DKS 6003 User manual

6003
Owner’s Manual
6003
Vehicular Swing Gate Operator
Copyright 2008 DoorKing, Inc. All rights reserved.
OPEN
CLOSE

Class of Operation Model 6003 - UL325 Class I
Type of Gate Vehicular Swing Gates Only
Motor RPM 1400
Maximum Thrust 300 daN
Voltage / Phase 115 VAC Single Phase Input Power – 24 VDC Operating Power
Current 3 Amps
Max Gate Weight 300 Lbs.
Max Gate Length 10 Feet
Useful Rod Stroke 14 inches
Cycles Per Hour 10 Per Hour
Speed 90° in approximately 20 seconds
Entrapment Protection Primary - Inherent entrapment sensing system (Type A)
Secondary - Provision for connection of a non-contact sensor (Type B1)
SPECIFICATIONS
DoorKing, Inc. reserves the right to make changes in the products described in this manual without notice and without obligation of DoorKing, Inc. to notify any
persons of any such revisions or changes. Additionally, DoorKing, Inc. makes no representations or warranties with respect to this manual. This manual is
copyrighted, all rights reserved. No portion of this manual may be copied, reproduced, translated, or reduced to any electronic medium without prior written
consent from DoorKing, Inc.
32.47”
4.9”
3.2”
4.25”
4.25”
16.5”
12.5”
24.5”
14.5”
2.5”
2.5”
Deluxe Box P/N 4302-112
Standard Box P/N 4302-111
Control Boxes
Actuator Arm
Drawings not to scale
Deluxe control box provides three
115 VAC convenience outlets to
power auxiliary power transformers.
Both control boxes include batteries
to power the actuator during power
outages.
Rod
Extends
14”
1
6003-065-G-6-08

26003-065-G-6-08
SPECIFICATIONS 1
SECTION 1 - INSTALLATION 9
SECTION 2 - WIRING 14
UL325 Entrapment Protection
Gate Construction
Important Safety Instructions
Instructions regarding intended installation:
Important Notices
Swing Gate Requirements
Swing Gate Protection
Glossary
3
4
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1.1 Manual Key Release
1.2 Gate “Opens to the Outside” Bracket Locations
1.3 Gate “Opens to the Inside” Bracket Locations
1.4 Mounting Actuator Arm
1.5 Mounting Control Box with Conduit and Warning Signs
2.1 Wiring Actuator Arm(s)
2.2 Secondary Entrapment Protection Wiring
2.3 Main Terminal Description
2.4 Main Terminal Wiring
2.5 Loop Detector Wiring
2.6 High Voltage Wiring and Battery Connection
SECTION 3 - ADJUSTMENTS 20
20
21
22
22
22-23
3.1 Circuit Board Adjustments
3.2 DIP-Switch Descriptions and Functions
3.3 Limit Sensor Adjustments
3.4 Reverse Sensor Adjustment
3.5 Shutdown Conditions
Soft Shutdown
Hard Shutdown
SECTION 4 - TECHNICAL INSTRUCTIONS 24
4.1 Maintenance Schedule
4.2 Troubleshooting
4.3 Diagnostics Check
4.4 Accessories
Wiring Schematics for Standard and Deluxe Control Boxes
24
24-25
26
26
27-28
TABLE OF CONTENTS

