Dometic RTX1000 User manual

AIR CONDITIONER
COOLAIR
Form No. 3317633.000 54-536-MA13 08/20 | ©2020 Dometic Corporation
WARNING
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
RTX 1000 and RTX 2000
EN Parking Cooler
Installation and Operation Manual.................. 2
FR Climatiseur de stationnement
Manuel d’installation et d’utilisation ...............24
ES Equipo de aire acondicionado a motor parado
Manual de instalación y uso ......................46

2EN
Contents Parking Cooler
1 Explanation of Symbols and Safety
Instructions ............................ 2
1.1 Recognize Safety Information .............2
1.2 Understand Signal Words................3
1.3 Supplemental Directives.................3
1.4 General Safety Messages ................3
2 Intended Use ........................... 3
3 General Information ..................... 4
3.1 Tools and Materials .....................4
3.2 Model Identification ....................5
3.3 Component Locations. . . . . . . . . . . . . . . . . . .5
3.4 External Dimensions ....................6
3.5 Internal Dimensions.....................6
3.6 Unit Placement Requirements.............6
4 Specifications .......................... 7
4.1 Product Specifications ..................7
5 Wiring Diagram......................... 8
6 Pre-Installation ......................... 9
6.1 Preparing the Roof Opening..............9
6.2 Preparing the Unit .....................10
6.3 Attaching the Seal to the Roof Opening ...10
7 Installation.............................11
7.1 Positioning the Unit on the Roof .......... 11
7.2 Securing the Unit to the
Mounting Brackets .................... 11
7.3 Routing the Wiring ....................12
7.4 Installing the Cover ....................13
8 Configuring the System Software ......... 13
8.1 Entering and Exiting
Configuration Mode ...................13
8.2 Setting the Low Voltage Shut-Down
Voltage - P.01.........................13
8.3 Setting the Unit For Temperature
Display - P.02 .........................14
9 Operation............................. 14
9.1 Understanding the Controls .............14
9.2 Available Menus ......................17
9.3 Menu Mode..........................17
10 Using the Parking Cooler ................ 17
10.1 Turning the Parking Cooler On ...........18
10.2 Switching the Parking Cooler to
Standby Mode........................18
10.3 Turning the Parking Cooler Off ...........18
10.4 Using Menus .........................18
10.5 Using the Air Conditioner ...............19
10.6 Setting the Temperature ................19
10.7 Setting the Mode .....................19
10.8 Setting the Timer ......................20
11 Display Messages ...................... 20
11.1 Control Panel Warnings ................20
11.2 Control Panel Fault Messages............21
12 System Specifications...................22
13 Cleaning and Maintenance ..............22
14 Disposal ..............................23
Limited One-Year Warranty .................23
Contents
Service Center & Dealer Locations
Visit: www.dometic.com
Read these instructions carefully. These instructions
MUST stay with this product.
1 Explanation of Symbols and
Safety Instructions
This manual has safety information and instructions to help
you eliminate or reduce the risk of accidents and injuries.
1.1 Recognize Safety Information
This is the safety alert symbol. It is used to alert
you to potential physical injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.

3
EN
Parking Cooler Intended Use
1.2 Understand Signal Words
A signal word will identify safety messages and property
damage messages, and also will indicate the degree or
level of hazard seriousness.
DANGER!
Indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING
Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE: Used to address practices not related to
physical injury.
IIndicates additional information that is not related
to physical injury.
1.3 Supplemental Directives
To reduce the risk of accidents and injuries, please
observe the following directives before proceeding to
install or operate this unit:
• Read and follow all safety information and
instructions.
• Read and understand these instructions before
installing or operating this product.
• The unit shall be installed in accordance with national
wiring regulations.
• For an all-pole disconnection device that has at least
0.12 in. (3 mm) clearances in all poles and has a
leakage current that may exceed 10 mA, the residual
current device (RCD) with a rated residual operating
current not exceeding 30 mA and disconnection
must be incorporated in the fixed wiring in
accordance with the wiring rules.
• The installation must comply with all applicable local
or national codes.
1.4 General Safety Messages
WARNING: ELECTRICAL SHOCK, FIRE, AND/
OR EXPLOSION HAZARD. Failure to obey the
following warnings could result in death or
serious injury:
• Use only Dometic replacement parts and
components that are specifically approved for use
with the unit.
• Avoid improper installation, adjustment, alterations,
service, or maintenance of the unit. Service and
maintenance must be done by a qualified service
person only.
• Do not modify this product in any way. Modification
can be extremely hazardous.
• This unit is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning the use of the unit by a person
responsible for their safety.
• Children should be supervised to ensure that they do
not play with the unit.
• If the supply lead is damaged, it must be replaced
by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
• Use care when diagnosing and/or adjusting
components on a powered unit.
2 Intended Use
The parking cooler (also referred to as the “product” or
“unit”) is used to supply the interior of the driver’s cab
with cool and dehumidified air. The system is designed
for stationary use or can be used while driving. The
parking cooler is not suitable for use in agricultural or
construction vehicles. The parking cooler is suitable for
ambient temperatures of 41 °F to 126 °F (5 °C to
52 °C).

