DKS 6300 Series Operating instructions

WARNING
MOVINGGATECANCAUSE
Operategateonlywhengateareaisinsight
andfreeofpeopleandobstructions.
Donotallowchildrentoplayingatearea
oroperategate.
Donotstandingatepathorwalkthrough
pathwhilegateismoving.
Readowner’smanualandsafetyinstructions.
SERIOUSINJURYORDEATH
CLASS
CERTIFIEDTO
CAN/CSAC22.2NO.247
CONFORMSTO
ANSI/UL-325
VEHICULARGATE OPERATOR
HP
53382
MODEL
SERIAL
VOLTSPHASE
AMPS60Hz
MAXGATELOAD
DoorKing,Inc.,Inglewood,CA
Series 6300
Installation/Owner’s Manual
Copyright 2009 DoorKing, Inc.All rights reserved.
Copyright 2016 DoorKing, Inc.All rights reserved.
Date Installed:
Installer/Company Name:
Phone Number:
Leave Manual with Owner
Vehicular Swing Gate Operator
UL 325 Compliant
Circuit Board
Serial Number
and Revision Letter:
Series 6300
Pad Mount
Post Mount
Use this manual for circuit board 4502-010 Revision AA or higher.
EXTERNAL ENTRAPMENT PROTECTION MUST be
installed or the gate operator WILL NOT function.
6300-065-G-2-16

6300-065-G-2-16
2 Quick Guide - 1
QUICK GUIDE: DIP-Switches See page 20 for descriptions about DIP-switches.
When a switch setting is changed, power must be turned OFF and then turned back ON for the new setting to take affect.
Switch Function Setting Description
SW 4 (Top 8 Switches)
OFF
ON
OFF
ON
OFF
OFF
ON
1-OFF
1-OFF
1-ON
1-ON
2-OFF
2-ON
2-OFF
2-ON
Auto-Close
Timer
Not Used
Dual Operators
Single Operator
Circuit
Board
Relay
3
4
5
7
1 and 2
Auto-close timer is OFF. Manual input required to close gate.
Auto-close timer is ON. Adjustable from 1-23 seconds to close gate.
Leave in the OFF position.
OFF
ON
3-Button
Single Button
6OFF when using a 3-button station (DoorKing 3-button control stations only).
ON when using a single button control,
terminals 13 &14 become a STOP input.
Switch must be OFF when bi-parting (dual) gates are used.
Switch must be ON for single operator.
OFF
ON
Tamper Protect
8Tamper protect is OFF.
Normal Setting. Tamper protect is ON. Operator will close gate when being forced open.
Relay activates when gate is open (Shadow loop setting when used).
Relay activates when gate is not closed.
Relay activates when gate is opening and open.
Relay activates when gate is opening and closing.
The output wired to terminal #12 becomes the output from the exit loop detector plugged
into the EXIT Loop port.
Normal Setting. Terminal #12 is a normal full open input.
Exit Loop Port
Output
Full Open Input
Every time the operator is powered up, the First open command will
automatically set the open and close limits of the gate. (See page 21).
OFF
ON
Reverse
Shadow Loop
Terminal 15 is a STANDARD Reverse input.
Terminal 15 is a Shadow input. Gate will NOT stop during the close cycle.
Switch Function Setting Description
SW 3 (Bottom 8 Switches)
Secondary 6300
Gate Opening
Direction
OFF
OFF
ON
Not Used
Single Gates
OR
Bi-Parting Gates
Primary 6300
Gate Opening
Direction
2
3
4
6
1
Leave in OFF position.
Switch is OFF when using a single operator.
Switch is ON when using dual gate operators (Primary/Secondary Bi-Parting gates).
5
7
8
Gate Overlap
Monitored
Edge/Beam
OFF
ON
OFF
ON
Primary and secondary operators start at the same time.
Secondary operator starts 1-2 seconds prior to primary operator.
No Photo Sensor connected to Aux terminal 7 and 8.
Photo sensor is connected to Aux terminal 7 and 8 and monitored. (Close ONLY)
OFF
ON
No Edge or Beam connected to Aux terminal 9 and 10.
Edge OR Beam is connected to Aux terminal 9 and 10 and monitored. (Open/Close)
ON OFF
Opens
Clockwise
Opens
Counter-Clockwise
Same as above, for secondary 6300 ONLY.
Monitored
Close Beam

