DSC Sur-Gard DVACS PC54OO User manual

1
Introduction 3
Features ........................................................................................................................... 3
Module Specifications ..................................................................................................... 3
Installation ........................................................................................................................ 3
PC5400 Hook-up Diagram 4
Programming Section Descriptions 5
ProgrammingWorksheets 7
PC5010, PC5015, PC5008, PC1555, PC580 Programming Sections .............................. 7
PC1575 DVACS Programming ....................................................................................... 19
Appendix A: DVACS ReportingTypeTables 24
Appendix B: PC5010, PC5015, PC5008, PC1555, PC580
DVACS Default Reporting Codes 28
Appendix C: PC1575 DVACS Default Reporting Codes 32
Table of Contents
firealarmresources.com

2
Notes:
firealarmresources.com

3
Introduction
Features
Allows compatible alarm control panels to be
connected to a DVACS communications network.
Module Specifications
• 4 wire (QUAD) hook-up to keybus
• Normal current draw of 35 mA
• Tamper and Trouble reporting codes
• Maximum cable length: 61m (200 ft)
PC5400 connected to a DVACS network
• Automatic programming for DVACS function
bytes and reporting codes.
• Programmable response type to all calls
• Monitoring for DVACS line fault
• Module self diagnostics
Compatible Products
• PC5015
• PC5010
• PC5008
• PC1575
• PC1555
• PC580
Installation
Mounting the Cabinet
When mounting a new cabinet for the PC5400,
select a dry location close to the F1/F2 subset.
To mount the PC5400:
1. Press the four white circuit board stand-offs
into the raised mounting holes from the back
of the cabinet.
2. Hold the cabinet in position and pull the wires
into the cabinet.
3. Mount the cabinet securely to the wall using
the mounting screws provided. Use the
appropriate wall anchors when securing the
panel to the drywall, plaster, concrete, brick or
other similar surfaces.
4. With the cabinet mounted press the PC5400
module into the stand-offs.
Wiring
Refer to the Hook-up Diagram included in this
manual.
RED, BLK, YEL and GRN Terminals
Connect the RED, BLK, YEL and GRN terminals to
the RED, BLK, YEL and GRN terminals on the
control panel. Refer to the control panel
Installation Manual for complete instructions on
keybus wiring.
T1 and T2
Connect T1 and T2 to a normally closed switch
that will be used to monitor tampers. If no tamper
switch is desired place a wire between T1 and T2.
firealarmresources.com

4
PC5400 Hook-up Diagram
firealarmresources.com

5
Programming Section Descriptions
If you will be connecting the PC5400 to a PC5010, PC5015, PC1555 or PC580 control panel, access the
PC5400 programming sections at a system keypad by entering [*][8][Installer's Code][803]. Then enter
the 2-digit number of the section you want to program.
If you will be connecting the PC5400 to a PC1575, access the PC5400 programming sections at a
system keypad by entering [*][8][Installer's Code][87]. Then enter the 2-digit number of the section you
want to program.
Sections [10-13] Wireless & Miscellaneous Reporting Codes
Program the DVACS reporting codes in these sections (see DVACS Transmission Table for Transmission
Codes):
•To have the PC5400 transmit a pre-programmed code from the internal table, leave the
programming at the default value FF. Default reporting codes are listed in the Appendices B and C.
•To prevent the PC5400 from reporting an event, program the code as 00.
•To have the PC5400 transmit a different code, program a value from 01-FE.
Sections [20-23] Wireless & Miscellaneous Reporting Types
By programming the Reporting Types sections, you can add additional information to each transmission.
For example, you can program the reporting code for zone 1 as 01 and the reporting type for zone 1 as
00, to indicate that zone 1 is a fire zone. Refer to the DVACS Reporting Type tables on pages 24-27.
•To have the PC5400 transmit a pre-programmed code from the internal table, leave the
programming at the default value FF. Default reporting types are listed in the Appendix A.
•To have the PC5400 transmit a different code, program a value from 00-7F.
NOTE: Do not program values above 7F.
Sections [36-39] Zone Definitions
Make sure that the zone definitions match those programmed in the control panel.
Section [40] DVACS ID Code
Program the DVACS ID code in this section. This code identifies a PC5400 module on a DVACS subset,
specifying which poll from a F2 node the module will respond to. Valid entries are 01 - F0.
Section [41] All Call Select
Use this section to program which all call response the PC5720 will have. The options are:
(00)no response on any all call
(01)response on all call #1 only
(02)response on all call #2 only
(03)response on both all calls
(04)modules with odd-numbered ID codes (see section 40) respond to All Call #1. Modules with even-
numbered ID codes respond to All Call #2. (E.g. a module withID code 03 will respond to All Call
#1. A module with ID code 04 will respond to All Call #2.)
firealarmresources.com