4EN
General Information Parking Cooler
Dometic accepts no liability for damage in the following
cases:
• Faulty assembly or connection
• Damage to the product resulting from mechanical
influences and excess voltage
• Alterations to the product without express permission
from Dometic
• Use for purposes other than those described in the
operating manual
Dometic Corporation reserves the right to modify
appearances and specifications without notice.
3 General Information
This section provides information regarding the
tools and materials, component locations, model
identification, external and internal dimensions, and unit
placement.
IThe images used in this document are for reference
purposes only. Components and component
locations may vary according to specific product
models. Measurements may vary ±0.38 in. (10 mm).
3.1 Tools and Materials
Dometic recommends that the following tools and
materials be used:
Included Parts Quantity
Cover Frame Universal CoolAir 3rd
Generation 1
Seal 0.4 in. x 0.8 in.
(10 mm x 20 mm) 1 x 2.7 mm
Support Bracket 2
Hex Bolt M8 x 100 4
Threaded Insert With Flange M8 4
Threaded Insert With Flange M6 4
Washer 8.5 x 20 x 1.25 4
Spring Washer M8 4
Nut M8 4
Allen Screw With Cylinder Head
M6 x 110 4
Spacer 6.2 x 10 x 48 8
Included Parts Quantity
Washer M6 4
Power Cable External Short
RTX 12V 1
Cable Ties 1
1/4 in. Hex Bit 1
80 A Fuse 1
200 A Fuse Holder 1
2 A Fuse 1
Cable Terminals for Battery Cable
AWG 4 3/8 in. 2
Cable Terminal for Fuse Holder
1/4 in. 2
Ring Terminal 0.02 in. (0.5 mm) 2
Joint Connector 0.02 in. (0.5 mm) 1
2 A Fuse Holder 1
Loom Tubing 9.8  (3 m) 1
Opening Template
18.9 in. x 15.3 in. (480 mm x
390mm) 1
Seal 35 x 20 x 3000 1
Recommended Tools
Angle Grinder Impact Gun
Cutting Disc for Metal Screwdriver Bit Set
Extension Cord Hole Saw Set
Drill Self Tapping Screws
Automotive Staple Remover Flat Head Screwdriver
Phillips Screwdriver Pliers
Side Cutters

5
EN
Parking Cooler General Information
3.2 Model Identification
1 Data Plate Location
Model
SKU
Rated Voltage: 12VDC
Refrigerant: R 34a/0.350kg, GWP=1430
C02-Equivalent: 0.500t
Rated power input: 570W
Fuse: 80A
Max Pressure: LP 11bar/HP 25bar
Protection: IPX6K (For outside)
RTX1000
Contains fluorinated greenhouse gases. Hermetically sealed equpiment.
Manufactured by Dometic (Zhuhai) Technology Co., Ltd.
Made in China dometic.com
Building A1 to A8, B1 to B6, No. 18, Jinhu Road, Sanzao Town, Jinwan District, Zhuhai City, Guangdong Province 519041, P. R. China
9600028489
Truck Parking Cooler
PNC
Serial
936003520
02520001
g
©US
2 Data Plate RTX 1000
Model
SKU
Rated Voltage: 12VDC
Refrigerant: R 34a/0.850kg, GWP=1430
C02-Equivalent: 1.215t
Rated power input: 650W
Fuse: 80A
Max Pressure: LP 11bar/HP 25bar
Protection: IPX6K (For outside)
RTX2000
Contains fluorinated greenhouse gases. Hermetically sealed equpiment.
Manufactured by Dometic (Zhuhai) Technology Co., Ltd.
Made in China dometic.com
Building A1 to A8, B1 to B6, No. 18, Jinhu Road, Sanzao Town, Jinwan District, Zhuhai City, Guangdong Province 519041, P. R. China
9600028490
Truck Parking Cooler
PNC
Serial
936003521
02520555
g
©US
3 Data Plate RTX 2000
3.3 Component Locations
This section identifies the unit’s main components.
q
w
y
e
t
r
4 RTX Component Locations
qExternal Cover rBlower Nozzle
wCover Frame tControl Panel
eIntake Grille yMounting Bracket
