Dometic MagicWatch MWE7006 User manual

1
6x
5
1x
2
1x
1
1x
3
a
90° 10°
a
––
a = 45 cm
a = 60 cm 24 mm
∅ ∅
24 mm
––
4
1x
a
≥
30
30 cm
C
A
B
6x
6
6x
7
Click!
10 – 20 cm
10 – 30 cm
10 – 20 cm
35 – 40 cm 35 – 40 cm30 – 40 cm 30 – 40 cm
35 – 40 cm35 – 40 cm 5 – 10 cm30 – 40 cm 30 – 40 cm
35 – 40 cm 35 – 40 cm
55 cm
55 cm
30 cm 30 cm
1
2
3 4
5
61
2 3 4
5
6
1
2
3 4
5
6
MWE7006
1
3
5
4
2
6
8
7
EN: 7
DE: 21
FR: 36
ES: 51
PT: 66
IT: 81
NL: 96
DA: 110
SV: 124
NO: 137
FI: 151
RU: 165
PL: 180
SK: 194
CS: 208
HU: 222
EN: 7
DE: 21
FR: 36
ES: 51
PT: 66
IT: 81
NL: 96
DA: 110
SV: 124
NO: 137
FI: 151
RU: 165
PL: 180
SK: 194
CS: 208
HU: 222
EN: 7
DE: 21
FR: 36
ES: 51
PT: 66
IT: 81
NL: 96
DA: 110
SV: 124
NO: 137
FI: 151
RU: 165
PL: 180
SK: 194
CS: 208
HU: 222
EN: 6
DE: 20
FR: 35
ES: 50
PT: 65
IT: 80
NL: 95
DA: 109
SV: 123
NO: 136
FI: 150
RU: 164
PL: 179
SK: 193
CS: 179
HU: 221
EN: 5
DE: 19
FR: 34
ES: 49
PT: 64
IT: 79
NL: 94
DA: 108
SV: 122
NO: 135
FI: 149
RU: 163
PL: 178
SK: 192
CS: 206
HU: 220
MWE7006-IO-16s.book Seite 1 Montag, 29. August 2016 9:05 21

2
Dometic WAECO International GmbH
Hollefeldstrasse 63
D-48282 Emsdetten
www.dometic.com
1
2
br
rt/gr
bl/sw
gebl
5
6
7
4
9
31
21 9 3 156142
2
8
3
sw
sw
1
15
R
93,5
45 – 75 cm
45 – 75 cm
45 – 75 cm
B
C
A
1
2
3 4
5
6
15
2
R3
4
1.
2.
2.
1.
654321
ON!
0
b
EN DE FR ES PT IT NL DA
bl Blue Blau Bleu Azul Azul Blu Blauw Blå
br Brown Braun Marron Marrón Castanho Marrone Bruin Brun
ge Yellow Gelb Jaune Amarillo Amarelo Giallo Geel Gul
gr Grey Grau Gris Gris Cinzento Grigio Grijs Grå
rt Red Rot Rouge Rojo Vermelho Rosso Rood Rød
sw Black Schwarz Noir Negro Preto Nero Zwart Sort
SV NO FI PL RU SK CS HU
bl Blå Blå Sininen Niebieski Синий Modrá Modrá Kék
br Brun Brun Ruskea Brązowy Коричневый Hnedá Hněda Barna
ge Gul Gul Keltainen Żółty Желтый Žltá Žlutá Sárga
gr Grå Grå Harmaa Zielony Зеленый Zelená Zelená Szürke
rt Röd Rød Punainen Czerwony Красный Červená Červená Piros
sw Svart Svart Musta Czarny Черный Čierna Černá Fekete
9
a
c
EN: 8
DE: 23
FR: 38
ES: 53
PT: 68
IT: 83
NL: 97
DA: 111
SV: 125
NO: 138
FI: 152
RU: 167
PL: 181
SK: 195
CS: 209
HU: 223
EN: 9
DE: 24
FR: 39
ES: 54
PT: 69
IT: 84
NL: 98
DA: 112
SV: 126
NO: 139
FI: 153
RU: 168
PL: 182
SK: 196
CS: 210
HU: 224
4445101742 08/2016
MWE7006-IO-16s.book Seite 2 Montag, 29. August 2016 9:05 21

