DINGLI E-TECH ACE Series Installation guide

www.cndingli.com
SELF-PROPELLED SCISSOR LIFTS
TRAINING MANUAL E-TECH ACE SERIES
(Hydraulic Motor Drive / Electric Motor Drive)

i
www.cndingli.com
Contents
1. PARAMETERS.........................................................................................1
1.1 HASPECIFICATION......................................................................................................2
1.2 AC SPECIFICATION......................................................................................................9
2. PARTS INTRODUCTION........................................................................16
2.1 CHARGER &BATTERY ...............................................................................................17
2.1.1 Specification......................................................................................................................... 17
2.1.2 Charger Curve...................................................................................................................... 18
2.2 POWER UNIT MODULE ...............................................................................................19
2.2.1 General Overview................................................................................................................. 19
2.2.2 ECU Overview....................................................................................................................... 21
2.2.3 ZAPI controller ..................................................................................................................... 24
2.2.3.1 Pump-motor controller...................................................................................................................................... 24
2.2.3.2 Drive-motor controller....................................................................................................................................... 26
2.2.4 Motors................................................................................................................................... 28
2.3 PLATFORM CONTROLLER...........................................................................................29
2.3.1 Introduction of PCU............................................................................................................. 29
2.3.2 PCU Setting .......................................................................................................................... 31
2.3.2.1 Speed Setting...................................................................................................................................................... 31
2.3.2.2 Option Setting..................................................................................................................................................... 32
2.4 SENSORS &SWITCHES..............................................................................................33
2.4.1 Angle sensor & Lift down limit switch............................................................................... 33
2.4.2 Pothole switches.................................................................................................................. 34
2.4.3 Pressure sensor & Lowering valve.................................................................................... 36
3. OPERATION...........................................................................................37
3.1 FUNCTION TEST ........................................................................................................38
3.2 OPERATING INSTRUCTIONS.........................................................................................42
4. DIAGNOSE.............................................................................................45
5. ECU........................................................................................................48
5.1 DATA DETECTION.......................................................................................................49
5.2 ECU SETTING...........................................................................................................51
5.2.1 Settings Overview................................................................................................................ 51
5.2.2 Calibration ............................................................................................................................ 54
5.2.2.1 Load Sensing....................................................................................................................................................... 54

ii
www.cndingli.com
5.2.2.2 Tilt Sensing.......................................................................................................................................................... 55
5.2.2.3 Angle Sensing..................................................................................................................................................... 55
5.2.2.4 OL Descent High................................................................................................................................................. 55
5.2.2.5 Height Limit.......................................................................................................................................................... 56
6. EMERGENCY SYSTEM .........................................................................57
6.1 EMERGENCY LOWERING ............................................................................................58
6.2 BRAKE RELEASE.......................................................................................................59
7. ELECTRICAL SCHEMATIC ...................................................................60
7.1 HATYPE ..................................................................................................................61
7.2 AC TYPE ..................................................................................................................63
8. HYDRAULIC SCHEMATIC.....................................................................65
8.1 SCHEMATICS.............................................................................................................66
8.2 VALVE BLOCK............................................................................................................72

1
www.cndingli.com
1. Parameters

2
www.cndingli.com
1.1 HA Specification
S06HA
Items
Parameters
Items
Parameters
Maximum Working Height
25.59 ft
7.80 m
Maximum hydraulic
pressure (functions)
180bar
Maximum Platform Height
19.03 ft
5.80 m
Tire size
Φ323×100mm
Height, stowed
Rails up
7.05 ft
2.15 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.00 ft
1.83 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.49 ft
0.76 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
6.10 ft
1.86 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
9.06 ft
2.76 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
5.48 ft×2.43 ft
1.67 m×0.74 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
507 lbs
230 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
4.0km/h
Wheelbase
4.46 ft
1.36 m
Platform raised, maximum
0.6km/h
Turning radius (outside)
5.38 ft
1.64 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
1565 lbs
710 kg
Ground clearance
3.54 in
9 cm
Tire contact pressure
10.4 kg/cm²
1019 kPa
Ground clearance
(Pothole guards deployed)
0.63 in
1.6 cm
Occupied floor pressure
1373 kg/m²
13.5 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

3
www.cndingli.com
S0608HA
Items
Parameters
Items
Parameters
Maximum Working Height
26.25 ft
8.00 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
19.69 ft
6.00 m
Tire size
Φ381×127mm
Height, stowed
Rails up
7.32 ft
2.23 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.14 ft
1.87 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.72 ft
0.83 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14 ft
2.48 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09 ft
3.38 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45 ft×2.66 ft
2.27 m×0.81 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
838 lbs
380 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
3.5km/h
Wheelbase
6.14 ft
1.87 m
Platform raised, maximum
0.8km/h
Turning radius (outside)
6.89 ft
2.10 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2205 lbs
1000 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.1 kg/cm²
1086.9 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1339 kg/m²
13.1 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