3
6003-065-G-6-08
UL325 Entrapment Protection
Class I
Class I and II
Class III
Class IV
Class II
Class III Class IV
A vehicular gate operator (or system) intended for use in a
home of one-to four single family dwelling, or a garage or
parking area associated therewith.
A vehicular gate operator (or system) intended for use in a
industrial location or building such as a factory or loading
dock area or other locations not intended to service the
general public.
A vehicular gate operator (or system) intended for use in a
guarded industrial location or building such as an airport
security area or other restricted access locations not
servicing the general public, in which unauthorized access
is prevented via supervision by security personnel.
This table illustrates the entrapment protection requirements for each of the four UL325 classes.
A- Inherent entrapment protection system.
B1 - Provision for connection of, or supplied with, a non-contact sensor (photoelectric sensor or the equivalent).
When used as the PRIMARY device, must be monitored.
B2 - Provision for connection of, or supplied with, a contact sensor (edge device or the equivalent).
When used as the PRIMARY device, must be monitored.
C- Inherent adjustable clutch or pressure relief device.
D- Provision for connection of, or supplied with, an actuating device requiring continuous pressure to maintain
opening or closing motion of the gate.
E- An inherent audio alarm.
UL325
Classifications
Horizontal Slide, Vertical Lift, Vertical Pivot Swing and Vertical Barrier (arm)
Primary Protection
AB1, B2 or D A, B1, B2, C or DA or C
A, B1 or B2 A, B1, B2, D or E A, B1, B2, C or DA, B1, B2 or C
A, B1, B2 or D A, B1, B2, D or E A, B1, B2, C, D or EA, B1, B2, C or D
Secondary Protection Primary Protection Secondary Protection
STATE PRISON
A vehicular gate operator (or system) intended for use in a
commercial location or building such as a multi-family
housing unit (five or more single family units) hotel,
garages, retail store or other building servicing the general
public.

46003-065-G-6-08
Gate Construction
Instructions regarding intended installation:
Vehicular gates should be constructed and installed in accordance with ASTM F2200; Standard Specification for Automated
Vehicular Gate Construction. For a copy of this standard, contact ASTM directly at 610-832-9585; [email protected]; or
www.astm.org.
Important Safety Instructions
WARNING - To reduce the risk of injury or death:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Never let children operate or play with gate controls. Keep the remote control away from children.
3. Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE.
4. Test the operator monthly. The gate MUST reverse on contact with a rigid object or stop or reverse when an object
activates the non-contact sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to adjust
and retest the gate operator properly can increase the risk of injury or death.
5. Use the emergency release only when the gate is not moving.
6. KEEP GATES PROPERLY MAINTAINED. Read the owner's manual. Have a qualified service person make repairs to gate
hardware.
7. The entrance is for vehicles only. Pedestrians must use separate entrance.
8. SAVE THESE INSTRUCTIONS!
•Install the gate operator only if:
1. The operator is appropriate for the construction of the gate and the usage class of the gate.
2. All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 4 feet
(1.22 m) above the ground to prevent a 2 ¼ inch (57.2 mm) diameter sphere from passing through the openings
anywhere in the gate, and in that portion of the adjacent fence that the gate covers in the open position.
3. All exposed pinch points are eliminated or guarded.
4. Guarding is supplied for exposed rollers.
•The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a separate
access opening. The pedestrian access opening shall be designed to promote pedestrian usage. Locate the gate such that
persons will not come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
•The gate must be installed in a location so that enough clearance is supplied between the gate and adjacent structures
when opening and closing to reduce the risk of entrapment. Swinging gates should not open into public access areas.
•The gate must be properly installed and work freely in both directions prior to the installation of the gate operator. Do not
over-tighten the operator clutch, pressure relief valve or reduce reversing sensitivity to compensate for a damaged gate.
•For gate operators utilizing Type D protection:
1. The gate operator controls must be placed so that the user has full view of the gate area when the gate is moving.
2. A warning placard shall be placed adjacent to the controls.
3. An automatic closing device (such as a timer, loop sensor, or similar device) shall not be employed.
4. No other activation device shall be connected.
•Controls intended for user activation must be located at least ten feet (10’) away from any moving part of the gate and
where the user is prevented from reaching over, under, around or through the gate to operate the controls. Outdoor or
easily accessible controls should have a security feature to prevent unauthorized use.
•The Stop and/or Reset button must be located in the line-of-sight of the gate. Activation of the reset control shall not
cause the operator to start.
•A minimum of two (2) WARNING SIGNS shall be installed, one on each side of the gate where easily visible.
•For gate operators utilizing a non-contact sensor:
1. See the instructions on the placement of non-contact sensors for each type of application.
2. Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle trips the sensor while the gate
is still moving in the opening direction.
3. One or more non-contact sensors shall be located where the risk of entrapment or obstruction exist, such as the
perimeter reachable by a moving gate or barrier.

