Dolomite Legacy User manual

DOLOMITE LEGACY, OPAL 2000, MAXI
OPERATING INSTRUCTIONS
Study the operating instructions carefully before use.
The walker is suitable for use both indoors and outdoors.
*TESTED BY THE CENTRE FOR INDUSTRIAL RESEARCH (SINTEF), NORWAY
Do not use as a wheel-
chair or transport chair.
GB OPERATING INSTRUCTIONS

2
DOLOMITE LEGACY, OPAL 2000, MAXI
SAFETY
- Do not use as a wheelchair or transport chair.
- Do not under any circumstances stand on
the walker.
- Use seat for stationary seating only. Never
sit and push with your feet.
- Do not go up or down stairs or use on escalator.
- Both brakes must be in the parking position
when the walker is used as a seat.
- The walker must be fully unfolded when
used as walking support. N.B. The walker
may only be used as a walking support.
- Be extra careful when using the walker on
a sloping surface.
- Be extra careful when carrying heavy loads
in the basket. Loads may only be carried
in the basket or on the tray. Max load on
tray 11 lbs. (5 kg).
AB
21
C
ABC
FOLDING
A) DOLOMITE LEGACY
To fold, lift up handle.
B) DOLOMITE OPAL 2000, MAXI
1. Lift up the safety latch.
2. Lift the handle to fold the walker.
C) When folded the walker is easy to lift and
carry.
OPERATING POSITION
To reset to walking position, press firmly down-
wards on the seat until a clicking sound is
heard.
ACCESSORIES
A) Mounting of basket.
B) Secure the tray using the plastic plugs.
C) Cerb climber
FOLDING SEAT
The seat can be folded up to provide a larger
walking space, and in order to increase
accessibility.

3
DOLOMITE LEGACY, OPAL 2000, MAXI
BRAKES
Apply the brakes by pulling both brake-
handles upwards.
PARKING BRAKE
Press down carefully for parking brake. A
clear sound is heard when the brake is placed
in correct position. N.b. Always place both
brakes in parking position. Pull upwards to
loosen the brake.
Both brakes must be in the parking position
when the walker is used as a seat.
ADJUSTMENT OF BRAKE
EFFECT
For desirable braking strength, adjust the
brake wire.
Suitable tools 1x8 mm and 1x10 mm spanner
(not included).
HANDLEBARS
To adjust the handle to a suitable height,
stand behind the walker with shoulders level.
The handles should be at the same height as
the user’s wrist. A therapist may suggest dif-
ferent handle heights to accomodate the spe-
cial needs of a user.
DOLOMITE LEGACY, OPAL 2000
For adjustment of handles with holes:
Loosen the knob completely, remove the
screw. Adjust the handle to suitable height.
Fix the screw into the hexagonal hole and
fasten the knob properly.
DOLOMITE MAXI
For steples adjustment:
Loosen the wring, adjust the handle to sui-
table height and tighten the wring properly.

82038 04-05:1
DOLOMITE AB, Box 55, SE-334 21 ANDERSTORP, SWEDEN
TEL [phone], FAX [phone]
E-mail: [email protected], www.dolomite.se
MAINTENANCE – SAFETY
To ensure good performance and safety you should regularly check that the following is carried out:
• Clean the rollator with solvent-free household cleaner. Keep the wheels clean.
• Ensure that screws and adjustments are properly tightened.
• Immediately contact the nearest dealer if a fault should appear. Never use a defective
walker. Do not attempt repairs yourself!
N.B. Your walker should only be used as a walking aid! User’s max. weight: DOLOMITE
LEGACY, OPAL 2000 275 lbs. (125 kg, 20 stones). DOLOMITE MAXI 352 lbs. (160 kg, 25
stones) DOLOMITE HCP/DOLOMITE will not accept responsibility for adaptations, faulty
repairs etc that are outside their control.
INSTRUCTIONS FOR DESTRUCTION OF PRODUCT AND PACKAGING:
When the product can no longer be used, it and its accessories, together with packaging
material, should be sorted properly. The individual parts can be separated and handled accor-
ding to the materials description.
The label on the DOLOMITE LEGACY,OPAL 2000
and MAXI provides all important technical infor-
mation.
1: Article number
2: Product name
3: Serial number
4: Date of manufacture
5: Maximum user weight
6: NB: read the operating instructions
7: Manufacturer's contact information.
1
26
4357