6300-065-G-2-16 3
Quick Guide - 2
QUICK GUIDE: Main Terminal Descriptions
See page 24 for main terminal wiring.
9
10
11
12
13
14
15
NC
NO
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
Low Voltage Common
Low Voltage Common
24 VDC Maglock Power
Dry Relay Contact
Dry Relay Contact
CLOSE - DoorKing 3-Button station ONLY
OPEN - DoorKing 3-Button station ONLY
Standard Reverse or Shadow
Full Open/Open Loop
Full Open
24 VAC - 250 ma. max.
12 VAC - 150 ma. max.
Pulse 1 - Primary Operator
Pulse 2 - Secondary Operator
Not Used
Motor
Motor
DANGER
HIGH VOLTAGE!
•lf SW 4, switch 3 is ON, functions as a
normal full open input (Normal setting).
•lf SW 4, switch 3 is OFF, input to
terminal #12 becomes the output from the
EXIT loop detector plugged into the EXIT
loop port. (Used for specialized functions). 12
•When gate is closed, input will open gate.
•When gate is open and auto close timer
SW 4, switch 4 is turned ON, input will
re-set and hold timer.
•When gate is open and auto close timer
SW 4, switch 4 is turned OFF, input will
close gate.
•When gate is closing, input will reverse gate.
11
15
Operation of the circuit board dry relay
contact is dependent on setting of SW 4,
switches 1 and 2.
Relay contacts can be set for Normally
Open (NO) or
Normally Closed (NC)
operation.
Contact rating is
1 amp maximum
at 24-volts DC.
NC
NO
16
24-volt DC magnetic lock
power is provided constantly
except when the gate is
opening or open (Normally
Closed function). 1 Amp Max.
18
This input ONLY functions when gate is fully
opened or in the closing cycle.
• When gate is closing: SW 3, switch 5 is OFF,
an input to terminal #15 will reverse and
open the gate.
Note: If the auto-close timer is ON, when
gate reaches the open position, timer will
then time out and close the gate.
• When gate is closing: SW 3, switch 5 is
ON, an input to terminal #15 has NO
effect on the gate operator (Set for
Shadow input).
ON
12345678
SW 4
ON
12345678
SW 4
ON
12345678
SW 3
ON
12345678
SW 4
115 VAC Hot
115 VAC - Neutral
115 VAC - Neutral

6300-065-G-2-16
4
Class of Operation Model 6300 - UL325 Class I, II, III, IV
Type of Gate Vehicular Swing Gates Only
Inherent Entrapment Protection Device Inherent Reverse Sensor System (Type A) - Adjustment is NOT needed.
Inherent Adjustable Clutch (Type C) - Adjustment is needed for UL compliance, see page 22.
External Entrapment Protection Device Inputs Connection inputs for Non-contact Sensor - Photo Sensor (Type B1)
(Monitored Inputs) Connection input for Contact Sensor - Reversing Edge (Type B2)
SPECIFICATIONS
Model # Max Gate
Weight
Max Gate
Length
Horsepower - Volts
1/2 HP - 115 VAC
1/2 HP - 115 VAC
1 HP - 115 VAC
1 HP - 115 VAC
1ø
1ø
1ø
1ø
6300-080
6300-081
6300-084
6300-085
600 Lbs.
600 Lbs.
800 Lbs.
800 Lbs.
Type
Operator
Primary
Secondary
Primary
Secondary
18 Ft.
18 Ft.
22 Ft.
22 Ft.
Cycles Per
Hour
60
60
60
60
Speed
90°
15-18 Sec
15-18 Sec
15-18 Sec
15-18 Sec
Amp Phase (Ø)
5.4
5.4
9.7
9.7
13.5”
32”
Post Mount Kit
P/N 2600-263
Pad Mount Kit
P/N 2600-264
9.5” 6”
Arm Assembly
Arm Assembly
Distance can vary.
7” minimum.
16.25”
8.125”
10”
19.75”
24”
3.5”
10.25”
5”
5”
11”
8.5”
Dimensions are the same
as shown above for the
operator cover.
Operator Cover
Use this manual for the Model 6300 operator with circuit board 4502-010 Rev AA or higher ONLY.
DoorKing, Inc. reserves the right to make changes in the products described in this manual without notice and without obligation of DoorKing, Inc. to notify any persons
of any such revisions or changes. Additionally, DoorKing, Inc. makes no representations or warranties with respect to this manual. This manual is copyrighted, all rights
reserved. No portion of this manual may be copied, reproduced, translated, or reduced to any electronic medium without prior written consent from DoorKing, Inc.
Note: 208/230/460/575 VAC input voltage can be connected to the operator by installing an “OPTIONAL” High Voltage Kit (P/N 2600-266).
Installation of ONE MONITORED external entrapment protection device MUST be installed or operator WILL NOT function.