5
6003-065-G-6-08
•For gate operators utilizing contact sensors:
1. One or more contact sensors shall be located where the risk of entrapment or obstruction exist, such as at the
leading edge, trailing edge, and post mounted both inside and outside of a vehicular horizontal slide gate.
2. One or more contact sensors shall be located at the bottom edge of a vehicular vertical lift gate.
3. One or more contact sensors shall be located at the pinch point of a vehicular vertical pivot gate.
4. A hardwired contact sensor shall be located and its wiring arranged so that the communication between the sensor
and the gate operator is not subjected to mechanical damage.
5. A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for
entrapment protection functions shall be located where the transmission of the signals are not obstructed or
impeded by building structures, natural landscaping or similar obstructions. A wireless contact sensor shall function
under the intended end-use conditions.
6. One or more contact sensors shall be located at the bottom edge of a vertical barrier (arm).
Vehicular gate operator products provide convenience and security. However, gate operators must use high levels of force
to move gates and most people underestimate the power of these systems and do not realize the potential hazards associ-
ated with an incorrectly designed or installed system. These hazards may include:
•Pinch points
•Entrapment areas
•Reach through hazards
•Absence of entrapment protection devices
•Improperly located access controls
•Absence of vehicle protection devices
•Absence of controlled pedestrian access
In addition to these potential hazards, automated vehicular gate systems must be installed in accordance with the UL-325
Safety Standard and the ASTM F2200 Construction Standard. Most lay persons are unaware of, or are not familiar with,
these standards. If an automated vehicular gate system is not properly designed, installed, used and maintained, serious
injuries or death can result. Be sure that the installer has instructed you on the proper operation of the gate and gate
operator system.
Be sure that the installer has trained you about the basic functions of the required reversing systems associated with your
gate operating system and how to test them. These include reversing loops, inherent reversing system, electric edges,
photoelectric cells, or other external devices.
•This Owner’s Manual is your property. Keep it in a safe place for future reference.
•Be sure that all access control devices are installed a minimum distance of 10 feet away from the gate and gate
operator, or in such a way that a person cannot touch the gate or gate operator while using the device. If access
control devices are installed in violation of these restrictions, immediately remove the gate operator from service
and contact your installing dealer.
•Loops and loop detectors, photo-cells or other equivalent devices must be installed to prevent the gate from
closing on vehicular traffic.
•The speed limit for vehicular traffic through the gate area is 5 MPH. Install speed bumps and signs to keep
vehicular traffic from speeding through the gate area. Failure to adhere to posted speed limits can result in
damage to the gate, gate operator, and to the vehicle.
•Be sure that all persons who will use the gate system are familiar with the proper use of the gate and gate
operator and are familiar with the possible hazards associated with the gate system.
•Be sure that warning signs are permanently installed on both sides of the gate in an area where they are fully
visible to traffic.
•It is your responsibility to periodically check all entrapment protection devices. If any of these devices are
observed to function improperly, remove the operator from service immediately and contact your installing or
servicing dealer.
•Follow the recommended maintenance schedule.
•Do not allow children to play in the area of the operator or to play with any gate-operating device.
•To remove the gate operator from service, operate the gate to the full open position and then shut off power to
the operator at the service panel.
Important Notices

66003-065-G-6-08
Swing Gate Requirements
The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a separate
access opening. The pedestrian access opening shall be designed to promote pedestrian usage. Locate the gate such that
persons will not come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
(ref. UL325 56.8.4.b)
If space is greater than 4 inches,
entrapment protection in this area
is required. ASTM F2200 7.1.1.1
and 7.1.1.2
If space is less than 16 inches,
entrapment protection in this area
is required. ASTM F2200 7.1.1.1
and 7.1.1.2
A
A
B
Not Allowed OK
A
B
Closed Gate
Closed Gates
With the hinge mounted on
the corner of the pilaster,
the entrapment area is
eliminated and protection is
not required for this area.
Gates shall have smooth bottom edges, with vertical bottom edged protrusions not exceeding 0.50 inches. ASTM F2200 4.3
Closed Gate
Opened Gate
Opened Gate

