DT Research 301MD Assembly instructions

Medical Tablet
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2020, DT Research, Inc. All Rights Reserved. BOG051120 DT301MDMQ ENG
INTRODUCTION
Thank you for acquiring the 301MD/ 301MQ, part of DT Research’s line of Medical
Tablets. Featuring a slim yet robust enclosure, the 301MD/ 301MQ with 10.1”
TFT display is powered by the Intel® Core™ i quad-core or Qualcomm octa-core
processor, oering opmal combinaons of performance and power savings. The
301MD/ 301MQ is available with Microso® Windows® or Android operang system.
The soware operang system features web browser, client/ server compung
soware, media player, accessories, and applicaons support.
PACKAGE CONTENTS
• One 301MD/ 301MQ with Baery Pack and Handstrap
• AC-DC Power Adapter with Power Cord
• Basic Operaon Guide
301MD/ 301MQ

23
PRECAUTIONS
• Always exercise care when operang and handling the 301MD/ 301MQ.
• Do NOT apply excessive pressure to the display screen.
• We recommend using the Digital Pen (oponal) to keep the screen clean.
• Avoid prolonged exposure of the display panel to any strong heat source.
Wherever possible, the 301MD/ 301MQ should face away from direct light to
reduce glare.
• If the AC-DC power adapter is used to recharge or power the tablet, do NOT use
any AC-DC adapter other than the one provided or acquired from the manufac-
turer or its partners.
• In the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power o the 301MD/ 301MQ and disconnect all power sources.
Report the problem to your device provider immediately.
• Never aempt to disassemble the 301MD/ 301MQ, as this will void the warranty.
BASIC FEATURES
The 301MD/ 301MQ rugged tablet integrates a bright display, USB ports, and
embedded networking elements such as wireless LAN and Bluetooth or oponal 4G.
A 301MD/ 301MQ typically integrates an 802.11ac wireless LAN (WLAN) adapter
that may connect to other wireless devices or access points. If your 301MD/ 301MQ
does not come with such a network adapter, please consult your device provider to
establish the desired network connecvity.
NOTE:
To obtain protecon consistent with any IP rang for the device, the I/O (audio,
power, USB, card reader, etc.) port doors must be closed. If the IP protecon is
compromised by mishandling or misuse, such as by leaving port doors open or
improperly closed, any resulng product damage will not be covered under any
DT Research warranty.
Button Functions
BUTTON ACTION
Power Buon
Programmable Buons
Brightness Control Buons
Baery Latch *Push the switch up to unlock the latch, then slide the latch le to remove the baery.
Input/ Output Ports
Headphone Jack
LAN Port
USB 3.0 Port
USB Type-C Port (power input)
Smart Card Reader (301MD only)
1
2
3
4
A
B
C
E
D
Baery/Power LED 2
2
43
1
E
A
C
D
B

Start Up
If the power up (from Standby mode or otherwise) is successful, the appropriate
interface will be displayed aer a launch sequence of several seconds. The wireless
LAN connecon may take 10-15 seconds to be established.
Configuring the Mobile Tablet
The 301MD/ 301MQ may be congured using the ulies and methods dictated
by the soware operang system. The 301MD/ 301MQ should be congurable
for various properes such as user proles, network features, and several system
elements.
Wireless Networking
Wireless LAN
The 301MD/ 301MQ is oen delivered with an embedded (user-inaccessible)
802.11ac WLAN adapter equipped with a hidden custom antenna.
• Through the support of typical WLAN adapters, the 301MD/ 301MQ should be
able to detect all 802.11 access points in the vicinity for you to select the access
point of your choice for connecon.
• The SSID and WEP/WPA/WPA2 (if enabled) parameters on the 301MD/ 301MQ
and the access points have to match. The SSID is case-sensive and it is recom-
mended that you enable WEP/WPA/WPA2 encrypon (or advanced alternaves)
for secure access.
• When WEP/WPA/WPA2 is enabled, you may need to consult your network
administrator or your networking equipment literature to properly congure
associated sengs such as Authencaon mode, etc.
• Refer to the access point operang manuals for seng up the 802.11 access
points.
Bluetooth
The Bluetooth configuration application is enabled from the Windows System Tray
or from the Android Settings APP. Follow the instructions and options provided
within the application to configure and invoke Bluetooth connectivity with the
corresponding peripherals.
OPERATION
Powering ON and OFF
To acvate the 301MD/ 301MQ, push and quickly release the Power Buon. The
display will come on in a few seconds. To put the 301MD/ 301MQ in Standby mode,
push and quickly release the Power Buon. To turn the 301MD/ 301MQ o for
extended storage, power o safely using any soware funcon that “shuts down
computer” provided in the soware operang system.
NOTE:
The baery pack shipped with your tablet may be low in power—please use the
AC-DC adapter with the 301MD/ 301MQ when seng up for the rst me to
fully charge the baery pack, or use the oponal baery charger kit.
NOTE:
When the baery pack is charging, the blue-colored Baery LED should blink
slowly. If plugging in the AC-DC adapter does not trigger this blinking acvity
and the LED stays dark, the baery pack(s) may have been drained substanally.
Try unplugging/ replugging the AC-DC adapter to the 301MD/ 301MQ a few
mes to acvate the charging process.
NOTE:
To conserve power, use (push and quick release) the Power Buon to put the
tablet in “Standby” mode while not in use. Pushing briey on the same buon
will wake up the system within seconds.
NOTE:
For 301MD, avoid using the Power Buon (“hold 4+ seconds” feature) to turn
o the tablet—this form of hardware shutdown is intended to be a means of
recovery from lockups, and not as normal operaon.
45

USING THE MOBILE TABLET
Peripherals Support
Through its USB 3.0 port, the 301MD/ 301MQ supports a wide range of USB-based
peripherals. These peripherals are applicable for soware installaon, applicaons
storage, data storage, and system soware recovery and updates.
For More Support
Users can download the Tablet Modules Basic Operaon Guides from the DT Research
website.
If the 301MD/ 301MQ comes with a Mobile broadband module, please contact your
product and/or service provider for the SIM Card installaon procedures.
67
Federal Communication Commission Interference
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protecon against harmful interference in
a residenal installaon. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instrucons, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or
television recepon, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Cauon: Any changes or modicaons not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operaon is subject to the following two condions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operaon.
This device and its antenna(s) must not be co-located or operang in
conjuncon with any other antenna or transmier.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du
Canada.
To Hold the Tablet
Le hand: grip the le back side of the tablet
with your le hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
Right hand: grip the right back side of the tablet
with your right hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
