DURAVIT SensoWash i Plus User manual

SensoWash®i Plus
Operating instructions
Manual de instrucciones
Notice d’utilisation
Integrated shower toilet
Inodoro con lavado integrado
Toilette à douche intégrée

2
4
7
5
6
1
135 mm
9
12
14
16
21
11
13
15
17
18
19
20
10
8
3

31
24
26
28
30
29
23
22
146 mm
25
27
www.sensowash.us

Contents
. Brief overview............................................................................................
. Toilet unit .........................................................................................
. Remote control .................................................................................
. App...................................................................................................
. Functional area.................................................................................
. Right product side.............................................................................
. Left product side...............................................................................
. Description of Symbols...............................................................................
. For your safety...........................................................................................
. Normal Use.......................................................................................
. Safety instructions............................................................................
. Basic product information ........................................................................
. About this manual...........................................................................
. Operation........................................................................................
. LED indication.................................................................................
. Initial operation .......................................................................................
Activate / deactivate SensoWash®......................................................
Switch SensoWash® on / off .................................................................
Download app......................................................................................
Pairing app..........................................................................................
Remote control (batteries)...................................................................
. Operating.................................................................................................
Open / close lid....................................................................................
Activate full flush.................................................................................
Activate eco flush.................................................................................
Activate / deactivate Rearwash............................................................
Activate / deactivate Ladywash............................................................
Activate / deactivate warm air dryer ...................................................
Adjust spray wand position..................................................................
Adjust water spray intensity ................................................................
Adjust water temperature ...................................................................
Activate odor extraction.......................................................................
Set user profile....................................................................................
Activate user profile.............................................................................
1
EN

. Cleaning and Care ....................................................................................
. Cleaning..........................................................................................
. Care................................................................................................
Manual cleaning mode (spray wand and nozzle) .................................
Self-cleaning (spray wand and nozzle)................................................
Manual cleaning (odor extraction strainer) .........................................
Holiday mode.......................................................................................
Water filter .........................................................................................
Descaling.............................................................................................
. Disposal ...................................................................................................
. Troubleshooting support..........................................................................
. Technical Data ..........................................................................................
2
EN

. Toilet unit
1Seat sensor
2Auto opening lid
3Seat heating
4Night light
5Power / status indication (LED)
6Bluetooth
7Full flush
8Integrated flushing system
. Remote control
9User profile 1
10 User profile 2
11 Full flush
12 Eco flush
13 Rearwash
14 Ladywash
15 Odor extraction
16 Warm air dryer
17 Water temperature
18 Water spray intensity
19 Spray wand position
20 Open / close lid
21 Stop
. App
22 Menu
23 Add / delete device
24 Ladywash
25 Warm air dryer
26 Rearwash
27 Odor extraction
28 Eco flush
29 Open / close lid
30 Full flush
31 Stop
. Brief overview
3
EN

. Functional area
. Right product side
Odor extraction
strainer
Spray wand
Warm air dryer
Spray nozzle
Night light
Right side
panel
Stop valve:
| open
— closed
Water filter
Descaling
connection
4
EN

Power switch
. Left product side
5
EN

. Description of Symbols
The following warning signs warn you of dangerous situations and
their severity:
Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, may result in
minor or moderate injury.
NOTICE Addresses practices not related to physical injury.
The following symbols are used:
Hints and tips are provided here.
> This is a prompt requesting your input.
Functions / settings controlled on seat unit.
Functions / settings controlled via remote control.
Functions / settings controlled via app.
CAUTION
6
EN

. For your safety
To ensure that you will enjoy your SensoWash®, read these operating
instructions carefully, particularly the safety instructions.
Keep the operating instructions in a safe place and in the case of a
change in ownership, ensure they are given to the new owner.
These operating instructions correspond to the device’s state of
technology at the time of printing. Duravit reserves the right to
make changes in terms of further development.
. Normal Use
SensoWash®is a shower toilet with spray attachment for Rear-
wash and Ladywash cleansing functions with an integrated flushing
system. Its use is limited exclusively to enclosed spaces.
Any other usage will be deemed as not corresponding with normal
usage. Duravit undertakes no liability for abnormal usage.
. Safety instructions
Read and observe the following safety instructions carefully!
Requirements for the user
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsi-
ble for their safety.
> Children should be supervised to ensure that they do not play with
the appliance.
WARNING Damage to health caused by electric shock and /
or product damage
> This product has to be grounded. Compare with the mounting
instructions.
Only use the device when it is fully functional.
> Make sure that the power cable is not damaged.
> The power cable must not become jammed or pinched.
> Keep the power cable away from hot surfaces and sharp edges.
7
EN