7
6003-065-G-6-08
Swing Gate Protection
Non-contact Sensor
Reverse Loop
Shadow Loop
Automatic Exit Loop
C
D
D
C
Minimizes the potential of the gate
closing when a vehicle is present.
Number and placement of loops is
dependent on the application.
Reverse Loop
Minimizes the potential of the gate
closing when a vehicle is present.
Number and placement of loops is
dependent on the application.
(Optional) will provide an open
command to the gate operator(s)
when a vehicle is exiting the
property.
Provides a hold open command to
the operator(s) only if the gate(s)
are at the full open position.
Separate Pedestrian
Walkway
Located so pedestrians
cannot come in contact
with the vehicular gate.
Minimizes the potential
of the gate closing on
vehicular or other traffic
that loops cannot sense.
Warning Signs
D
Permanently mounted
and easily visible from
either side of the gate.
Moving Gate Can Cause
Serious Injury or Death
KEEP CLEAR! Gate may move at any time
without prior warning.
Do not let children operate the gate or play
in the gate area.
This entrance is for vehicles only.
Pedestrians must use separate entrance.

86003-065-G-6-08
Glossary
GATE - A moving barrier such as a swinging, sliding, raising, lowering, or the like, barrier, that is a stand-alone passage
barrier or is that portion of a wall or fence system that controls entrance and/or egress by persons or vehicles and
completes the perimeter of a defined area.
RESIDENTIAL VEHICULAR GATE OPERATOR – CLASS I - A vehicular gate operator (or system) intended for use in a home
of one-to four single family dwelling, or garage or parking area associated therewith.
COMMERCIAL / GENERAL ACCESS VEHICULAR GATE OPERATOR - CLASS II - A vehicular gate operator (or system)
intended for use in a commercial location or building such as a multi-family housing unit (five or more single family units),
hotels, garages, retail store, or other building servicing the general public.
INDUSTRIAL / LIMITED ACCESS VEHICULAR GATE OPERATOR - CLASS III - A vehicular gate operator (or system)
intended for use in an industrial location or building such as a factory or loading dock area or other locations not intended
to service the general public.
RESTRICTED ACCESS VEHICULAR GATE OPERATOR - CLASS IV - A vehicular gate operator (or system) intended for use in
a guarded industrial location or building such as an airport security area or other restricted access locations not servicing
the general public, in which unauthorized access is prevented via supervision by security personnel.
VEHICULAR BARRIER (ARM) OPERATOR (OR SYSTEM) - An operator (or system) that controls a cantilever type device (or
system), consisting of a mechanical arm or barrier that moves in a vertical arc, intended for vehicular traffic flow at
entrances or exits to areas such as parking garages, lots or toll areas.
VEHICULAR HORIZONTAL SLIDE-GATE OPERATOR (OR SYSTEM) - A vehicular gate operator (or system) that controls a
gate which slides in a horizontal direction that is intended for use for vehicular entrance and exit to a drive, parking lot, or
the like.
VEHICULAR SWING-GATE OPERATOR (OR SYSTEM) - A vehicular gate operator (or system) that controls a gate which
moves in an arc in a horizontal plane that is intended for use for vehicular entrance and exit to a drive, parking lot, or the
like.
SYSTEM - In the context of these requirements, a system refers to a group of interacting devices intended to perform a
common function.
WIRED CONTROL - A control implemented in a form of fixed physical interconnections between the control, the associated
devices, and an operator to perform predetermined functions in response to input signals.
WIRELESS CONTROL - A control implemented in means other than fixed physical interconnections (such as radio waves or
infrared beams) between the control, the associated devices, and an operator to perform predetermined functions in
response to input signals.
INHERENT ENTRAPMENT PROTECTION SYSTEM - A system, examples being a motor current or speed sensing system,
which provides protection against entrapment upon sensing an object and is incorporated as a permanent and integral part
of the operator.
EXTERNAL ENTRAPMENT PROTECTION DEVICE - A device, examples being an edge sensor, a photoelectric sensor, or
similar entrapment protection device, which provides protection against entrapment when activated and is not incorporated
as a permanent part of an operator.
ENTRAPMENT - The condition when an object is caught or held in a position that increases the risk of injury.

