Dometic MagicWatch MWE7006 Installation manual

1
2x
6
4x
5
1x
2
1x
1
1x
3
a
90° 10°
a
––
a = 45 cm
a = 60 cm 24 mm
∅ ∅
24 mm
––
4
1x
a
≥
30
30 cm
C
A
B
6x
7
6x
8
Click!
10 – 20 cm
10 – 30 cm
10 – 20 cm
35 – 40 cm 35 – 40 cm30 – 40 cm 30 – 40 cm
35 – 40 cm35 – 40 cm 5 – 10 cm30 – 40 cm 30 – 40 cm
35 – 40 cm 35 – 40 cm
55 cm
55 cm
30 cm 30 cm
1
2
3 4
5
61
2 3 4
5
6
1
2
3 4
5
6
MWE7006
DE: 20
EN: 6
FR: 35
ES: 50
IT: 65
NL: 80
DA: 94
SV: 108
NO: 122
FI: 136
PT: 150
RU: 165
PL: 181
CS: 196
SK: 210
HU: 224
DE: 21
EN: 7
FR: 36
ES: 51
IT: 66
NL: 81
DA: 95
SV: 109
NO: 123
FI: 137
PT: 151
RU: 166
PL: 182
CS: 197
SK: 211
HU: 225
DE: 21
EN: 7
FR: 36
ES: 51
IT: 66
NL: 81
DA: 95
SV: 109
NO: 123
FI: 137
PT: 151
RU: 166
PL: 182
CS: 182
SK: 211
HU: 225
1
3
5
4
2
6
8
7
DE: 21
EN: 7
FR: 37
ES: 51
IT: 66
NL: 81
DA: 95
SV: 109
NO: 123
FI: 137
PT: 151
RU: 167
PL: 183
CS: 197
SK: 211
HU: 225
DE: 21
EN: 7
FR: 37
ES: 51
IT: 67
NL: 81
DA: 95
SV: 109
NO: 123
FI: 137
PT: 152
RU: 167
PL: 183
CS: 197
SK: 211
HU: 225

2
Dometic WAECO International GmbH
Hollefeldstrasse 63
D-48282 Emsdetten
www.dometic-waeco.com
br
rt/gr
bl/sw
gebl
5
6
7
4
9
31
21 9 3 156142
2
8
3
sw
sw
1
15
R
93,5
45 – 75 cm
45 – 75 cm
45 – 75 cm
B
C
A
1
2
3 4
5
6
15
2
R3
4
1.
2.
2.
1.
654321
ON!
DE: 23
EN: 8
FR: 38
ES: 53
IT: 68
NL: 82
DA: 96
SV: 110
NO: 124
FI: 138
PT: 153
RU: 168
PL: 184
CS: 198
SK: 212
HU: 227
0
b
DE EN FR ES IT NL DA
bl Blau Blue Bleu Azul Blu Blauw Blå
br Braun Brown Marron Marrón Marrone Bruin Brun
ge Gelb Yellow Jaune Amarillo Giallo Geel Gul
gr Grau Grey Gris Gris Grigio Grijs Grå
rt Rot Red Rouge Rojo Rosso Rood Rød
sw Schwarz Black Noir Negro Nero Zwart Sort
SV NO FI PL RU CS SK
bl Blå Blå Sininen Niebieski Синий Modrá Modrá
br Brun Brun Ruskea Brązowy Коричневый Hněda Hnedá
ge Gul Gul Keltainen Żółty Желтый Žlutá Žltá
gr Grå Grå Harmaa Zielony Зеленый Zelená Zelená
rt Röd Rød Punainen Czerwony Красный Červená Červená
sw Svart Svart Musta Czarny Черный Černá Čierna
9
a
DE: 24
EN: 9
FR: 39
ES: 54
IT: 69
NL: 83
DA: 97
SV: 111
NO: 125
FI: 139
PT: 154
RU: 169
PL: 185
CS: 199
SK: 213
HU: 228
4445101213 F 10/2014