6300-065-G-2-16 1
ASTM F2200 Standard for Gate Construction
Important Safety Instructions
Instructions regarding intended installation:
Important Notices
UL 325 Entrapment Protection
Glossary
Swing Gate Requirements
Swing Gate Protection
2
2
2-3
3
4
5
6
7
SECTION 1 - INSTALLATION 8
8
9
10
10
11
11
12
12
13-14
15
1.1 Operator Position
1.2 Post Mount or Pad Mount Base Assembly
1.3 Underground Conduit Requirements
1.4 Pad Mount
1.5 Post Mount
1.6 Arm and Gate Bracket Installation
1.7 Manually Adjust the Open and Closed Gate Positions
1.8 Installation of Warning Signs
1.9 Entrapment Protection Installation REQUIRED
1.10 Gates Opening Wider Than 90°
SECTION 2 - AC POWER TO OPERATOR(S) 16
16
16
17
2.1 High Voltage Wire Runs
2.2 High Voltage Terminal Connection
2.3 Bi-Parting Gates Wiring - Dual Gate Operators
SECTION 3 - ADJUSTMENTS 18
18
19
20
21
22
22
3.1 4502 Circuit Board Description and Adjustments
3.2 DIP-Switch SW 3 & SW 4 Settings
3.3 DIP-Switch Descriptions
3.4 Automatic Open / Close Limit Adjustment
3.5 Clutch Adjustment
3.6 Inherent Reverse Sensor System
SECTION 6 - MAINTENANCE AND TROUBLESHOOTING 31
6.1 Maintenance
6.2 Troubleshooting
6.3 Accessory Items
Model 6300’s Wiring Diagrams
31
32-33
34
35-37
SECTION 5 - OPERATING INSTRUCTIONS 27
5.1 Power and Reset Switches
5.2 Shutdown Conditions
5.3 Manual Gate Operation
27
28-29
29-30
SECTION 4 - WIRING
4.1 Main Terminal Description
4.2 Control Wiring
4.3 Auxiliary Terminal Wiring
4.4 Loop Detector Wiring
23
24
25
26
23
TABLE OF CONTENTS
QUICK GUIDE - DIP-SWITCHES and MAIN TERMINAL Quick Guide-1 & 2
SPECIFICATIONS Previous Page

6300-065-G-2-16
2
Instructions regarding intended installation:
Vehicular gates should be constructed and installed in accordance with ASTM F2200; Standard Specification for Automated
Vehicular Gate Construction. For a copy of this standard, contact ASTM directly at 610-832-9585; [email protected]; or
www.astm.org.
Important Safety Instructions
WARNING - To reduce the risk of injury or death:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Never let children operate or play with gate controls. Keep the remote control away from children.
3. Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE.
4. Test the operator monthly. The gate MUST reverse on contact with a rigid object or stop or reverse when an object
activates the non-contact sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to adjust
and retest the gate operator properly can increase the risk of injury or death.
5. Use the emergency release only when the gate is not moving.
6. KEEP GATES PROPERLY MAINTAINED. Read the owner's manual. Have a qualified service person make repairs to gate
hardware.
7. The entrance is for vehicles only. Pedestrians must use separate entrance.
8. SAVE THESE INSTRUCTIONS!
•Install the gate operator only if:
1. The operator is appropriate for the construction of the gate and the usage class of the gate.
2. All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 6 feet
(1.83 m) above the ground to prevent a 2 ¼ inch (57.2 mm) diameter sphere from passing through the openings
anywhere in the gate, and in that portion of the adjacent fence that the gate covers in the open position.
3. All exposed pinch points are eliminated or guarded.
4. Guarding is supplied for exposed rollers.
•The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a separate
access opening. The pedestrian access opening shall be designed to promote pedestrian usage. Locate the gate such that
persons will not come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
•The gate must be installed in a location so that enough clearance is supplied between the gate and adjacent structures
when opening and closing to reduce the risk of entrapment. Swinging gates should not open into public access areas.
•The gate must be properly installed and work freely in both directions prior to the installation of the gate operator. Do not
over-tighten the operator clutch, pressure relief valve or reduce reversing sensitivity to compensate for a damaged gate.
•For gate operators utilizing Type D protection:
1. The gate operator controls must be placed so that the user has full view of the gate area when the gate is moving.
2. A warning placard shall be placed adjacent to the controls.
3. An automatic closing device (such as a timer, loop sensor, or similar device) shall not be employed.
4. No other activation device shall be connected.
•Controls intended for user activation must be located at least six feet (6’) away from any moving part of the gate and
where the user is prevented from reaching over, under, around or through the gate to operate the controls.
Exception: Emergency access controls only accessible by authorized personnel (e.g. fire, police, EMS) may be placed at
any location in the line-of-sight of the gate.
•The Stop and/or Reset button must be located in the line-of-sight of the gate. Activation of the reset control shall not
cause the operator to start.
•A minimum of two (2) WARNING SIGNS shall be installed, one on each side of the gate where easily visible.
•For gate operators utilizing a non-contact sensor:
1. See the instructions on the placement of non-contact sensors for each type of application.
2. Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle trips the sensor while the gate
is still moving in the opening direction.
3. One or more non-contact sensors shall be located where the risk of entrapment or obstruction exist, such as the
perimeter reachable by a moving gate or barrier.
ASTM F2200 Standard for Gate Construction