MWE7006
Parking aid
Installation and Operating Manual. . . . . . . .3
Einparkhilfe
Montage- und Bedienungsanleitung . . . . . 17
Aide au stationnement
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . . . .32
Sistema de ayuda para aparcar
Instrucciones de montaje y de uso . . . . . . .47
Sistema de ajuda de parqueamento
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Ausilio per il parcheggio
Istruzioni di montaggio e d’uso . . . . . . . . .77
Inparkeerhulp
Montagehandleiding en
gebruiksaanwijzing . . . . . . . . . . . . . . . . . . .92
Parkeringshjælp
Monterings- og betjeningsvejledning . . .106
Parkeringshjälp
Monterings- och bruksanvisning . . . . . . . 120
Parkeringshjälp
Monterings- og bruksanvisning. . . . . . . . 133
Parkkitutka
Asennus- ja käyttöohje . . . . . . . . . . . . . . . 147
Парковочный радар
Инструкция по монтажу и эксплуатации 161
System parkowania
Instrukcja montażu i obsługi. . . . . . . . . . . 176
Parkovací asistent
Návod na montáž a uvedenie
do prevádzky. . . . . . . . . . . . . . . . . . . . . . . 190
Parkovací asistent
Návod k montáži a obsluze . . . . . . . . . . . 204
Parkolósegéd
Szerelési és használati útmutató . . . . . . . 218
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
SAFETY & SECURITY
MAGICWATCH
MWE7006-IO-16s.book Seite 1 Montag, 29. August 2016 9:09 21

MWE7006-IO-16s.book Seite 2 Montag, 29. August 2016 9:09 21

EN
MWE7006
3
Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 Safety and installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
6 Instructions before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
7 Fitting the parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
8 Connecting the parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
9 Registering and identifying sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
10 Detection range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
11 Setting the system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
12 Performing a functional test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
13 Using the parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
14 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
15 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
16 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
17 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
MWE7006-IO-16s.book Seite 3 Montag, 29. August 2016 9:09 21

EN
Explanation of symbols MWE7006
4
1 Explanation of symbols
!
A
I
2 Safety and installation instructions
The following texts only complete the figures on the supplementary sheet.
They do not contain the full installation and operating instructions. Please
observe the figures on the supplementary sheet.
Pleaseobservetheprescribed safetyinstructionsand stipulations fromthe
vehicle manufacturer and service workshops.
Observe the applicable legal regulations.
The manufacturer accepts no liability for damage in the following cases:
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
!WARNING!
•Secure the parts of the parking aid installed in the vehicle in such a way
that they cannot become loose under any circumstances (sudden
braking, accidents) and cause injuries to the occupants of the
vehicle.
•Do not fit the parts of the parking aid installed where an airbag may
open. This could cause injury if the airbag opens.
•The parking aid is intended as an additional aid, which means it does
not relieve you of the obligation to take due care when manoeuvring.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
MWE7006-IO-16s.book Seite 4 Montag, 29. August 2016 9:09 21

EN
MWE7006 Scope of delivery
5
ANOTICE!
•Installing the parking aid can cause problems on vehicles with LED tail
lights.
•If you would like to install the sensors on metal bumpers, you require
suitable adapters (not included in the scope of delivery).
•Do not expose the control electronics to dampness.
•The control electronics must not be installed near other control
modules.
•The sensors may not cover signal lamps.
•When fitting the sensors, make sure there are no objects fixed to the
vehicle (such as a bicycle rack) that are in the detection range of the
sensors.
3Scopeofdelivery
See fig. 1
No. Quantity Designation Ref. no.
1 1 Control electronics 9101500069
21Loudspeaker
3 1 Control electronics connection cable
4 1 Sensor distributor 9101500067
5 6 Ultrasonic sensors with connection cable 9101500070
6 6 0° sensor holder with cover ring
7 6 10° sensor holder with cover ring
– 2 Extension cable, 3 m
– 1 Fastening material
MWE7006-IO-16s.book Seite 5 Montag, 29. August 2016 9:09 21

EN
Accessories MWE7006
6
4Accessories
Available as accessories (not included in the scope of delivery):
5 Intended use
Dometic MWE7006 (ref. no. 9600000359) is a parking aid based on ultrasound.
When manoeuvring, it monitors the space behind the vehicle and provides an audi-
ble and visible warning signal for any obstacles it detects.
MWE7006 is designed for installation in motor homes.
6 Instructions before installation
6.1 Painting the sensors
See fig. 2
I
Designation Ref. no.
Sensor holder for metal bumper 9101500015
Sensor extension cable, 1.5 m 9103555747
Subframe sensor holder (fig. c1) 9101500078
Rubber sensor holder for surface mounting (fig. c2) 9101500071
Loudspeaker MWD-900
LED display 9101500079
NOTE
The sensors may be painted. The manufacturer recommends having the
sensors painted by a specialist workshop.
MWE7006-IO-16s.book Seite 6 Montag, 29. August 2016 9:09 21