f5 01
> 2 s
01
< 1 s
< 1 s
+
–
6004
> 2 s
60
< 1 s
< 1 s
+
–
c5
> 2 s
70
f5
> 10 s
70
2
1
3
01 012 2
max. 300 cm
3
2
1
4 (STOP)
~ 300 cm
~ 230 cm
~ 145 cm
~ 60 cm
c
d
EN: 10
DE: 25
FR: 40
ES: 55
IT: 70
NL: 84
DA: 98
SV: 112
NO: 126
FI: 140
PT: 155
RU: 170
PL: 186
CS: 200
SK: 214
HU: 229
EN: 11
DE: 26
FR: 41
ES: 56
IT: 71
NL: 85
DA: 99
SV: 113
NO: 127
FI: 141
PT: 156
RU: 171
PL: 187
CS: 201
SK: 215
HU: 230
EN: 11
DE: 26
FR: 41
ES: 56
IT: 71
NL: 85
DA: 99
SV: 113
NO: 127
FI: 141
PT: 156
RU: 171
PL: 187
CS: 201
SK: 215
HU: 230
e
Programmieranleitung • Programming instructions • Instructions de programmation • Instrucciones de
programación • Istruzioni per la programmazione • Programmeerhandleiding • Programmeringsvejledning •
Programmeringsanvisning • Programmeringsveiledning • Ohjelmointiohje • Instruções de programação •
Инструкция по программированию • Instrukcja programowania • Návod k programování •
Návod na naprogramovanie • Programozási utasítások
MWE7006

01 012 2
Min … Max FactoryMin … Max Factory
10
00
OFF, …cm, SW OFF
00 02,, 05 00
07 0 , 2 – 5 s 5 s
002
..., 05 5
93,5
0
59
0... 10
54 01
00,01
56 01
00,01
51 00
00 ,,, 2010 30
52 00
00 ,,, 2010 30
53 00
00 ,,, 2010 30
41 5
–9 ... +9
0, 2, 3, 4, 6
03 6
n
42 5
–9 ... +9
43 5
–9 ... +9
44 120 – 300 cm 300 cm
12 ... 30 30
46 50 – 190 cm 160 cm
50 ... 19 16
62 100 – 130 cm 100 cm
10 ... 13 10
STOP
63 100 – 130 cm 100 cm
10 ... 13 10
STOP
100 – 130 cm 100 cm
10 ... 13
61 10
STOP
48 35 – 120 cm 65 cm
35 ... 12 65
STOP
49 35 – 120 cm 65 cm
35 ... 12 65
STOP
35 – 120 cm 65 cm
35 ... 12
47 65
STOP
45 300 cm
30
120 – 300 cm
12 ... 30
1 2
↔ <100: 12 cm
↔ ≥100: 12 dm
fEN: 11
DE: 26
FR: 41
ES: 56
IT: 71
NL: 85
DA: 99
SV: 113
NO: 127
FI: 141
PT: 156
RU: 171
PL: 187
CS: 201
SK: 215
HU: 230
4445101213 P 11/2014

Parking aid
Installation and Operating Manual . . . 3
Einparkhilfe
Montage- und Bedienungsanleitung 17
Aide au stationnement
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . 32
Sistema de ayuda para aparcar
Instrucciones de montaje y de uso . 47
Ausilio per il parcheggio
Istruzioni di montaggio e d’uso . . . . 62
Inparkeerhulp
Montagehandleiding en
gebruiksaanwijzing . . . . . . . . . . . . . 77
Parkeringshjælp
Monterings- og
betjeningsvejledning . . . . . . . . . . . . 91
Parkeringshjälp
Monterings- och bruksanvisning . . 105
Parkeringshjälp
Monterings- og bruksanvisning . . . 119
Parkkitutka
Asennus- ja käyttöohje . . . . . . . . . 133
Sistema de ajuda de
parqueamento
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . 147
EN
DE
FR
ES
IT
NL
DA
SV
NO
FI
PT
Парковочный радар
Инструкция по монтажу и
эксплуатации . . . . . . . . . . . . . . . . 162
System parkowania
Instrukcja montażu i obsługi . . . . . 178
Parkovací asistent
Návod k montáži a obsluze. . . . . . 193
Parkovací asistent
Návod na montáž a uvedenie do
prevádzky . . . . . . . . . . . . . . . . . . . 207
Parkolósegéd
Szerelési és használati útmutató . 221
RU
PL
CS
SK
HU
MWE7006

EN
MWE7006
3
Please read this instruction manual carefully before installation and
first use, and store it in a safe place. If you pass on the product to
another person, hand over this instruction manual along with it.
Table of contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety and installation instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Instructions before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Fitting the parking aid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Connecting the parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8 Registering and identifying sensors . . . . . . . . . . . . . . . . . . . . . . . . . . 9
9 Detection range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
10 Setting the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
11 Performing a functional test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
12 Using the parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
13 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
14 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
15 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
16 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