6300-065-G-2-16 3
•For gate operators utilizing contact sensors:
1. One or more contact sensors shall be located where the risk of entrapment or obstruction exist, such as at the
leading edge, trailing edge, and post mounted both inside and outside of a vehicular horizontal slide gate.
2. One or more contact sensors shall be located at the bottom edge of a vehicular vertical lift gate.
3. One or more contact sensors shall be located at the pinch point of a vehicular vertical pivot gate.
4. A hardwired contact sensor shall be located and its wiring arranged so that the communication between the sensor
and the gate operator is not subjected to mechanical damage.
5. A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for
entrapment protection functions shall be located where the transmission of the signals are not obstructed or
impeded by building structures, natural landscaping or similar obstructions. A wireless contact sensor shall function
under the intended end-use conditions.
6. One or more contact sensors shall be located at the bottom edge of a vertical barrier (arm).
Vehicular gate operator products provide convenience and security. However, gate operators must use high levels of force
to move gates and most people underestimate the power of these systems and do not realize the potential hazards associ-
ated with an incorrectly designed or installed system. These hazards may include:
•Pinch points
•Entrapment areas
•Reach through hazards
•Absence of entrapment protection devices
•Improperly located access controls
•Absence of vehicle protection devices
•Absence of controlled pedestrian access
In addition to these potential hazards, automated vehicular gate systems must be installed in accordance with the UL-325
Safety Standard and the ASTM F2200 Construction Standard. Most lay persons are unaware of, or are not familiar with,
these standards. If an automated vehicular gate system is not properly designed, installed, used and maintained, serious
injuries or death can result. Be sure that the installer has instructed you on the proper operation of the gate and gate
operator system.
Be sure that the installer has trained you about the basic functions of the required reversing systems associated with your
gate operating system and how to test them. These include reversing loops, inherent reversing system, electric edges,
photoelectric cells, or other external devices.
•This Owner’s Manual is your property. Keep it in a safe place for future reference.
•Be sure that all access control devices are installed a minimum distance of 6 feet away from the gate and gate
operator, or in such a way that a person cannot touch the gate or gate operator while using the device. If access
control devices are installed in violation of these restrictions, immediately remove the gate operator from service
and contact your installing dealer.
•Loops and loop detectors, photo-cells or other equivalent devices must be installed to prevent the gate from
closing on vehicular traffic.
•The speed limit for vehicular traffic through the gate area is 5 MPH. Install speed bumps and signs to keep
vehicular traffic from speeding through the gate area. Failure to adhere to posted speed limits can result in
damage to the gate, gate operator, and to the vehicle.
•Be sure that all persons who will use the gate system are familiar with the proper use of the gate and gate
operator and are familiar with the possible hazards associated with the gate system.
•Be sure that warning signs are permanently installed on both sides of the gate in an area where they are fully
visible to traffic.
•It is your responsibility to periodically check all entrapment protection devices. If any of these devices are
observed to function improperly, remove the operator from service immediately and contact your installing or
servicing dealer.
•Follow the recommended maintenance schedule.
•Do not allow children to play in the area of the operator or to play with any gate-operating device.
•To remove the gate operator from service, operate the gate to the full open position and then shut off power to
the operator at the service panel.
Important Notices

6300-065-G-2-16
4
UL 325 Entrapment Protection
Class I - Residential
Vehicular Gate Operator
Entrapment Protection Types
Class II - Commercial/General Access
Vehicular Gate Operator
Class III - Industrial/Limited Access
Vehicular Gate Operator
Class IV -
Restricted Access
Vehicular Gate Operator
A vehicular gate operator (or system) intended for use in garages
or parking areas associated with a residence of one-to four single
families.
A vehicular gate operator (or system) intended for use in a
commercial location or building such as a multi-family housing
unit (five or more single family units), hotel, garages, retail store,
or other buildings accessible by or servicing the general public.
A vehicular gate operator (or system) intended for use in an
industrial location or building such as a factory or loading dock
area or other locations not accessible by or intended to service
the general public.
A vehicular gate operator (or system) intended for use in a
guarded industrial location or building such as an airport security
area or other restricted access locations not servicing the general
public, in which unauthorized access is prevented via supervision
by security personnel.
Gate Operator Category
UL 325 Classifications
Type A - Inherent entrapment protection system.
Type B1 - Non-contact sensor (photoelectric sensor or the equivalent).
Type B2 - Contact sensor (edge device or equivalent).
Type C - Inherent force limiting, inherent adjustable clutch or inherent pressure relief device.
Type D - Actuating device requiring constant pressure to maintain opening or closing motion of the gate.
*B1 and B2 means of entrapment protection must be MONITORED.
Vertical Barrier Note: Barrier gate operators (arm)
that is not intended to move toward a rigid object
closer than 16 inches (406 mm) are not required to
be provided with a means of entrapment protection.
STATE PRISON
Horizontal Slide, Vertical Lift, Vertical Pivot Swing, Vertical Barrier (Arm)
A, B1*, B2* or D A, B1*, B2*, C or D
Effective January 12, 2016
Authorized
Personnel ONLY

