VV-ZELA-RB
BI-DIRECTIONAL WIRELESS BATTERY SIREN
Installation and use manual 15.10-M:1.0.1-H:SI-02v1-14-F:RC7

2
1. DESCRIPTION
VV-ZELA-RB is a universal wireless siren with armed/disarmed system signalling and sounder characteristics similar to traditional wired siren.
Power supply Battery powered: lithium 7,2 V / 13 Ah or alkaline 7,5 V / 12 Ah (not provided).
Autonomy about 2 years (average use: about 50 alarm sounds + 4 daily arming/disarming).
Bi-directional The siren is bi-directional: it receives and transmits radio codes to communicate with the control panel and act accordingly.
The siren can communicate directly with compatible control panels or combined with TSR or TSR2 transmitters (TSR =
transmitter, TSR2 = transmitter/receiver, both for sirens) for use with any control panel.
Received radio codes (from control panel or transmitter):
System armed: single long blink of the siren lamp
System disarmed: three short blinks of siren lamp
Alarm: siren sound
End alarm: siren silence
Transmitted radio codes (to control panel or TSR2 transmitter):
Tamper
Low battery
Alarm The siren emits acoustic alarm “beep”that lasts 1 minute maximum and five alarms signalling each arming. Further
alarm events will be ignored. Alarm counting is reset at next arming of the system (radio arming code sent from the control
panel or transmitter).
It is possible to disable the alarm-counting block.
2. COMPATIBILITY
CE100-3GSMBUS
CE100-8
(from vers. 7.4)
CE60-3GSM
(from vers. 2.0)
CE50-2PLA
CE16-2
Maintenance



―
―
Bi-directional
communication




―
Bi-directional
learning

(from vers. 1.30)
―

(from vers. 4.30)
―
―
Arming





Disarming






3
3. TECHNICAL
POWER SUPPLY
Battery: lithium 7,2 V - 13 Ah or alkaline 7,5 V - 12 Ah
Batteries not provided
ABSORPTION
Stand-by: 73 µA Alarm: 850 mA
ALARM CYCLES
5 cycles
SINGLE ALARM TIME
About 1 min
ACOUSTIC POWER
115 dB/m
SIGNALLING
TOTAL >single long blink
PARTIAL 1 > long + 1 short blink
PARTIAL 2 > long + 2 short blinks
PARTIAL 3 > long + 3 short blinks
DISARMED > 3 blinks
RADIO COMMUNICATION
Frequency: 433,92 MHz
Range: 100 m (open filed)
Power: 10 mW
TEMPERATURE
-5 °C / +45 °C
DIMENSION
310 (H) x 210 (L) x 85 (P) mm
TERMINALS
LED
TMP
Tamper (to disable the tamper short-circuit the terminal)
SIR
Siren speaker
BAT
Battery
ANT
Antennas
LED1
High power LEDs for blinking signalling
All LEDs light simultaneously
LED2
LED3
LED4

4
DIP-SWITCH - FUNCTIONS
OFF
ON
DIP1
BI-DIREZIONAL LEARNING
Start the BI-DIRECTIONAL learning procedure to pair the siren with control
panel. Complete the procedure starting the same operation on control panel.
Normal working
Learning
DIP2
“BY DETECTION” LEARNING
Starts the “by detection” learning to pair the siren with control panels without
the BI-DIRECTIONAL function.
The siren emits some times its TAMPER radio code (which must be learned int
radio zone memory of the panel) then listens for control panel radio code in
order to store it.
Normal working
Learning
(press the temper
switch to start)
DIP3
SUPERVISION
The siren sends a special “in life” radio code to inform the control panel of its
correct working and presence.
The supervision code is transmitted after about 1 hour from last transmission.
The supervision enabled causes higher battery consumption.
Supervision off
Supervision on
DIP4
ALARM BLOCK (COUNTER)
The siren sounds for max 5 alarms (each alarm sound lasts about 1 minute)
during the same arming, then stops the sounds until the next arming.
It is possible to disable the alarm counting and make the siren sound without
limits.
Block Enabled
Block Disabled
DIP5
LIGHT ALERTS AT ARMING AND DISARMING
The lamp LEDs light on at the arming and disarming of the system to give a
visual feedback to the user:
TOTAL ARMED > long blink
PARTIAL 1 >long blink + 1 short
PARTIAL 2 >long blink + 2 short
PARTIAL 3 >long blink + 3 short
DISARMED >three blinks
Disable this function if this signalling is not used.
The light alerts enabled causes higher battery consumption.
Alerts ON
Alerts OFF
DIP6
NOT USED
Leave OFF
-
DIP7
NOT USED
Leave OFF
-
DIP8
NOT USED
Leave OFF
-
4. RESET
It is possible to reset the siren to factory settings with the following steps:
1. Unplug the battery
2. Set all DIPs to ON
3. Connect the battery: the siren emits some “BEEP” and LED blinking
4. Unplug the battery and set all DIPs to OFF, the start with new programming

