DT Research 504T User manual

I/O Ports
The Medical-Grade Integrated LCD System has a comprehensive set of I/O ports. The following
ports are located along the bottom side of the unit.
Medical-Grade Integrated LCD System
Front Back
Bo
�
om
A B C D E F
G H I C J K 504T
INTRODUCTION
Thank you for acquiring DT Research’s Medical-Grade Integrated LCD System. With a 23.8-
inch or 27-inch TFT display and powered by the Intel® Core™ i processor, the Medical-Grade
Integrated LCD System offers optimal combinations of performance and power savings. With
fully-integrated point-of-care modules within an elegant, space-saving design, the Medical-Grade
Integrated LCD System is the optimum solution to enhance workflow and service.
Please take a few moments to review the contents of this document to ensure that the setup
Cleaning the Screen
•A screen cleaning solution that is alcohol-free and non-abrasive can be used to clean the
touch screen.
•Cleaning with a micro-fiber cloth is recommended.
•Please spread the solution onto the cloth and then clean the touch screen.
Cleaning the Anti-microbial Enclosure
•Use a soft/non-abrasive cloth moistened with water to clean the enclosure.
•If using a cleaner, an alcohol-free and oxide-free cleaning liquid is recommended.
•To prevent scratching the anti-microbial coating, please wipe gently.
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright© 2020,DT Research, Inc.All RightsReserved. BOG102020 504T ENG
and startup proceed smoothly. The Medical-Grade Integrated LCD System is ready for use, out of
the box, in its default configuration when powered by the power source provided. The following
documentation offers guidance on the hardware elements and features of the computer. Please
refer to your device provider for information pertaining to the software operating system or
software applications.
PACKAGE CONTENTS
•504T
•AC-DC power adapter with power cord
•Basic operation guide
MEDICAL – GENERAL MEDICAL EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND MECHANICAL
HAZARDS ONLY IN ACCORDANCE WITH ANSI/AAMI
ES60601-1 (2005) + AMD (2012) & “CAN/CSA-C22.2
No. 6060-1 (2008) + (2014)
A Power button F USB 3.0 ports
B Programmable buttons G Ethernet ports (RJ45)
C Speakers H Audio jack
D DC-in I USB 2.0 ports
E HDMI output J COM ports
K Potential equalization
conductor (optional)
NOTE:
To conserve power, use (push and quick release) the Power Button to put the device in
“Standby” mode while not in use. Pushing briefly on the same button will wake up the
system within seconds.
NOTE:
Avoid using the Power Button (“hold 4+ seconds” feature) to turn off the device — this form
of hardware shutdown is intended to be a means of recovery from device lockups, and not as
normal operation.
PRECAUTIONS
•Always exercise care when operating and handling the Medical-Grade Integrated LCD
System.
•Never disassemble any portion of the enclosure, as this will void any product warranty on
the Medical-Grade Integrated LCD System.
•Do not use any AC/DC adapter other than the one provided with the device or a replacement
acquired from the manufacturer.
•In the unlikely event that smoke, abnormal noise or strange odor is present, immediately
power down the Medical-Grade Integrated LCD System and disconnect all power sources.
Please report the problem to your deviceprovider immediately.
BASIC FEATURES
The Medical-Grade Integrated LCD System integrates a bright 23.8” or 27” display with a high
performance system and USB ports for a comprehensive point-of-care solution.
Attach The Tabletop Stand (Optional)
1. Insert the top two tabs of the tabletop stand into the top two open slots on the 504T back
panel.
2. Push the latch to pivot the two lower tabs of the tabletop stand.
3. Push the two lower tabs into the two lower slots on the 504T back panel. Make sure the latch
locks back into position so the stand is securely attached.
Detach the Tabletop Stand (Optional)
1. Push the latch to pivot the twolower tabs.
2. Pull out the two lower tabs, then the two upper tabs from the 504T back panel.
Powering ON and OFF
Please use the AC-DC adapter with the Medical-Grade Integrated LCD System for the power
supply. To activate the Medical-Grade Integrated LCD System, push and quickly release the Power
Button and the display will come on in a few seconds. To put in Standby mode, push and quickly
release the Power Button. To turn off for extended storage, power off the device safely using any
software function that “shuts down computer” provided in the software operating system.
Wireless Networking
Wireless LAN
The Medical-Grade Integrated LCD System is often delivered with an embedded (user-
inaccessible) 802.11ac WLAN adapter equipped with a hidden custom antenna.
•Through the support of typical WLAN adapters, the Medical-Grade Integrated LCD System
should be able to detect all 802.11 access points in the vicinity for you to select the access
point of your choice forconnection.
•The SSID and WEP/WPA/WPA2 (if enabled) parameters on the Medical-Grade Integrated LCD
System and the access points have to match. The SSID is case-sensitive and it is recom-
mended that you enable WEP/WPA/WPA2 encryption (or advanced alternatives) for secure
access.
•When WEP/WPA/WPA2 is enabled, you may need to consult your network administrator
or your networking equipment literature to properly configure associated settings such as
Authentication mode, etc.
•Refer to the access point operating manuals for setting up the 802.11 access points.
Bluetooth
The Medical-Grade Integrated LCD System features a built-in Bluetooth adapter that operates on
the Microsoft Windows Bluetooth protocol. The Bluetooth configuration application is invoked
from the System Tray or from the Control Panel. Follow the instructions and options provided
within the application to configure and invoke Bluetooth connectivity with the corresponding
peripherals.
NOTE:
Bluetooth devices or accessories that are not compatible with the Microsoft Windows
Bluetooth protocol may not work with the Medical-Grade Integrated LCD System.
2
3
Federal Communication Commission Interference
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
RF Exposure Compliance
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied
antenna.
Supplier's Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier Trade Name:
Model No.:
504T
Responsible Party
– U.S. Contact Information
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
http://www.dtresearch.com
FCC Compliance Statement
This device complies with Part
15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
RF Exposure Information(RED)
To be protected against all verified adverse effects, the separation distance of at least 0.2m must be maintained between the antenna of the radio having max. 3.2dBi antenna and all persons.
The band 5150-5350 MHz for this device are restricted to indoor use only within all European Union countries.
Hereby, [DT Research, Inc.] declares that the radio equipment type [504T] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following
internet address: http://www.dtresearch.com.
Maximum EIRP for EU
Bluetooth:2402MHz-2480MHz 14.4dBm
Bluetooth LE:2402MHz-2480MHz 2.42dBm
Wifi: 2412MHz-2472MHz/2422MHz-2462MHz 20dBm
Wifi: 5150MHz-5725MHz 22.9dBm
Wifi: 5725MHz-5875MHz
13.9dBm