6300-065-G-2-16 5
Glossary
GATE - A moving barrier such as a swinging, sliding, raising, lowering, or the like, barrier, that is a stand-alone passage
barrier or is that portion of a wall or fence system that controls entrance and/or egress by persons or vehicles and
completes the perimeter of a defined area.
RESIDENTIAL VEHICULAR GATE OPERATOR – CLASS I - A vehicular gate operator (or system) intended for use in garages
or parking areas associated with a residence of one-to four single families.
COMMERCIAL / GENERAL ACCESS VEHICULAR GATE OPERATOR - CLASS II - A vehicular gate operator (or system)
intended for use in a commercial location or building such as a multi-family housing unit (five or more single family units),
hotel, garages, retail store, or other buildings accessible by or servicing the general public.
INDUSTRIAL / LIMITED ACCESS VEHICULAR GATE OPERATOR - CLASS III - A vehicular gate operator (or system)
intended for use in an industrial location or building such as a factory or loading dock area or other locations not accessible
by or intended to service the general public.
RESTRICTED ACCESS VEHICULAR GATE OPERATOR - CLASS IV - A vehicular gate operator (or system) intended for use in
a guarded industrial location or building such as an airport security area or other restricted access locations not servicing
the general public, in which unauthorized access is prevented via supervision by security personnel.
VEHICULAR BARRIER (ARM) OPERATOR (OR SYSTEM) - An operator (or system) that controls a cantilever type device (or
system), consisting of a mechanical arm or barrier that moves in a vertical arc, intended for vehicular traffic flow at
entrances or exits to areas such as parking garages, lots or toll areas.
VEHICULAR HORIZONTAL SLIDE-GATE OPERATOR (OR SYSTEM) - A vehicular gate operator (or system) that controls a
gate which slides in a horizontal direction that is intended for use for vehicular entrance and exit to a drive, parking lot, or
the like.
VEHICULAR SWING-GATE OPERATOR (OR SYSTEM) - A vehicular gate operator (or system) that controls a gate which
moves in an arc in a horizontal plane that is intended for use for vehicular entrance and exit to a drive, parking lot, or the
like.
SYSTEM - In the context of these requirements, a system refers to a group of interacting devices intended to perform a
common function.
WIRED CONTROL - A control implemented in a form of fixed physical interconnections between the control, the associated
devices, and an operator to perform predetermined functions in response to input signals.
WIRELESS CONTROL - A control implemented in means other than fixed physical interconnections (such as radio waves or
infrared beams) between the control, the associated devices, and an operator to perform predetermined functions in
response to input signals.
INHERENT ENTRAPMENT PROTECTION SYSTEM - A system, examples being a motor current or speed sensing system,
which provides protection against entrapment upon sensing an object and is incorporated as a permanent and integral part
of the operator.
EXTERNAL ENTRAPMENT PROTECTION DEVICE - A device, examples being an edge sensor, a photoelectric sensor, or
similar entrapment protection device, which provides protection against entrapment when activated and is not incorporated
as a permanent part of an operator.
ENTRAPMENT - The condition when an object is caught or held in a position that increases the risk of injury.

6300-065-G-2-16
6
Swing Gate Requirements
The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a separate
access opening. The pedestrian access opening shall be designed to promote pedestrian usage. Locate the gate such that
persons will not come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
(ref. UL325 56.8.4.b)
Not Allowed OK
Closed Gates
Gates shall have smooth bottom edges, with vertical bottom edged protrusions not exceeding 0.50 inches. ASTM F2200 4.3
If distance is greater than 4 inches,
entrapment protection for this area is
required. ASTM F2200 7.1.1.1
If distance is less than 16 inches,
entrapment protection in this area
is required. ASTM F2200 7.1.1.2
A
B
A
B
Closed Gate
With the hinge mounted on
the corner of the pilaster,
the entrapment area is
eliminated and protection
is NOT required for this
area.
Closed Gate
Opened Gate
Opened Gate
A

6300-065-G-2-16 7
Swing Gate Protection
Non-contact Sensor
Reverse Loop
Shadow Loop
Automatic Exit Loop
C
E
F F
E
D
D
C
Minimizes the potential of the gate
closing when a vehicle is present.
Number and placement of loops is
dependent on the application.
Reverse Loop
Minimizes the potential of the gate
closing when a vehicle is present.
Number and placement of loops is
dependent on the application.
(Optional) will provide an open
command to the gate operator(s)
when a vehicle is exiting the
property.
Provides a hold open command to
the operator(s) only if the gate(s)
are at the full open position.
Separate
Pedestrian
Walkway
Located so
pedestrians
cannot come in
contact with the
vehicular gate.
Warning Signs
D
Permanently mounted
and easily visible from
either side of the gate.
E
Minimizes the potential of
the gate closing on vehicular
or other traffic that loops
cannot sense. Monitored
device helps protect against
entrapment.
Non-contact
Sensor
Minimizes the potential
of the gate striking
vehicular or other traffic
that loops cannot sense.
Monitored device helps
protect against
entrapment.
Minimizes the potential
of the gate striking
vehicular or other traffic
that loops cannot sense.
Monitored device helps
protect against
entrapment.
FContact Sensor
, or is
REQUIRED
for operator
to function.
EC F