6
Section [42] Miscellaneous (Transmission) Options
Option 1: Turn this option ON to have the PC5400 send alarms during an all call. Turn this option OFF to
have the PC5400 send alarms and restorals during an all call.
Option 2: Turn this option ON to have the PC5400 report which zones have been bypassed. Turn this
option OFF for prevent the PC5400 from reporting which zones have been bypassed.
Option 3: Turn this option ON to have the PC5400 report openings and closings. Turn this option OFF to
to prevent the PC5400 from reporting openings and closings.
Sections [43-68] Reporting Codes
Program the DVACS reporting codes in these sections (see DVACS Transmission Table for Transmission
Codes):
•To have the PC5400 transmit a pre-programmed code from the internal table, leave the
programming at the default value FF. Default reporting codes are listed in the Appendices B and C.
•To prevent the PC5400 from reporting an event, program the code as 00.
•To have the PC5400 transmit a different code, program a value from 01-FE.
Sections [69-94] Reporting Types
By programming the Reporting Types sections, you can add additional information to each transmission.
For example, you can program the reporting code for zone 1 as 01 and the reporting type for zone 1 as
00, to indicate that zone 1 is a fire zone. Refer to the DVACS Reporting Type tables on pages 24-27.
•To have the PC5400 transmit a pre-programmed code from the internal table, leave the
programming at the default value FF. Default reporting types are listed in the Appendix A.
•To have the PC5400 transmit a different code, program a value from 00-7F.
NOTE: Do not program values above 7F.
NOTE: If you change any of the above options from the default settings, test the PC5400 to make sure
it is operating as desired.
firealarmresources.com

7
PC5010, PC5015, PC5008, PC1555, PC580 Programming Sections
(see page 20 for PC1575 programming sections)
If you will be connecting the PC5400 to a PC5010, PC5015, PC1555 or PC580 control panel, access the
PC5400 programming sections at a system keypad by entering [*][8][Installer's Code][803]. Then enter
the 2-digit number of the section you want to program.
[10] Handheld Keypad Low Battery Reporting Codes
Default Default
FF I____I____IHandheld Keypad #1 FF I____I____IFor future use
FF I____I____IHandheld Keypad #2 FF I____I____IFor future use
FF I____I____IHandheld Keypad #3 FF I____I____IFor future use
FF I____I____IHandheld Keypad #4 FF I____I____IFor future use
[11] Wireless Key 1-8 Low Battery Reporting Codes
Default Default
FF I____I____IWireless Key #1 FF I____I____IWireless Key #5
FF I____I____IWireless Key #2 FF I____I____IWireless Key #6
FF I____I____IWireless Key #3 FF I____I____IWireless Key #7
FF I____I____IWireless Key #4 FF I____I____IWireless Key #8
[12] Wireless Key 9-16 Low Battery Reporting Codes
Default Default
FF I____I____IWireless Key #9 FF I____I____IWireless Key #13
FF I____I____IWireless Key #10 FF I____I____IWireless Key #14
FF I____I____IWireless Key #11 FF I____I____IWireless Key #15
FF I____I____IWireless Key #12 FF I____I____IWireless Key #16
[13] Miscellaneous Option Reporting Codes
Default Default
FF I____I____IPolice Code FF I____I____IFor future use
FF I____I____IDelinquency Code FF I____I____IFor future use
FF I____I____ILate to Close FF I____I____IFor future use
FF I____I____IEvent Buffer 75% Full FF I____I____IFor future use
[20] Handheld Keypad Low Battery Reporting Types
Default Default
FF I____I____IHandheld Keypad #1 FF I____I____IFor future use
FF I____I____IHandheld Keypad #2 FF I____I____IFor future use
FF I____I____IHandheld Keypad #3 FF I____I____IFor future use
FF I____I____IHandheld Keypad #4 FF I____I____IFor future use
Programming Worksheets
firealarmresources.com

