DSC 3G2055 User manual

INSTALLATION MANUAL
Warning: This manual contains information on limitations regarding product use and function and infor-
mation on the limitations as to liability of the manufacturer.
3G2055 v3.0
HSPA/3G Wireless Alarm Communicator
SCW 3G Communicator – International
N5167
0682

3G Alarm Communicator Installation Manual
2
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Communicator Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Hardware Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Communicator Pre Installation Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Remote Programming via DLS 5: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Communicator Configuration with SCW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Communicator Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Establishing a Communication Channel with the SCW Panel. . . . . . . . . . . . . . . . . . . . . . . 8
Label Programming for SMS Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programming Options Sections
Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
System Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Communications Reporting Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cellular Receiver 1 Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cellular Receiver 2 Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cellular Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
System Information (Read Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
System Reset Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Programming Worksheets Sections
Cellular Programming Worksheets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
System Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Cellular Receiver 1 Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Cellular Receiver 2 Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
System Information (Read Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
System Reset Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
End User License Agreement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
TABLE OF CONTENTS

3G Alarm Communicator Installation Manual Warning: Installer Please Read Carefully
3
WARNING: INSTALLER PLEASE READ CAREFULLY
Note to Installers
The Warnings on this page contain vital information. As the only
individual in contact with system users, it is the installer’s responsi-
bility to bring each item in this Warning to the attention of all users of
this system.
System Failures
This system has been carefully designed to be as effective as possible.
There are circumstances, however, involving fire, burglary, or other
types of emergencies where it may not provide protection. Any alarm
system of any type may be compromised deliberately or may fail to
operate as expected for a variety of reasons. Some, but not all, of the
reasons may be:
Access by Intruders
Intruders may enter through an unprotected access point, circumvent
a sensing device, evade detection by moving through an area of insuf-
ficient coverage, disconnect a warning device, or interfere with or
prevent the proper operation of the system.
Component Failure
Although every effort has been made to make this system as reliable
as possible, the system may fail to function as intended due to the
failure of a component.
Compromise of Radio Frequency (Wireless) Devices
Signals may not reach the receiver under all circumstances which
could include metal objects placed on or near the radio path or delib-
erate jamming or other inadvertent radio signal interference.
Criminal Knowledge
This system contains security features which were known to be effec-
tive at the time of manufacture. It is possible for persons with crimi-
nal intent to develop techniques which reduce the effectiveness of
these features. It is important that your security system be reviewed
periodically to ensure that its features remain effective and that it is
updated or replaced if it is found that it does not provide the protec-
tion expected.
Failure of Replaceable Batteries
This system’s wireless transmitters have been designed to provide
several years of battery life under normal conditions. The expected
battery life is a function of the device environment, usage, and type.
Ambient conditions such as high humidity, high or low temperatures,
or large temperature fluctuations may reduce the expected battery
life. While each transmitting device has a low battery monitor which
identifies when the batteries need to be replaced, this monitor may
fail to operate as expected. Regular testing and maintenance will keep
the system in good operating condition.
Inadequate Installation
A security system must be installed properly in order to provide ade-
quate protection. Every installation should be evaluated by a security
professional to ensure that all access points and areas are covered.
Locks and latches on windows and doors must be secure and operate
as intended. Windows, doors, walls, ceilings and other building mate-
rials must be of sufficient strength and construction to provide the
level of protection expected. A reevaluation must be done during and
after any construction activity. An evaluation by the fire and/or police
department is highly recommended if this service is available.
Inadequate Testing
Most problems that would prevent an alarm system from operating as
intended can be found by regular testing and maintenance. The com-
plete system should be tested weekly and immediately after a break-
in, an attempted break-in, a fire, a storm, an earthquake, an accident,
or any kind of construction activity inside or outside the premises.
The testing should include all sensing devices, keypads, consoles,
alarm indicating devices, and any other operational devices that are
part of the system.
Insufficient Time
There may be circumstances when the system will operate as
intended, yet the occupants will not be protected from an emergency
due to their inability to respond to the warnings in a timely manner. If
the system is remotely monitored, the response may not occur in time
to protect the occupants or their belongings.
Motion Detectors
Motion detectors can only detect motion within the designated areas
as shown in their respective installation instructions. They cannot dis-
criminate between intruders and intended occupants. Motion detec-
tors do not provide volumetric area protection. They have multiple
beams of detection and motion can only be detected in unobstructed
areas covered by these beams. They cannot detect motion which
occurs behind walls, ceilings, floor, closed doors, glass partitions,
glass doors or windows. Any type of tampering whether intentional
or unintentional such as masking, painting, or spraying of any mate-
rial on the lenses, mirrors, windows or any other part of the detection
system will impair its proper operation.
Passive infrared motion detectors operate by sensing changes in tem-
perature. However their effectiveness can be reduced when the ambi-
ent temperature rises near or above body temperature or if there are
intentional or unintentional sources of heat in or near the detection
area. Some of these heat sources could be heaters, radiators, stoves,
barbeques, fireplaces, sunlight, steam vents, lighting and so on.
Power Failure
Control units, intrusion detectors, smoke detectors and many other
security devices require an adequate power supply for proper opera-
tion. If a device operates from batteries, it is possible for the batteries
to fail. Even if the batteries have not failed, they must be charged, in
good condition and installed correctly. If a device operates only by
AC power, any interruption, however brief, will render that device
inoperative while it does not have power. Power interruptions of any
length are often accompanied by voltage fluctuations which may
damage electronic equipment such as a security system. After a
power interruption has occurred, immediately conduct a complete
system test to ensure that the system operates as intended.
Security and Insurance
Regardless of its capabilities, an alarm system is not a substitute for
property or life insurance. An alarm system also is not a substitute for
property owners, renters, or other occupants to act prudently to pre-
vent or minimize the harmful effects of an emergency situation.
Smoke Detectors
Smoke detectors that are a part of this system may not properly alert
occupants of a fire for a number of reasons, some of which follow.
The smoke detectors may have been improperly installed or posi-
tioned. Smoke may not be able to reach the smoke detectors, such as
when the fire is in a chimney, walls or roofs, or on the other side of
closed doors. Smoke detectors may not detect smoke from fires on
another level of the residence or building.
Every fire is different in the amount of smoke produced and the rate
of burning. Smoke detectors cannot sense all types of fires equally
well. Smoke detectors may not provide timely warning of fires
caused by carelessness or safety hazards such as smoking in bed, vio-
lent explosions, escaping gas, improper storage of flammable materi-
als, overloaded electrical circuits, children playing with matches, or
arson.
Even if the smoke detector operates as intended, there may be cir-
cumstances when there is insufficient warning to allow all occupants
to escape in time to avoid injury or death.
Telephone Lines
If telephone lines are used to transmit alarms, they may be out of ser-
vice or busy for certain periods of time. Also an intruder may cut the
telephone line or defeat its operation by more sophisticated means
which may be difficult to detect.
Warning Devices
Warning devices such as sirens, bells, horns, or strobes may not warn
people or waken someone sleeping if there is an intervening wall or
door. If warning devices are located on a different level of the resi-
dence or premise, then it is less likely that the occupants will be
alerted or awakened. Audible warning devices may be interfered with
by other noise sources such as stereos, radios, televisions, air condi-
tioners, other appliances, or passing traffic. Audible warning devices,
however loud, may not be heard by a hearing-impaired person.