6300-065-G-2-16
8
SECTION 1 - INSTALLATION
1.1 Operator Position
35”
90°
Open Gate
Closed Gate
Gate Bracket
Operator
Output Shaft
An imaginary straight line drawn from the closed
gate bracket through the open gate bracket MUST
intersect the operator output shaft.
This layout is for the pad or post mount
with the gate opening 90°.
See Section 1.9 for gate’s opening wider than 90°.
Minimum distance required
for arm clearance in the
open position.
Note: The operator can be placed further away from the open gate than
shown as long as the imaginary straight line drawn from the closed gate
bracket through the open gate bracket intersects the operator output shaft.
34”
12”
43”
Prior to beginning the installation of the swing gate operator, we suggest that you become familiar with the
instructions, illustrations, and wiring guide-lines in this manual. This will help insure that your installation is
performed in an efficient and professional manner compliant with UL 325 safety and ASTM F2200 construction
standards.
The proper installation of the vehicular swing gate operator is an extremely important and integral part of the
overall access control system. Check all local building ordinances and building codes prior to installing this
operator. Be sure your installation is in compliance with local codes.

6300-065-G-2-16 9
1.2 Post Mount or Pad Mount Base Assembly
Hardware for Pad Mount:
Pad Support Base
Post Support Base
(8) 1 inch bolts, lockwashers and nuts.
For support legs.
(6) 1 1/2 inch bolts, lockwashers and nuts.
For support plate.
(4) Non-slip nuts. For existing threaded
studs on bottom of 6300.
Support Plate
Left Support Leg
Right Support Leg
1” Bolts
1 1/2” bolts through the main
gear bracket mounting holes.
1 1/2” bolts through the main gear
bracket mounting holes.
Bottom of 6300
Support
Plate
Bottom of 6300
Hardware for Post Mount:
(6) 1 1/2 inch bolts. For support plate.
(4) Non-slip nuts. For existing
threaded studs on bottom of 6300.
Remove the cover
from the operator
and GENTLY place
the operator on its
side before attaching
the pad base.
Screw the posts to the support
plate and mount into concrete
BEFORE attaching the operator.

6300-065-G-2-16
10
9.5” 6”
1.4 Pad Mount
Open Gate
Closed Gate
3”
3”
1.5”
1.5”
3”
90°
Depth of the concrete pad is
determined by soil conditions and
local building codes. Reinforced
concrete recommended.
Note: If allowed by local codes, the
top of the concrete pad can be flush
with ground level, which will allow
the gate bracket to be mounted
lower on the gate.
Low
Volt
Arm
Rotation
Area
High
Volt
Gate Bracket Height Concrete Pad Position
3/8
Secure the operator to the
concrete pad with six (6)
3/8” x 3” sleeve anchors
(not supplied).
Operator MUST be level.
Interconnection
Cable
Note: Right support leg removed from
this illustration to show conduit detail.
Pad Support
Base Output
Shaft
5”
11”
Note: 2” thick
gate Illustrated.
Important Note: These pad mount measurements will
ONLY work when the operator is positioned using the
“1.1 Operator Position” measurements on page 8.
16.5”
30”
23”
Concrete Pad
43”
12”
14”
10” Conduit
1.3 Underground Conduit Requirements
Sweeps
Concrete Pad
Primary
Operator
Position
Secondary
Operator
Position
•The conduit requirements are for a typical slide gate operator installation (the secondary operator is shown for those
applications where a secondary operator may be used). The conduit requirements for your application may vary from this
depending on your specific needs.
•Use only sweeps for conduit bends. Do not use 90° elbows as this will make wire pulls very difficult
and can cause damage to wire insulation. DoorKing recommends using 3/4-inch conduit.
• Installation of External Entrapment Protection Devices is REQUIRED (photo sensor and/or reversing edge).
•Be sure that all conduits are installed in accordance with local codes.
•Never run low voltage rated wire insulation in the same conduit as high voltage rated wire insulation.
Elbow
NO
Sweep
YES
External Safety Devices, Controls and P.A.M.S. Wires (Low Voltage wire insulation)
DoorKing’s Primary/Secondary Interconnection Cable (Dual Operator Application Only)
(Secondary Operator AC Power and Communication wires)
Loop Lead-In Wires (Low Voltage wire insulation)
AC Input Power (High Voltage wire insulation)