8
[21] Wireless Key 1-8 Low Battery Reporting Types
Default Default
FF I____I____IWireless Key #1 FF I____I____IWireless Key #5
FF I____I____IWireless Key #2 FF I____I____IWireless Key #6
FF I____I____IWireless Key #3 FF I____I____IWireless Key #7
FF I____I____IWireless Key #4 FF I____I____IWireless Key #8
[22] Wireless Key 9-16 Low Battery Reporting Types
Default Default
FF I____I____IWireless Key #9 FF I____I____IWireless Key #13
FF I____I____IWireless Key #10 FF I____I____IWireless Key #14
FF I____I____IWireless Key #11 FF I____I____IWireless Key #15
FF I____I____IWireless Key #12 FF I____I____IWireless Key #16
[23] Miscellaneous Option Reporting Types
Default Default
FF I____I____IPolice Code FF I____I____IFor future use
FF I____I____IDelinquency Code FF I____I____IFor future use
FF I____I____ILate to Close FF I____I____IFor future use
FF I____I____IEvent Buffer 75% Full FF I____I____IFor future use
ZONE DEFINITIONS
00 Null Zone (Not Used) 10 24-Hour Supervisory Buzzer 20 24-Hour Freeze
01 Delay 1 11 24-Hour Burglary 21 24-Hour Latching Tamper
02 Delay 2 12 24-Hour Holdup 22 Momentary Keyswitch Arm
03 Instant 13 24-Hour Gas 23 Maintained Keyswitch Arm
04 Interior 14 24-Hour Heat 24 LINKS Answer
05 Interior, Home-Away 15 24-Hour Medical 25*Interior Delay
06 Delay, Home-Away 16 24-Hour Panic 26*24-Hour Non-Alarm
07 Delayed 24-Hour Fire (Hardwired) 17 24-Hour Emergency 87 Delayed 24-Hour Fire (Wireless)
08 Standard 24-Hour Fire (Hardwired) 18 24-Hour Sprinkler 88 Standard 24-Hour Fire (Wireless)
09 24-Hour Supervisory (LINKS) 19 24-Hour Water
*25 for v2.1 and higher control panels only
**26 for v2.2 and higher control panels only
[36] Zone 1-8 Definitions
Default Default
01 I____I____IZone 1 04 I____I____IZone 5
03 I____I____IZone 2 04 I____I____IZone 6
03 I____I____IZone 3 04 I____I____IZone 7
03 I____I____IZone 4 04 I____I____IZone 8
firealarmresources.com

9
[37] Zone 9-16 Definitions
Default Default
00 I____I____IZone 9 00 I____I____IZone 13
00 I____I____IZone 10 00 I____I____IZone 14
00 I____I____IZone 11 00 I____I____IZone 15
00 I____I____IZone 12 00 I____I____IZone 16
[38] Zone 17-24 Definitions
Default Default
00 I____I____IZone 17 00 I____I____IZone 21
00 I____I____IZone 18 00 I____I____IZone 22
00 I____I____IZone 19 00 I____I____IZone 23
00 I____I____IZone 20 00 I____I____IZone 24
[39] Zone 25-32 Definitions
Default Default
00 I____I____IZone 25 00 I____I____IZone 29
00 I____I____IZone 26 00 I____I____IZone 30
00 I____I____IZone 27 00 I____I____IZone 31
00 I____I____IZone 28 00 I____I____IZone 32
[40] ID Code
Default
00 I____I____I
[41] All Call Select
Default
01 I____I____I
00 No response on All Call
01 Response on All Call #1 only
02 Response on All Call #2 only
03 Response on both All Calls
04 Modules with odd-numbered ID codes (see section 40) respond to All Call
#1. Modules with even-numbered ID codes respond to All Call #2. (E.g. a
module withID code 03 will respond to All Call #1. A module with ID code 04
will respond to All Call #2.)
[42] Miscellaneous Options
Default Option ON Option OFF
ON I____IOption 1 All Call Sends Alarms Only All Call Sends Alarms & Restorals
ON I____IOption 2 Zone Bypass Report Enabled Zone Bypass Report Disabled
ON I____IOption 3 Openings/Closings Enabled Openings/Closings Disabled
OFF I____IOption 4 -8 For future use
firealarmresources.com

