Dometic SPX1200T User manual

1
291286
60 t100
t100 t100
779
Ø 8,5 mm
8x
d4 m
d8°
w
r
o
i
u
y
t
e
q
a s df g h
l 2!2)1(
j k
CoolAir
SPX1200C
SPX1200T
MAN TGX/TGS (XXL, XLX, XL, LX)
1
2
3
4
7
6
8
5
SPX1200T-MAN-XLX-I-16s.book Seite 1 Mittwoch, 7. November 2018 9:41 21

2
Dometic WAECO International GmbH
Hollefeldstrasse 63
D-48282 Emsdetten
dometic.com
1234
d4,2 m
A B
a
M6
M6 x 100
u
i
o
y
10 x 40
24 V
1
2.
1. < 0,3 m
gf jk
h
s
d
l
1(2!
2)
2)
8 Nm
w
r
t
e
q
M8 x 60
M8
14 x 18
8,5 x 20
9 b
c
0
a
d
4445102654 08/2018
SPX1200T-MAN-XLX-I-16s.book Seite 2 Mittwoch, 7. November 2018 9:41 21

AIR CONDITIONERS
COOLAIR
SPX1200T
Assembly kit for
MAN TGX/TGS (XXL, XLX, XL, LX)
Installation Manual . . . . . . . . . . . . . . . . . . 3
Montagesatz für
MAN TGX/TGS (XXL, XLX, XL, LX)
Montageanleitung . . . . . . . . . . . . . . . . . .16
Kit de montage pour
MAN TGX/TGS (XXL, XLX, XL, LX)
Instructions de montage. . . . . . . . . . . . . 29
Juego de montaje para
MAN TGX/TGS (XXL, XLX, XL, LX)
Instrucciones de montaje . . . . . . . . . . . . 42
Kit de montagem para
MAN TGX/TGS (XXL, XLX, XL, LX)
Instruções de montagem . . . . . . . . . . . . 55
Set di montaggio per
MAN TGX/TGS (XXL, XLX, XL, LX)
Indicazioni di montaggio . . . . . . . . . . . . 69
Montageset voor
MAN TGX/TGS (XXL, XLX, XL, LX)
Montagehandleiding . . . . . . . . . . . . . . . 82
Monteringssæt til
MAN TGX/TGS (XXL, XLX, XL, LX)
Monteringsvejledning . . . . . . . . . . . . . . 95
Monteringssats för
MAN TGX/TGS (XXL, XLX, XL, LX)
Monteringsanvisning . . . . . . . . . . . . . . . 107
Monteringssett for
MAN TGX/TGS (XXL, XLX, XL, LX)
Monteringsanvisning . . . . . . . . . . . . . . . 119
Asennussarja malleihin
MAN TGX/TGS (XXL, XLX, XL, LX)
Asennusohje . . . . . . . . . . . . . . . . . . . . . . 131
Монтажный комплект для
MAN TGX/TGS (XXL, XLX, XL, LX)
Инструкция по монтажу . . . . . . . . . . . . 143
Zestaw montażowy do
MAN TGX/TGS (XXL, XLX, XL, LX)
Instrukcja montażu . . . . . . . . . . . . . . . . . 157
Montážna súprava pre
MAN TGX/TGS (XXL, XLX, XL, LX)
Návod na montáž . . . . . . . . . . . . . . . . . . 170
Montážní sada pro vozidla
MAN TGX/TGS (XXL, XLX, XL, LX)
Návod k montáži. . . . . . . . . . . . . . . . . . . 183
Szerelőkészlet a következőkhöz:
MAN TGX/TGS (XXL, XLX, XL, LX)
Szerelési útmutató . . . . . . . . . . . . . . . . .195
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