EN
MWE7006 Fitting the parking aid
7
6.2 Determining the place of installation for the sensors
See fig. 3to fig. 6
I
Note the following during installation:
•The area around the sensors must be free from other objects.
•The distance from the sensors to the ground should be at least 45 cm and a
maximum of 60 cm (fig. 3).
•Note that the installation angle depends on the installation height.
Select the right sensor holder and the appropriate drill diameter by consulting
the table in fig. 3.
•If a bicycle rack has been fitted, then install the sensors at least 30 cm below it
(fig. 4).
Supplement to fig. 6
➤Observe the intervals between sensors.
I
7 Fitting the parking aid
See fig. 7to fig. 0
Supplement to fig. 8
A
➤Push the sensor holders into the holes until they lock into place.
Supplementary to fig. 0
➤Ensure that the loudspeaker is switched on (Middle or High position).
NOTE
The sensors must be correctly aligned for the device to work properly.
If they point to the ground, irregularities and bumps on the surface may
be interpreted as obstacles. If they point too far up, obstacles will not be
detected at all.
NOTE
You can also distribute the sensors as shown in alternative B and C.
NOTICE! Risk of malfunction!
Align the sensor holders so that the fastening lugs are horizontal. Other-
wise, there is no guarantee the parking aid will function correctly.
MWE7006-IO-16s.book Seite 7 Montag, 29. August 2016 9:09 21

EN
Connecting the parking aid MWE7006
8
8 Connecting the parking aid
See fig. a
INOTE
On some vehicles, the reversing light only works when the ignition is
switched on. In this case, you must switch on the ignition to identify the
positive and earth cables.
No. Designation Plug socket
for plug
1 Control electronics –
2 Reversing light –
3 Blue/black cable: connection to the reversing light 14
4 Brown cable: connection to earth 2
5 Yellow wire from the loudspeaker 15
6 Blue wire from the loudspeaker 3
7 Red/grey cable: connection to the radio's mute connection
(optional)
6
8 Sensors connection cable 9/21
(12/24)
(10/22)
(11/23)
9 Sensors –
MWE7006-IO-16s.book Seite 8 Montag, 29. August 2016 9:09 21

EN
MWE7006 Registering and identifying sensors
9
9 Registering and identifying sensors
The sensors and their position must be registered by the control unit. To do this,
proceed as follows:
➤Switch on the ignition.
➤Engage the reverse gear.
✓The control unit registers the sensors connected.
✓The display on the control unit shows LE.
✓The loudspeaker emits short acoustic signals repeatedly.
Once the registration is complete, LE flashes on the display. The sensors must now
be identified by the control unit.
➤Park the vehicle so that it is surrounded by at least 1.5 m of free space to ensure
the sensors cannot detect any obstacles.
➤Switch the ignition off and on again.
➤Engage the reverse gear.
➤Press both buttons on the control unit for more than three seconds.
✓The control unit registers the sensors connected.
Once the registration is complete, the loudspeaker emits a long acoustic signal. The
sensors must now be identified by the control unit.
The display shows a running light and the loudspeaker emits short acoustic signals
repeatedly.
➤Proceed as follows in accordance with the installation alternative you selected
(fig. 6):
– Alternative A: Use a large object approx. 0.5 m² in size (e.g. a piece of sturdy
paper) and go to sensors 1 to 6 successively (fig. bA)
– Alternatives B and C: Starting at the driver's door, walk around the vehicle
from the first to the last sensor (fig. bB and C).
✓The loudspeaker acknowledges each sensor detected with a short acoustic
signal.
Once identification is complete, the loudspeaker emits a long acoustic signal.
INOTE
If an error occurs during this procedure, you can restart the procedure
by pressing both buttons together for longer than three seconds.
MWE7006-IO-16s.book Seite 9 Montag, 29. August 2016 9:09 21

EN
Detection range MWE7006
10
10 Detection range
See fig. d
The detection range of the parking aid is divided into four zones:
•Zone 1
This zone is the first limit range. Small objects or those with poor reflective
characteristics may not be detected here.
•Zone 2
Nearly all objects in this zone are displayed.
•Zone 3
Virtually all objects are displayed in this zone, but some objects may end up in the
blind spot of the sensors.
•Stop zone (4)
If there are objects in this zone, the parking aid emits a continuous tone warning
you to stop.
Virtually all objects are displayed in this zone, but some objects may end up in
the blind spot of the sensors.
There must be no objects such as bicycle racks or spare wheels in the detection
range of the sensors, as this would result in an incorrect display.
The display of fixed objects, such as a trailer coupling or a part of the spare
wheel, can be suppressed (parameters 51, 52 and 53).
MWE7006-IO-16s.book Seite 10 Montag, 29. August 2016 9:09 21