10
[43] First SG-DVACS Reporting Codes
Default Default
FF I____I____IDuress Alarm FF I____I____IAux. Input Alarm / Restore
FF I____I____IKeypad [F] Key Alarm / Restore FF I____I____IPC5132 Tamper / Restore
FF I____I____IKeypad [A] Key Alarm / Restore FF I____I____IPC5208 Tamper / Restore
FF I____I____IKeypad [P] Key Alarm / Restore FF I____I____IPC5204 Tamper / Restore
[44] Second SG-DVACS Reporting Codes
Default Default
FF I____I____IPC5400 Tamper / Restore FF I____I____IBell Circuit Trouble / Restore
FF I____I____ILINKS Module Tamper / Restore FF I____I____IFire Trouble Alarm / Restore
FF I____I____IBattery Trouble / Restore FF I____I____IAux Power Trouble / Restore
FF I____I____IAC Trouble / Restore FF I____I____ITLM (LINKS) Trouble / Restore
[45] Third SG-DVACS Reporting Codes
Default Default
FF I____I____IPhone Number 1 Trouble / Restore FF I____I____ICritical Shutdown
FF I____I____IPhone Number 2 Trouble / Restore FF I____I____IPC5204 AC Trbl / Rest
FF I____I____IDLS Lead Out Failed FF I____I____IPC5204 Battery Trbl / Rest
FF I____I____IKeybus Fault / Restore FF I____I____IPC5204 Aux Power Trbl / Rest
[46] Fourth SG-DVACS Reporting Codes
Default Default
FF I____I____IPC5204 Output Fault / Restore FF I____I____IPC5204 Supv. Fault / Rest
FF I____I____IDownlook Module Supv./Restore FF I____I____IPC5400 Supv. Fault / Rest
FF I____I____IPC5132 Supervisory Fault / Restore FF I____I____IAlt. Comm (LINKS) Supv Flt/Rest
FF I____I____IPC5208 Supervisory Fault / Restore FF I____I____IPC59XX Supv. Fault / Rest
[47] Fifth SG-DVACS Reporting Codes
Default Default
FF I____I____IESCORT 5580 Supv Fault / Restore FF I____I____ISystem Test
FF I____I____IKeypad Lockout FF I____I____IInstaller Lead In / Lead Out
FF I____I____IRemote ESCORT Access FF I____I____ICold Start
FF I____I____IDLS Lead In / Lead Out FF I____I____IWarm Start
[48] Sixth SG-DVACS Reporting Codes
Default Default
FF I____I____ISwinger Shutdown FF I____I____IAuto Arm Cancellation
FF I____I____IS-A Mode / Activate S-A Zones FF I____I____IPartial Closing
FF I____I____IOpening After Alarm FF I____I____IBell Supervisory (PC5720)
FF I____I____IRecent Closing FF I____I____IDwnlook Module Remote Trigger
firealarmresources.com

11
[49] Zone 1-8 Alarm / Restore / Bypass Reporting Codes
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[50] Zone 9-16 Alarm / Restore / Bypass Reporting Codes
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
[51] Zone 17-24 Alarm / Restore / Bypass Reporting Codes
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[52] Zone 25-32 Alarm / Restore / Bypass Reporting Codes
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
[53] Zone 1-8 Tamper / Restore Reporting Codes
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[54] Zone 9-16 Tamper / Restore Reporting Codes
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
firealarmresources.com

12
[55] Zone 17-24 Tamper / Restore Reporting Codes
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[56] Zone 25-32 Tamper / Restore Reporting Codes
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
[57] Zone 1-8 Trouble / Restore Reporting Codes
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[58] Zone 9-16 Trouble / Restore Reporting Codes
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
[59] Zone 17-24 Trouble / Restore Reporting Codes
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[60] Zone 25-32 Trouble / Restore Reporting Codes
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
firealarmresources.com