3
EN
SPX1200T
Original instructions
Please read this instruction manual carefully before installation and
first use, and store it in a safe place. If you pass on the product to
another person, hand over this instruction manual along with it.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Using the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Handling electrical cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.1 Notes on installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.2 Removing the roof hatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.3 Preparing the unit fixings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.4 Attaching the seal for the cab roof. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.5 Fitting the unit in the roof hatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.6 Routing the electrical power supply leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.7 Installing supply lines to the condenser unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
6.8 Fixing the cover frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Configuring the system software . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.1 Entering and exiting configuration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.2 P.01: Low voltage shut-down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.3 P.02: Unit for temperature display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.4 P.05: Tilt sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

EN
Explanation of symbols SPX1200T
4
1 Explanation of symbols
!
!
A
I
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and incorrect
connection voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
WARNING!
Safety instruction: Failure to observe this instruction can cause death or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair the
function of the product.
NOTE
Supplementary information for operating the product.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

5
EN
SPX1200T Safety instructions
2.1 Using the device
•Only use the parking cooler for the purpose specified by the manufacturer
and do not make any alterations or structural changes to the device.
•Do not use the parking cooler if it is visibly damaged.
•The parking cooler must be installed safely so that it cannot tip over or fall
down.
•Installation, maintenance and repair work may only be carried out by
qualified personnel from a specialist company who are familiar with the risks
involved and the relevant regulations.
•Do not use the parking cooler near flammable fluids and gases.
•Do not operate the parking cooler if the ambient temperature is below 0 °C.
•Do not undo the upper cover of the parking cooler in the event of a fire. Use
approved extinguishing agents instead. Do not use water to extinguish fires.
•Please inform your vehicle manufacturer if the height entered in your vehicle
documents needs to be altered due to the installation of the parking cooler.
– SPX1200T height: 53 mm
•Disconnect all power supply lines when working on the parking cooler
(cleaning, maintenance, etc).
2.2 Handling electrical cables
•Use cable ducts to lay cables through walls with sharp edges.
•Do not lay loose or bent cables next to electrically conductive materials
(metal).
•Do not pull on the cables.
•Attach and lay the cables in such a manner that they cannot be tripped over
or damaged.
•The electrical power supply may only be connected by a specialist work-
shop.
•The connection to the vehicle's electrical system should be protected as
follows:
– power supply: 40 A
– voltage monitor: 2 A
•Never lay power supply lines (battery leads) in the vicinity of signal or control
cables.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

EN
Target group SPX1200T
6
3 Target group
This installation manual contains the essential information and instructions for
installing the parking cooler. It is intended for competent installer technical staff
who are familiar with the guidelines and safety precautions to be applied when
installing lorry accessories.
This installation manual should always be kept with the unit to which it relates.
4 Intended use
A
The installation kit enables the installation of a CoolAir STX1200T roof evaporator
in a roof ventilation opening (hatch) provided at the plant in a MAN TGX/
TGS (XXL, XLX, XL, LX) driver cab.
NOTICE!
•The parking cooler is not suitable for installation in construction machines,
agricultural machines or similar equipment. They will not work properly if
exposed to strong vibrations.
•Operating parking cooler with voltages other than those specified can
result in damage to the devices.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

7
EN
SPX1200T Scope of delivery
5 Scope of delivery
CoolAir SPX1200T installation kit for
MAN TGX/TGS (XXL, XLX, XL, LX)
Item in
fig. 1Part designation Quantity
.Spacer sleeve L = 18 mm, ∅14 mm 8
3MAN underlay strip 4
$Washer 8.5 x 20 8
/Spring washer M8 8
1Hex screw M8 x 60 8
4Spacer sleeve L = 40 mm, ∅10 mm 8
2Cover frame MAN 1
(Washer M6 4
,Allen screw with cylindrical head M6 x 95 4
"2.5 m insulating tape (profile: 10 x 20 mm) 1
 Connection cable 6 mm² x 11 m 1
 Cable binder 20
 Maxi Fuse 40 A 1
 Maxi Fuse holder (40 A) 1
 Ring terminal 6 mm², M8 1
 Ring terminal 6 mm², M10 1
 Joint connector 6 mm² 1
 Blade fuse, 2 A 1
 Fuse holder (2 A) 1
 Ring terminal 0.5 mm², M8 2
 Joint connector 0.5 mm² 1
 1/4" hexagon bit 1
– Installation manual 1
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