9
6003-065-G-6-08
OPEN
CLOSE
Sample Installation
Dual Gate Operators
SECTION 1 - INSTALLATION
1.1 Manual Key Release
Prior to beginning the
installation of the swing gate
operator, we suggest that you become
familiar with the instructions, illustrations,
and wiring guide-lines in this manual. This will
help insure that your installation is performed in an
efficient and professional manner.
The proper installation of the vehicular swing gate operator is an
extremely important and integral part of the overall access control
system. Check all local building ordinances and building codes prior to
installing this operator. Be sure your installation is in compliance with local
codes.
Manually key release the actuator. Powered shaft can be
pulled out.
It is important to consider hinge placement on a
pilaster when installing the gate. Placing hinges
close to the edge of the pilaster can eliminate a
potential entrapment area (See Swing Gate
Requirements on page 6).
Powered Shaft

10 6003-065-G-6-08
1.2 Gate “Opens to the Outside” Bracket Locations
47.5” Open Position
7”
Addition to
support bracket
must be
fabricated to
reach wall.
Gate Hinge Pivot Point
Front Bracket
Pivot Point
Gate in Closed Position
Rear Bracket Pivot Point
Closed Position
Open Position
Actuator arm and brackets MUST be level!
A support bar must span
the entire length of the
gate to support the gate
pickets. The pickets will
bend if not supported.
Support Bar
90°
7”
Rear Bracket
Do not install the
actuator in fully
extended (Bottomed out)
position. This will
damage the arm. See
Section 1.4 to prevent
this from happening.
Lock Washers
(Not Supplied)
Front Bracket
Bolt to support bar.
Bolt support bracket to
fabricated steel plate
with supplied lock nuts.
A
ttaching Brackets
The brackets must be securely mounted and level.
Sleeve Anchors
(Not Supplied)
Support
Bracket
Fabricated
Reinforced
Steel Plates
(Not Supplied)
Front Bracket
A rear bracket will need to be fabricated.
The bracket will vary in size depending
on the gate hinge inset (see section
1.4). It can be attached to the wall by
welding or bolting, depending on the
type wall. The bracket MUST be level
and VERY secure to the wall. Extreme
force will be exerted on this bracket
during gate cycling.
Rear Bracket
Fabrication

11
6003-065-G-6-08
1.3 Gate “Opens to the Inside” Bracket Locations
47.5” Closed Position
7”
7”
90°
Gate Hinge Pivot Point
Front Bracket Pivot Point
Front Bracket
Rear Bracket Pivot Point
Attaching Brackets
Closed Position
Open Position
Actuator arm and brackets MUST be level!
A support bar must span
the entire length of the
gate to support the gate
pickets. The pickets will
bend if not supported.
Support Bar
Gate in Closed Position
Do not install the actuator in fully
extended (Bottomed out) position.
This will damage the arm. See
Section 1.4 to prevent this from
happening.
Lock Washers
(Not Supplied)
Front Bracket
Bolt to support bar.
The brackets must be securely mounted and level.
Angles will reduce operators
distance from wall. See next page.
Angled Configurations
Wall
2” 21/2”
51/2”
3”
Straight
Rear Bracket Options
Assemble straight out (shown)
or 3 different angles.
Sleeve Anchors
(Not Supplied)