4
www.cndingli.com
S0808HA
Items
Parameters
Items
Parameters
Maximum Working Height
32.81ft
10.00m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
26.25 ft
8.00m
Tire size
Φ381×127mm
Height, stowed
Rails up
7.74ft
2.36m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.56ft
2.00m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.72ft
0.83m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14ft
2.48m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09ft
3.38m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45ft × 2.66ft
2.27m ×0.81m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95ft
0.90m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
507lbs
230kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
3.5km/h
Wheelbase
6.14ft
1.87m
Platform raised, maximum
0.8km/h
Turning radius (outside)
6.89ft
2.10m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2116lbs
960kg
Ground clearance
3.94in
10cm
Tire contact pressure
10.7kg/cm²
1045kPa
Ground clearance
(Pothole guards deployed)
0.75in
1.9cm
Occupied floor pressure
1287.4kg/m²
12.6kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

5
www.cndingli.com
S0812HA
Items
Parameters
Items
Parameters
Maximum Working Height
32.81ft
10.00m
Maximum hydraulic pressure
(functions)
240bar
Maximum Platform Height
26.25 ft
8.00m
Tire size
Φ381×127mm
Height, stowed
Rails up
7.74ft
2.36m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.00ft
1.83m
Maximum sound level at normal operating
workstations (A-weighted)
Width
3.77ft
1.15m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14ft
2.48m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09ft
3.38m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45ft × 3.67ft
2.27m ×1.12m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95ft
0.90m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
992lbs
450kg
Drive speeds
Maximum wind speed
28mile/h
12.5m/s
Stowed, maximum
3.5km/h
Wheelbase
6.14ft
1.87m
Platform raised, maximum
0.8km/h
Turning radius (outside)
7.22ft
2.20m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2734lbs
1240kg
Ground clearance
3.94in
10cm
Tire contact pressure
12.1kg/cm²
1182.6kPa
Ground clearance
(Pothole guards deployed)
0.75in
1.9cm
Occupied floor pressure
1174.1kg/m²
11.5kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

6
www.cndingli.com
S1012HA
Items
Parameters
Items
Parameters
Maximum Working Height
39.37 ft
12.00 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
32.81 ft
10.00 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.17 ft
2.49 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.43 ft
1.96 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
3.77 ft
1.15 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14 ft
2.48 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09 ft
3.38 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45 ft×3.67 ft
2.27 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
705 lbs
320 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
3.5 km/h
Wheelbase
6.14 ft
1.87 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
7.22 ft
2.20 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2888 lbs
1310 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.8 kg/cm²
1159.7 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1250.7 kg/m²
12.3 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

7
www.cndingli.com
S1212HA
Items
Parameters
Items
Parameters
Maximum Working Height
45.28 ft
13.80 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
38.71 ft
11.80 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.60 ft
2.62 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.86 ft
2.09 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
3.90 ft
1.19 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14 ft
2.48 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09 ft
3.38 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45 ft×3.67 ft
2.27 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
705 lbs
320 kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
3.5 km/h
Wheelbase
6.14 ft
1.87 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
7.22 ft
2.20 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2822 lbs
1280 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.1 kg/cm²
1083.7 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1169.8 kg/m²
11.5 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

8
www.cndingli.com
S1412HA
Items
Parameters
Items
Parameters
Maximum Working Height
51.51 ft
15.70 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
44.95 ft
13.70 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.60 ft
2.62 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.86 ft
2.09 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
4.10 ft
1.25 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
9.32 ft
2.84 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
12.27 ft
3.74 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
8.66 ft×3.67 ft
2.64 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
551 lbs
250 kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
3.5 km/h
Wheelbase
7.28 ft
2.22 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
8.69 ft
2.65 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2976 lbs
1350 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.7 kg/cm²
1142 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1013.1 kg/m²
9.9 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

9
www.cndingli.com
1.2 AC Specification
S06 ACE
Items
Parameters
Items
Parameters
Maximum Working Height
25.59 ft
7.80 m
Maximum hydraulic
pressure (functions)
180bar
Maximum Platform Height
19.03 ft
5.80 m
Tire size
Φ323×100mm
Height, stowed
Rails up
7.05 ft
2.15 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.00 ft
1.83 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.49 ft
0.76 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
6.10 ft
1.86 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
9.06 ft
2.76 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
5.48 ft×2.43 ft
1.67 m×0.74 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
507 lbs
230 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
4.5km/h
Wheelbase
4.46 ft
1.36 m
Platform raised, maximum
0.6km/h
Turning radius (outside)
5.38 ft
1.64 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
1565 lbs
710 kg
Ground clearance
3.54 in
9 cm
Tire contact pressure
10.4 kg/cm²
1019 kPa
Ground clearance
(Pothole guards deployed)
0.63 in
1.6 cm
Occupied floor pressure
1373 kg/m²
13.5 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

