dji SPARK User manual

SPARK
User Manual V1.0
2017.03

2
Using this manual
Lengends
Warning Important Hints and Tips Reference
Read Before the First Flight
Read the following documents before using the SPARKTM:
1. Spark In the Box
2. Spark User Manual
3. Spark Quick Start Guide
4. Spark Disclaimer and Safety Guidelines
5. Spark Intelligent Flight Battery Safety Guidelines
We recommend that you watch all tutorial videos on the official DJITM website and read the
Disclaimer before you fly. Prepare for your first flight by reviewing the Spark Quick Start Guide and
refer to the User Manual for more details.
Video Tutorials
Please watch the tutorial videos at the link below, which demonstrates how to use
Spark safely:
http://www.dji.com/Spark/info#video
Download the DJI GO 4 App
Ensure to use the DJI GOTM 4 app during flight. Scan the QR code on the right to
download the latest version.
The Android version of the DJI GO 4 app is compatible with Android 4.4 or later.
The iOS version of the DJI GO 4 app is compatible with iOS 9.0 or later.

3
Contents
Using this manual..............................................................................................................................2
Lengends ...................................................................................................................................2
Read Before the First Flight.......................................................................................................2
Video Tutorials ..........................................................................................................................2
Download the DJI GO 4 App......................................................................................................2
Product Profile ..................................................................................................................................4
Introduction ..............................................................................................................................4
Aircraft Diagram ........................................................................................................................4
Aircraft ..............................................................................................................................................5
Gimbal and Camera...................................................................................................................5
Attaching and Detaching the Propellers....................................................................................6
Intelligent Flight Battery............................................................................................................7
Vision System and Infrared Sensing System..............................................................................9
Flight Mode .............................................................................................................................10
Using Mobile Device to Control Aircraft..........................................................................................10
DJI GO 4 App ...................................................................................................................................12
Flight................................................................................................................................................15
Appendix .........................................................................................................................................18
Specifications ..........................................................................................................................18
Compliance Information .........................................................................................................20

4
Product Profile
Introduction
The DJI Spark is DJI’s smallest flying camera, featuring a fully stabilized camera, Intelligent
Flight Modes and Obstacle Avoidance inside a revolutionary design. It captures 1080p videos and
12 megapixel photos, and is capable of both ActiveTrackTM and TapFlyTM making complex shots
effortless.
Spark boasts a maximum flight speed of 29 mph (46.8 kph) and a maximum flight time of 16.5
minutes*.
Aircraft Diagram
1. Propeller
2. Motor
3. Front LED Indicator
4. Gimbal and Camera

5
5. Infrared Sensing System
6. Aircraft Status Indicator
7. Intelligent Flight Battery
8. Power Button
9. Battery Level Indicators
10. Micro USB Port
11. microSD Card Slot
12. Charging Port
13. Downward Vision System
Aircraft
Gimbal and Camera
Gimbal
Profile
The 2-axis gimbal provides a steady platform for the attached camera, allowing you to capture clear,
stable images and video. The gimbal can tilt the camera within a 85˚ range.
Go to Camera View in the DJI GO 4 app, tap and hold on the screen until a blue circle appears, then
drag the circle to control the camera’s tilt.
Gimbal Operation Modes
Two gimbal operation modes are available. Switch between the different operation modes on the
camera settings page of the DJI GO 4 app.
Follow Mode
The angle between the gimbal’s orientation and aircraft’s nose
remains constant at all times.
FPV Mode
The gimbal will synchronize with the movement of the aircraft to
provide a first-person perspective flying experience.

6
Camera
Profile
The on-board camera uses the 1/2.3 inch CMOS sensor to capture video up to 1080p at 30 fps with
the Spark and 12 megapixel stills. You may choose to record video in either MOV or MP4 formats.
Available picture shooting modes include burst, continuous, and interval mode. A live preview of
what the camera sees can be monitored on the connected mobile device via the DJI GO 4 app.
Camera Micro SD Card Slot
To store your photos and videos, insert the Micro SD card into the slot, as shown below, before
turning on the Spark. The Spark supports Micro SD cards up to 64 GB. A UHS-1 Micro SD card is
recommended due to their fast read and write speeds allowing you to save high-resolution video
data.
Do not remove the Micro SD card from the Spark when it is turned on.
To ensure the stability of the camera system, single video recordings are capped at 30
minutes.
Camera Data Port
Turn on the Spark and connect a USB cable to the Micro USB Port to download photos and videos
to your computer.
The aircraft must be turned on before attempting to access the files on the Micro SD card.
Attaching and Detaching the Propellers
White ring and unmarked propellers indicate where they should be attached and in which direction
whey should spin.
Propellers
White Ring
Unmarked
Figure
Attach On
Motors with white marks
Motors without white marks
Legends
Lock：Turn the propellers in the indicated direction to mount and tighten.
Unlock：Turn the propellers in the indicated direction to loosen and
remove.