13
[61] Zone 1-8 Low Battery / Restore Reporting Codes
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[62] Zone 9-16 Low Battery / Restore Reporting Codes
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
[63] Zone 17-24 Low Battery / Restore Reporting Codes
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[64] Zone 25-32 Low Battery / Restore Reporting Codes
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
[65] Keypad Tamper / Restore Reporting Codes
Default Default
FF I____I____IKeypad 1 FF I____I____IKeypad 5
FF I____I____IKeypad 2 FF I____I____IKeypad 6
FF I____I____IKeypad 3 FF I____I____IKeypad 7
FF I____I____IKeypad 4 FF I____I____IKeypad 8
[66] Zone Expander Tamper / Restore Reporting Codes
Default Default
FF I____I____IZone Expander 1 FF I____I____IZone Expander 5
FF I____I____IZone Expander 2 FF I____I____IZone Expander 6
FF I____I____IZone Expander 3 FF I____I____IPC5100
FF I____I____IZone Expander 4 FF I____I____IFor future use
firealarmresources.com

14
[67] Keypad Supervisory / Restore Reporting Codes
Default Default
FF I____I____IKeypad 1 FF I____I____IKeypad 5
FF I____I____IKeypad 2 FF I____I____IKeypad 6
FF I____I____IKeypad 3 FF I____I____IKeypad 7
FF I____I____IKeypad 4 FF I____I____IKeypad 8
[68] Zone Expander Supervisory / Restore Reporting Codes
Default Default
FF I____I____IZone Expander 1 FF I____I____IZone Expander 5
FF I____I____IZone Expander 2 FF I____I____IZone Expander 6
FF I____I____IZone Expander 3 FF I____I____IPC5100
FF I____I____IZone Expander 4 FF I____I____IExpander Module
Reporting Types - Refer to the Reporting Type Table
[69] Zone 1-8 Alarm / Restore / Bypass Reporting Types
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[70] Zone 9-16 Alarm / Restore / Bypass Reporting Types
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
[71] Zone 17-24 Alarm / Restore / Bypass Reporting Types
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[72] Zone 25-32 Alarm / Restore / Bypass Reporting Types
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
firealarmresources.com

15
[73] Zone 1-8 Tamper / Restore Reporting Types
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[74] Zone 9-16 Tamper / Restore Reporting Types
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
[75] Zone 17-24 Tamper / Restore Reporting Types
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[76] Zone 25-32 Tamper / Restore Reporting Types
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
[77] Zone 1-8 Trouble / Restore Reporting Types
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[78] Zone 9-16 Trouble / Restore Reporting Types
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
firealarmresources.com

16
[79] Zone 17-24 Trouble / Restore Reporting Types
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[80] Zone 25-32 Trouble / Restore Reporting Types
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
[81] Zone 1-8 Low Battery / Restore Reporting Types
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IZone 7
FF I____I____IZone 4 FF I____I____IZone 8
[82] Zone 9-16 Low Battery / Restore Reporting Types
Default Default
FF I____I____IZone 9 FF I____I____IZone 13
FF I____I____IZone 10 FF I____I____IZone 14
FF I____I____IZone 11 FF I____I____IZone 15
FF I____I____IZone 12 FF I____I____IZone 16
[83] Zone 17-24 Low Battery / Restore Reporting Types
Default Default
FF I____I____IZone 17 FF I____I____IZone 21
FF I____I____IZone 18 FF I____I____IZone 22
FF I____I____IZone 19 FF I____I____IZone 23
FF I____I____IZone 20 FF I____I____IZone 24
[84] Zone 25-32 Low Battery / Restore Reporting Types
Default Default
FF I____I____IZone 25 FF I____I____IZone 29
FF I____I____IZone 26 FF I____I____IZone 30
FF I____I____IZone 27 FF I____I____IZone 31
FF I____I____IZone 28 FF I____I____IZone 32
firealarmresources.com

