Dometic PERFECTWALL PW3800 Instruction Manual

1
4.0m
4.5m
5.0m
5.5m
6.0m
1315
1490
1640
1705
1880
1315
1490
1640
1705
1880
40
40
40
200
200
40
40
40
200
200
1200
1350
1550
1600
1750
1.
2.
32
4 5 6 7 8
9 10 11 12 13
14 15 16
17
1
19
2.
1.
18





15 – 20 Nm
1
2
5
6
3
4
8
9
7
0
ab
PW3800
leaflet_figures.fm Seite 1 Montag, 7. Mai 2018 3:58 15

2
Dometic WAECO International GmbH
Hollefeldstrasse 63
D-48282 Emsdetten
dometic.com
AB
og
rd
bk
rd
bk
bu
T15A
bn
T3A
D+
bu
bn
bu
bn
2
43
5
6
7
8
810 11
1
+12 Vg
2
1.
2.
Ø3 mm
Ø 3 mm
1
2
3
1
1
1
2
3
f
e
cd g
hi
4445102497 0700298 03/2018
leaflet_figures.fm Seite 2 Montag, 7. Mai 2018 3:58 15

PW3800
Awning
Installation Manual. . . . . . . . . . . . . . . . . . . . . 3
Markise
Montageanleitung. . . . . . . . . . . . . . . . . . . . 14
Store extérieuru
Instructions de montage . . . . . . . . . . . . . . .25
Told o
Instrucciones de montaje . . . . . . . . . . . . . .36
Told o
Instruções de montagem . . . . . . . . . . . . . .47
Tend a da so le
Indicazioni di montaggio . . . . . . . . . . . . . .58
Zonnescherm
Montagehandleiding . . . . . . . . . . . . . . . . .69
Markise
Monteringsvejledning. . . . . . . . . . . . . . . . .80
Markis
Monteringsanvisning. . . . . . . . . . . . . . . . . . 91
Markise
Monteringsanvisning. . . . . . . . . . . . . . . . . 101
Markiisi
Asennusohje . . . . . . . . . . . . . . . . . . . . . . . .111
Синусоидальный инвертор
Инструкция по монтажу. . . . . . . . . . . . . . 121
Markiza
Instrukcja montażu . . . . . . . . . . . . . . . . . . 132
Markýza
Návod k montáži . . . . . . . . . . . . . . . . . . . . 143
Markiza
Navodilo za montažo . . . . . . . . . . . . . . . . 153
ȉȑȞIJĮ
ȅįȘȖȓİȢ IJȠʌȠșȑIJȘıȘȢ. . . . . . . . . . . . . . 163
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
CS
SL
EL
AWNINGS
PERFECTWALL
PW3800-I-16s.book Seite 1 Donnerstag, 12. April 2018 3:24 15

PW3800-I-16s.book Seite 2 Donnerstag, 12. April 2018 3:24 15

EN
PW3800 Explanation of symbols
3
!
Table of contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2 Important safety and installation instructions. . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
6 Installing the awning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
7 Connecting the awning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
1 Explanation of symbols
!
A
I
WARNING!
•This instruction manual must be read and understood before
installation, set up, operation and servicing. This device must be
installed by a specialist. Improper installation can lead to serious
injury. Alterations to the device can be extremely dangerous and
lead to serious injury or damage to the device.
•Keep this operating manual with the device. The owner must read it
carefully.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
PW3800-I-16s.book Seite 3 Donnerstag, 12. April 2018 3:24 15

EN
Important safety and installation instructions PW3800
4
2 Important safety and installation
instructions
Please observe the safety instructions and stipulations issued by the
vehicle manufacturer and service workshops.
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
!WARNING!
•If you do not have sufficient technical knowledge for installing
components in vehicles, you should have a specialist fit the awning to
your vehicle.
3Scopeofdelivery
No. in
fig. 1,
page 1
Awning width
Description
4 m, 4.5 m,
5 m, 5.5 m, 6 m
1 1x Awning
2 2x Mounting plate (400 mm)
3 2x Mounting plate (160 mm)
4 12x Counter plate
5 12x Square-head bolt
6 6x Countersunk bolt
7 18x Serrated lock washer
8 18x Hexagon nut
9 12x Cover for the counter plate
10 18x Self-tapping screw
11 2x Mounting bracket (lower section)
12 2x Mounting bracket (upper section)
PW3800-I-16s.book Seite 4 Donnerstag, 12. April 2018 3:24 15