EN
Installation SPX1200T
8
6 Installation
!
A
6.1 Notes on installation
The following tips and guidance should be followed when installing the parking
cooler:
!
•Before installing the parking cooler, check whether any vehicle components
could be damaged or have their function impaired as a result of the installa-
tion.
Check the dimensions of the system to be installed (fig. 2).
The dotted line indicates the middle of the roof hatch opening.
•The top cowl of the parking cooler can be painted (fig. 3). The
manufacturer recommends that the painting is done by a specialist paint
shop.
•Before installation, check with the vehicle manufacturer whether the vehicle
body is designed for the static weight of the parking cooler and the dynamic
loads created by it when the vehicle is in motion. The manufacturer of the
parking cooler accepts no liability whatsoever in that regard.
•The downward slope of the roof in forward direction in the area where the
unit is installed must not be more than: 20°
CAUTION!
Incorrect installation of the parking cooler may place the safety of the user at
risk.
The manufacturer accepts no liability whatsoever for personal injury or property
damage if the parking cooler is not installed according to this installation
manual.
NOTICE!
•The parking cooler may only be installed by qualified personnel from a
specialist company. The following information is intended for technicians
who are familiar with the guidelines and safety precautions to be applied.
•The manufacturer only assumes liability for parts included in the scope of
delivery. The validity of the warranty expires if the device is installed
together with third-party parts.
•Check whether the roof of the vehicle is able to support the weight of a
person before climbing onto it. Ask the vehicle manufacturer about the
permitted roof loads.
WARNING! Electric shock hazard
Before carrying out any work on electrically operated components, make sure
that they are disconnected from the power supply.
Before installing the parking cooler, disconnect all connections to the vehicle
battery.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

9
EN
SPX1200T Installation
•The assembly parts supplied must not be modified during installation.
•The ventilation openings must not be covered over (minimum distance from
other external attachments: 100 mm).
•Follow the vehicle manufacturer's guidelines when installing the system and
establishing the electrical connections.
I
6.2 Removing the roof hatch
Proceed as follows (fig. 6):
➤Remove all screws and fixings for the existing roof hatch.
➤Take out the roof hatch.
➤Remove the sealant around the opening so that the surface is clean and free
of grease.
I
6.3 Preparing the unit fixings
➤Drill out the 8 factory-made holes to a diameter of 8.5 mm (fig. 7).
6.4 Attaching the seal for the cab roof
A
➤Glue the sealing strip to the cab roof (fig. 9A).
Follow the contour of the roof hatch opening. The join between the ends of
the seal should be at the back.
➤Apply a flexible, non-hardening butyl sealant (e.g. SikaLastomer-710) to the
join between the ends of the sealing strip and to the top edge of the sealing
strip (fig. 9B).
NOTE
After installation of the system, the pre-set parameters on the system software
must be checked (chapter “Configuring the system software” on page 12).
NOTE
Dispose of all waste material, glue, silicon and seals separately. When doing
so, follow the waste disposal requirements applicable in your local area.
NOTICE!
Ensure that the surface where the seal between the unit and the cab roof is to
be glued is clean (free of dust, oil, etc.).
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