EN
Explanation of symbols MWE7006
4
1 Explanation of symbols
!
A
I
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
Fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
2 Safety and installation instructions
The following texts only complete the figures on the supplementary
sheet. They do not contain the full installation and operating instruc-
tions. Please observe the figures on the supplementary sheet.
Please observe the prescribed safety instructions and stipulations
from the vehicle manufacturer and service workshops.
Observe the applicable legal regulations.
The manufacturer accepts no liability for damage in the following cases:
Damage to the product resulting from mechanical influences and excess
voltage
Alterations to the product without express permission from the manu-
facturer
Use for purposes other than those described in the operating manual
WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
NOTE
Supplementary information for operating the product.

EN
MWE7006 Safety and installation instructions
5
!WARNING!
Secure the parts of the parking aid installed in the vehicle in
such a way that they cannot become loose under any circum-
stances (sudden braking, accidents) and cause injuries to the
occupants of the vehicle.
Do not fit the parts of the parking aid installed where an airbag
may open. This could cause injury if the airbag opens.
The parking aid is intended as an additional aid, which means it
does not relieve you of the obligation to take due care when
manoeuvring.
ANOTICE!
Installing the parking aid can cause problems on vehicles with
LED tail lights.
If you would like to install the sensors on metal bumpers, you
require suitable adapters (not included in the scope of delivery).
Do not expose the control electronics to dampness.
The control electronics must not be installed near other control
modules.
The sensors may not cover signal lamps.
When fitting the sensors, make sure there are no objects fixed
to the vehicle (such as a bicycle rack) that are in the detection
range of the sensors.

EN
Scope of delivery MWE7006
6
3 Scope of delivery
See fig. 1
3.1 Accessories
Available as accessories (not included in the scope of delivery):
4 Intended use
Dometic MWE7006 (item no. 9101500065) is a parking aid based on ultra-
sound. When manoeuvring, it monitors the space behind the vehicle and
provides an audible and visible warning signal for any obstacles it detects.
MWE7006 is designed for installation in motor homes.
No. Quantity Designation Item no.
1 1 Control electronics 9101500069
2 1 Loudspeaker
3 1 Control electronics connection cable
4 1 Sensor distributor 9101500067
5 4 Ultrasonic sensors (black) 9101500068
6 2 Ultrasonic sensors with connection cable 9101500070
7 6 0° sensor holder with cover ring
8 6 10° sensor holder with cover ring
– 2 Extension cable, 3 m
– 1 Fastening material
Designation Item no.
Sensor holder for metal bumper 9101500015
Sensor extension cable, 1.5 m 9103555747
Rubber sensor holder for surface mounting (sensor 9101500070) 9101500071

EN
MWE7006 Instructions before installation
7
5 Instructions before installation
5.1 Painting the sensors
See fig. 2
I
5.2 Determining the place of installation for the
sensors
See fig. 3to fig. 6
I
Note the following during installation:
The area around the sensors must be free from other objects.
The distance from the sensors to the ground should be at least 45 cm and
a maximum of 60 cm (fig. 3).
Note that the installation angle depends on the installation height.
Select the right sensor holder and the appropriate drill diameter by
consulting the table in fig. 3.
If a bicycle rack has been fitted, then install the sensors at least 30 cm
below it (fig. 4).
Supplement to fig. 6
➤Observe the intervals between sensors.
I
NOTE
The sensors may be painted. The manufacturer recommends
having the sensors painted by a specialist workshop.
NOTE
The sensors must be correctly aligned for the device to work
properly.
If they point to the ground, irregularities and bumps on the surface
may be interpreted as obstacles. If they point too far up, obstacles
will not be detected at all.
NOTE
You can also distribute the sensors as shown in alternative B
and C.