12 6003-065-G-6-08
1.4 Mounting Actuator Arm
Gate must be in good working condition before the actuator arm can be installed. Determine what direction the actuator arm
will open the gate: “1.2 Gate Opens to the Outside” or “1.3 Gate Opens to the Inside”(See previous 2 pages).
If brackets are going to be welded to the gate and/or wall, only tack weld the brackets with the arm attached. Protect the arm
from welding sparks during tack welding. Remove arm before completely welding around the brackets. Make sure the
brackets are level when tack welding them! The arm will not operate properly if not level.
It is very important that the powered shaft is not fully extended when installed on the gate (bottoming out). This will damage the
arm. To prevent this, manually release the arm and fully extend the powered shaft. Rotate it back two full turns before
installing the arm.
This illustrates when the gate “Opens to the Inside” Only.
Front bracket and operator
always stay in a fixed location.
Rear bracket is adjusted for
gate hinge inset.
A support bar that spans the entire length of the gate must be installed to keep the pickets from bending. Do not mount the
front bracket directly to gate pickets!
Rear Bracket Configurations for Different Gate Hinge Insets
Welding Brackets to Surfaces
Gate Support Bar
Prevent Powered Shaft Bottoming Out
Rotate back 2 turns before installing.
Manual Release
Fully Extended (Bottomed Out)
40.5” Fixed Distance
47.5”
OPEN
CLOSE
Powered Shaft
2”
21/2”
51/2”
Thin Wall
Thick Wall
Large Gate Hinge Inset
Medium Gate Hinge Inset
Small Gate Hinge Inset
No Gate Hinge Inset
Gate Hinge Pivot Point
Gate HingeClosed Gate Position
3”
7”
7”
7”
7” Fixed Distance
between gate hinge
pivot point and arm’s
rear pivot point.

13
Install Warning Signs
1.5 Mounting Control Box with Conduit
This DoorKing Swing Gate Operator is shipped with two warning
signs. The purpose of the warning sign is to alert uninformed
persons, and to remind persons familiar with the gate system, that
a possible hazard exists so that appropriate action can be taken to
avoid the hazard or to reduce exposure to the hazard.
•Permanently install the supplied warning signs in locations so
that the signs are visible by persons on both sides of the gate.
•Use appropriate hardware such as wood or sheet metal screws
(not supplied) to install the warning signs.
Position the control box on the wall, close enough to the actuator arm so the primary actuator cable can be easily routed inside
the box. Secure the control box to the wall with appropriate hardware (not included). Control box has predrilled mounting holes.
All power and control wires should be routed to control box in conduits with sweeps. Never run high voltage and low voltage
wires in the same conduit, keep them in separate conduits.
Permanent wiring must be installed to the operator as required by local electrical codes. It is recommended that a licensed
electrical contractor perform this work. Check local building codes prior to installing any permanent wiring to ensure all wiring
and connections comply with local electrical code requirements.
Coaxial Cable Antenna Kit
(Sold separately)
Primary
Actuator
Cable
Secondary Actuator Cable Conduit
Control Box must be
properly grounded.
Power Conduit Loops Conduit
•Use only sweeps for conduit bends. Do not use 90° elbow connectors as this will make wire pulls very difficult and
can cause damage to wire insulation.
6003-065-G-6-08

14 6003-065-G-6-08
2.1 Wiring Actuator Arm(s)
SECTION 2 - WIRING
Before attempting to connect any wiring to the control box, be sure that the circuit breaker in the electrical panel is in the OFF
position. Permanent wiring must be installed to the control box as required by local electrical codes. It is recommended that a
licensed electrical contractor perform this work.
Since building codes vary from city to city, we highly recommend that you check with your local building department prior
to installing any permanent wiring to be sure that all wiring to the control box (both high and low voltage) complies with
local code requirements.
THIS GATE OPERATOR MUST BE PROPERLY GROUNDED!!
Primary
Actuator
Cable
Secondary
Actuator
Cable
1
7
6
5
4
3
2
123456789 10 11 12 13 14 15 16 17 18 19 20
Brown
Blue
Orange
Red
Yellow
Green
Green/White
Not Used
Secondary Actuator Cable (Interconnection cable)
Primary or Secondary Cable Connection
Primary Actuator Cable
1
7
8
6
5
4
3
2
DoorKing interconnection cable (P/N 2600-75x) inside underground conduit (Not supplied)
1
7
6
5
4
3
2