6300-065-G-2-16 11
Closed Gate
5”
5”
1.5 Post Mount
1.6 Arm and Gate Bracket Installation
Open Gate
Closed Gate
23”
12”
22”
34”
5”
Depth of the concrete is
determined by soil conditions
and local building codes.
Do not insert the locking pin or padlock
into the crank arm. It will be installed
after arms have been adjusted.
Do not secure the elbow assembly
to the arms until the arms have
been adjusted. (See next page).
Mount the post base into the concrete
before installing the operator.
The post mount installation will allow
the operator to be mounted low enough
to attach the gate bracket to the lower
gate rail if desired.
Adjust the locknut on the crank power
arm so that it is snug against the
washer, but will still allow the crank arm
to rotate with little force. This is the
operator’s manual release option when
the crank arm is unlocked.
Assemble arms as shown with the gate in the closed
position. The elbow assembly’s flange MUST be on the
opposite side of the gate in the closed position. This is
the physical stop used to set the open and close limits.
Low
Volt
Interconnection
Cable
Arm
Rotation
Area
High
Volt
Gate Bracket Height
Concrete
Position
Gate Rail
Run all conduit on the opposite
side of the open gate.
Install gate
bracket to gate.
Conduit
Post Base
Operator MUST be level.
30” Crank Arm
60” Connecting Arm
Flange
Crank Power Arm
Elbow
Assembly
Point arms towards
gate bracket.
Gate Hinge Pivot Point
Arms MUST be level.
This distance can vary (7” minimum).
Varies
60” Connecting Arm
Gate
Bracket
Note: 2” thick
gate Illustrated. Important Note: These post mount measurements will
ONLY work when the operator is positioned using the
“1.1 Operator Position” measurements on page 8.
90°
Output Shaft
Concrete
2”
12”
43”

6300-065-G-2-16
12
1.7 Manually Adjust the Open and Closed Gate Positions
1.8 Installation of Warning Signs
90°90°
Open Gate Open Gate
Closed Gate
Arms will be aligned on the SAME imaginary
straight line when open or closed. Slide elbow
assembly back and fourth, manually opening
and closing gate until arms function as shown.
DO NOT power up the operator to set the open and closed gate positions. The first time the operator is powered up and
cycled, it will automatically set the open and close limits. To do this, the arms MUST already be in the correct configuration.
Once you are sure that the gate opens and closes correctly,
trim off excess length from arms and secure the arms with
the 6 allen screws. Install safety cover on elbow assembly.
The arms are now in the
correct configuration. Arms must be on the
imaginary straight line.
Arms must be on the
imaginary straight line.
Approximate pivot
point distances.
Elbow flange MUST
be in this position.
Closed Arms Position Open Arms Position
37.5”
24”
Crank Power Arm
Crank Arm
Install the locking pin and padlock in the “Closed Arms Position”.
The operator is now ready for AC power.
This DoorKing Swing Gate Operator is shipped with two warning
signs. The purpose of the warning sign is to alert uninformed
persons, and to remind persons familiar with the gate system, that
a possible hazard exists so that appropriate action can be taken to
avoid the hazard or to reduce exposure to the hazard. See page 7 for
suggested mounting positions of signs.
• Permanently install the supplied warning signs in locations so
that the signs are visible by persons on both sides of the gate.
• Use appropriate hardware such as wood or sheet metal screws
(not supplied) to install the warning signs.
Locking Pin Safety Cover

6300-065-G-2-16 13
Monitored OPEN Photo Sensor Mounting Position
Monitored OPEN Photo Sensor
Monitored CLOSE Photo Sensor
Mounting Position
Monitored CLOSE Photo Sensor
Wall
UL sensor mounted just
above top of operator
5” or
Less
Gate Frame (Closed) Gate Frame (Closed)
21”
Typical
27.5”
Max.
1.9 Entrapment Protection Installation REQUIRED
CLOSE Beam
OPEN Beam
Potential
Entrapment
Area
A monitored photo sensor (Type B1) or monitored reversing edge (Type B2, see next page) MUST be installed or operator WILL
NOT function.
See page 25 for AUX terminal wiring
for monitored photo sensor.
Potential Entrapment Area:
Installation of MONITORED entrapment
protection is REQUIRED or operator
will NOT function.

6300-065-G-2-16
14
Typical Monitored Reversing Edge mounted on end of gate.
Greater than 6” but less than 16”
Gate Frame (Closed)
1.9 Continued
Monitored
Reversing
Edge
Edge
Transmitter
Gate Frame (Closed)
Reversing Edge
Edge
Transmitter
See page 25 for aux terminal wiring
for monitored reversing edge.
Typical Reversing Edge mounted on
bottom of gate when necessary.
If the bottom of gate is greater than 6” but less than
16” above the ground at any point in its arc of
travel, it is recommended mounting
a reversing edge for safety.
OPTIONAL wireless transmitter can be used.
OPTIONAL wireless transmitter can be used.
Reversing Edge
Potential
Entrapment
Area
Closing Gate
Mointored Sensor Note:
Input is active in both directions of travel.
Potential Entrapment Area:
Installation of MONITORED entrapment
protection is REQUIRED or operator
will NOT function.
A monitored reversing edge (Type B2) or a monitored photo sensor (Type B1, see previous page) MUST be installed or operator
WILL NOT function.