EN
Fitting the parking aid MWE7006
8
6 Fitting the parking aid
See fig. 7to fig. 0
Supplement to fig. 8
A
➤Push the sensor holders into the holes until they lock into place.
Supplementary to fig. 0
➤Ensure that the loudspeaker is switched on (ON position).
7 Connecting the parking aid
See fig. a
I
NOTICE! Risk of malfunction!
Align the sensor holders so that the fastening lugs are horizontal.
Otherwise, there is no guarantee the parking aid will function cor-
rectly.
NOTE
On some vehicles, the reversing light only works when the ignition
is switched on. In this case, you must switch on the ignition to
identify the positive and earth cables.
No. Designation Plug socket
for plug
1 Control electronics –
2 Reversing light –
3 Blue/black cable: connection to the reversing light 14
4 Brown cable: connection to earth 2
5 Yellow wire from the loudspeaker 15
6 Blue wire from the loudspeaker 3
7 Red/grey cable: connection to the radio's mute connection
(optional)
6
8 Sensors connection cable 9/21
9 Sensors –

EN
MWE7006 Registering and identifying sensors
9
8 Registering and identifying sensors
The sensors and their position must be registered by the control unit. To do
this, proceed as follows:
➤Switch on the ignition.
➤Engage the reverse gear.
✓The control unit registers the sensors connected.
✓The display on the control unit shows LE.
✓The loudspeaker emits short acoustic signals repeatedly.
Once the registration is complete, LE flashes on the display. The sensors
must now be identified by the control unit.
➤Park the vehicle so that it is surrounded by at least 1.5 m of free space to
ensure the sensors cannot detect any obstacles.
➤Switch the ignition off and on again.
➤Engage the reverse gear.
➤Press both buttons on the control unit for more than three seconds.
✓The control unit registers the sensors connected.
Once the registration is complete, the loudspeaker emits a long acoustic
signal. The sensors must now be identified by the control unit.
The display shows a running light and the loudspeaker emits short acoustic
signals repeatedly.
➤Proceed as follows in accordance with the installation alternative you
selected (fig. 6):
– Alternative A: Use a large object approx. 0.5 m² in size (e.g. a piece of
sturdy paper) and go to sensors 1 to 6 successively (fig. bA)
– Alternatives B and C: Starting at the driver's door, walk around the
vehicle from the first to the last sensor (fig. bB and C).
✓The loudspeaker acknowledges each sensor detected with a short acous-
tic signal.
Once identification is complete, the loudspeaker emits a long acoustic signal.

EN
Detection range MWE7006
10
I
9 Detection range
See fig. c
The detection range of the parking aid is divided into four zones:
Zone 1
This zone is the first limit range. Small objects or those with poor reflective
characteristics may not be detected here.
Zone 2
Nearly all objects in this zone are displayed.
Zone 3
Virtually all objects are displayed in this zone, but some objects may end
up in the blind spot of the sensors.
Stop zone (4)
If there are objects in this zone, the parking aid emits a continuous tone
warning you to stop.
Virtually all objects are displayed in this zone, but some objects may end
up in the blind spot of the sensors.
There must be no objects such as bicycle racks or spare wheels in the
detection range of the sensors, as this would result in an incorrect dis-
play.
The display of fixed objects, such as a trailer coupling or a part of the
spare wheel, can be suppressed (parameters 51, 52 and 53).
NOTE
If an error occurs during this procedure, you can restart the pro-
cedure by pressing both buttons together for longer than three
seconds.

EN
MWE7006 Setting the system
11
10 Setting the system
See fig. cto fig. f
!
The control electronics have the following control elements:
I
Restoring the factory settings
➤Press the right-hand button for longer than 2 s to access programming
mode.
➤The display now shows 01.
➤Press both buttons for longer than two seconds.
✓The display shows F5.
WARNING!
Incorrect settings can impair operational safety.
No. in fig. dDesignation
1 Display F5 Factory settings activated
C5 Your own settings
2, 3 Buttons for setting the system
NOTE
To save the settings, disengage and engage the reverse gear
and wait for 2 s.
To cancel setting the parameters without saving your
changes, or to stop the entire setting process: refrain from
pressing any buttons for a while.

EN
Performing a functional test MWE7006
12
Suppressing use of a bicycle rack or trailer
I
You can use an external switch (not included in the scope of delivery) to:
Switch over the standard stop zone (parameters 47, 48 and 49) to a higher
stop zone (parameters 61, 62 and 63) if you are using a bicycle rack and
this is being folded out.
Deactivate the parking aid while you are using a trailer.
To do this, proceed as follows:
➤Connect pin 17 of the connection cable plug to earth using the external
switch.
➤For trailers only: Set parameter 56 to 00.
Suppressing the display of a trailer coupling or an external spare
wheel
➤Set the parameters 51, 52 and 53 to suit your trailer coupling or your spare
wheel.
11 Performing a functional test
Conduct the functional test of the sensors as follows:
➤Switch on the ignition and engage the reverse gear.
Be very careful when you operate the device for the first time, and make sure
that you familiarize yourself with the various sequences of beeps.
!
NOTE
You can program PIN 17 either for switching over the stop zones
or for deactivation when using a trailer.
WARNING!
In zone 4, some obstacles may not be detected, because they are
no longer within range of the sensors (design-related characteris-
tic).