EN
MWE7006 Setting the system
11
11 Setting the system
See fig. dto fig. g
!
The control electronics have the following control elements:
I
Restoring the factory settings
➤Press the right-hand button for longer than 2 s to access programming mode.
➤The display now shows 01.
➤Press both buttons for longer than two seconds.
✓The display shows F5.
WARNING!
Incorrect settings can impair operational safety.
No. in fig. eDesignation
1DisplayF5 Factory settings activated
C5 Your own settings
2, 3 Buttons for setting the system
NOTE
•To save the settings, disengage and engage the reverse gear and
wait for 2 s.
•To cancel setting the parameters without saving your changes,
or to stop the entire setting process: refrain from pressing any
buttons for a while.
MWE7006-IO-16s.book Seite 11 Montag, 29. August 2016 9:09 21

EN
Performing a functional test MWE7006
12
Suppressing use of a bicycle rack or trailer
I
You can use an external switch (not included in the scope of delivery) to:
•Switch over the standard stop zone (parameters 47, 48 and 49) to a higher stop
zone (parameters 61, 62 and 63) if you are using a bicycle rack and this is being
folded out.
•Deactivate the parking aid while you are using a trailer.
To do this, proceed as follows:
➤Connect pin 17 of the connection cable plug to earth using the external switch.
➤For trailers only: Set parameter 56 to 00.
Suppressing the display of a trailer coupling or an external spare wheel
➤Set the parameters 51, 52 and 53 to suit your trailer coupling or your spare wheel.
12 Performing a functional test
Conduct the functional test of the sensors as follows:
➤Switch on the ignition and engage the reverse gear.
Be very careful when you operate the device for the first time, and make sure that you
familiarize yourself with the various sequences of beeps.
!
NOTE
You can program PIN 17 either for switching over the stop zones or for
deactivation when using a trailer.
WARNING!
In zone 4, some obstacles may not be detected, because they are no
longer within range of the sensors (design-related characteristic).
MWE7006-IO-16s.book Seite 12 Montag, 29. August 2016 9:09 21

EN
MWE7006 Using the parking aid
13
13 Using the parking aid
The sensors are activated automatically when you engage the reverse gear with the
ignition on or the engine running. An activation signal is emitted (two short tones).
As soon as there is an obstacle within the detection range, a repeated signal tone is
emitted.
As you approach, the tone sequence changes, depending on the zone in which the
obstacle is, thereby indicating the distance.
Be very careful the first time you use the system, until you are familiar with the various
sequences of beeps.
!
14 Troubleshooting
The device shows no function.
The cables to the reversing light are not connected or are not properly connected.
The plugs for the sensors are not connected or are not correctly plugged into the
control electronics.
➤Check the plugs and make sure they lock into place.
WARNING!
Stop the vehicle immediately and investigate the situation (getting out if
necessary), if the following happens while you are manoeuvring:
the device first indicates an obstacle and the tone sequence speeds up
normally (e.g. from slow to medium) when manoeuvring. the signal tone
suddenly slows down, or no obstacle is indicated at all.
This means that the original obstacle is in the blind spot of the sensors
(construction-related characteristic), and there is still a potential for
collision.
MWE7006-IO-16s.book Seite 13 Montag, 29. August 2016 9:09 21

EN
Troubleshooting MWE7006
14
Low error tone for three seconds after engaging reverse gear
One or more sensors are defective or no longer connected to the control
electronics. The display shows the defective sensor:
•for example, E1 for sensor 1
Sensor 1 has the shortest connection cable, sensor 6 the longest.
•If more than one sensor is defective, they are shown in succession.
➤Check the plugs and make sure they lock into place.
➤Replace the defective sensor(s).
A
No acoustic signals
The loudspeaker is switched off, or incorrectly connected.
➤Check whether the loudspeaker is switched on.
➤Check whether the loudspeaker is connected correctly.
➤Set parameter 01 to “1” or “2” (see chapter “Setting the system” on page 11).
Device indicates obstacles incorrectly
False alarms may have the following causes:
•Dirt or frost on the sensors.
➤Clean the sensors.
•The sensors were incorrectly installed.
➤Adjust the position of the sensors (fig. 3).
➤If necessary, use parameters 41, 42 and 43 to adjust the sensitivity of the sensors
(see chapter “Setting the system” on page 11).
•The sensors are in contact with the vehicle chassis.
➤Separate the sensors from the chassis.
The spare wheel is causing false alarms
➤Set the parameters 51, 52 and 53 to suit your spare wheel (see chapter “Setting the
system” on page 11).
NOTICE!
The system does not work if one or more sensors are defective.
MWE7006-IO-16s.book Seite 14 Montag, 29. August 2016 9:09 21

