D8RE2 Troubleshooting - Part 1
This D8RE2 - 40 GPM Troubleshooting Part 1 will cover: The injector is clicking, but not
drawing the concentrate.
Scan the QR code to
watch our D8RE2 -
Troubleshooting video.
Step 1: Take a look at the strainer. If it is clogged clean it and
retest your Dosatron. If there is still no suction but the Dosatron is
clicking turn the water on.

Page 2
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D8RE2 Troubleshooting - Part 1
Step 6: Press the air bleed button on the bell housing a few times
to release the pressure.
Step 5: After you reattach you should see the liquid begin
moving up the suction hose. If you don’t see liquid moving up the
hose or you don’t feel suction on your nger, turn the water off.
Step 4: If you feel suction, just cut a half inch off the top of the
hose and reattach. If the hose is cracked, ridged, or looks really
old just replace it.

Page 3
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 9: Unscrew the injection stem nut.
Step 8: Remove the suction hose. Set it aside.
D8RE2 Troubleshooting - Part 1
Step 7: Unscrew the suction hose nut.

Page 4
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 12: To change the plunger seal, pinch and roll it off
the plunger.
Step 11: Take a close look at the plunger seal for nicks, scratches,
or wear. If you see damage or don’t remember the last time you
changed the plunger seal, just replace it now (Part #: JDI121).
D8RE2 Troubleshooting - Part 1
Step 10: Pull the injection stem straight out from the body of the
injector.

Page 5
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 15: Then, reinstall the injection stem nut, hand tight.
Step 14: To reinstall the injection stem, align the notches in the
lower part of the blue body with the teeth on the top of the injection
stem assembly.
D8RE2 Troubleshooting - Part 1
Step 13: Install the new one into the groove on the plunger.

Page 6
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 18: Reinstall the nut hand tight.
Step 17: Pull the stem down slightly, rotate it and push it back up.
D8RE2 Troubleshooting - Part 1
Step 16: If the scale you prefer is not facing out, just loosen the
stem nut and remove.

Page 7
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D8RE2 Troubleshooting - Part 1
Step 19: Your injector should now be drawing the concentrate.

Page 8
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 3: Grab the barb and pull the check valve assembly
straight out.
Step 2: Unscrew and remove the check valve nut.
Step 1: Remove the hose nut and hose, set aside.
D8RE2 Troubleshooting - Part 2
This D8RE2 - 40 GPM Troubleshooting Part 2 will cover: The injector is pushing water
down into the concentrate tank.

Page 9
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 4: To inspect the check valve parts, hold the assembly
and twist the white top guide one quarter turn counter
clockwise to remove.
D8RE2 Troubleshooting - Part 2
Step 5: Remove the spring and cone.
Step 6: Inspect all of the check valve parts. If they are dirty, you
may be able to soak, brush off, and re-install. If you see damage
or if you don’t remember the last time you changed these parts,
just replace them now (Part #: PJDI118).

Page 10
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 9: Position the top guide over the shaft.
Step 8: Then slide the spring over the shaft.
Step 7: Insert the cone into the top of the barb.
D8RE2 Troubleshooting - Part 2

Page 11
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 12: You can now reinstall the check valve assembly
into the stem.
Step 11: Give it a tug to make sure everything is in position.
Step 10: Align the guide and twist it one quarter turn
clockwise to lock.
D8RE2 Troubleshooting - Part 2

Page 12
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 15: Slide it onto the barb and hand tighten the nut. This
should stop the water from dripping back into the concentrate tank.
Step 14: Thread the suction hose nut onto the hose.
Step 13: Reinstall the check valve nut.
D8RE2 Troubleshooting - Part 2

Page 13
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 2: Unscrew to remove. Set it aside.
Step 1: Using the strap wrench (Part #: TOOL01), loosen
the bell housing.
D8RE2 Troubleshooting - Part 3
This D8RE2 - 40 GPM Troubleshooting Part 3 will cover: The injector isn’t clicking or is
stalling at low ow.
Step 3: Grasp the white plastic bridge and pull the piston straight
out of the body. Set the body aside.

Page 14
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 5: You can visually inspect the upper and lower anges on
the piston shell. If they are worn or have deep scratches, the
pistion shell (Part #: 8MP033) needs to be replaced.
Step 4: Holding the piston, press the push rod up and down.
NOTE: It should click in both directions. If not, please give us a
call for assistance at 800-523-8499.
D8RE2 Troubleshooting - Part 3
Step 6: Another way to check the anges is by doing a t test. To
test the upper ange, invert the piston and insert squarely, halfway
into the bell housing. It should stay in place.

Page 15
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
Step 8: Insert the piston into the body squarely about halfway. It
should stay in place.
NOTE: If either is loose, the piston shell needs to be replaced. For
assistance in replacing the pistion shell please contact Dosatron
Technical Service at 800-523-8499.
Step 7: To test the lower ange remove the plunger by turning it a
quarter turn counter clockwise and pulling it straight out.
D8RE2 Troubleshooting - Part 3
Step 9: Reinstall the plunger into the retainer.

Page 16
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D8RE2 Troubleshooting - Part 3
Step 12: Hand tighten the bell housing.
Step 11: Now insert the piston back into the blue body.
Step 10: Twist it a quarter turn clockwise to lock.
To learn more, scan the QR codes below for more information.
Scan the QR
code to go to
Dosatron’s
video page.
Scan the QR code
to go to Dosatron’s
YouTube Channel.