EN
Installation SPX1200T
10
6.5 Fitting the unit in the roof hatch
➤Place the parking cooler centrally and facing forwards in the roof hatch
opening (fig. 0).
I
A
➤Fix the parking cooler in place as illustrated (fig. a).
6.6 Routing the electrical power supply leads
D
!
A
Connect the unit directly to the battery.
When doing so, you should also follow the vehicle manufacturer's guidelines.
Route the power supply lead as illustrated (fig. b):
➤Feed the wiring loom to the right through the roof cupboard to the A-pillar.
➤Run the wiring loom downwards to the main fuse/relay panel (preferably
along the roof hatch drain hose) and via the body interface to the outside.
➤Run the wiring loom to the battery compartment along a route where it is
protected.
➤Connect the power supply negative lead (black) to the battery negative
terminal as illustrated.
NOTE
Once the unit is in position on the vehicle roof, the seal should make contact all
the way round. Only then can a reliable seal be achieved.
NOTICE!
Do not exceed the specified tightening torque under any circumstances. That
is the only way to ensure that the threaded plugs are not pulled out.
DANGER!
For EX/III and FL vehicles (according to ADR guideline), a battery master switch
must be installed.
WARNING!
•The electrical connections may only be made by competent technical staff
with the appropriate specialist knowledge.
•Before carrying out any work on electrically operated components, make
sure that they are disconnected from the power supply.
NOTICE!
•The connection to the vehicle's electrical system should be protected by a
40 A fuse for the power supply and a 2 A fuse for the voltage monitor.
•The battery must be capable of supplying the required current and voltage
(chapter “Technical data” on page 15).
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

11
EN
SPX1200T Installation
➤Connect the voltage monitor negative lead (black) to the battery negative
terminal as illustrated.
I
➤Connect the power supply positive lead (red) to the battery positive terminal
as illustrated via a 40 A fuse.
➤Connect the voltage monitor positive lead (red) to the battery positive
terminal as illustrated via a 2 A fuse.
➤Connect the wiring loom to the unit and fix with a cable tie in a suitable
position (fig. b2.).
6.7 Installing supply lines to the condenser unit
Observe the following instructions when installing the supply lines:
•Also observe the installation instructions for the condenser unit.
•The maximum cable length between the evaporator and condenser unit is
4.20 m (fig. d).
•When installing and bending supply lines, avoid narrow radii. Use a suitable
round object as a bending aid. A radius which is too narrow will buckle the
refrigerant line, and the parking cooler will be inoperable.
➤Shorten any supply line which is not needed by bending a curve.
➤Apply packing compound (fig. d1) to prevent water entering between the
rear wall of the truck and the clip.
I
➤Fasten the supply lines to the rear wall of the truck using the clips provided
(fig. d).
➤Insert the corrugated piping in the holder provided (fig. d2).
➤Put the cover on (fig. d4).
NOTE
Place the fuse holder no more than 0.3 m from the positive terminal of the
battery.
NOTE
If you wish to avoid damaging the rear wall of the truck (drilling a hole), you can
also apply the clip using a suitable adhesive. Observe the instructions provided
by the adhesive manufacturer.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

EN
Configuring the system software SPX1200T
12
6.8 Fixing the cover frame
A
➤Fix the cover frame in place as illustrated (fig. c).
7 Configuring the system software
Before the system is first put into operation, the control unit settings can be
adjusted to suit the various installation conditions. Those adjustments must be
made by the installer (fig. 5).
I
7.1 Entering and exiting configuration mode
➤Press and hold the button.
➤Press and hold the button for longer than 3 s.
✓The display shows the symbol .
✓The parking cooler switches to configuration mode.
✓The display shows “P.01” and the symbol flashes.
➤Scroll through the menu by pressing the or button to select the
desired menu item.
➤Press the button to open the desired menu item.
➤Press and hold the button for longer than 3 s to exit configuration mode.
NOTICE!
Tighten the screws carefully in order not to damage the cover frame.
Display
indication Parameter Meaning Factory setting
P.01 Low voltage
shut-down
The battery monitor shuts down the
system at the voltage defined here.
22.8 V
P.02 Unit for tempera-
ture display
The temperature can be displayed in
°C or °F.
°C
P.05 Tilt sensor The tilt sensor can be calibrated to a
zero setting.
–
NOTE
Configuration mode can still be activated if the low voltage cut-out has
switched off the system and only residual voltage is available.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

