important Safety Advice.
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of re, electrical shock and
injury to persons, including the following:
If the appliance is damaged, check with the
supplier before installation and operation.
- Do not use outdoors.
- Do not use in the immediate surroundings
of a bath, shower or a swimming pool.
- Do not use this heater if it has been dropped.
- Do not use if there are visible signs of
damage to the heater.
- Use this heater on a horizontal and stable
surface, or x it to the wall, as applicable.
- Do not locate the appliance immediately
below a xed socket outlet or connection box.
The appliance carries the Warning
symbol DO NOT COVER, indicating
that it must not be covered.
This appliance can be used by children aged
from 8 years and above and persons with re-
duced physical, sensory or mental capabilities
or lack of experience and knowedge if they
have been given supervision or instruction
concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by Children without supervision.
Children of less than 3 years should be
kept away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position and
they have been given supervision or instruc-
tion concerning use of the appliance in a safe
way and understanding the hazards involved.
Children aged from 3 years and less than 8
years shall not plug in, regulate and clean the
appliance or perform user maintenance.
Do not use this appliance in series with a
thermal control, a program controller, a timer
or any other device that switches on the heat
automatically, since a re risk exists when
the appliance is accidentally covered or dis-
placed.
In the event of a fault unplug the appliance.
Unplug the appliance when not required for
long periods.
Although this appliance complies with safety
standards, we do not recommend its use on
deep pile carpets or on long hair type of rugs.
The appliance must be positioned so that
the plug is accessible.
If the supply cord is damaged it must be
replaced by the manufacturer or service
agent or a similarly qualied person in order
to avoid a hazard.
Keep the supply cord away from the front of
the appliance.
WARNING: Do not use this heater in small
rooms when they are occupied by persons
not capable of leaving the room on their
own, unless constant supervision is provid-
ed.
WARNING: To reduce the risk of re, keep
textiles, curtains and or ammable materi-
al a minimum distance of 1m from the air
outlet.
WARNING: In order to avoid overheating,
do not cover the appliance. Do not place
material or garments on the appliance, or
obstruct the air circulation around the appli-
ance, for instance by curtains or furniture,
as this could cause overheating and a re
risk.
WARNING: In order to avoid a hazard due
to inadvertent resetting of the thermal cut-
out, this appliance must not be supplied
through an external switching device, such
as a timer, or connected to a circuit that is
regularly switched on and off by the utility.
CAUTION - Some parts of this product can
become very hot and cause burns. Particu-
lar attention has to be given where children
and vulnerable people are present.
Model No: LUC20
Heat Output 230V 240V
Nominal Heat Output P Nom 1.8 - 1.9 kW
Minimum Heat Output P min 0.9 - 1.0 kW
Maximum Continous Heat Output P max,c 1.8 - 1.9 kW
Auxiliary Electricity Consumption
In Standby mode el SB 0.37 - 0.41 W
UK

General
Unpack the heater carefully and retain the packaging for possible
future use, in the event of moving or returning the re to your supplier.
These models are designed to be free standing and are normally
positioned against a wall.
The re incorporates a ame effect, which can be used with or without
heating, so that the comforting effect may be enjoyed at any time of
the year. Using the ame effect on its own only requires little electricity.
A choice of 1kW or 2kW heat output is provided by the fan heater,
which is located at the bottom of the unit.
Before connecting the heater check that the supply voltage is the
same as that stated on the heater.
Please note: Used in an environment where background noise is
very low, it may be possible to hear a sound which is related to the
operation of the ame effect. This is normal and should not be a
cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage
marked on the heater must correspond to the supply voltage.
Before switching on, please read the safety warnings and operating
instructions.
Controls - see Fig. 2
These switches provide a choice of heat settings, The appliance is
in standby mode when the mainslead is plugged in. This is indicated
by the red neon behind the ame effect screen. The two selector
switches are in the ON position when the side with the markings on
(i.e. I, or II) is pushed in.
Selector switch 1 ( ) Controls the electricity supply to the
appliance and ame effect. Press for ‘ON’
and ‘Standby’. If both selector switches 2
and 3 are in the OFF position, the product
works on ame effect only.
Selector Switch 2 (I) Provides 1kW heat output
Selector Switch 3 (II) Provides 2kW output with switch 2
Thermostat (T) - see Fig. 3
In order to maintain a certain room temperature, set the controller to
‘max.’. Operate the appliance at full power until the required room
temperature is reached. Set back the thermostatic controller until the
appliance switches off with an audible “click”. This temperature will
be kept almost constant by the thermostatic control switching on and
off automatically.Please note that the appliance can only be switched
on when the thermostat setting is higher then the room temperature.
Remote control - see Fig. 4
The maximum range of use is ~ 15metres.
Warning: It takes time for the receiver to respond to the transmitter.
Do not press the buttons more than once within two seconds for
correct operation.
Battery information - see Fig. 4
1. To activate the remote control remove the battery isolation strip,
which is used to ensure your remote control reaches you fully charged.
2. To replace the remote control battery, turn over the remote control,
and follow the diagram embossed on the remote control
3. Only use CR2025 or CR2032 size of batteries.
Discard leaking batteries
Dispose of batteries in the proper manner according to provincial and
local regulations.
Any battery may leak electrolyte if mixed with a different battery type, if
inserted incorrectly, if all the batteries are not replaced at the same time,
if disposed of in a re, or if an attempt is made to charge a battery not
intended to be recharged.
Maintenance
WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.
Light Emitting Diode
This re is tted with LED (Light Emitting Diode) lamps. These LED
lamps are maintenance-free and should not require replacing during
the life of the product.
Thermal Safety Cut-out
The built-in overheat cut-out switches off the appliance automatically in
the event of a fault. If this occurs switch off the appliance or disconnect
the mains plug from the socket. After a short cooling down phase, the
appliance is ready for use again. If the fault should occur again, see
your local dealer.
Cleaning
WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.
For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully with a
soft cloth. DO NOT use proprietary glass cleaners.
To remove any accumulation of dust or uff the soft brush attachment of
a vacuum cleaner should occasionally be used to clean the outlet grille
of the fan heater.
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not
be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for
recycling advice in your country.
After Sales Service
Your product is guaranteed for one year from the date of purchase.
Within this period, we undertake to repair or exchange this product free
of charge (excluding lamps & subject to availability) provided it has been
installed and operated in accordance with these instructions.
Your rights under this guarantee are additional to your statutory rights,
which in turn are not affected by this guarantee.
Should you require after sales information or assistance with this product
please go to www.dimplex.co.uk where you will nd our self help guide
by clicking on “After Sales” or ring our helpdesk on 0844 879 3588 (UK)
or 01 842 4833 (R.O.I.) .
Spare parts are also available on the website:
www.dimplex.co.uk
Please retain your receipt as proof of purchase.
