Dimplex DHMH20C User manual

INSTRUCTION MANUAL
For domestic household use
2kW Mica Panel Heater
Model: DHMH20C
only.

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE
INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY
Please read the operating instructions carefully before using your product
for the first time and keep them in a safe place.
• When using electrical appliances, basic precautions should always be
followed to reduce the risk of fire, electrical shock and injury to persons,
including the following:
• If the appliance is damaged, check with the supplier before installation
and operation.
- Do not use outdoors.
- Do not use in the immediate surroundings of a bath, shower or
a swimming pool.
- Do not use this heater if it has been dropped.
- Do not use if there are visible signs of damage to the heater.
- Use this heater on a horizontal and stable surface, or fix it to
the wall, as applicable.
• Do not locate the appliance immediately below a fixed socket outlet or
connection box.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• Do not use this appliance in series with a thermal control, a program
controller, a timer or any other device that switches on the heat
automatically, since a fire risk exists when the appliance is accidentally
covered or dis-placed.
• In the event of a fault, unplug the appliance.
• Unplug the appliance when not required for long periods.
• This product is only intended for INDOOR RESIDENTIAL applications
only.
• DO NOT cover cord with carpeting, throw rugs, runners, or similar
coverings.
• DO NOT route cord under furniture or appliances. Take care to position
IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED
FOR FUTURE REFERENCE. Note also the information presented on the
appliance
2

the cord away from traffic areas and where it will not be a tripping
hazard.
• This appliance must not be used in a bathroom.
• Although this appliance complies with safety standards, we do not
recommend its use on deep pile carpets or on long hair type of rugs
• The appliance must be positioned so that the plug is accessible.
• If the supply cord is damaged it must be replaced by the manufacturer
or service agent or a similarly qualified person in order to avoid a hazard.
• Keep the supply cord away from the front of the appliance.
• Do not use this heater in small rooms when they are occupied by
persons not capable of leaving the room on their own, unless constant
supervision is provided.
• To reduce the risk of fire, keep textiles, curtains and or flammable material
a minimum distance of 1m from the air outlet.
• In order to avoid overheating, DO NOT COVER the appliance. Do
not place material or garments on the appliance, or obstruct the air
circulation around the appliance, for instance by curtains or furniture, as
this could cause overheating and a fire risk.
• In order to avoid a hazard due to inadvertent resetting of the thermal cut-
out, this appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly switched
on and off by the utility.
• DO NOT use the unit with an extension lead or power board.
• CAUTION: Some parts of this product can become very hot and cause
burns. Particular attention has to be given where children and vulnerable
people are present.
• Do not use this appliance in series with a thermal control, a program
controller, a timer or any other device that switches on the heat
automatically, since a fire risk exists when the appliance is accidentally
covered or dis-placed.
IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED
FOR FUTURE REFERENCE. Note also the information presented on the
appliance
3

Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
No extension leads or
power boards
Where there is risk
of fire or close to
a naked flame
Where the power
cable may be
damaged
On a slope or
uneven surface
Where it may be
damaged by
chemicals
If there is a risk
of water falling on
the unit
Where there is a risk
of interference by
foreign objects
This product is not
made for DIY repair
4

Model no. DHMH20C
Power supply 220-240V~50-60Hz
Rated power 2000W
Heat settings 2
Thermostat Y
IP rating IP24
Wall mountable Y
Castors Y
Noise Level 50dB(A)
Timer N
Turbo Fan N
Weight (net) (with feet & castors) 5.36kg
Dimensions (w x d x h) 780 x 267 x 580mm
Specifications
For greater precision, please always refer to the rating label placed on the product.
5

Assembly
Castor and Feet Assembly
1. Assemble the castors.
2. Fix the castors into the base of the feet.
3. Fix the feet into the base of the unit, by removing the screws on the base and
screwing back in through the holes of the feet.
Wall Installation
1. To install the unit on a wall, please ensure to remove the feet and castors. Ensure
there is 30cm of space between each side of the unit in the intended mount
location.
2. Mark two dots on the wall and use the plastic plaque to ensure the distance
between the holes meets the requirements as per below (13.5cm).
3. Drill two holes in the wall with a distance of 135mm from each other, and ensure
the diameter of each hole is 6mm, and the depth is 30mm.
6

Assembly
4. Fix the provided rubber plugs into the two holes.
5. Fix the provided screws into the rubber plugs. Ensure the screws are sticking out 5mm,
to be able to hang the unit.
6. Install the wall bracket into one of the slots at the bottom of the heater and drill a
third hole into the wall where the provided hole in the bracket is. Repeat above steps
regarding hole diameter, rubber plugs and screws to correctly drill the third hole and
install the bracket into the wall.
7

Operation
Put the unit into standby state by plugging into an electrical outlet compliant with
the device and local legislation, and switch on.
1. Turn the power switch on the unit to 'I' or 'II.'
2. Turn the thermostat to the max, and the heater will begin to work. Adjust
accordingly for your desired temperature.
3. When the power switch is on 'I,' the power is 1200W, and when the power switch
is on 'II,' it will work at 2000W.
4. Turn the power switch to the original position to stop the heater.
Thermostat
Power Switch
Min Max
8

Positioning
Select the position for the heater ensuring there is clearance from any furniture and
fittings of at least 300mm each side. The heater should only be operated on a flat
stable surface.
NOTE: The Mica Panel heater is designed for operation on an AC electricity supply,
and is only suitable for domestic use and similar indoor locations.
Tips
• The Mica Panel heater is fitted with castors and handles for ease of movement.
• A power switch provides the ability to choose an available heat output and
an adjustable thermostat enables the room temperature to be controlled
accordingly.
• Once the castors have been correctly fitted, no other assembly is required, just
plug in and play!
Safety Features
This appliance incorporates a number of safety devices. In addition to the ‘Important
Safety Advice’ section your attention is drawn to the following;
Tilt Switch
The tilt switch will prevent the heater from working if it is accidentally tipped over on
its side.
If the radiator is tipped over while it is hot, disconnect the power and allow it to cool,
then stand the radiator back upright. Reconnect the power - normal operation should
be resumed.
9

WARNING - ALWAYS DISCONNECT THE POWER SUPPLY BEFORE CLEANING THE
HEATER.
• Do not use detergents, abrasive cleaning powder or polish of any kind on the
body of the panel heater.
• Allow the panel heater to cool, then wipe with a dry cloth to remove dust and
a damp cloth (not wet) to clean off any marks. Be careful not to allow moisture
into to the heater.
Storage
If the heater is not required for long periods, for example during the summer, it should
be stored in a dry place and preferably covered to prevent the accumulation of dirt
and dust. The supply cord should be neatly coiled around the cable wrap ensuring that
the plug does not trail on the floor.
Cleaning
10

If the unit fails to operate efficiently, is broken or other problems arise, unplug and
do not operate. Ask for advice by calling your local after sales service agent or the
Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
Maintenance
Recycling: Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well-being.
Warranty
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
11

12

13

14

15

Customer Care: 1300 556 816
[e-mail]
www.dimplex.com.au
Supplied by Glen Dimplex Australia
8 Lakeview Drive, Scoresby, Victoria, 3179
© Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex Australia.
DHMH20C v1