5
5. PAIR THE SIREN WITH THE CONTROL PANEL (LEARNING)
DURING THE LEARNING PROCEDURE AVOID TRANSMISSSION FROM OTHER RADIO DEVICES (EG.: DETECTORS).
ALWAYS MOUNT THE ANTENNA ON CONTROL PANEL FOR RADIO RECEIVING.
THE SIREN CAN BE LEARNED ONLY IN ONE OF THE TWO MODES (“BI-DIRECTIONAL” OR “DETECTION”)
CONTROL PANELS WITH “BI-DIRECTIONAL LEARNING”FUNCTION
VERIFY THE CONTROL PANEL HAS THE “BI-DIRECTIONAL”FUNCTION, IF NOT FOLLOW THE PROCEDURE
DESCRIBED BELOW.
1. Control panel: enter in Installer Menu:
Select the “TX Code” item and set a value different from “000” (zero-zero-zero)
Select the “Bi-directional learning”item, select an empty memory position (indicated with “O”symbol).
2. Siren: set DIP1 to ON: the siren emits a long “beep” and lights on the lamp
3. Control panel: press –within 30 seconds –the button for start the procedure (“X”or “”).
The control panel and the siren will learn their radio codes (this operation is automatic).
4. If all ends correctly: the control panel displays “Learning OK”. The siren emits some “beep”, the lamp blinks some times and then
stay solid on.
5. Siren: set DIP1 to OFF: the siren emits a “beep” and switch off the lamp. Close the cover of the siren.
6. In case of errors, repeat the procedure.
CONTROL PANELS WITHOUT THE “BI-DIRECTIONAL LEARNING”FUNCTION
THE CONTROL PANELS “AN” VERSION MUST BE SET IN “DETECTION LEARNING”MODE.
1. Control panel: enter in Installer Menu
Enable the radio codes transmission on control panel
[CE100-8, CE100-3: set the “TX Code” different from “000”]
[CE60-3: set the “TX Code” different from “000” or learn an activator in memory position “Activator 01”]
Select the “Radio Zones Learning”item, select an empty memory position (indicated with “O”symbol).
2. Siren: set DIP2 to ON. And press the TAMPER switch.
The siren transmits its TAMPER radio code for five times (one blink for each transmission).
If the code is learned correctly, the control panel displays a solid “X”symbol.
3. After the TAMPER code transmission, the siren waits for the radio code from control panel (emits one “beep”and switch on the
lamp).
4. Control panel: exit from Installer Menu
The control panel sends its radio code and the siren learns it (the siren emits two “beep” and one blink).
If the siren does NOT learn the control panel radio code, the lamp lights solid on: make a disarming, the control panel transmits its
radio code and the siren learn it.
5. Siren: set DIP2 to OFF (the siren emits three “beep”).

