Doro PHONEEASY 410GSM User manual

PhoneEasy
410gsm






















20 17
18
21

Loudspeaker
Display
Left soft key
Call key
1/ Voice mail
Numeric keypad
Microphone
#/ Silent mode
End call/Power on/off
Arrow keys
Right soft key
For lanyard attaching
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Charging contacts, for use
with charging stand (not
included)
Led light (new message/
missed call)
Led light (battery level low)
Emergency call key
Charging socket
Headset socket
Battery cover
Side key +
Side key -
13.
14.
15.
16.
17.
18.
19.
20.
21.
English
Altavoz
Pantalla
Tecla programable izquierda
Tecla de llamada
1/ Buzón de voz
Teclado numérico
Micrófono
#/ modo Silencio
Fin. llam. / Encender / Apagar
Teclas de echa
Tecla programable derecha
Collar porta teléfono
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Cargando contactos (para
utilizar con soporte cargador)
Indicador LED
(nuevo mensaje)
Indicador LED
(nivel de batería bajo)
Tecla de llamada de
emergencia
Toma para el cargador
Toma para auriculares
Tapa de la batería
Tecla lateral (+)
Tecla lateral (-)
13.
14.
15.
16.
17.
18.
19.
20.
21.
Español
Attaching a lanyard
to the phone
Collar porta teléfono
12

1
English
Contents
Installation .................................... 3
Installing the SIM card and battery. . . . . . . . . . . . . . . . . . 3
Charging .................................... 4
Operation...................................... 5
Activatingthephone............................ 5
Makingacall................................. 6
Making a call from the Phonebook . . . . . . . . . . . . . . . . . . 6
Receivingacall ............................... 6
Volumecontrol................................ 6
DisplaySymbols................................. 7
AdditionalFunctions.............................. 8
Calloptions .................................. 8
Callwaiting .................................. 9
Callinformation ............................... 9
Calllog ..................................... 9
Phonebook.................................. 10
Silentmode................................. 11
Headset.................................... 12
SOScalls................................... 12
EmergencyCallkey............................ 13
Alarm...................................... 14
Games..................................... 14
Calendar ................................... 15
Calculator................................... 15
FMradio ................................... 16
Textinput................................... 18
SMSMessaging................................ 19
Creating and sending SMS. . . . . . . . . . . . . . . . . . . . . . . 19
IncomingSMS(Inbox).......................... 19
OutgoingSMS(Outbox)......................... 20

2
English
Settings...................................... 22
Timeanddate................................ 22
Usersetup.................................. 23
Tone settings (rings & tones) . . . . . . . . . . . . . . . . . . . . . 25
Silent...................................... 26
Bluetoothsettings............................. 27
Blockingfunctions ............................ 28
Emergency.................................. 28
Voicemail .................................. 29
Speeddial.................................. 30
Callsetup................................... 30
Messages................................... 32
Securitysettings.............................. 34
MasterReset ................................ 35
MasterClear................................. 36
Troubleshooting ................................ 37
SafetyInstructions.............................. 39
Disclaimer and Limitation of Liability . . . . . . . . . . . . . . . . . 44
CareandMaintenance ........................... 45
Warranty and Technical Data . . . . . . . . . . . . . . . . . . . . . . . 46

3
English
Installation
Note!
Turn off the phone and disconnect the charger before
removing the battery cover.
Installing the SIM card and battery
The SIM card holder is located behind the battery.
Remove the battery cover by pressing it carefully down and
sliding away from the emergency call key.
Remove the battery if it is already installed.
Press lightly on the cardholder and carefully slide it towards
the emergency call key.
The SIM card holder can now be folded into an upright position.
Placing the SIM-card on the marked area of the
compartment. Make sure that the SIM card’s contacts are
facing downwards and that the cut-off corner is placed
accordingly with the marked area. See picture. Take care not
to scratch or bend the contacts on the SIM card.
Fold the SIM-card holder down and carefully slid it away from
the emergency call key until it “clicks” into place.
Insert the battery by sliding it into the battery compartment
with the contacts facing towards the emergency call key.
Replace the battery cover until it “clicks” into place.
1.
2.
3.
4.
5.
6.
7.
8.

4
English
Charging
Warning!
Only use batteries, charger and accessories that have been
approved for use with this particular model. Connecting
other accessories may be dangerous and may invalidate the
phone’s type approval and guarantee.
When the battery is running low, is displayed and a warning
signal is heard. To charge the battery, connect the mains adapter
to a wall socket and to the charging socket y.
is displayed briey when the charger is connected to the
phone, and when it is disconnected.
The battery charge indicator will be animated while charging.
It takes approximately 3 hours to fully charge the battery.
is displayed on the screen when charging is completed.
Note!
Full battery capacity will not be reached until the battery has
been charged 3–4 times.
Batteries degrade over time, which means that call time and
standby time will normally decrease with regular use.
Phone indicators
When 5 ash you have a new message or a missed call.
When ] ash the battery is running low.

5
English
Operation
Activating the phone
Press and hold the red button on the phone to turn it on/off.
It takes several seconds so keep holding until you hear the sound.
The following messages may be displayed:
SIM card missing or
incorrectly inserted.
SIM card damaged or not
valid.
If the SIM card is valid but protected with a PIN code (Personal
Identication Number), PIN: is displayed.
Enter the PIN code and press OK ( upper left corner of
keypad).
Delete with Clear ( upper right corner of keypad).
Note!
If PIN and PUK codes were not provided with your SIM card,
please contact your network operator.
Trials: # shows the number of PIN attempts left. When no
more attempts remain, SIM blocked is displayed. The SIM
card must now be unlocked with the PUK code (Personal
Unblocking Key).
OK.
OK.
Setting the language, time and date
These are all set for you. The menu language will default to
English. See the full manual if you would like to change this
setting. The date and time are automatically set to the local time
for the area you are in when the phone is powered on.

6
English
Making a call
Enter the phone number. Delete with Clear.
Press qto dial. Press Cancel to cancel dialing.
Press Lto end the call.
Note!
When making international calls, press *twice for the
     
code (instead of 00 or similar) for best operation.
Making a call from the Phonebook
Press Name to open the Phonebook.
Use the arrow keys /to scroll through the
Phonebook, or quick search by pressing the key
corresponding to the rst letter of the entry, see .
Press Call to dial the selected entry, or press Back to return
to standby mode.
Receiving a call
Press qto answer, or press Silent to switch off the ring
signal and then Reject to reject the call (busy signal).
Alternatively, press Lto reject the call directly.
Press Lto end the call.
See also Call options.
Volume control
Use the side keys +/– to adjust the sound volume during a call.
The volume level is indicated on the display.
1.
2.
3.
1.
2.
3.
1.
2.

7
English
Display Symbols
Signal strength Headset connected
Ring only Bluetooth on
Vib & ring Bluetooth connected
Vib only Battery level
Alarm active New message
Silent
SIM card missing Charger connected
SIM card error Charger disconnected
Mute Headset connected
New message Headset disconnected
SOS calls only Handsfree on
OK (conrmed) Handsfree off
Query Warning
Battery level low Error
Calling Charging (animated)
Incoming call Call ended
Searching Missed call
Progressing (animated) Call on-hold