7
Attaching the Propellers
Attach the white ringed propellers to the mounting base with white marks. Press the propeller
down onto the mounting plate and rotate in the lock direction until it is secured. Attach the other
propellers to the mounting bases without marks. Unfold all the propellers blades.
Detaching the Propellers
Press the propellers down into the motor mount and rotate in the unlock direction.
Be aware of the sharp edges of the propellers. Handle with care.
Use only the DJI approved propellers. Do not mix propeller types.
Stand clear of the motors and DO NOT touch the propellers when they are spinning.
Check that the propellers and motors are installed correctly and firmly before every
flight.
Ensure that all propellers are in good condition before each flight. DO NOT use aged,
chipped, or broken propellers.
To avoid injury, STAND CLEAR of and DO NOT touch propellers or motors when they
are spinning.
Intelligent Flight Battery
Introduction
The DJI Intelligent Flight Battery has a capacity of 1480 mAh, a voltage of 11.4 V, and a smart
charge/ discharge functionality. It should only be charged using an appropriate DJI approved
charger.
The Intelligent Flight Battery must be fully charged before using it for the first time.

8
Using the Battery
Turning ON/OFF
Turning On: Press the Power Button once, then press again and hold for 2 seconds to turn on. The
remote controller system status screen will display the current battery level.
Turning Off: Press the Power Button once, then press again and hold for 2 seconds to turn off.
Checking the Battery Level
The Battery Level Indicators display how much power remains. When the battery is turned off,
press the Power Button once, the Battery Level Indicators will light up to display the current battery
level. See below for details.
The Battery Level Indicators will also show the current battery level during charging and
discharging. The indicators are defined below.。
LED is on. : LED is flashing. : LED is off.
Charging the Intelligent Flight Battery
1. Connect the Battery Charger to a power source (100-240V, 50/60Hz).
2. Connect the Micro USB port on the Spark to the Charger to start charging.
3. The Battery Level Indicator will display the current battery level as it is charging.。
4. The Intelligent Flight Battery is fully charged when the Battery Level Indicators are all off.

9
•Never insert or remove a battery when it is turned on.
•Allow battery temperature to drop to room temperature before storing for an
extended period.
•The charger will stop charging the battery if the battery cell’s temperature is not
within the operating range (5°C to 40°C).
Vision System and Infrared Sensing System
The Infrared Sensing System consists [1] of two 3D infrared modules on front of the aircraft.
The downward Vision System uses 3D infrared modules and image data to help the aircraft
maintain its current position. With the help of the Downward Vision System, your Spark can hover
in place more precisely and fly indoors or in other environments where a GPS signal is not available.
The main components of the Downward Vision System is located on the bottom of the aircraft;
they include [2] monocular sensors and [3] 3D infrared modules.

10
Using the Downward Vision System
The Downward Vision System is activated automatically when the aircraft is turned on. No further
action is required. The Downward Vision System is typically used in indoor environments where
GPS is unavailable. Using the Downward Vision System, the aircraft can hover precisely even
without GPS.
The Downward Vision System may not be able to recognize patterns on the ground
in low light (less than 100lux).
Downward Vision Systems may not function properly when the aircraft is flying over
water.
Flight Mode
P-mode (Positioning): P-mode works best when the GPS signal is strong. The aircraft utilizes the
GPS and Downward Vision Systems to locate itself, automatically stabilize, and navigate between
obstacles. Advanced features such as TapFly and ActiveTrack are enabled in this mode.
S-mode (Sport): The handling of the aircraft is adjusted in to enhance maneuverability and speed.
Infrared Sensing System is disabled in this mode.
Using Mobile Device to Control Aircraft
You may use the Wi-Fi connection on the mobile device to control the aircraft. Follow the
instructions below to learn how to control the aircraft over Wi-Fi.
1. Power on the aircraft.
2. Turn on your mobile device's Wi-Fi and enter the Wi-Fi password.
3. Launch DJI GO 4.