EN
MWE7006 Using the parking aid
13
12 Using the parking aid
The sensors are activated automatically when you engage the reverse gear
with the ignition on or the engine running. An activation signal is emitted (two
short tones).
As soon as there is an obstacle within the detection range, a repeated signal
tone is emitted.
As you approach, the tone sequence changes, depending on the zone in
which the obstacle is, thereby indicating the distance.
Be very careful the first time you use the system, until you are familiar with
the various sequences of beeps.
!
13 Troubleshooting
The device shows no function.
The cables to the reversing light are not connected or are not properly con-
nected.
The plugs for the sensors are not connected or are not correctly plugged into
the control electronics.
➤Check the plugs and make sure they lock into place.
WARNING!
Stop the vehicle immediately and investigate the situation (getting
out if necessary), if the following happens while you are manoeu-
vring:
the device first indicates an obstacle and the tone sequence
speeds up normally (e.g. from slow to medium) when manoeu-
vring. the signal tone suddenly slows down, or no obstacle is indi-
cated at all.
This means that the original obstacle is in the blind spot of the
sensors (construction-related characteristic), and there is still a
potential for collision.

EN
Troubleshooting MWE7006
14
Low error tone for three seconds after engaging reverse gear
One or more sensors are defective or no longer connected to the control
electronics. The display shows the defective sensor:
for example, E1 for sensor 1
Sensor 1 has the shortest connection cable, sensor 6 the longest.
If more than one sensor is defective, they are shown in succession.
➤Check the plugs and make sure they lock into place.
➤Replace the defective sensor(s).
A
No acoustic signals
The loudspeaker is switched off, or incorrectly connected.
➤Check whether the loudspeaker is switched on.
➤Check whether the loudspeaker is connected correctly.
➤Set parameter 01 to “1” or “2” (see chapter “Setting the system” on
page 11).
Device indicates obstacles incorrectly
False alarms may have the following causes:
Dirt or frost on the sensors.
➤Clean the sensors.
The sensors were incorrectly installed.
➤Adjust the position of the sensors (fig. 3).
➤If necessary, use parameters 41, 42 and 43 to adjust the sensitivity of the
sensors (see chapter “Setting the system” on page 11).
The sensors are in contact with the vehicle chassis.
➤Separate the sensors from the chassis.
The spare wheel is causing false alarms
➤Set the parameters 51, 52 and 53 to suit your spare wheel (see chapter
“Setting the system” on page 11).
NOTICE!
The system does not work if one or more sensors are defective.

EN
MWE7006 Warranty
15
Objects on the vehicle (e.g. spare wheel) are causing false alarms
➤Set parameters 51, 52 and 53 to suit your object to 00 or 01 (see chapter
“Setting the system” on page 11).
➤Adjust the stop zone using the parameters 47, 48 and 49 to suit your object
(see chapter “Setting the system” on page 11).
14 Warranty
The statutory warranty period applies. If the product is defective, please
contact the manufacturer's branch in your country (see the back of the
instruction manual for the addresses) or your retailer.
For repair and guarantee processing, please send the following items:
Defect components
A copy of the receipt with purchasing date
A reason for the claim or description of the fault
15 Disposal
➤Place the packaging material in the appropriate recycling waste bins
wherever possible.
MIf you wish to finally dispose of the product, ask your local recycling
centre or specialist dealer for details about how to do this in
accordance with the applicable disposal regulations.

EN
Technical data MWE7006
16
16 Technical data
I
MWE7006
Item no.: 9101500065
Detection range: approx. 0.60 m up to 3 m
Ultrasound frequency: 58 kHz
Supply voltage: 10 – 32 V
Current: Max. 350 mA
Operating temperature: –35 °C to 70 °C
Certification:
NOTE
The sensors may be painted. The manufacturer recommends
having the sensors painted by a specialist workshop.
E8