Keypad Data Display 3G Alarm Communicator Installation Manual
4
Domain Name Service (DNS) programming is not permitted in UL/ULC listed systems.
KEYPAD DATA DISPLAY
•Section-Toggle Options: The number is displayed when Toggle is ON, the number is not displayed when Toggle is OFF.
(e.g., Toggle Options displays: “[
-- 3 -- 6 -- ]”. Options 3and 6are ON, all others are OFF). Pressing keys 1 through 8 will
alternately turn the Toggle ON and OFF.
•HEX/Decimal Data: Values that are provided with two defaults, separated by a / character, use the format: hexadecimal fol-
lowed by decimal equivalent (e.g., Default [0BF5/3061]). Hexadecimal numbers are shown, with all leading zeroes, to the
full field length defined for the number.
ENTERING DATA FROM KEYPAD
To enter data at the keypad, press the number key, from the table below, to select the character that you want. Pressing the number
key repeatedly will scroll through the characters available for that key. Press the [*] key and use
[<] [>] keys to scroll to one of the
following selections: (Press [*] to select the Option.)
•ASCII Entry. Use this mode to enter ASCII characters from the keypad.
•Clear to End. This selection will clear the remainder of the display.
•Clear Display.This selection will completely erase all entries on the display.
•Change Case. Toggles between upper/lower depending on current selection.
NOTE: The “0” on the keypad is used to delete characters.
ENTERING ASCII CHARACTERS
To enter American Standard Code for Information Interchange (ASCII) characters at the keypad, perform the following:
1. Press [*] and use [<] [>] keys to scroll to “ASCII Entry”.
2. Press [*] to select ASCII entry mode.
3. Use the
[<] [>] keys to scroll to display the ASCII character you want to use and press [*] to accept.
4. Press [*] to exit ASCII character entry mode and return to normal entry.
NOTE: Authorized access to DLS 5 is required to modify any Cellular Programming Section. Specific panel sections must be
configured for proper operation of the Communicator with the panel.
MOUNTING CONSIDERATIONS
The Cellular Communicator is a fixed, wall-mounted unit and shall be installed in the location specified in these instructions. The
equipment enclosure must be fully assembled and closed, with all the necessary screws/tabs and it must be secured to a wall
before operation.
Internal wiring must be routed in a manner that prevents:
• Excessive strain on wire and on terminal connections,
• Interference between power limited and non power limited wiring,
• Loosening of terminal connections, or
• Damage of conductor insulation.
WARNING: NEVER INSTALL THIS EQUIPMENT DURING ALIGHTNING
STORM!
The Installer must instruct the System user on each of the following items:
• This manual shall be used in conjunction with the Alarm controller manual; all the safety instructions specified within that
manual shall be observed.
• Do not attempt to service this product. Opening or removing covers may expose the user to dangerous
voltages or other risks.
• Any servicing shall be referred to trained service person only.
• Use authorized accessories only with this equipment.
Cellular Coverage for Alarm Communicator Operation
The HSPA/3G performance of the 3G2055 Alarm Communicators depends greatly on Cellular network coverage. The SCW
(with internal Alarm Communicator) should not be mounted in the final location without first ensuring that Cellular radio recep-
tion is adequate for communication using the HSPA/3G paths. Perform the “Communicator Placement Test” on page 9.
GENERAL INFORMATION
Table 1: Data Entry at Keypad
Key Valu e Key Val u e Key Value
1 1-A-B-C 4 4-J-K-L 7 7-S-T-U
2 2-D-E-F 5 5-M-N-O 8 8-V-W-X
3 3-G-H-I 6 6-P-Q-R 9 9-Y-Z-0

3G Alarm Communicator Installation Manual General Information
5
GENERAL INFORMATION
All versions of the HSPA/3G Alarm Communicator, operate on a HSPA/3G network and are housed inside the Self Contained Wireless
SCW9055/9057. The Communicators use an Internal Antenna, optional extension antennas are also available as required.
Each version of Alarm Communicators covered by this Installation Manual are described below:
3G2055: A High Speed Packet Access/Global System for Mobile (HSPA/3G) wireless Alarm Communicator that sends alarm commu-
nication to Sur-Gard System I, II, III (SG-DRL3IP), IV (SG-DRL4IP) and 5 (SG-DRL5IP) central station receivers via a HSPA/3G dig-
ital cellular network.
NOTE: For European market the following model names is available: 3G2055-EU. For the South America/Mexico market
(excludes Brazil) the following model is available 3G2055-LAT. For Australian/New Zealand/Brazil market the following model
name is available: 3G2055-AU. The Generic name "3G2055" used throughout this manual is representative of all models unless
otherwise indicated.
CAUTION:
• Do not stay close to the equipment during device operation and do not touch exposed wires and other conductive surfaces,
• Recycle the battery according to the local rules and regulations.
NOTE: Prior to installation of the 3G2055 Communicator, confirm with your local carrier that the HSPA/3G network is avail-
able and active in the area where the Communicator will be installed, and that the location provides a radio signal strength that is
adequate for uninterrupted service.
FEATURES
COMMUNICATOR FREQUENCY BANDS BY MARKET
COMMUNICATOR TECHNICAL SPECIFICATIONS
• 128-bit Advanced Encryption Standard (AES) encryption via HSPA/3G.
• Remote programming through DLS 5.
• Back up or primary HSPA/3G/2G alarm communication.
• Does not require an external HSPA/3G/2G antenna.
• Full event reporting to central station.
• 2-way audio (Listen-In feature) provided over Cellular (with SCW9057 only).
• Integrated call routing.
• Remote Firmware upgrade capability of the Communicator and Panel Firmware via HSPA/3G radio.
• CID and SIA format reporting.
• Supervision heartbeats via HSPA/3G/2G.
Table 2: 2G Frequency Bands - All Markets
Transmit Direction Cellular 900 DCS 1800
Transmit Frequency 880 MHz to 915 MHz 1710 MHz to 1785 MHz
Receive Frequency 925 MHz to 960 MHz 1805 MHz to 1880 MHz
Table 3: 3G Frequency Bands - Europe
Transmit Direction UMTS 900 UMTS 2100 (IMT)
Transmit Frequency 882.4 MHz to 912.6 MHz 1922.4 MHz to 1977.6 MHz
Receive Frequency 927.4 MHz to 957.6 MHz 2112.4 MHz to 2167.6 MHz
Table 4: 3G Frequency Bands - Australia, New Zealand and Brazil
Transmit Direction UMTS 850 (CLR) UMTS 2100 (IMT)
Transmit Frequency 826.4 MHz to 846.6 MHz 1922.4 MHz to 1977.6 MHz
Receive Frequency 871.4 MHz to 891.6 MHz 2112.4 MHz to 2167.6 MHz
Table 5: 3G Frequency Bands - Mexico and South America (excluding Brazil)
Transmit Direction Cellular 850 North America PCS 1900 North America
Transmit Frequency 824 MHz to 849MHz 1850 MHz to 1910 MHz
Receive Frequency 869 MHz to 894MHz 1930 MHz to 1990 MHz