6
6. VISUAL FEEDBACK
SIREN
CE100-8 / CE100-3GSM
CE60-3GSM
1 long flash
Total arming
Total arming
1 long flash + 1 short flash
Partial 1 arming
Partial arming
1 long flash + 2 short flashes
Partial 2 arming
Outdoor arming
1 long flash + 3 short flashes
Partial 3 arming
-
3 short flashes
Disarming
Disarming
7. MAINTENANCE
By sending to the control panel this command, the siren enter in “maintenance” mode” allowing to open the cover without tamper alarm.
Start maintenance: when the siren receives the “start maintenance”radio code, emits some “beep” and blinks indicating that now it is
possible to open the cover without tamper alarm. The max time available is about 4 minutes.
Stop maintenance: when the siren receives the “stop maintenance”radio code, enable the tamper control, emits some “beep” and blinks
long one time.
8. TAMPER
The tamper alarm is active 24 H/24, also at system disarmed (excluded the case of “maintenance”function).
When the siren cover opens, the tamper radio code is sent to the control panel and both start to sound.
Once the tamper alarm is send, it is disabled until the next ARMING of the system.
Thus, in case of tamper alarm, remember that –to enable it again –it is necessary to arm at least one time the alarm system.
Note: when the siren is new or after a RESET, to enable the tamper it is necessary to arm at least once time.
Note: the tamper switch is used to start the “by detection”learning when DIP2 = ON.
To disable the tamper, short the tamper terminals with a piece of wire.
9. LOW BATTERY
The siren signals its battery level is under the minimum threshold by a quick blinking of the LEDs for some seconds at disarming (after the
three blinks for “disarming” feedback).
The siren sends a special “low battery” radio code (LWB) to the control panel, which perform proper actions (visualization on display and
sending of SMS).
10.WARNINGS
BEFORE TO INSTALL THE SIREN, VERIFY THE RADIO RANGE OF THE CONTROL PANEL FROM THE INSTALLATION
POSITION.
THE INSTALLER MUS FOLLOW CURRENT REGULATION

7
THE MANUFACTURER SHALL NOT BE LIABLE FOR ANY IMPROPER USE OF THE PRODUCT, INCORRECT
INSTALLATION OR FAILURE TO COMPLY WITH INSTRUCTIONS OF THIS MANUAL AND THE LAW REGARDING
ELECTRICAL SYSTEMS.
THIS DEVICE WORKS WITH LITHIUM 7,2 V / 13 Ah BATTERY OR ALKALINE 7,5 V / 12 Ah (NOT INCLUDED)
HANDLE WITH CARE. DANGER OF EXPLOSION AND FIRE
DO NOT DISPOSE THE BATTERY IN FIRE, DO NOT WELD OR DAMAGE THE BATTERY
REPLACE ONLY WITH THE SAME BATTERY TYPE
RESPECT THE POLARITY SHOWN IN INSTRUCTIONS
THE BATTERY MUST BE REPLACED ONLY BY A QUALIFIED TECHNICIAN
DISPOSE USED BATTERIES ACCORDING TO APPLICABLE LAW, EVEN IN CASE OF DISUSED EQUIPMENT
IN CASE OF RELEASE OF LIQUID, PROTECT HANDS WITH PROPER GLOVES

8
Pursuant to Legislative Decree No. 49 of 14 March 2014 “Implementation of Directive 2012/19 / EU on waste electrical and
electronic equipment (WEEE)”.
The symbol of the crossed-out dustbin indicates that the product at the end of its life must be collected separately from other
waste.
The user must, therefore, take the device complete of its essential components to an authorized disposal center for collection
of electronic and electrical garbage, or return it to the dealer when buying a new equivalent device, in relation of one to one or one to none
for the equipment having the larger side less than 25 cm.
Appropriate separate collection of the disused equipment for recycling, treatment and environmentally compatible disposal helps to
prevent negative impact on the environment and human health and promotes recycling of the materials making up the product.
Illegal dumping of the product by the user entails the application of administrative sanctions provided for in Legislative Decree n. 49 of
March 14, 2014.
This device meets the R&TTE requirements (European Union)
This manual may be subject to change without notice
Made in Italy