EN
PW3800 Accessories
5
4Accessories
Available as accessories (not included in the scope of delivery):
If you have questions regarding the accessories, please contact your local service
partner.
13 1x Crank bracket (lower section)
14 1x Crank bracket (upper section)
15 4x Rivets
16 4x Pegs
17 1x Crank (only awnings without motor)
Emergency crank (only awnings with motor)
18 1x Receiver with connection material
19 1x Remote control with holder
Description
TieDown Kit
Straps for anchoring the awning
Dometic Light LK120
LED light kit with remote control for installation on the awning arms
LED LightStrip
LED strip available in different lengths for installation on the underside of the awning
LED Profile
LED lighting available in different lengths for installation on the underside of wall-mounted
awnings
Awning cleaner
Special awning cleaner
Repair Kit
Awning repair patch
Wall switch
No. in
fig. 1,
page 1
Awning width
Description
4 m, 4.5 m,
5 m, 5.5 m, 6 m
PW3800-I-16s.book Seite 5 Donnerstag, 12. April 2018 3:24 15

EN
Intended use PW3800
6
5 Intended use
The PerfectWall PW3800 awning is suitable for installing on motorhomes or
caravans.
The awning must only be used whilst the vehicle is stationary. Please observe the
operating manual.
6 Installing the awning
6.1 Required installation material
For the installation of the awning, you will need:
•Various tools, e.g. screwdriver
•A suitable flexible adhesive/sealant, e.g. Sikaflex®-252
•A cleaning agent that is recommended for use with the adhesive
•A primer that is recommended for use with the adhesive
•Acid-free silicone
6.2 Notes on the installation position
When choosing the installation location, observe the following:
!WARNING!
•Keep a sufficient distance from objects or other vehicles. Once it is
retracted, it should be at least 40 cm away from other objects and
vehicles.
•Ensure the wall of the motorhome can safely take the weight of the
awning before installation. Otherwise, the awning may become
unstable and bend or break.
ANOTICE!
•Make sure that the inner screw joints are accessible.
•Only attach the awning to flat and vertical wall surfaces (fig. 2and
fig. 3, page 1). On curved wall surfaces, the mounting plates need to
be adequately lined under the fastening points.
PW3800-I-16s.book Seite 6 Donnerstag, 12. April 2018 3:24 15

EN
PW3800 Installing the awning
7
•If there is insufficient space above the door after the awning is
mounted, the door must remain closed when retracting or extending
to avoid the door making contact with the arms or the lead rail.
The required space depends on the design of the door (door width,
swing or sliding door) as well as the set awning angle of inclination
(fig. 4, page 1).
•The cables and cabinets in the interior of the vehicle may not be
damaged by drilling the holes.
INOTE
•Ensure the user of the vehicle is aware that the screws on the rear hinge
(fig. 5, page 1) must be tightened up (see operating manual). The
arms must not bear any load. This must be doneby the service partner.
6.3 Installing the awning
During installation, observe the following general information:
•The mounting plates are bolted to the vehicle in the area of the rear hinge. In
addition, they are glued with installation adhesive (e.g. Sikaflex®-221 or a similar
product) to ensure the load is evenly spread and an optimal level of protection
from moisture is maintained.
•Observe the sealant manufacturer's instructions.
•Before installation, check the access to the screw joints. Make sure no cables or
cabinets are damaged when drilling.
•Contact your local service partner if you wish to have an angle of inclination
different to the default setting.
•If you want to use an awning tent with the awning at a later date, ensure that the
vent windows and hatches of the erected tent remain accessible when choosing
the awning size and installation position (fig. 6, page 1).
•Clean the adhesive surfaces on the mounting rails and the wall.
•Prepare the adhesive surfaces with the primer.
•After gluing, wait until the adhesive has set. For further details, please refer to the
information provided by the sealant manufacturer.
•Carefully seal the drill holes to prevent moisture from entering the motorhome
wall.
PW3800-I-16s.book Seite 7 Donnerstag, 12. April 2018 3:24 15

EN
Installing the awning PW3800
8
•Do not open the awning or leave it unattended, before the awning has been
fastened to the mounting rails.
•As part of the regular maintenance procedure, the screwson the rear hinge must
be tightened up by a service partner. Ensure the users of the vehicle are aware of
this.
Installing the awning with mounting plates
➤Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
I
➤Align the mounting plates on the vehicle and mark where the holes are to be
drilled (fig. 8, page 1).
➤At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
➤Clean the outer sides of the mounting plates and the installation surface on the
vehicle.
➤Fill the drill holes in the vehicle wall with an acid-free silicone.
➤Insert the square-head bolts through the relevant holes in the mounting plates
(fig. 9, page 1).
➤To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for example, to
the back of the mounting plates (fig. 9, page 1).
➤Place all of the mounting plates through the drill holes and fasten them with
counter plate, serrated lock washers and hexagon head bolts (fig. 0, page 1).
➤Fasten the inner (narrow) mounting plates using a countersunk bolt, counter
plate, serrated lock washer and hexagon nut (fig. a, page 1).
➤Wait until the glue has set. For further details, please refer to the information
provided by the sealant manufacturer.
➤Use two people to hook the awning on to the mounting plates (fig. b, page 1).
➤Insert the cover caps on the counter plates (fig. c, page 2).
➤Drill two holes with a diameter of 3 mm through the awning and each of the long
mounting plates (fig. d, page 2).
NOTE
Recommended mounting position for each counter plate: fig. 7,
page 1.