Ratings 3G Alarm Communicator Installation Manual
6
RATINGS
HARDWARE COMPATIBILITY
Products or components of products, which perform communications functions only shall comply with the requirements applicable to
communications equipment as specified in UL60950 or CAN/CSA-C22.2 No. 60950-1, Information Technology Equipment - Safety -
Part 1: General Requirements. Where network interfaces are internal to the control unit or receiver, compliance to CAN/CSA-C22.2 No.
60950-1 is adequate. Such components include, but are not limited to: hubs; routers; NIDs; Third party communications service provid-
ers; DSL modems; and Cable modems.
REMOTE PROGRAMMING VIA DLS 5:
NOTE: Before programming, you will require your network’s Public IP Address and Public listening port for incoming DLS 5
connections. You must send an SMS message to the unit, therefore, you must know the phone number assigned to the SIM.
1. Run the DLS 5 software on your computer. If required, download the DLS 5 software from DSC: http://www.dsc.com/
index.php?n=library#self
2. Create an account for the Panel/Communicator, select the Communicator type (e.g., SMS - 3G2055) and enter all relevant informa-
tion under SMS section, including the Communicator’s cellular telephone number.
3. All available Communicator and panel options can be configured in the DLS 5 account. Refer to Panel Installation Guide and Com-
municator Manual for detailed programming information. Also, refer to your DLS 5 manual and Help file.
4. When you have finished programming the account, click Global Download and choose SMS as Connection Type. Click OK.
5. DLS 5 will generate the required text for the SMS message. This message has the Public IP and Port Number of the DLS Server to
allow the Communicator to link up with your computer. Type the SMS message in to your cell phone and send to the Communica-
tor’s cellular phone number. Then Click OK.
6. The SMS message will trigger the unit to establish a connection to your DLS 5 software. New programming of the Communicator
will be downloaded to the unit remotely via cellular or Ethernet/Internet. The actual path for the downloading will be determined by
the Communicator’s communication settings in Section [851][005], Toggle Option [4].
NOTE: You can disable DLS over cellular. Refer to Programming Worksheets Section [006] Toggle Option [7]. If you disable
DLS over cellular, remote programming will not work on the 3G2055 Communicator, regardless of the path set in Programming
Options Section [005] Toggle Option [4].
E NCRYPTION
The Communicator uses 128 Bit AES Encryption. Encryption can only be enabled from the monitoring station receiver. Each receiver
can independently have encryption enabled or disabled. When encryption is enabled, the central station will configure the device to
encrypt communications the next time the Communicator module performs a communication to that receiver.
NOTE: Packets will start being encrypted only after the next event is sent to that receiver, or if the unit is restarted.
Table 6: Communicator Electrical Ratings
Model 3G2055 Cellular Only
Power Supply Ratings
Input Voltage 3.5 / 3.9 / 4.2 VDC (min / NOM / MAX) from the SCW panel
Current Consumption 75 mA
Standby Current (@ 3.7V) 75 mA
Alarm (Transmitting) Current 400 mA @ 3.7V during transmission
Antenna Specifications
Dual band Antenna See Table 2 and Table 3
Environmental Specifications
Operating Temperature 0°C - 49°C (32°F- 120°F)
Humidity 5% ~ 85% relative humidity, non-condensing
Mechanical Specifications
Board Dimensions (mm) 109 x 110
Weight (grams) 60
Table 7: Compatibility
Communicator Receiver/Control Panel Description
3G2055 Receiver
SG System I, v1.14+
SG System II, v2.11+
SG-DRL3-IP, v2.3+
SG-DRL4-IP, v1.2+
SG-DRL5-IP, V1.00+
Control Panel SCW9055/SCW9057 V1.1+
COMMUNICATOR PRE INSTALLATION CONFIGURATION

3G Alarm Communicator Installation Manual Installation Location
7
NOTE: The Alarm Communicator
is installed in the SCW prior to ship-
ment by Digital Security Controls
(DSC). The Factory Installation
includes insertion of the SIM card.
The SCW should not be mounted in
its final location without performing
a Communicator Test to ensure ade-
quate HSPA/3G coverage for the
3G2055 Alarm Communicator.
INSTALLATION LOCA-
TION
The Communicator shall be installed
in an indoor location only.
This HSPA/3G Communicator shall
be installed by Service Persons only.
(Service Person is defined as a person
having appropriate technical training
and experience necessary to be aware
of hazards to which that person may
be exposed in performing a task and of
measures to minimize the risks to that
person or other persons). The Com-
municator shall be installed and used
within an environment that provides
the pollution degree max 2, over volt-
ages category II, in non-hazardous,
indoor locations only. This manual
shall be used with the Installation Manual of the alarm control panel which is connected to the HSPA/3G Communicator. All instruc-
tions specified within the control panel manual must be observed.
All the local rules imposed by local electrical codes shall be observed and respected during installation.
INSERTING/REMOVING THE SIM
CARD
1. Remove the front cover of the SCW Control
Panel to access SIM card holder.
2. Remove power from the SCW and disconnect the
backup battery connections.
3. On the SIM card holder push gently to slide the
cover towards OPEN as indicated by the arrow on
SIM holder. This will unlatch the SIM card holder
on the side furthest from edge of the Communica-
tor. See Figure 1.
4. Lift up the SIM card holder from the side that is not hinged.
NOTE: The SIM card can be damaged by bending or scratching contacts. Use caution when handling the SIM card.
5. Insert or remove the SIM card, noting the orientation of the notches on the SIM card and the SIM card holder.
6. When inserting a SIM card, insert the card in the proper orientation and gently push the SIM card holder down and slide the holder
as indicated by the arrow on SIM holder, to LOCK.
7. Apply AC power to panel, and replace the panel cover.
NOTE: If two way audio is enabled you will NOT be able to swap the SIM card with another card.
COMMUNICATOR RESET
The Communicator can be reset by cycling the power on the SCW.
COMMUNICATOR CONFIGURATION WITH SCW
Figure 1: Communication Board Connection Points
Mounting
Hole
Mounting
Hole
SIM Card Holder
RJ-45
Connector
(TL255 and
TL2553G only)
SIM Card Pinouts
DG0009396
Figure 2: SIM Card Pinouts

