DOD S1+ Mounting instructions

ﻴﺔﺑﺮﻌﻟﺍ

1
S1+ Use Manual
Table of Contents
Preface·············································································································04
General············································································································05
Product Features····························································································06
Product Structure·························································································· 08
Use and Installation······················································································· 09
Operating Instruction····················································································10
Files Saving and Videos Playing··································································· 13
Button Function····························································································· 14
Menu Setup·····································································································15
Specifications··································································································16
Package Accessories·······················································································17
Easy Troubleshooting·····················································································17
Installation Instruction for Bracket····························································· 18

2
Инструкция по эксплуатации S1+
Содержание
Предисловие··································································································19
Общее изложение о продуктах···································································20
Особенности продукта·················································································21
Структура продукта···················································································· 23
Применение и монтаж·················································································24
Справочник по эксплуатации····································································25
Сохранение документа и передача видеочастоты································· 30
Функции кнопок·························································································· 31
Настройка меню···························································································32
Спецификация продукта············································································ 34
Упаковочные аксессуары··········································································· 35
Решение простой проблемы·······································································36
Объяснение о монтаже опоры····································································37

3
+ نو سا ماﺪﺨﺘﺳا ﻞﯿﻟد
سﺮﮭﻔﻟا
38··································································································· ﺔﻣﺪﻘﻤﻟا
39······························································································ ﺔﻣﺎﻋ ةﺮﻈﻧ
40··························································································ﺞﺘﻨﻤﻟا تاﺰﯿﻤﻣ
42····························································································· ﺞﺘﻨﻤﻟا ﻞﻜﯿھ
43··················································································· ﺐﯿﻛﺮﺘﻟاو ماﺪﺨﺘﺳﻷا
44························································································ﻞﯿﻐﺸﺘﻟا تﺎﻤﯿﻠﻌﺗ
47··································································تﺎھﻮﯾﺪﻔﻟا ﻞﯿﻐﺸﺗ و تﺎﻔﻠﻤﻟا ﻆﻔﺣ
48··························································································زارزﻻا ﻒﺋﺎﻇو
49·····························································································ﺔﻤﺋﺎﻘﻟا ﻂﺒﺿ
50 .........................................................................................تﺎﻔﺻاﻮﻤﻟا
51···················································································تاراﻮﺴﺴﻛﻹا ﺔﻣﺰﺣ
51······························································· ﺎﮭﺣﻼﺻاو ءﺎﻄﺧﻷا فﺎﺸﺘﻛا ﺔﻟﻮﮭﺳ
52·················································································ﻞﻣﺎﺤﻟا ﺖﯿﺒﺜﺗ تﺎﻤﯿﻠﻌﺗ

4
Preface
Thank you for purchasing the DOD series products, this S1+ product can capture the moving
photos efficiently. It has a high definition lens with one million pixels, which is uniquely
lens of 180° overturn. The product is designed for safety recording of car driving process and
can also be used as a DV for video recording/taking photos. It is exquisite in appearance and
has won many patents and certifications, in a word, S1+ will make your life more wonderful.
This manual will teach you how to use the product and give you more detailed information,
including the use, operation and installation precautions and technical specifications, etc.
Before the use, please read it carefully and keep it properly. We hope that the product can
meet your demand and serve you permanently.

5
General
This product is a high-definition driving recorder to cater to the market demand. It has leading
functions such as high-definition video recording/photos taking, hi-speed USB data
transmission, USB charging and car charging.
Widely Used, Convenient for Video Recording at any time any where

6
Product Features
lens rotation design with multi-functions, easy for high-definition video recording/photo
taking at anywhere, capture high-resolution photo at will.
Lens: 100° wide-angle lens
Exposure Compensation: EV(-2.0/+2 adjustable)
Screen: 2.5 inch high-definition TFT LCD
4X digital zoom
Infrared rays
In-built microphone/loudspeaker
High-capacity rechargeable lithium battery
Support high-capacity SD (SDHC) memory card
Cycle video recording
Motion detection
Seamless connection
Outage auto-save
Recording time can be set
Video recording is realizable while charging
Auto power on to make records when starting car
Manual emergency lock (SOS)
G-SENSOR gravity file protection

7
Capacity Display
The number of videos or photos vary with different setting of host machine, brand of
memory card, file size etc.
1G 2G 4G 8G
1440*1080(FPS15) 17min 34min 69min 139min
1280*720(FPS30) 16min 32min 65min 130min
848*480(FPS60) 18min 36min 73min 146min
10M 287photos 574photos 1148photos 2296photos
8M 354photos 708photos 1416photos 2832photos
5M 572photos 1144photos 2288photos 4576photos
3M 1003photos 2006photos 4012photos 8024photos

8
Product Structure

9
Use and Installation
Install and Take out Battery
1. Slide battery cover downward to open it.
2. Put battery into battery case based on plus-minus marks on it until it is installed in position.
3. Battery power symbols are shown as below:
4. Push open the battery cover and take it out.
Install and Take out Memory Card
1. Insert memory card into the slot as instructed until it is fixed in the slot.
2. When taking memory card out, press it down gently and take it out after the card pops up.
Attentions:
1. Insert in the SD memory card before use.
2. Before use, check if the write-protect switch on the card is on or off.
3. Please pay attention to the direction of card, if it is inserted reversely, the machine and
card might be damaged.
4. If the memory card is incompatible with the machine, please insert it again or retry
with another card.