15
123456789 10 11 12 13 14 15 16 17 18 19 20
2.2 Secondary Entrapment Protection Wiring
In addition to the inherent reversing sensor system, this operator has provisions for the connection of a non-contact (type B1)
secondary entrapment protection device.
Entrapment protection devices are required to reduce the risk of injury. Install sensors where the risk of entrapment or obstruc-
tion exists while gate is moving.
Safety Protection
Closed Gates
Entrapment Protection
Entrapment Protection
Photo Cells
PHOTO OPEN (Photo Cell)
Stops gate movement in the open cycle. Gate resumes
normal operation when the input (obstruction) is
cleared.
PHOTO CLOSE (Photo Cell)
Stops the gate in the closing cycle. Gate resumes
closing when the input (obstruction) is cleared.
Not used
Not used
COMMON
Terminal for the secondary entrapment device input.
COMMON
1
1
2
3
4
5
6
1
ON
2 3 4 56 7 8
SW 1
Switch 5 OFF
N.O.
Com
N.O. Com
Safety Photo Cell
DIP-Switch Setting
6003-065-G-6-08

16 6003-065-G-6-08
123456789 10 11 12 13 14 15 16 17 18 19 20
2.3 Main Terminal Description
24 VAC INPUT 24 VAC INPUT 24V COMMON ALARM RESET Not Used 12 VOLT BATTERY Not Used DC LOCK POWER COMMON 24 VDC Maglock POWER DRY RELAY CONTACT DRY RELAY CONTACT 24V COMMON REVERSE INPUT/SHADOW INPUT 24V COMMON OPEN INPUT 24V COMMON SINGLE BUTTON ACTIVATION INPUT/ EXIT LOOP LOGIG OUTPUT 24V DC RADIO POWER ONLY 250 ma. maximum RADIO RELAY - SINGLE BUTTON ACTIVATION INPUT 24V COMMON
Operation of relay is dependent on setting of
SW 2, switches 1 and 2. Relay contacts can
be set for Normally Open (NO) or Normally
Closed (NC) operation. Contact rating is
1 amp maximum at 24 Volts.
1
ON
23 4
SW 2
•Switch 1 OFF, Switch 2 OFF:
Relay activates when gate is OPEN.
•Switch 1 OFF, Switch 2 ON:
Relay activates when gate is OPEN,
OPENING or CLOSING.
•Switch 1 ON, Switch 2 OFF:
Relay activates when gate is OPEN or OPENING.
•Switch 1 ON, Switch 2 ON:
Relay activates when gate is OPENING or CLOSING.
NO NC
1
ON
234
SW 2
Maglock:
Switch 3 ON,
1 sec. delay
at start.
1
ON
2 3 45 6 7 8
SW 1
•When gate is closed, input will open gate.
•When gate is open and auto close
timer SW 1, switch 4 is turned ON,
input will re-set and hold timer.
•When gate is open and auto close
timer SW 1, switch 4 is turned OFF,
input will close gate.
•When gate is closing, input will
reverse gate.
•lf SW 1, switch 3 is ON,
this input is identical to
Single Button Activation.
•lf SW 1, switch 3 is OFF,
this terminal becomes the
logic output of the EXIT loop
detector.
1
ON
234 5 6 7 8
SW 1
•When gate is closed, this input has no
affect on the gate operator.
•When gate is open and auto close
timer SW 1, switch 4 is turned ON,
input will re-set and hold timer.
•When gate is open and auto close
timer SW 1, switch 4 is turned OFF,
input will prevent gate from closing.
•When gate is closing, input will
reverse gate if SW 1, switch 5 is OFF.
•When gate is closing, input has no
affect on the gate operator if SW 1,
switch 5 is ON (set for shadow input).
1
ON
2 3 45 6 7 8
SW 1
1
ON
2 3 4 56 7 8
SW 1
4
8
2
15
12
10
11
DC power is not present on the board
until first initial cycle of gate.