Establishing a Communication Channel with the SCW Panel. 3G Alarm Communicator Installation Manual
8
ESTABLISHING ACOMMUNICATION CHANNEL WITH THE SCW PANEL.
The Communicator interfaces to the SCW through a keyed 16 pin Ribbon cable. See Table 8 . The key prevents incorrect connec-
tion of the ribbon cable connector to the SCW and Communicator. The pin-out for the Ribbon cable is provided in the Table
below:
Establishing a communication channel between the Communicator and the SCW is critical to ensuring the desired operation of the two
units. The following steps must be completed during the on-site installation. Program the following to ensure that the Communicator
and the panel will work together as intended.
Initial Programming of Communicator and SCW
1. Enter [*][8][Installer Code] [Section Number] for panel programming. Record any values that are modified from their
default, in the appropriate Programming Worksheets.
NOTE: When programming Toggle Options, the toggle is ON when the number is displayed and OFF when the number is not
displayed. (e.g., [1 ---5---],ToggleOptions1and5areON,allothersareOFF).
2. Panel Section [167] Cellular/Ethernet Interface Communications ‘Wait for ACK’: Default value is: 060 seconds.
3. When the communicator is installed with the SCW panel, 4 telephone numbers are available to backup one another. You can set up
these 4 telephone numbers to perform in one of two ways: Backup dialling or Alternate dialling.
a. Backup dialling: each of the 4 telephone numbers will make 5 dialling attempts in turn, before an FTC trouble is dis-
played on the keypad.
b. Alternate dialling: each telephone number makes 1 dialling attempt before moving on to the next number, cycling
through each of the 4 numbers for a total of 5 times each. If all 4 numbers fail the 5 attempts, an FTC trouble is displayed
on the keypad.
4. Panel Sections [301], [302], [303], and [305] can be configured as Primary communication paths.
a. Panel Sections [302], [303], and [305] may also be configured for backup or redundant communications by using Panel
Section(s) [383] or [351] - [376]. Refer to the SCW panel Installation Manual for more information.
b. If a valid telephone number is programmed, communications will use Public Switched Telephone Network (PSTN).
Entering a 4 digit hexadecimal value for a telephone number will change the call routing to the Communicator, as deter-
mined by the number programmed:
DCAAF: Internal (All Receivers). Signals will be routed depending on Section [851] [006] programming.
DCDDF: Cellular Receiver 1 (Primary).
DCEEF: Cellular Receiver 2 (Backup).
NOTE: Add a single ‘F’ as a suffix to the 4 digit hex number to populate the unused remainder of the 32 character field.
5. Panel Section [350] : If any of the phone numbers have been programmed as DCAA, DCDD, or DCEE, panel Section [350] must be
set to [04] if SIA format or [03] if Contact ID (CID) format is used by control panel.
6. Panel Section
[382] : Toggle Option [5] , ‘GS/IP Module Enabled’, must be set to ON .
7. Panel Section
[401] : Toggle Option [1] must be set to ON in order to perform panel DLS session through Cellular or Ethernet data
channel.
8. Panel section
[310] , account code, auto syncs with the communicator account code in section [021] . The panel account code
([
*][8] [installer code] [310] ), will overwrite the communicator account code section ([ *][8] [installer code] [850] [021] ) if pro-
grammed differently.
NOTE: Keep a record of the SIM card telephone number, it is required by users for SMS Command and Control functions. (The
number can be recorded in the Programming Worksheets Section of this document, under Option [996]). Due to the nature of the
SIM card activation process with Cellular network carriers, it can take up to 24 hours for SIM card activation to be complete.
SMS COMMAND AND CONTROL FUNCTIONS
SMS Command and Control is available on SCW9055/57 panels. Users can send SMS text messages from their mobile phone to
the cellular phone number assigned to their system. Commands are only accepted from telephone numbers that have been pro-
grammed in Sections [311]-[318]. The system will reject messages sent from telephone numbers that are not on the programmed
list.
When the received SMS text matches a valid Section message, the function is performed on the control panel. Text messages are
not case sensitive and extra spaces are ignored. A User Access Code may be required for some SMS messages.
The User can send just the partition number or the complete label.(e.g., “Away arm Partition 2 1234” is treated the same as “away
arm 2 1234”).
The SMS Message format is in 3 parts: Command, Partition Label (or only the partition number), and Access Code.
If an Access Code is included in the message, it is sent to the control panel for validation, along with the requested function.
If the panel is configured to require an Access Code and the code is not sent (or invalid) the panel will fail the function (unsuc-
cessful).
Table 8: Communicator Ribbon cable to SCW
Pin # Signal Pin # Signal
1 PC-Link TX 2 PC-Link RX
3 GND 4 Vref
5 Vref 6 GND
7 AUD-OUT_N 8 AUD-OUT_P
9 AUD-IN_P 10 AUD-IN_N
11 GND 12 SI
13 GND 14 SO
15 GND 16 Wall Tamper

3G Alarm Communicator Installation Manual Label Programming for SMS Message
9
If the panel fails the function, an SMS response message is sent to the user. The SMS response will echo the command sent, fol-
lowed by the label “unsuccessful”. (e.g., “night arm partition 2 1234 unsuccessful”).
The partition label or partition number may be excluded from the SMS request in a single partition system (e.g., disarm 9123).
NOTE: The communicator cellular phone number can be viewed in Section [851], [996] and/or [851], [229] or by user entering
*6, then scrolling down to ‘SMS Programming” and scrolling down to “Cellular phone No.” [<] [>] “Cellular Phone No.” at the
keypad. An Access Code is required for all SMS commands, except Help.
LABEL PROGRAMMING for SMS MESSAGE
Programmable Labels can be modified using DLS 5 for label programming only, if labels need to be modified. Before initiating remote
programming, record your network’s Public IP Address and port for incoming DLS 5 connections.
1. Run the DLS 5 software on your computer. DLS 5 will connect to the unit, using the Public IP address, and make an Ethernet
connection. If the Ethernet connection fails, DLS 5 will report an error and prompt you to connect using Cellular.
NOTE: If required, download the DLS 5 software from DSC: http://www.dsc.com/index.php?n=library#self.
2. DLS will generate a prompt to enter the public IP and port of the computer with DLS, once this is completed an SMS message will
appear, send this SMS message to the communicator using a cellular device.
NOTE: The communicator phone number can be found in section [995].
3. SMS message will establish a connection to your computer’s DLS 5 software (to change programming labels only).
4. Create an account for the panel/Communicator, select the Communicator type (e.g., SMS - 3G2055) and enter all relevant informa-
tion in
SMS section.
NOTE: The Cellular telephone number will also be required by the user, to send SMS Command and Control messages to their
system.
5. Program the account information, then click Global Download and choose SMS as the Connection Type . Click OK .
6. The download path configured in Programming Section
[005] Toggle Option[4] determines the Cellular or Ethernet path to be used.
COMMUNICATOR PLACEMENT TEST
1. Using the keypad enter the installer mode: * 8 [installer code] [850].
2. View and record the number of bars showing on the SCW LCD.
3. Compare with the number of bars indicated in the “CSQ Levels” column shown in Table 9 .
4. If 3 or more bars are shown, the location is GOOD and no further action is required.
5. If the location is BAD, move the SCW to various suitable locations until 3 or more bars are obtained.
NOTE: The communicator is capable of indicating signal strength even without an active SIM, but signal indication may take up
to 1-2 minutes.
Table 9: Communicator CSQ Levels
Signal
Strength CSQ Level Signal Level dBm Installer Action
No Signal 0 -108.8 Check if Cellular coverage is active in your area.
1 Bar 1 to 4 -108d to -103 Location is BAD. Not suitable for Cellular operation.
2 Bars 5 to 6 -102 to -99
Location is FAIR. If the average signal strength is CSQ is 5, the system
may not communicate events successfully to the Monitoring Station.
Installer should consider relocation, if possible.
3 Bars 7 to 10 -98d to -91 Location is GOOD.
4 Bars 11 to 13 -90 to -85 Location is GOOD
5 Bars 14 and higher -84 and higher Location is GOOD.