13
EN
SPX1200T Configuring the system software
7.2 P.01: Low voltage shut-down
The battery monitor protects the battery against discharging excessively.
A
If only the power supply voltage specified here is available to the parking cooler,
the system is switched off.
➤Switch to configuration mode (chapter “Entering and exiting configuration
mode” on page 12).
✓The display shows “P.01” and the symbol flashes.
➤Press the button to change the setting.
✓The current setting is displayed.
➤Use the or button to select the voltage level for low voltage shut-
down.
The low voltage shut-down setting can be adjusted in 0.1 V increments from
20.0 V to 23.5 V.
I
➤Press the button to save the setting.
✓The set value is saved and is then applied when the system is restarted.
✓You are then returned to the menu and can select another menu item by
pressing the or button.
NOTICE!
If the unit is switched off by the battery monitor, it means the battery charge
level is low. Avoid repeated starting or using electrical equipment. Make sure
that the battery is recharged. As soon as the required voltage is available again,
the system can be operated again.
NOTE
The level for the low voltage shut-down should not be set any lower than the
minimum battery voltage required to be able to start the engine under any
conditions.
As a rule that should be no less than 22 V.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

EN
Configuring the system software SPX1200T
14
7.3 P.02: Unit for temperature display
The system can display the room temperature in °C or °F.
➤Switch to configuration mode (chapter “Entering and exiting configuration
mode” on page 12).
✓The display shows “P.01” and the symbol flashes.
➤Press the or button to select the menu item P.02.
✓The display shows “P.02” and the symbol lights up.
➤Press the button to change the setting.
✓The code for the current setting is displayed:
– 0: °C
– 1: °F
➤Use the or button to select the desired temperature unit.
➤Press the button to save the setting.
✓The set value is saved and is then applied when the system is restarted.
✓You are then returned to the menu and can select another menu item by
pressing the or button.
7.4 P.05: Tilt sensor
The electronics of the system prevents that the system is switched on when the
vehicle is parked at a slope. Since some vehicles‘ roof already is tilted, the tilt
sensor has to calibrated to the zero setting before first use.
➤Park the vehicle on a level place.
➤Switch to configuration mode (chapter “Entering and exiting configuration
mode” on page 12).
✓The display shows “P.01” and the symbol flashes.
➤Press the or button to select the menu item P.05.
✓The display shows “P.05”.
➤Press the button to change the setting.
✓The code for the current setting is displayed.
➤Use the or button to select “1”.
➤Press the button to save the setting.
✓The set value is saved and is then applied when the system is restarted.
✓You are then returned to the menu and can select another menu item by
pressing the or button.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

15
EN
SPX1200T Technical data
8 Technical data
CoolAir SPX1200T
Cooling capacity: 1200 W
Rated input voltage: 24 Vg(20 Vg– 30 Vg)
Max. current consumption: 5 – 25 A
Operating temperature range: +5 bis +52 °C
Low voltage shutdown: Configurable (chapter “P.01: Low voltage shut-
down” on page 13)
Noise emission: < 70 dB(A)
Dimensions(L x B x H): 778x577x182 mm
Weight: ca. 15 kg
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

DE
SPX1200T
16
Original-Betriebsanleitung
Bitte lesen Sie diese Anleitung vor Einbau und Inbetriebnahme sorg-
fältig durch und bewahren Sie sie auf. Geben Sie sie im Falle einer
Weitergabe des Produktes an den Nutzer weiter.
Inhaltsverzeichnis
1 Erklärung der Symbole. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2 Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1 Umgang mit dem Gerät. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
2.2 Umgang mit elektrischen Leitungen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3 Zielgruppe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4 Bestimmungsgemäßer Gebrauch. . . . . . . . . . . . . . . . . . . . . . . . . 19
5 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.1 Hinweise zur Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.2 Dachluke ausbauen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.3 Anlagenbefestigung vorbereiten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4 Dichtung zum Fahrerhausdach anbringen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.5 Anlage in Dachluke einbauen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.6 Elektrische Versorgungsleitungen verlegen. . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.7 Versorgungsleitungen zur Kondensatoreinheit verlegen . . . . . . . . . . . . . . . . 24
6.8 Abdeckrahmen befestigen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7 Anlagen-Software konfigurieren . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.1 Einstellungsmodus starten und beenden. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.2 P.01: Unterspannungsabschaltung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.3 P.02: Anzeige Temperatureinheit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.4 P.05: Neigungssensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8 Technische Daten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

