Dormakaba RTS Series User manual

RTS Series Package 06
Side load wood door and aluminum frame
Installation instructions
08280271 – 02-2020
| EN |

2RTS88 Closers 02-2020
08280271
dormakaba RTS88 Package 06 Installation Instructions Table of Contents
Table of contents
1 Installation instructions 3
1.1 Prepare frame and install closer 3
1.2 Prepare top of door and install closer arm 4
1.3 Prepare bottom of door, install arm and
floor bearing 5
1.4 Install door 6
2 Adjustments 7
2.1 Door alignment 7
2.2 Clearance requirements 7
2.3 Adjust closing speeds 8
3 Door removal 8

dormakaba RTS88 Package 06 Installation Instructions
08280271 02-2020RTS88 Closers 3
Frame
Closer
. Prepare frame and install closer
1 Installation instructions
Fig.
1.1.1 Prepare header and side jamb according to
template.
1.1.2 Fasten mounting bracket to side jamb with
three No. 8-32 pan head machine screws.
1.1.3 Fasten header to side jamb with two No. 10-32
flat head machine screws.
1.1.4 Fasten two 1/4-20 flat head machine screws to
header with lock washers and nuts.
1.1.5 Fasten angle bracket to closer with 2 hex head
machine screws and flat washers.
1.1.6 Install 2 fillister head machine screws into
mounting tabs on closer.
1.1.7 Make approximately 3 turns.
NOTE: For RTS88 models only, do not remove spacer
washers.
1.1.8 Install closer into header by inserting
mounting tabs into mounting bracket.
1.1.9 Raise end of closer with angle bracker onto
the two 1/4-20 screws.
1.1.10 Fasten angle bracket with teh two remaining
1/4-20 nuts and lock washers.
1.1.11 Tighten the two fillister machine screws.
TIGHTEN SECURELY!
1.1.12 Install cover plate by sliding tab into frame.
1.1.13 Fasten opposite end to mounting bracket with
two No. 8-32 flat head machine screw
provided.
Header
Mounting bracket
Angle bracket
Fillister head
machine
screws Closer
Cover plateSide
jamb
1/4-20 flat
head machine
screws,
washers, nuts
1/4-20 nuts
and lock
washers

dormakaba RTS88 Package 06 Installation Instructions
08280271 02-2020RTS88 Closers
4
Top of door
Top arm
. Prepare top of door and install closer arm
Fig.
Adjustment
stud
1/4-20 hex
head alignment
screws
Lateral
adjustment
screw
Closer arm
Closer
Cover plate
1.2.1 Prepare top of door according to template.
NOTE: Cut-out side of door should face interior of
building.
1.2.2 Fasten 8832 mounting channel to door with
four No. 12 flat head wood screws.
1.2.3 Install two 1/4-20 hex head alignment screws
into closer arm.
1.2.4 Place arm over adjustment stud in arm
channel.
1.2.5 Center arm in door, turning both 1/4-20 hex
head alignment screws counter-clockwise
until they are wedged against door channel.
1.2.6 Thread lateral adjustment screw into
adjustment stud on 8832 mounting channel.
1.2.7 Secure arm into place with 1/4-20 flat head
machine screw and flat washer.
1/4-20 flat
head machine
screw and flat
washer
Mounting
channel
Header
Side
jamb
No.12 flat head
wood screws

dormakaba RTS88 Package 06 Installation Instructions
08280271 02-2020RTS88 Closers 5
Bottom of door
Bottom arm
Floor bearing
. Prepare bottom of door, install arm and floor bearing
Fig.
1.3.1 Prepare bottom of door according to template.
1.3.2 Fasten arm to door with five No. 14 flat head
wood screws.
1.3.3 Prepare floor according to template.
1.3.4 Fasten floor bearing with three flat head wood
screws and plastic anchors.
• Optional: see template for threshold
preparation.
Closer
Arm Floor bearing
Header
Side
jamb

dormakaba RTS88 Package 06 Installation Instructions
08280271 02-2020RTS88 Closers
6
Install the door
. Install door
Fig.
1.4.1 With door parallel to opening, place bottom of
door onto floor bearing.
1.4.2 Push door to vertical position until closer
spindle is completely engaged into closer arm.
1.4.3 Fasten clamping block to arm with three
1/4-20 socket head cap screws.
NOTE: Alternate fastening screws when tightening
clamping block. TIGHTEN SECURELY!
1.4.4 Fasten arm cover plate to door with screws
provided.
Closer arm/
Top rail arm
Closer
Clamping
block
Socket head
cap screws
Arm cover
plate
Header
Side
jamb
Floor
bearing

dormakaba RTS88 Package 06 Installation Instructions
08280271 02-2020RTS88 Closers 7
Adjustments - door alignment
Adjustments - clearances
2 Adjustments
Lateral
adjustment
screw
Closer
Cover plate
1/4-20 flat
head screw
. Door alignment
Fig.
2.1.1 Double acting -
• Center door in frame by loosening 1/4-20 flat
head screw and adjusting the two 1/4-20 hex
head alignment screws as required.
• To adjust clearance between door and frame,
adjust lateral adjustment screw.
• Retighten 1/4-20 flat head screw.
• TIGHTEN SECURELY!
1/4-20 hex
head alignment
screws
2.1.2 Single acting -
• Adjust arm to insure that door closes tightly
against stop.
• Loosen 1/4-20 flat head screw.
• Adjust closer arm fully in the direction of door
swing.
• To adjust clearance between door and frame,
adjust lateral adjustment screw.
• Retighten 1/4-20 flat head screw.
• TIGHTEN SECURELY!
. Clearance requirements
Fig.
2.2.1 The standard spindle for 7471K will achieve a
door clearance of 11/16” measured from
finished floor to bottom of door.
2.2.2 See chart on template for optional spindles
and door clearances.

dormakaba RTS88 Package 06 Installation Instructions
08280271 02-2020RTS88 Closers
8
Adjustments - closing speeds
Door removal
2.3.1 Valve “A” - controls closing speed from
maximum opening angle to 0°.
• Clockwise - decreases closing speed
• Counter-clockwise - increases closing speed
2.3.2 Valve “B” - increases closing speed from
maximum openig angle to 20°.
Counter-clockwise - increases closing speed.
Valve “B”
“A”
“B”
20°
Valve “A”
. Adjust closing speeds
Fig.
3 Door removal
Fig.
Clamping
block
Closer
Arm cover
plate
3.1.1 Remove arm cover plate from
side of door.
3.1.2 Remove clamping block from
top arm.
3.1.3 Lean top of door out until it
clears frame.
3.1.4 Lift door off of floor bearing.
Floor
bearing