EN
MWE7006 Warranty
15
Objects on the vehicle (e.g. spare wheel) are causing false alarms
➤Set parameters 51, 52 and 53 to suit your object to 00 or 01 (see chapter “Setting
the system” on page 11).
➤Adjust the stop zone using the parameters 47, 48 and 49 to suit your object (see
chapter “Setting the system” on page 11).
15 Warranty
The statutory warranty period applies. If the product is defective, please contact the
manufacturer's branch in your country (see the back of the instruction manual for the
addresses) or your retailer.
For repair and guarantee processing, please send the following items:
•Defect components
•A copy of the receipt with purchasing date
•A reason for the claim or description of the fault
16 Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
MWE7006-IO-16s.book Seite 15 Montag, 29. August 2016 9:09 21

EN
Technical data MWE7006
16
17 Technical data
I
MWE7006
Ref. no.: 9600000359
Detection range: approx. 0.60 m up to 3 m
Ultrasound frequency: 58 kHz
Supply voltage: 10 – 32 V
Current: Max. 350 mA
Operating temperature: –35 °C to 70 °C
Certification:
NOTE
The sensors may be painted. The manufacturer recommends having the
sensors painted by a specialist workshop.
E8
MWE7006-IO-16s.book Seite 16 Montag, 29. August 2016 9:09 21

DE
MWE7006
17
Bitte lesen Sie diese Anleitung vor Einbau und Inbetriebnahme sorgfältig
durch und bewahren Sie sie auf. Geben Sie sie im Falle einer Weitergabe
des Produktes an den Nutzer weiter.
Inhaltsverzeichnis
1 Erklärung der Symbole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
2 Sicherheits- und Einbauhinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4 Zubehör. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5 Bestimmungsgemäßer Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 Hinweise vor dem Einbau. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7 Einparkhilfe montieren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8 Einparkhilfe anschließen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9 Sensoren registrieren und identifizieren . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10 Erfassungsbereich. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
11 System einstellen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
12 Funktion testen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
13 Einparkhilfe benutzen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
14 Fehler suchen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
15 Gewährleistung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
16 Entsorgung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
17 Technische Daten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
MWE7006-IO-16s.book Seite 17 Montag, 29. August 2016 9:09 21

DE
Erklärung der Symbole MWE7006
18
1 Erklärung der Symbole
!
A
I
2 Sicherheits- und Einbauhinweise
DiefolgendenTexteergänzen dieAbbildungenaufdemBeiblatt lediglich.
Sie alleine sind keine vollständigen Einbau- und Bedienhinweise! Bitte
beachten Sie unbedingt die Abbildungen auf dem Beiblatt!
Beachten Sie die vom Fahrzeughersteller und vom Kfz-Handwerk
vorgeschriebenen Sicherheitshinweise und Auflagen!
Beachten Sie die geltenden gesetzlichen Vorschriften.
Der Hersteller übernimmt in folgenden Fällen keine Haftung für Schäden:
•Beschädigungen am Produkt durch mechanische Einflüsse und Über-
spannungen
•Veränderungen am Produkt ohne ausdrückliche Genehmigung vom Hersteller
•Verwendung für andere als die in der Anleitung beschriebenen Zwecke
!WARNUNG!
•Befestigen Sie die im Fahrzeug montierten Teile der Einparkhilfe so,
dass sie sich unter keinen Umständen (scharfes Abbremsen, Verkehrs-
unfall) lösen und zu Verletzungen der Fahrzeuginsassen führen
können.
•Montieren Sie die im Fahrzeug montierten Teile der Einparkhilfe nicht
im Wirkungsbereich eines Airbags. Sonst besteht Verletzungsgefahr,
wenn der Airbag auslöst.
WARNUNG!
Sicherheitshinweis: Nichtbeachtung kann zu Tod oder schwerer
Verletzung führen.
ACHTUNG!
Nichtbeachtung kann zu Materialschäden führen und die Funktion des
Produktes beeinträchtigen.
HINWEIS
Ergänzende Informationen zur Bedienung des Produktes.
MWE7006-IO-16s.book Seite 18 Montag, 29. August 2016 9:09 21