10
Operating Instruction
Set Menu Mode
1. In photo taking/video/replay mode, press “MENU” to set relevant menus, please refer to the
“Set Menu” for details.
2. In “Set Menu” in any mode, press OK to get into the next menu, press Up and Down to
select relevant settings, and then press OK to confirm and then press MENU to exit.
Turn on/off and Auto-off Settings of Camera
1. Press on Power button for about 1s to turn on the camera, when it is on, press on the Power
button for 3s and then release it to turn it off.
2. To save battery power, you can set auto-off time in the menu. When no operation happens
within the setting time, it will shut down automatically.
3. Turn the power on, press MENU button twice to switch to Setup Menu, and then press
Down to select “Auto-off” and then press OK to get into the next menu. The auto-off time can
be set as “OFF, 2Min, 5Min and 10Min”.
Set Date and Time
Turn the power on, press MENU button twice and switch to the Setup Menu, then press Down
to select “Date/Time” and then press OK to enter into Year, Month, Day, Hour, Minute and
Second, then press Up, Down, Left and Right to select the item to be set and then press OK.
When the item turns red, press Up or Down to make adjustment, after that, press OK to exit,
and then press Down to move to “√” and then press OK.

11
Video Mode
1. Turn the power on, the camera is then started. The Camera mode appears on the screen,
then the symbol “ ” appears at the top right corner, and the screen shows video information
and time displays at the bottom right corner. If the “ ” twinkles on the screen, it means it has
already got into the auto-recording mode.
2. Press “REC” button to start video recording and press it again to stop.
While video recording, red “ ” and timer will appear at the bottom of screen, and they will
disappear once it stops.
3. Infrared rays
When you take videos with your hand, you can press “Right” arrow key to open or close
infrared rays. If open infrared rays in nonluminous condition, you can see photos through
screen that cannot be seen due to darkness.
Photo Mode
Turn the power on, the camera is then started. Press “MODE” button in video mode, then the
symbol “ ” will appear at the top left corner, which means it has already got into photo
mode.
1. Aim the lens at the subjects and press Up or Down button to realize digital zoom, at this
time, hold on the camera tightly and do not shake it.
2. Press “REC” button, the camera give a crack sound, and then the photo is taken.
Shooting Method
Select “MENU” button in photo mode, then press “Down” to select “Shooting Method”, and
then press OK to select the “Continuous Shooting, Single Shot, 2s, 5s and 10s” for self-timer.
Notes：
1. Press “MODE” in Video or Photo mode can switch to the other mode.
2. Press “MODE” Video or Photo mode can enter replay mode.

12
Replay Mode
1. Press “MODE” Photo or Video mode can replay photos or videos, and then select the
photo or video with Left or Right button. When browsing the photos, press REC button to
play or stop, and press “Preview” button to pause.
2. Delete
When replaying photos or videos, press “MENU” button to select the current file mode, and
then press OK to delete the current video or photo. Select all files and press OK to confirm,
and then press OK again to delete all files.
Set Motion Detection
When the Motion Detection Function is open, the relative displacement in photos will be
detected automatically, if the object moves out of the default displacement, the record is
started automatically. Each time, the record lasts for 15s, after that, the machine will continue
detecting.
When the power is on, press “MENU” button to select detected item, and then press Up or
Down to select ON/OFF, and then press OK to save or exit.
Set G-SENSOR Function
After starting of gravity sensing function, in case of vehicle collision or impact during video
recording, it will lock and save current video automatically and set to avoid the previous video
and following video files of loop recording cycle from being covered by the loop recording
lock of the machine in order to guarantee safety of important video.
In the “ON” status, press MENU key to enter the option of gravity sensing strength. Press up
or down key to select sensitivity. Press OK key to save the option and exit.

13
Set SOS Emergency Lock File
When the SOS emergency lock file is started, you can save any photo segment at will during
the recording without being covered.
In the video mode, long press OK button, then “ ” appears and the current video is saved,
but the video will disappear automatically when next video starts.
Charging-Recording Mode
when the power is off, connect the car charger power to the machine. Once the car is started, it
will turn on automatically and starts recording, meanwhile, the battery will be charged.
Attention: when the car stops, it will use battery power until auto power-off.
Files Saving and Videos Playing
USB Backup Mode
When the power is on, connect the machine to computer with USB cable, if disc drive and IP
camera appear on the screen, then it is in USB mode. Open “My Computer” on the desktop
and find the saved files in “DCIM\********”.
Connect to TV and Play Videos
1. Connect camera to TV with TV connecting line to browse or play Videos/Photos.
Note: without the need to install driver, the portable disk can only be used when the
camera is on.