System Options 3G Alarm Communicator Installation Manual
10
The Programming Sections described in this document can be viewed at the SCW LCD. To start programming enter: [*][8][installer
code][851][###]
, Where # # # is the 3 digit Section number referenced in this section. The Programming Worksheets at the end of
this document can be used to record the new values when programming changes have been made from the default values.
SYSTEM OPTIONS
[004] Receiver Supervision Interval
Default (0087/135)
When receiver supervision is enabled (ON) in Section [005] Toggle Option [3], the unit sends heartbeats to Cellular Receiver 1 to
test the communications path. Use this Section to set the interval time (in seconds) when heartbeats will be sent to the receivers.
Valid range 000A-FFFF seconds. If the programmed value is less than (000A/10) seconds, supervision is disabled.
•Receiver Window: This is the supervision timeout that must be configured at the central station receiver.
•Recommended Values: This is the recommended heartbeat interval that should be programmed into the Communicator.
[005] System Toggle Options
[2] Cellular Receiver 1 Supervised
Default (OFF)
ON: Cellular Receiver 1 will be supervised and heartbeats will be sent to Cellular Receiver 1 based on the supervision inter-
val programmed in Section [004]. If ACK to heartbeat is not received, it is retransmitted every 5 seconds. Failure to ACK 2
consecutive heartbeats will reset the radio.
OFF: Cellular Receiver 1 will not be supervised. When disabled, heartbeat is not sent to the receiver. Supervisory trouble is
indicated.
NOTE: Cellular Receiver 2 can not be supervised.
[3] Supervision Type
Default (OFF)
ON: Heartbeat 1 (Commercial Supervision). This supervision type is suitable for applications where swap detection is
required on the supervisory packet.
OFF: Heartbeat 2 (Residential Supervision). This supervision type is suitable for applications where supervision of the
communication path to the receiver is required. (no swap detection).
NOTE: Commercial supervision is more data intensive than residential supervision and should only be used when required to
meet the approval for the installation.
[4] Primary Path
Default (ON)
ON: Cellular channel is the primary path.
OFF: Not available.
[5] Not used
[6] Remote Firmware Upgrade
Default (ON)
ON: The Communicator module firmware can be remotely upgraded using the Ethernet/Cellular paths.
OFF: The Communicator module firmware can not be remotely upgraded. Local firmware upgrade is still possible.
[7] Alternate Test Transmissions
Default (OFF).
ON: When the periodic test transmission interval occurs, the test transmission will alternate between being sent to the pri-
mary and secondary receivers with each test transmission interval.
OFF: When the periodic test transmission interval occurs, the test transmission will be sent to the programmed receivers,
based on the settings of the periodic test transmission reporting codes.
[8] Cellular Low Signal Trouble.
Default (OFF)
This option masks the Low Signal trouble from the Cellular trouble event.
ON : A Cellular Trouble event is transmitted to receiver when the radio signal level falls below threshold level (average CSQ level is 4 or less).
OFF: A Cellular Trouble event is not transmitted to receiver when the radio signal level falls below threshold level (average
CSQ level is 4 or less).
[006] System Toggle Options 2
[1] Not used
Default (OFF).
[2] Not used
Default (OFF).
[3] Reserved. ( ).
[4] Cellular 1 Receiver Enabled.
Default (ON).
ON: Cellular Receiver 1 is enabled.
OFF: Cellular Receiver 1 is disabled.
[5] Cellular 2 Receiver Enabled.
Default (ON).
CELLULAR PROGRAMMING OPTIONS

3G Alarm Communicator Installation Manual Programming Options
11
ON: Cellular Receiver 2 is enabled.
OFF: Cellular Receiver 2 is disabled.
[6] Reserved ( ).
[7] DLS Over Cellular.
Default (ON).
NOTE: Program this toggle as OFF if you want to completely disable DLS from using the Cellular path.
ON: DLS is enabled on the Cellular path.
OFF: DLS is disabled on the Cellular path.
NOTE: If this Toggle is OFF, DLS sessions will occur on the Ethernet path only, regardless of Primary Path set in Section [005]
Toggle Option [4]. If it is ON then the Communicator will connect to the Primary path first for DLS and if the session fails, the
Secondary path will be used.
[8] Reserved ( ).
[007] DNS Server IP 1
Default (000.000.000.000)
 Programming this Section is not permitted on a UL/ULC listed system.
Enter the IP address for DNS Server 1. Format is 4 fields, each field is a 3 digit decimal. Valid range: 000-255.
NOTE: If no value is programmed and DHCP is used, the DHCP Server will configure the address. If an address is programmed
and DHCP is used, the address that you program will be used instead of the DHCP address.
[008] DNS Server IP 2
 Programming this Section is not permitted on a UL/ULC listed system.
Default (000.000.000.000)
Enter the IP address for DNS Server 2. Format is 4 fields, each field is a 3 digit decimal. Valid range: 000-255.
NOTE: If no value is programmed and DHCP is used, the DHCP Server will assign this value. If an address is programmed and
DHCP is used, the address that you program will be used instead of the DHCP address.
PROGRAMMING OPTIONS
[010] System Toggle Option
Default (Disable)
[1] This bit is used to enable/disable two way audio over 3G.
[011] Installer Code
Default (CAFE)
Program your installer code for this Communicator module. The installer code will be required when programming the Commu-
nicator module. Valid range: 0000 - FFFF.
[012] DLS Incoming Port
Default (0BF6/3062)
The DLS Incoming Local Port (listening port) is the port DLS 5 will use when connecting to the Communicator. If a router or
gateway is used, it must be programmed with a Transmission Control Protocol (TCP) port forward for this port to the Communi-
cator module IP address. Valid range: 0000 - FFFF.
[013] DLS Outgoing Port
Default (0BFA/3066)
The DLS Outgoing Port is used for outgoing session to DLS 5 after an SMS request has been sent to the Communicator. Use this
Section to set the value of the local outgoing port. The value must be changed if the Communicator is located behind a firewall
and must be assigned a particular port number, as determined by your network administrator. In most cases, changing the default
value or configuring your firewall with this port is not required.
Valid range: 0000-FFFF.
NOTE: If Section [006] Toggle Option [7] is ON, DLS will use the Primary path for session. If Section [006] Toggle Option [7]
is OFF DLS will use the Ethernet path, if available.

Programming Options 3G Alarm Communicator Installation Manual
12
[020] Time Zone
Default (00)
Use Column 2 (Offset Hours) to find your local Time Zone. Record the two digit HEX value from Column 1 (HEX Value) on the same
row. Program this HEX value for your Time Zone. Valid range is 00 - FF.
Table 10: World Wide Time Zones
HEX
Value
Offset
Hours
Std
Abbrev Location HEX Valu e
Offset
Hours
Std
Abbrev Location
01 -12 BIT Baker Island Time 47 5.5 IST Indian Standard Time
05 -11 NUT Niue Time 48 5.75 NPT Nepal Time
SST Somoa Standard Time
49 6
XJT Xinjiang Standard Time
09 -10
HAST Hawaii-Aleutian Standard Time EKST East Kazakhstan Stan-
dard Time
THAT Tahiti Time LKT Sri Lanka Time
TKT Tokelau Time VOST Vostok Time
CKT Cook Island Time OMSK Omsk Standard Time
0B -9.5 MIT Marquesas Island Time NOVT Novosibirsk Time
0D -9
AKST Alaska Standard Time BTT Bhutan Time
GIT Gambier Island Time BIOT British Indian Ocean
Time
11 -8
PST Pacific Standard Time 4B 6.5 CCT Cococ Islands Time
PST Pitcarirn Standard Time MMT Myanmar Time
CIST Clipperton Island Standard Time
4D 7
CXT Christmas Island Time
15 -7 MST Mountain Standard Time KOVT Khovd Time
19 -6
CST Central Standard Time KRAT Krasnoyarsk Time
GALT Galapagos Time WIB Waktu Indonesia Bagian
Barat
PIT Peter Island Time ICT Indochina Time
EAST Easter Island Standard Time BDT Bangladesh Standard
Time