17
[85] Keypad Tamper / Restore Reporting Types
Default Default
FF I____I____IKeypad 1 FF I____I____IKeypad 5
FF I____I____IKeypad 2 FF I____I____IKeypad 6
FF I____I____IKeypad 3 FF I____I____IKeypad 7
FF I____I____IKeypad 4 FF I____I____IKeypad 8
[86] Zone Expander Tamper / Restore Reporting Types
Default Default
FF I____I____IZone Expander 1 FF I____I____IZone Expander 5
FF I____I____IZone Expander 2 FF I____I____IZone Expander 6
FF I____I____IZone Expander 3 FF I____I____IPC5100
FF I____I____IZone Expander 4 FF I____I____IFor future use
[87] Keypad Supervisory / Restore Reporting Types
Default Default
FF I____I____IKeypad 1 FF I____I____IKeypad 5
FF I____I____IKeypad 2 FF I____I____IKeypad 6
FF I____I____IKeypad 3 FF I____I____IKeypad 7
FF I____I____IKeypad 4 FF I____I____IKeypad 8
[88] Zone Expander Supervisory / Restore Reporting Types
Default Default
FF I____I____IZone Expander 1 FF I____I____IZone Expander 5
FF I____I____IZone Expander 2 FF I____I____IZone Expander 6
FF I____I____IZone Expander 3 FF I____I____IPC5100
FF I____I____IZone Expander 4 FF I____I____IExpander Module
[89] First DVACS Reporting Types
Default Default
FF I____I____IDuress Alarm FF I____I____IPGM2 Input Alarm/Restore
FF I____I____IKeypad [F] Key Alarm / Restore FF I____I____IPC5132 Tamper / Restore
FF I____I____IKeypad [A] Key Alarm / Restore FF I____I____IPC5208 Tamper / Restore
FF I____I____IKeypad [P] Key Alarm / Restore FF I____I____IPC5204 Tamper / Restore
[90] Second DVACS Reporting Types
Default Default
FF I____I____IPC5400 Tamper / Restore FF I____I____IBell Circuit Trouble / Restore
FF I____I____ILINKS Module Tamper / Restore FF I____I____IFire Trouble Alarm / Restore
FF I____I____IBattery Trouble / Restore FF I____I____IFor future use
FF I____I____IAC Trouble / Restore FF I____I____ITLM (LINKS) Trouble / Restore
firealarmresources.com

18
[91] Third DVACS Reporting Types
Default Default
FF I____I____IPhone Number 1 Trouble / Restore FF I____I____ICritical Shutdown
FF I____I____IPhone Number 2 Trouble / Restore FF I____I____IPC5204 AC Trbl / Rest
FF I____I____IDLS Lead Out Failed future use FF I____I____IPC5204 Battery Trbl / Rest
FF I____I____IKeybus Fault / Restore FF I____I____IPC5204 Aux Power Trbl / Rest
[92] Fourth DVACS Reporting Types
Default Default
FF I____I____IPC5204 Output Fault / Restore FF I____I____IPC5204 Supv. Fault / Rest
FF I____I____IDwnlk Module Supervisory Fault FF I____I____IPC5400 Supv. Fault / Rest
FF I____I____IPC5132 Supervisory Fault / Restore FF I____I____ILINKS Mod. Supv. Fault / Rest
FF I____I____IPC5208 Supervisory Fault / Restore FF I____I____IPC59XX Supv. Fault / Rest
[93] Fifth DVACS Reporting Types
Default Default
FF I____I____IESCORT 5580 Supv Fault / Restore FF I____I____ISystem Test
FF I____I____IKeypad Lockout FF I____I____IInstaller Lead In / Lead Out
FF I____I____IRemote ESCORT Access FF I____I____ICold Start
FF I____I____IDLS Lead In / Lead Out FF I____I____IWarm Start
[94] Sixth DVACS Reporting Types
Default Default
FF I____I____ISwinger Shutdown FF I____I____IAuto Arm Cancellation
FF I____I____IH-A Mode / Activate H-A Zones FF I____I____IPartial Closing
FF I____I____IOpening After Alarm FF I____I____IBell Supervisory (PC5720)
FF I____I____IRecent Closing FF I____I____IDwnlk Module Remote Trigger
firealarmresources.com