10
www.cndingli.com
S0608ACE
Items
Parameters
Items
Parameters
Maximum Working Height
26.25 ft
8.00 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
19.69 ft
6.00 m
Tire size
Φ381×127mm
Height, stowed
Rails up
7.32 ft
2.23 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.14 ft
1.87 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.72 ft
0.83 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14 ft
2.48 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09 ft
3.38 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45 ft×2.66 ft
2.27 m×0.81 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
838 lbs
380 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
4.0km/h
Wheelbase
6.14 ft
1.87 m
Platform raised, maximum
0.8km/h
Turning radius (outside)
6.89 ft
2.10 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2205 lbs
1000 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.3 kg/cm²
1104.6 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1360.7 kg/m²
13.3 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

11
www.cndingli.com
S0808ACE
Items
Parameters
Items
Parameters
Maximum Working Height
32.81ft
10.00m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
26.25 ft
8.00m
Tire size
Φ381×127mm
Height, stowed
Rails up
7.74ft
2.36m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.56ft
2.00m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.72ft
0.83m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14ft
2.48m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09ft
3.38m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45ft × 2.66ft
2.27m ×0.81m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95ft
0.90m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
507lbs
230kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
4.0km/h
Wheelbase
6.14ft
1.87m
Platform raised, maximum
0.8km/h
Turning radius (outside)
6.89ft
2.10m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2116lbs
960kg
Ground clearance
3.94in
10cm
Tire contact pressure
10.8kg/cm²
1062.7kPa
Ground clearance
(Pothole guards deployed)
0.75in
1.9cm
Occupied floor pressure
1309.1kg/m²
12.8kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

12
www.cndingli.com
S0812ACE
Items
Parameters
Items
Parameters
Maximum Working Height
32.81ft
10.00m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
26.25 ft
8.00m
Tire size
Φ381×127mm
Height, stowed
Rails up
7.74ft
2.36m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.00ft
1.83m
Maximum sound level at normal operating
workstations (A-weighted)
Width
3.77ft
1.15m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14ft
2.48m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09ft
3.38m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45ft × 3.67ft
2.27m ×1.12m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95ft
0.90m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
992lbs
450kg
Drive speeds
Maximum wind speed
28mile/h
12.5m/s
Stowed, maximum
4.0km/h
Wheelbase
6.14ft
1.87m
Platform raised, maximum
0.8km/h
Turning radius (outside)
7.22ft
2.20m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2734lbs
1240kg
Ground clearance
3.94in
10cm
Tire contact pressure
12.2kg/cm²
1198kPa
Ground clearance
(Pothole guards deployed)
0.75in
1.9cm
Occupied floor pressure
1189.4kg/m²
11.7kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

13
www.cndingli.com
S1012ACE
Items
Parameters
Items
Parameters
Maximum Working Height
39.37 ft
12.00 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
32.81 ft
10.00 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.17 ft
2.49 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.43 ft
1.96 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
3.77 ft
1.15 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14 ft
2.48 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09 ft
3.38 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45 ft×3.67 ft
2.27 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
705 lbs
320 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
4.0 km/h
Wheelbase
6.14 ft
1.87 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
7.22 ft
2.20 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2888 lbs
1310 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
12.9 kg/cm²
1267.4 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1258.4 kg/m²
12.3 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

14
www.cndingli.com
S1212ACE
Items
Parameters
Items
Parameters
Maximum Working Height
45.28 ft
13.80 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
38.71 ft
11.80 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.60 ft
2.62 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.86 ft
2.09 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
3.90 ft
1.19 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14 ft
2.48 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09 ft
3.38 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45 ft×3.67 ft
2.27 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
705 lbs
320 kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
4.0 km/h
Wheelbase
6.14 ft
1.87 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
7.22 ft
2.20 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2822 lbs
1280 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.2 kg/cm²
1097.5 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1184.6 kg/m²
11.6 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

15
www.cndingli.com
S1412ACE
Items
Parameters
Items
Parameters
Maximum Working Height
51.51 ft
15.70 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
44.95 ft
13.70 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.60 ft
2.62 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.86 ft
2.09 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
4.10 ft
1.25 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
9.32 ft
2.84 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
12.27 ft
3.74 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
8.66 ft×3.67 ft
2.64 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
551 lbs
250 kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
4.0 km/h
Wheelbase
7.28 ft
2.22 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
8.69 ft
2.65 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2976 lbs
1350 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.8 kg/cm²
1159.2 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1028.4 kg/m²
10.1 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

16
www.cndingli.com
2. Parts Introduction

17
www.cndingli.com
2.1 Charger & Battery
2.1.1 Specification
Lead-acid type
Charger:
Model: GPSC3024
AC Input: 100-135 V~, 50-60 Hz, 10.5 A Max
180-240 V~, 50-60 Hz, 4.8 A Max
DC Output: 24 V, 30 A
Battery:
Items
Parameters
Items
Parameters
S06ACE- - S0812ACE
Standard
S1012ACE--S1412ACE
Standard
Voltage
6VDC
Voltage
6VDC
Type
6TB170
(Hoppecke)
Type
6TB220
(Hoppecke)
Quantity
4
Quantity
4
Battery capacity, max.
170Ah
Battery capacity, max.
220Ah
Maintenance-free
Yes
Maintenance-free
Yes