6300-065-G-2-16 15
1.10 Gates Opening Wider Than 90°
Open Gate
Connecting Arm
Elbow Assembly
Crank Arm
Closed Gate
44.5”
40” 22.25”
22.25” 8.5”
62.25”
36”
24”
28”
Operator
Output Shaft
An imaginary line drawn from the
closed gate bracket through the
open gate bracket MUST intersect
the operator output shaft. The
crank and connecting arm’s pivot
point calculations will be made
from the 2 measurements taken
from this line.
Note: Mount operator square to the fence line
and NOT parallel to the open gate.
The installation of an operator opening gates wider that 90° is the same for sections 1.3 through 1.9 except the operator and
concrete pad will be in a different position. Individual requirements can be calculated following this 105° opening sample.
105°
Sample
3”
away from
gate for any
configuration.
Crank arm’s pivot point measurement
in the open position on imaginary line.
Safety cover’s installed
measurement for any
configuration.
Connecting arm’s pivot point measurement
62.25” minus (crank arm) 22.25” = 40”
Crank arm’s pivot point measurement
44.5” divided by 2 = 22.25”
Gate bracket
should not be
mounted any
farther than
28” from
hinge for any
configuration.
Distance needed for arm
clearance in the open position.
Arm Assembly
1
2
3
Imaginary Line
27”

6300-065-G-2-16
16
2.2 High Voltage Terminal Connections
DANGER
HIGH VOLTAGE!
2.1 High Voltage Wire Runs
SECTION 2 - AC POWER TO OPERATOR(S)
Before attempting to connect any wiring to the operator, be sure that the circuit breaker in the electrical panel is in the OFF
position. Permanent wiring must be installed to the operator as required by local electrical codes. It is recommended that a
licensed electrical contractor perform this work.
Since building codes vary from city to city, we highly recommend that you check with your local building department prior
to installing any permanent wiring to be sure that all wiring to the operator (both high and low voltage) complies with local
code requirements. THIS GATE OPERATOR MUST BE PROPERLY GROUNDED!!
The distance shown in the chart is measured in Feet from the operator to the power source. If power wiring is greater than the
maximum distance shown, it is recommended that a service feeder be installed. When large gauge wire is used, a separate
junction box must be installed for the operator connection. The wire table is based on stranded copper wire. The wire run
calculations are based on a power source with a 3% voltage drop on the power line, plus an additional 10% reduction in
distance to allow for other losses in the system.
“Optional” Heater Installation Note: When installing a heater, refer to the “high voltage AC power wire size
and distance limitations” table on the instruction sheet with the heater kit for AC power wire run limitations.
This table illustrates the high voltage AC power wire size and distance limitations for a single operator.
Reduce the wire distance in half for a primary/secondary dual gate operator application
Model
Type
Voltage
Required
Amps
Required
Wire Size / Max Distance in Feet
12 AWG 10 AWG 8 AWG 6 AWG
Never run low voltage rated wire insulation in the same conduit as high voltage rated wire insulation.
180
100
5.4
9.7
115
115
290
162
485
270
725
405
6300 1/2 HP
6300 1 HP
Section 1 MUST be completed before power can be turned on.
Every time the operator is powered up, the First open command will
automatically set the open and close limits of the gate. (See page 21).
• Route incoming high voltage power through underground conduit and
into the operator as shown in Section 1.4 or 1.5 on page 10 or 11.
• Be sure wiring is installed in accordance with local codes. Be sure to
color code all wiring.
• It is recommended that a surge suppressor be installed on the high
voltage power lines to help protect the operator and circuit board from
surges and power fluctuations.
• Secondary operator in a dual operator application gets power through
the 8-wire interconnection cable that links the 2 operators together.
See Section 2.3 “Bi-Parting Gates Wiring - Dual Gate Operators” on the
next page.
“Optional” High Voltage Kit Installation Note: When installing a high voltage kit for 208/230/460/575 VAC input power,
refer to the “high voltage AC power wire size and distance limitations” table on the instruction sheet with the
high voltage kit (P/N 2600-266) for AC power wire run limitations.
Chassis
Ground
HotNeu
White - Neutral
Black - 115 VAC Hot
Green - Chassis Ground
Note: A separate power
disconnect switch may be
needed in your area. Check
local building codes before
installation.
Note: “Optional”
High Voltage Kit
black and white wires
connect the same as
shown.
High Voltage
AC Power Wire
External
Power
Disconnect
Switch
AC POWER
ON
OFF
115 VAC
AC Power Terminal
An EXTERNAL ENTRAPMENT PROTECTION DEVICE MUST be connected
or the gate operator WILL NOT function. (see pages 13, 14 and 25)