17
6003-065-G-6-08
Key Switch
(Dry contact)
123456789 10 11 12 13 14 15 16 17 18 19 20
2.4 Main Terminal Wiring
1
ON
234
SW 2
Switch 3 ON
Controls must be far enough from the gate so that the user is prevented from coming in contact with the gate while operating
the controls. Outdoor or easily accessible controls should have a security feature to prevent unauthorized use. When installing
electrical equipment make certain all wiring complies with local code requirements. Do not power any control devices from the
circuit board other than low voltage devices.
Connect optional
control devices to
the main terminal
strip. Use 18 AWG
wire for all low
voltage wiring,
maximum distance
3000 feet. Use a
low voltage surge
suppressor,
(DoorKing P/N
1878-010) if low
voltage wire runs
exceed 1000 feet.
All inputs to the
terminal strip must
be NORMALLY
OPEN.
1. Com
Com
N.C.
3. 24 Volt
2. Relay
Magnetic Lock
3-Wire Receiver
Mount inside of control box door.
Reversing input
on Terminal 8
only functions
while the gate
is at the full
open position
or during the
closing cycle. It
should not be
used as an
input for a
secondary
entrapment
protection
device during
the opening
gate cycle.
Refer to
Section 2.2
Secondary
Entrapment
Protection
Wiring.
Knox Box
(Dry contact)
1
ON
234 5 6 7 8
SW 1
Switch 3 ON
1
ON
234 5 6 7 8
SW 1
Switch 3 ON
Telephone
Entry
Note: Telephone entry device
must use a separate power
source.
Note: Circuit board
provides 24 VDC to
power maglock.

18 6003-065-G-6-08
Reverse
Reverse
Shadow
Automatic Exit
2.5 Loop Detector Wiring
To protect the operator from accidentally closing on vehicles in the gate’s path, a series of loop detectors must be installed.
Loops are laid underneath, cut into asphalt or concrete driveways or buried beneath gravel and earth driveways. A loop detec-
tion system will sense a vehicle like a metal detector and send a signal to the gate operator preventing the gate from automati-
cally closing on a vehicle when it is in the gate’s swing path. Refer to the separate loop and loop detectors information manual
(Loop Info G-3-02) for further information. DoorKing recommends that a licensed installer perform this work.
Loop detector wiring is
shown for DoorKing
plug-in loop detectors
P/N 9409-010 and P/N
9410-010 only. If other
loop detectors are used,
refer to the installation
instructions supplied
with those detectors for
wiring instructions.
Automatic Exit Loop
Automatically opens the gate for exiting vehicles
without having to use a transmitter or keypad.
The exit loop can be placed 20-100 feet away
from the gate so that the gate is open or partially
open as you drive up to it.
Reverse Loops
Reverse loops are placed just outside the
gate’s swinging path to prevent the gate from
closing on a vehicle in these areas. They will
stop or reverse the cycling of the gate while a
vehicle is in or near the gate’s swing pathway.
Reverse loops are wired in series.
Shadow Loop
The shadow loop is placed inside the gate’s swinging
path to prevent the gate from closing on a vehicle in
this area. It is only active when the gate is in the full
open position. Vehicles in the shadow area will activate
it. It will not allow the gate to close unless this area is
clear. After a closing cycle begins, the shadow loop will
not reverse the gate. Reverse loops work in conjunction
with the shadow loop and both should be used.
123456789 10 11 12 13 14 15 16 17 18 19 20
9410 9409
Com
N.O.
1
ON
23 4
SW 2
1
ON
2 3 4 56 7 8
SW 1
SW 1, switch 5
is OFF.
SW 2, switch 1
is ON and
switch 2 is OFF.
Shadow Loop Output
Shadow Loop
DIP-Switch Settings