14
Button Function
Video/Photo Mode ·
Power On/Off
Shutter Record/Stop Recording/Photo Taking
Arrow Key (Up) Select Up to zoom in
Arrow Key (Down) Select Down to zoom out
Arrow Key (Left) Adjust EV value
Arrow Key (Right) Open/Close infrared rays
OK Confirm（SOS button）
Menu Menu
Mode Mode selection/browse photos and videos
Replay Mode ·
Power Off
Arrow Key (Left) Last/fast backward
Arrow Key (Right) Next/fast forward
Menu Menu selection
OK Confirm/replay: start/pause
Mode Back to video/photo/pause play

15
Menu Setup
Mode
Menu
Menu Setup
Note
Video
Recordi
ng
Resolution
1080I/720P/QVGA
Cycle recording
OFF/2 min/5 min
Motion detection
ON/OFF
Audio
ON/OFF
G-sensor
OFF/High/ Medium/Low
Audio
ON/OFF
Date record
ON/OFF
Camera
Shooting method
Continuous shooting/single shot/2s/5s/10s
Resolution
10M/8M/7MHD/5M/3M/2MHD
Image quality
Best/good/ordinary
Sharpness
Strong/ordinary/soft
White balance
Auto/sunlight/cloudy/bulb/daylight lamp
Special effect
Color/black & white/nostalgic
Exposure
compensation
+2.0、+5/3、+4/3、+1.0、+2/3、+1/3+0.0、-1/3、
-2.3、-1.0、-4/3、-5/3、-2.0
ISO
Auto/100/200/400
Face detection
Off/Face detection
Anti-shake
ON/OFF
Quick view
Off/2s/5s
Date record
Off/Date/Date, time
Replay
Delete
Current file/all files
Formatting
Built-in RAM/Memory card
Setting
Frequency
50HZ/60HZ
Screen protection
Off/2 min/5min/10 min/
Tone
√/×
Auto-off
OFF/2 min/5 min/10 min
TV output
NTSC/PAL
Default
√/×
Language
Multinational language
Version
S12012*****
Date/time
Year, month, day/hour, minute, second

16
Specifications
Sensor 1 Mage pixels CMOS
Lens 3.5mm
Focal range 10cm -Infinity
LCD screen 2.5" TFT LCD
Video output TV synthetic symbol: NTSC/PAL
Photo format Photo format: JPEG
Maximum output: 10M(3648 x 2736)
Video format H.264
Video signal
1440*1080(15/s)
1280*720（30/s）
848*480（60/s）
Zoom 4x digital zoom
Video medium SD card（maximum 32G）
Audio Built-in microphone/loudspeaker(Mono)
Shutter Electronic shutter
Shutter speed 1/2-1/1000s
White balance Auto/sunlight/cloudy/CFL/Tungsten lamp
LED On/Off
Connector USB2.0/HDMI/TV
Battery External lithium battery, 3.7V 800mAh
USB USB2.0 hi-speed transmission
Size Length 111×Width 59× Thickness 29mm
Work temperature/humidity -10℃-60℃/10%-80%

17
Package Accessories
Warm Tips: to avoid any loss, please check the accessories when purchasing this product.
1. Vehicle Power Cable ×1
2. Bracket ×1
3. AV Video Cable ×1
4. USB Cable ×1
5. Lithium battery ×1
6. User Manual ×1
Easy Troubleshooting
No function of photographing or video recording?
Please change the resolution of photographing or video recording or replace a memory card
with sufficient space, and check whether the memory card is locked or not.
Photo or video not clear?
Please use it after wipe clean the lens, or check whether the far-near focus setting correct or not.
Operation Tips
The camera is similar to the computer, in case of any malfunction, please follow the
following steps:
1. Take out battery, re-load it and then restart camera.
2. If camera goes wrong, please press RESET button to restart it.
3. Please use RESET button with caution, otherwise, data might disappear.

18
Installation Instruction for Bracket
Installation Steps:
After assembling the bracket to the machine, knock the host machine to engage it with
the bracket.

19
Предисловие
Благодарим вас за закупку продуктов серии DOD, данный продукт S1+ может схватить
высокоскоростные передвижные изображения, обладает объективом высокого качества
изображения пикселом в 1 миллион, имеет своеобразную функцию по вращению экрана
270 градусов и переворачиванию объектива 180 градусов. Данный продукт применяется
в безопасном записывании автомобильного ходового процесса, тоже может снимать
видеочастоты DV / фотографии. Внешний вид данного продукта отборный, получил
разные патенты и удостоверения, S1+ приносит вашей жизни больше интересов.
Данная инструкция по эксплуатации говорится о том, что как используют данный
продукт, одновременно предоставляет тебе подробные информации, включает в себя
особые указания по эксплуатации, операции и монтажу, технические спецификации и
так далее, до эксплуатации серьёзно читайте и правильно сохраняйте данную
инструкцию, мы надеемся на то, что данный продукт может удовлетворять вашей
потребностью и долго служить вам!