3G Alarm Communicator Installation Manual Programming Options
13
1D -5
EST Eastern Standard Time
51 8
AWST Australian Western Stan-
dard Time
COT Colombia Time CST China Standard Time
ECT Ecuador Time HKST Hong Kong Standard
Time
PET Peru Time WITA Waktu Indonesia Bagian
Tengah
ACT Acre Time TWT Taiwan Time
1F -4.5 VST Venezuela Standard Time SST Scarborough Shoal Time
21 -4
AST Atlantic Standard Time SIT Spratly Island Time
CLST Chile Standard Time SGT Singapore Time
BWST Brazil Western Standard Time PST Philippine Standard Time
SLT San Luis Time PIT Pratas Islands
PYT Paraguay Time PIT Parcel Island Time
JFST Juan Fernandez Island Standard
Time MYT Malaysia Time
GYT Guyana Time MNT Mongolia Time
FKST Falkland Island Standard Time MBT Macclesfield Bank Time
BOT Bolivia Time IRKT Irkutsk Time
23 -3.5 NST Newfoundland Standard Time BDT Brunei Time
25 -3
CGT Central Greenland Time ACIT Ashmore and Cartier
Island Time
ART Argentina Time 52 8.25 APO Apo Island Time
BRT Brazilia Time 54 8.75 ACWST
Australian Central Western
Standard Time
UYT Uruguay Standard Time
55 9
YAKT Yakutsk Time
SRT Suriname Time JST Japan Standard Time
ROTT Rothera Time KST Korea Standard Time
PMST St. Pierre & Miquelon Standard
Time WIT Waktu Indonesia Bagian Timur
GFT French Guiana Time TPT East Timor Time
29 -2
GST South Georgia and the South
Sandwich Islands PWT Palau Time
BEST Brazil Eastern Standard Time 57 9.5 ACST Australian Central Stan-
dard Time
Table 10: World Wide Time Zones
HEX
Value
Offset
Hours
Std
Abbrev Location HEX Valu e
Offset
Hours
Std
Abbrev Location

Programming Options 3G Alarm Communicator Installation Manual
14
2D -1
EGT Eastern Greenland Time
59 10
AEST Australian Eastern Stan-
dard Time
CVT Cape Verde Time GST Guam Standard Time
AZOST Azores Standard Time YAPT Yap Time
31 0
WET Western European Time VLAT Vladivostok Time
GMT Greenwich Mean Time (UTC) TRUT Truk Time
SLT Sierra Leone Time PGT Papua New Guinea Time
IST Ireland Standard Time DTAT District de Terre Adelie
Time
35 1
CET Central European Time ChST Chamorro Standard Time
WAT Western Africa Time 5B 10.5 LHST Lord Howe Standard
Time
BST British Summer Time
5D 11
KOST Kosare Standard Time
39 2
EET Eastern European Time NCT New Caledonia Time
CAT Central Africa Time VUT Vanuatu Time
SYT Syrian Standard Time SBT Solomon Island Time
SAST South Africa Standard Time PONT Phonpei Standard Time
IST Israel Standard Time MAGT Magadan Island Time
3D 3
MSK Moscow Standard Time 5F 11.5 NFT Norfolk Island Time
EAT Eastern Africa Time
61 12
NZST New Zealand Standard
Time
AST Arabic Standard Time FJT Fiji Time
AST Arabia Standard Time WFT Wallis and Futuna Time
AST Al Manamah Standard Time TVT Tuvalu Time
3F 3.5 IRST Iran Standard Time PETT Petropavlovsk Time
41 4
AMST Armenia Standard Time NRT Nauru Time
SCT Seychelles Time MHT Marshall Island Time
GST Gulf Standard Time GILT Gilbert Island Time
SAMT Samara Time ANAT Anadyr Time
RET Reunion Time 64 12.75 CHAST Chatham Island Standard
Time
MUT Mauritius Time
65 13
PHOT Phoenix Island Time
ICT Iles Crozet Time TOT Tonga Time
GET Georgia Standard Time 69 14 LINT Line Island Time
AZT Azerbaijan Time 70 -
FF N/A Reserved
43 4.5 AFT Afghanistan Time
Table 10: World Wide Time Zones
HEX
Value
Offset
Hours
Std
Abbrev Location HEX Valu e
Offset
Hours
Std
Abbrev Location

3G Alarm Communicator Installation Manual Communications Reporting Codes
15
[021] Account Code
Default (FFFFFF)
The account code is included when transmitting any events generated by the Communicator. (e.g., Panel Absent Trouble). It is
recommended that the account code be the same as the control panel account number. Valid range: 000001-FFFFFE. If 4 digit
account codes are needed the 2 lowest digits shall be programmed as FF.
(e.g., Account 1234 is programmed as:1234FF).
NOTE: Programming this Section with all 0 or F will cause a Module Configuration Trouble.
[022] Communications Format
Default (04)
Program 03 for Contact ID (CID). Program 04 for SIA. The module can be configured to send Events in SIA or CID format. The
SIA communication format follows the level 2 specifications of the SIA Digital Communication Standard - October 1997. This
format will send the account code along with its data transmission. The transmission will look similar to the following at the
receiver. Example: Nri0 ET001
Where: N= New Event; ri0 = Partition/Area identifier; ET = Panel Absent Trouble; 001 = Zone 001.
COMMUNICATIONS REPORTING CODES
[023] Panel Absent Trouble
Default (FF)
Program 00 to disable this event or FF to enable. This event will occur when communications with the panel have been lost for
more than 60 seconds.
[024] Panel Absent Trouble Restore
Default (FF)
Program 00 to disable this event or FF to enable. This event will occur when communications with the control panel have
resumed.
45 5
CAST Casey Station (Aus) Standard Time
WKST West Kazakhstan Standard Time
PKT Pakistan Time
YEKT Yekaterinburg Time
UZT Uzbekistan Time
TMT Turkmenistan Time
TJT Tajikistan Time
TFT French Southern and Antarctic Time
MVT Maldives Time
MAWT Mawson Time
KGT Kyrgyzstan Time
HMT Heard and McDonald Island Time
DAVT Davis Time
Table 11: Communications Reporting Codes
Event SIA
Identifier
SIA
Reporting
Code
CID
Qualifier
CID Event
Code
CID
Reporting
Code
CID
User/
Zone
[023] Panel Absent Trouble ET 001 1 3 55 001
[024] Panel Absent Trouble Restore ER 001 3 3 55 001
[025] Radio Activation Restore RS 001 3 5 52 001
[028] Cellular 1 Test Transmission RP 003 1 6 A3 955
[029] Cellular 2 Test Transmission RP 004 1 6 A3 956
[030] FTC Restore YK 001 3 3 54 001
Table 10: World Wide Time Zones
HEX
Value
Offset
Hours
Std
Abbrev Location HEX Valu e
Offset
Hours
Std
Abbrev Location