17
DE
SPX1200T Erklärung der Symbole
1 Erklärung der Symbole
!
!
A
I
2 Sicherheitshinweise
Der Hersteller übernimmt in folgenden Fällen keine Haftung für Schäden:
•Montage- oder Anschlussfehler
•Beschädigungen am Produkt durch mechanische Einflüsse und falsche
Anschlussspannung
•Veränderungen am Produkt ohne ausdrückliche Genehmigung vom
Hersteller
•Verwendung für andere als die in der Anleitung beschriebenen Zwecke
WARNUNG!
Sicherheitshinweis: Nichtbeachtung kann zu Tod oder schwerer Verletzung
führen.
VORSICHT!
Sicherheitshinweis: Nichtbeachtung kann zu Verletzungen führen.
ACHTUNG!
Nichtbeachtung kann zu Materialschäden führen und die Funktion des
Produktes beeinträchtigen.
HINWEIS
Ergänzende Informationen zur Bedienung des Produktes.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU

DE
Sicherheitshinweise SPX1200T
18
2.1 Umgang mit dem Gerät
•Benutzen Sie die Standklimaanlage nur für den vom Hersteller angegebenen
Verwendungszweck und führen Sie keine Änderungen oder Umbauten am
Gerät durch.
•Wenn die Standklimaanlage sichtbare Beschädigungen aufweist, darf Sie
nicht in Betrieb genommen werden.
•Die Standklimaanlage muss so sicher installiert werden, dass diese nicht
umstürzen oder herabfallen kann.
•Die Installation, Wartung und etwaige Reparatur dürfen nur durch einen
Fachbetrieb erfolgen, der mit den damit verbundenen Gefahren bzw. ein-
schlägigen Vorschriften vertraut ist.
•Setzen Sie die Standklimaanlage nicht in der Nähe von entflammbaren
Flüssigkeiten und Gasen ein.
•Betreiben Sie die Standklimaanlage nicht bei Außentemperaturen unter
0 °C.
•Im Falle von Feuer lösen Sie nicht den oberen Deckel der Standklimaanlage,
sondern verwenden Sie zugelassene Löschmittel. Verwenden Sie kein
Wasser zum Löschen.
•Bitte informieren Sie sich bei Ihrem Fahrzeughersteller, ob aufgrund des
Aufbaues der Standklimaanlage eine Änderung des Eintrags der Fahrzeug-
höhe in ihren Fahrzeugpapieren notwendig ist.
– SPX1200T Aufbauhöhe: 53 mm
•Lösen Sie bei Arbeiten (Reinigung, Wartung usw.) an der Standklimaanlage
alle Verbindungen zur Stromversorgung.
2.2 Umgang mit elektrischen Leitungen
•Müssen Leitungen durch scharfkantige Wände geführt werden, so
verwenden Sie Leerrohre bzw. Leitungsdurchführungen.
•Verlegen Sie keine losen oder scharf abgeknickten Leitungen an elektrisch
leitenden Materialien (Metall).
•Ziehen Sie nicht an Leitungen.
•Befestigen und verlegen Sie Leitungen so, dass keine Stolpergefahr entsteht
und eine Beschädigung des Kabels ausgeschlossen ist.
•Der elektrische Anschluss darf nur von einem Fachbetrieb durchgeführt
werden.
•Sichern Sie den Anschluss ans Netz im Fahrzeug wie folgt ab:
– Stromversorgung: 40 A
– Spannungsmessung: 2 A
•Verlegen Sie niemals die Spannungsversorgungsleitung (Batteriekabel) in
räumlicher Nähe zu Signal- oder Steuerleitungen.
63;70$1;/;,VERRN6HLWH0RQWDJ1RYHPEHU