19
PC1575 DVACS Programming
If you will be connecting the PC5400 to a PC1575, access the PC5400 programming sections at a system
keypad by entering [*][8][Installer's Code][87]. Then enter the 2-digit number of the section you want to
program.
ZONE DEFINITIONS
00 Null Zone (Not Used) 09 24 Hour Supervisory (Links) 18 24 Hour Sprinkler
01 Delay 1 10 24 Hour Supervisory Buzzer19 24 Hour Water
02 Delay 2 11 24 Hour Burglary 20 24 Hour Freeze
03 Instant 12 24 Hour HEAT 21 24 Hour Latching Tamper
04 Interior 13 24 Hour Gas
05 Interior, Home-Away 14 24 Hour Hold-Up
06 Delay, Home-Away 15 24 Hour Medical
07 Delayed 24 Hour Fire (Hardwired) 16 24 Hour Panic
08 Standard 24 Hour Fire (Hardwired)17 24 Hour Emergency
[36] Zone 1-6 Definitions
Default Default
01 I____I____IZone 1 03 I____I____IZone 5
06 I____I____IZone 2 03 I____I____IZone 6
03 I____I____IZone 3 I____I____IFor future use
03 I____I____IZone 4 I____I____IFor future use
[37] - [39] For future use
[40] ID Code
Default
00 I____I____I
[41] All Call Select
Default
01 I____I____I
00 No response on All Call
01 Response on All Call #1 only
02 Response on All Call #2 only
03 Response on both All Calls
04 Modules with odd-numbered ID codes (see section 40) respond to All Call
#1. Modules with even-numbered ID codes respond to All Call #2. (E.g. a
module withID code 03 will respond to All Call #1. A module with ID code 04
will respond to All Call #2.)
firealarmresources.com

20
[42] Miscellaneous Options
Default Option ON Option OFF
ON I____IOption 1 All Call Sends Alarms Only All Call Sends Alarms & Restorals
ON I____IOption 2 Zone Bypass Report Enabled Zone Bypass Report Disabled
ON I____IOption 3 Openings/Closings Enabled Openings/Closings Disabled
OFF I____IOption 4 - 6 For future use
[43] First SG-DVACS Reporting Codes
Default Default
FF I____I____IDuress Alarm FF I____I____IPGM2 Alarm / Restore
FF I____I____IKeypad [F] Key Alarm / Restore FF I____I____IFor future use
FF I____I____IKeypad [A] Key Alarm / Restore FF I____I____IFor future use
FF I____I____IKeypad [P] Key Alarm / Restore FF I____I____IFor future use
[44] Second SG-DVACS Reporting Codes
Default Default
FF I____I____IBattery Trouble / Restore FF I____I____IAux Power Trouble / Restore
FF I____I____IAC Trouble / Restore FF I____I____ITLM (LINKS) Trouble / Restore
FF I____I____IBell Circuit Trouble / Restore FF I____I____IPhone Number 1 Trbl / Restore
FF I____I____IFire Trouble Alarm / Restore FF I____I____IPhone Number 2 Trbl / Restore
[45] Third SG-DVACS Reporting Codes
Default Default
FF I____I____IPC5400 Supv. Fault / Rest FF I____I____ISystem Test
FF I____I____IPC5400 Tamper / Restore FF I____I____ICold Start
FF I____I____IESCORT 5580 Supv Fault / Restore FF I____I____IPartial Closing
FF I____I____IKeypad Lockout FF I____I____IOpening After Alarm
[46] Fourth SG-DVACS Reporting Codes
Default Default
FF I____I____IPolice Code FF I____I____IFor future use
FF I____I____IDelinquency FF I____I____IFor future use
FF I____I____IEvent Buffer 75% Full FF I____I____IFor future use
FF I____I____IFor future use FF I____I____IFor future use
[47] - [48] For future use
[49] Zone 1-6 Alarm / Restore / Bypass Reporting Codes
Default Default
FF I____I____IZone 1 FF I____I____IZone 5
FF I____I____IZone 2 FF I____I____IZone 6
FF I____I____IZone 3 FF I____I____IFor future use
FF I____I____IZone 4 FF I____I____IFor future use
firealarmresources.com