System Test Options [026 - 029] 3G Alarm Communicator Installation Manual
16
[025] Radio Activation Restore
Default (FF)
Program 00 to disable this event or FF to enable. This event will occur after any successful programming session.
SYSTEM TEST OPTIONS [026 - 029]
Test Transmissions to Primary Receiver, with Backup to Secondary Receiver:
Set Cellular Section [028] to (FF); [029] to (00).
• If the test transmission fails to the primary receiver it will backup to the secondary receiver.
• If the test transmission fails to the secondary receiver an FTC trouble will be generated.
Test Transmission Unique to Primary and Secondary Receivers:
Set Cellular Section [028] to (FF); [029] to (FF).
• The module will send periodic test transmissions to each receiver independently, with no backups.
• If the test transmission fails to any of the programmed receivers, an FTC trouble will be generated.
Alternate Test Transmission:
Alternate Test Transmission can be enabled or disabled in Section [005] Toggle Option [7].
[028] Cellular 1 Transmission
Default (FF)
Program 00 to disable this event transmission or FF to enable. See System Test Options (above) for details on settings.
[029] Cellular 2 Transmission
Default (00)
Program 00 to disable this event transmission or FF to enable. See System Test Options (above) for details on settings.
NOTE: The time interval (in minutes) between periodic tests is programmed in Section [125] (Ethernet) and Section [225] (Cel-
lular).
[030] FTC Restore
Default (FF)
Program 00 to disable this event transmission or FF to enable. This event will occur when an FTC Trouble on the system restores.
[031] Priority Tamper Alarm
Program 00 to disable this event or FF to enable. This event will occur when panel tampered during the entry delay.
[032] Priority Tamper Restore
Program 00 to disable this event or FF to enable.This event will occur when panel tamper restored.
[033] Communicator Firmware Update Begin
Default (FF);
Program 00 to disable this event transmission or FF to enable. This event will occur when the communicator firmware update begins.
[034] Communicator Firmware Update Successful
Default (FF);
Program 00 to disable this event transmission or FF to enable. This event will occur when the communicator firmware update success-
fully completed.
[035] Panel Firmware Update Begin
Default (FF);
Program 00 to disable this event transmission or FF to enable. This event will occur when the panel firmware update begins.
[036] Panel Firmware Update Successful
Default (FF);
Program 00 to disable this event transmission or FF to enable. This event will occur when the panel firmware is updated successfully.
[037] Panel Firmware Update Fail
Default (FF);
Program 00 to disable this event transmission or FF to enable. This event will occur when the panel firmware updated has failed.
Table 12: Priority Temper Restore
Event SIA Identifier SIA Reporting
Code
Contact ID
Qualifier
Contact ID
Event Code
Contact ID
Reporting Code
Contact ID
User/Zone
Priority Tamper BA 000 1 1 4A 000
Priority Tamper Restore BR 000 3 1 4A 000

3G Alarm Communicator Installation Manual
17
Table 13: Panel Tamper Alarm Restore
CELLULAR RECEIVER 1 OPTIONS
[201] Cellular Receiver 1 Account Code
Default (0000000000)
The account code is used by the central station to distinguish between transmitters. This account code is used when transmitting
heartbeat signals to the central station receiver. Signals received from the control panel will use the control panel account number.
Valid range: 0000000001- FFFFFFFFFE. Programming all 0or all Fwill cause a Module Configuration Trouble (yellow LED =
12 flashes).
[202] Cellular Receiver 1 DNIS
Default (000000)
The DNIS is used in addition to the account code to identify the Communicator module at the central station. Valid range: 000000
- 099999. Values are entered as leading 0followed by the five digit DNIS. Format is BCD.
NOTE: Each Ethernet/Cellular receiver must be programmed with a unique DNIS.
[203] Cellular Receiver 1 Address
Default (000.000.000.000)
Enter the Cellular Receiver 1 IP address. This information will be provided by your central station system administrator. Each
3-digit segment of the address must be within a valid range of 000-255.
NOTE: When a valid IP address has been entered, the Cellular is enabled and will communicate events over the Cellular chan-
nel.
[204] Cellular Receiver 1 Port
Default (0BF5/3061)
This Section determines the port used by Cellular Receiver 1. Change the default value of this port when your installation is
located behind a firewall, and must be assigned a particular port number as determined by your central station system administra-
tor. Valid range: 0000 - FFFF.
NOTE: Programming this Section with 0000 will disable the receiver.
[205] Cellular Receiver 1 APN
Default ( )
The Access Point Name (APN) determines the Cellular network that the Communicator will connect to. This information is
available from your network carrier. Program this Section as 32 ASCII characters.
NOTE: When a SIM card with a custom APN is used, the unit will not have access to the Internet. DLS and remote flash can still
be done if Section [221] is programmed with a valid Public APN.
[206] Cellular Receiver 1 Domain Name
Default ( )
 Programming this Section is not permitted on a UL/ULC listed system.
Enter the Domain Name as 32 ASCII characters. This information will be provided by your central station system administrator.
CELLULAR RECEIVER 2 OPTIONS
[211] Cellular Receiver 2 Account Code
Default (0000000000)
The account code is used by the central station to distinguish between different transmitters. This account code is used when
transmitting signals to the central station receiver. Signals received on the panel will use the panel account number. Valid range:
0000000001- FFFFFFFFFE.
NOTE: Programming this Section as all 0 or F will cause a Module Configuration Trouble (yellow LED = 12 flashes).
Event SIA
Identifier
SIA
Reporting
Code
Contact ID
Qualifier
Contact ID
Event Code
Contact ID
Reporting
Code
Contact ID
User/Zone
[033]Comm. FW Update Begin LB 00 1 9 03 002
[034]Comm. FW Update Successful LS 00 3 9 03 002
[035]Panel FW Update Begin LB 00 1 9 03 003
[036]Panel FW Update Successful LS 00 3 9 03 003
[037]Panel FW Update Fail LU 00 1 9 04 003

Cellular Options 3G Alarm Communicator Installation Manual
18
[212] Cellular Receiver 2 DNIS
Default (000000)
The DNIS is used in addition to the Account Code to identify the Communicator module at the central station. Valid range:
000000 - 099999. Values are entered as a 0 followed by the 5 digit DNIS value. Format is BCD.
NOTE: Each Ethernet/Cellular receiver must be programmed with a unique DNIS.
[213] Cellular Receiver 2 Address
Default (000.000.000.000)
Enter the Cellular Receiver 2 IP address. This IP address will be provided by your central station. Format is 4 fields, each field is
3-digit decimal. Valid range: 000 - 255. When a valid address has been entered, Cellular Receiver 2 is enabled and will commu-
nicate events over the Cellular path.
[214] Cellular Receiver 2 Port
Default (0BF5/3061)
This Section defines the port of Cellular Receiver 2. Change the value of this port when your installation is located behind a fire-
wall and must be assigned a particular port number, as determined by your central station system administrator.
Valid range: 0000 - FFFF.
NOTE: Do not program Cellular Receiver 1 and Cellular Receiver 2 to communicate to the same receiver.
[215] Cellular Receiver 2 APN
Default ( )
The APN determines the Cellular network that the Communicator will connect to. This information is available from your net-
work carrier. Program this Section with up to 32 ASCII characters.
NOTE: When a SIM card with a custom APN is used, the unit will not have access to the internet. DLS and remote flash can still
be done if Section [221] is programmed with a valid Public APN.
[216] Cellular Receiver 2 Domain Name
Default ( )
 Programming this Section is not permitted on a UL/ULC listed system.
Enter the Cellular Receiver 2 Domain Name with up to 32 ASCII characters.
CELLULAR OPTIONS
[221] Cellular Public Access Point Name
Default ( )
When the Communicator is operating on a private APN, use this Section to select a public APN for DLS and Remote Firmware
Update. This information is available from your network carrier. The APN identifies the public Cellular network that the Com-
municator will connect to.
[222] Cellular Login User Name
Default ( )
Some network carriers require you to provide login credentials when connecting to an APN. Program your login User Name in
this Section. Format is up to 32 ASCII characters.
NOTE: This Section is not accessible via SCW keypad programming.
[223] Cellular Login Password
Default ( )
Some network carriers require you to provide login credentials when connecting to an APN. Program your login Password in this Section.
Format is up to 32 ASCII characters.
[224] Cellular Test Transmission Time of Day
Default (9999)
Enter a 4 digit value using the 24-hour clock format (HHMM) to set the test transmission time of day. Valid range: 00-23 for the
hours (HH) and 00-59 for the minutes (MM).
NOTE: To disable the test transmission time of day enter 9999 or FFFF in this Section.
The internal date and time will be automatically programmed by the primary receiver only.
[225] Cellular Test Transmission Cycle
Default (000000)
This value represents the interval in between test transmissions in minutes. Valid range: 000000 - 999999 minutes. Once the unit
has sent the initial periodic test transmission, all future test transmissions will be offset by the programmed number of minutes.
See Sections [026] - [029].
NOTE: Minimum value is 000005 minutes. Programming an interval that is less than 5 minutes will disable test transmission.
Table 14: Cellular Test Transmission Interval
Test Transmission Interval Daily Weekly Monthly
Programmed Minutes 001440 010080 043200

3G Alarm Communicator Installation Manual Command and Control Options
19
[226] Cellular Trouble Delay
Default (00)
This option is used to program the delay, in minutes, for reporting a Cellular Trouble Delay. Valid entries are 00 - FF. (e.g., for a
10 minute Cellular Trouble Delay enter: 0A). There is no reporting delay if value is programmed as 00.
[227] Voice Call Timeout
Default (00);
This option sets the Voice Call Timeout, in minutes. Programming a value of 00 will disable timeout. Valid range is 00 to FF.
[228] Voice Call Back Time
Default (0A);
This option sets the Voice call back time, in minutes. When the Communicator requests Call Back from the receiver, it will
answer incoming calls during the programmed timeout period. If an incoming call is received after the timeout from requesting
call back, the Communicator will answer the call and immediately hang up. Programming a value of 00 will disable timeout
(accept all incoming calls). Default value is 0A/10 seconds. Valid range is 00 to FF.
[229] Voice Call Back Number
Default (SIM Telephone Number);
This option sets the Voice Call Back Telephone Number for the receiver. This number is used for Two Way calling. Current SIM
telephone number can be viewed in Section [996]. Valid entry is 32 character ASCII.
COMMAND AND CONTROL OPTIONS
[301] Command and Control Toggle Options
[1]SMS Notification Default (ON).
[2]Reserved Default ( ).
[3]SMS Command and Control Default (ON).
[4]Reserved Default ( ).
[5]SMS Character Format Default.
ON: SMS Unicode, maximum message length is 70 characters.
OFF: 7 bit SMS, maximum message length is 160 characters.
[6]Long SMS Message Handling Default (OFF).
ON: If longer than maximum message length, it is split and sent as multiple SMS messages.
OFF: If longer than maximum message length, a single, truncated SMS message is sent.
[7-8] Reserved Default ( ).
[311] - [318] SMS Phone Number 1 - 8
Default ( );
These Sections may be programmed through DLS 5 or the keypad. Up to 8 SMS telephone numbers (4 - 32 digits) can be programmed
in Section [31x] Where x is an SMS telephone number from 1 to 8. Leaving programming blank for a telephone number will disable that
number. The User can program their own mobile telephone numbers at the keypad using
[*] [6] <> “SMS Programming” . The SMS
Command and Control feature utilize the SMS messaging service provided by the Cellular network and is subject to the limitations of
SMS messaging. These limitations include delayed messages and lack of guaranteed delivery.
NOTE: SMS Command and Control (Sections [601] - [618] will only process messages from the mobile telephone numbers
programmed in this Section if SMS Command and Control is enabled [301][ 3] ON. SMS responses are listed in Sections [621] -
[630]. A blank telephone number is disabled.
[601] Stay Arm
Default (Stay Arm);
Send this command to the system to stay arm. It may be followed by a Partition Label or partition number and Access Code.
[602] Away Arm
Default (Away Arm);
Send this command to the system to away arm. It may be followed by a Partition Label or partition number and Access Code.
[603] Night Arm
Default (Night Arm);
Send this command to the system to night arm. It may be followed by a Partition Label or partition number and Access Code.
[604] Disarm
Default (Disarm);
Send this command to the system to disarm. It may be followed by a Partition Label or partition number and Access Code.
[605] - [608] Activate Command Output 1 - 4
Default (Activate Command Output n);
Where n is a number from 1 - 4. Send this command to the system to activate a command output. It may be followed by a Parti-
tion Label or partition number and Access Code.
[609] - [612] Deactivate Command Output 1 - 4
Default (Deactivate Command Output n);
Where n is a number from 1 - 4. Send this command to the system to deactivate a command output. This command may be followed by
a Partition Label or partition number and optional Access Code.

SMS Command and Control Response 3G Alarm Communicator Installation Manual
20
[613] Bypass
Default (Bypass);
Send this command to the system to bypass a Zone. This command should be followed by a Zone label or Zone number and Access
Code.
[614] Unbypass
Default (Unbypass);
Send this command to the system to unbypass a Zone. This command should be followed by the Zone label or Zone number and
Access Code. [615] Status Request
Default (Status Request);
Send this command to request the status of the system. It may be followed by a partition label or partition number and Access Code. If
partition label is omitted, status of all enabled partitions will be sent. If there is a trouble on the system, the system label is sent, followed
by the trouble label, then the partition status.
NOTE: Status Request response may require more than one SMS message, depending on status of the system. There is a 10-sec-
ond delay between transmission of SMS messages.
[616] Alarm Memory Request
Default (Alarm Memory Request);
Send this command to the system to request the alarm memory from the system. This command may be followed by a Partition Label or
partition number, and Access Code. If partition label is omitted, alarm memory of all partitions will be sent. Alarm memory responses
will include Partition label and Zone label. Up to 8 partitions may be contained in 1 message.
NOTE: Alarm Memory Request response may require more than one SMS message, depending on alarm memory of the unit.
There is a 10-second delay between transmission of SMS messages.
[617] Help
Default (Help);
When help is sent, the SMS response is a listing of all interactive commands that can be sent to the module. Access Code is not required.
[619] Keypad Message
Default (Keypad Message);
The response format is: [Account Label] [Date and Time] [SMS Function] [Response] [Message Text]. Fields are space delimited.When
Keypad Message is sent, the SMS response is the message displayed on the keypad. If the message is too long to display on the keypad,
only the portion displayed is sent in the response.
SMS COMMAND AND CONTROL RESPONSE
NOTE: SMS Command and Control Response messages are up to 32 ASCII characters (Maximum 160 characters per SMS mes-
sage). The message language is specified in Section [009]. SMS responses are sent to the phone that initiated the command.
[621] Function Successful
Default (Successful);
When an SMS Command and Control function is successfully performed by the panel, the successful label is included in the response
sent to the user, following the command requested. (e.g., if “stay armed” command is completed by the panel, SMS response is: “stay
armed successful”).
[622] Function Unsuccessful
Default (Unsuccessful);
When an SMS Command and Control function is not successfully performed by the panel, the command sent to the unit will be included
in the response sent to the user, followed by this label. (e.g., if “stay armed” command is not completed, SMS response is: “stay armed
unsuccessful”).
[623] Invalid Command
Default (Invalid Command);
This label will be included in the response message if the command was not accepted as a valid SMS command.
[624] System Stay Armed
Default (Stay Armed);
This label will be included in the response to a status request command if a partition is stay armed.
[625] System Away Armed
Default (Away Armed);
This label will be included in the response to a status request command if a partition is away armed.
[626] System Night Armed
Default (Night Armed);
This label will be included in the response to a status request command if a partition is night armed.
[627] System Disarmed Ready
Default (Disarmed Ready);
This label will be included in the response to a status request command if a partition is disarmed and is ready to arm.
[628] System Disarmed Not Ready
Default (Disarmed Not Ready);
This label will be included in the response to a status request command if a partition is disarmed and is not ready to arm.