Do NOT use the product if it is not working properly.
> Disconnect from the power supply immediately. Close the stop
valve to interrupt the water supply. Contact [e-mail].
> Avoid malfunctions and damage to the product as a result of
improper use.
CAUTION Health damage and potential product damage!
> Supply the Shower WC with cold drinking water from the main
water system.
> The new hose-sets supplied with the appliance are to be used and
old hose-sets should not be reused.
> The product itself does not have electrical leakage protection func-
tion, it must be installed in circuit where there is leakage protection
device installed.
> Means for disconnection must be incorporated in the fixed wiring in
accordance with the wiring rules and having a contact separation in
all poles that provide full disconnection under overvoltage category
III conditions.
> Check the rated power and choose cross cable accordingly.
> Do NOT sit, stand or lean on the lid.
> Do NOT connect any waste water, grey water, industrial water,
sea water or other untreated or semi-treated water.
> Do NOT detach seat and lid for any purpose.
> Do NOT damage the surface of seat. If the surface of the seat is
damage, contact [e-mail].
> DO NOT open and close seat with excessive force.
> Open and close the lid via remote control and app only. Do not open
and close the lid manually.
> If the SensoWash®is moved from a cold location to a warm location,
condensation may form. Leave the unit switched off for a few hours.
> Do NOT install the SensoWash®in rooms where there is a danger
of frost. The room temperature must not be less than 4 °C (39 °F).
> Do NOT place open fire sources, candles, cigarettes, or similar, on
the SensoWash®.
> Do NOT expose the SensoWash® directly to water or sunlight.
> Do NOT climb on or stand on the product.
> Do NOT place any heavy objects on the lid.
> Do NOT deliberately soil, spray or block the spray wand.
8
EN

Repairs must only be carried out by a person with the necessary
expertise and qualification
> Do NOT carry out modifications, tamper with, install additional
equipment or attempt to repair the SensoWash®.
> If the supply cord is damaged, it must be replaced by the manuf-
acturer, its service agent or similarly qualified persons in order to
avoid a hazard.
> Repairs must be carried out by qualified electricians or technicians.
> Improperly performed repairs can lead to accidents, damage and
malfunctions.
> Do NOT use attachments not recommended by Duravit.
Use of batteries
Risk of fatal injury if swallowed / Chemical
burn hazard
This product contains coin / button cell batteries. Do not ingest
battery! If the cell battery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
> Do not ingest battery, Chemical Burn Hazard.
> Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the product and
keep it away from children.
> If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
Damage to health caused by leaking battery acid
> Avoid contact with skin, eyes and mucous membranes if battery
acid has leaked.
> In case of contact with the acid, flush the affected areas with large
amounts of clean water and consult a doctor immediately.
> Do not expose the batteries to extreme conditions: avoid contact
with hot surfaces or direct sunlight. Otherwise there is a risk of
leakage.
> The cells shall be disposed of properly, including keeping them
away from children. Even used cells may cause injury.
WARNING
CAUTION
9
EN

NOTICE Product and / or property damage
> Batteries may not be recharged, reactivated by other means,
dismantled or exposed to fire.
> The supply terminals are not to be short-circuited.
> Always remove empty batteries from the remote control immedia-
tely. They may leak and cause damage.
> Do not insert new and old batteries together in the remote control.
> Different types of batteries are not to be mixed.
> Clean the battery and contacts before inserting the battery.
> Batteries are to be inserted with the right polarity.
> Remove the batteries if you do not use the remote control for an
extended period.
IMPORTANT SAFEGUARDS
When using electrical products, especially when children are pre-
sent, basic safety precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING
DANGER
To reduce the risk of electrocution!
> Do not use while bathing.
> Do not place or store product where it can fall or be pulled into a
tub or sink.
> Do not place in or drop into water or other liquid.
> Do not reach for a product that has fallen into water. Unplug
immediately.
WARNING To reduce the risk of burns, electrocution, fire,
or injury to persons!
> Close supervision is necessary when this product is used by, on,
or near children or invalids.
> Use this product only for its intended use as described in this
manual. Do not use attachments not recommended by the
manufacturer.
10
EN

> Never operate this product if it has a damaged cord or plug, if it
is not working properly, if it has been dropped or damaged, or
dropped into water. Return the product to a service center for
examination and repair.
> Keep the cord away from heated surfaces.
> Never block the air openings of the product or place it on a soft
surface, such as a bed or couch, where the air openings may be
blocked.
> Keep the air openings free of lint, hair, and the like.
> Never use while sleeping or drowsy.
> Never drop or insert any object into any opening or hose.
> Do not use outdoors or operate where aerosol (spray) products
are being used or where oxygen is being administered.
> Unplug this product before filling. Fill (reservoir) with water only
unless otherwise specified by manufacturer. Do not overfill (or
specify filling instructions).
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This product should be connected to a grounded, metallic, permanent
wiring system, or an equipment-grounding conductor should be run
with the circuit conductors and connected to the equipment groun-
ding terminal or lead on the product.
FFC Compliance statement
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, inclu-
ding interference that may cause undesired operation.
11
EN

WARNING
Changes or modification not expressly approved by the party respon-
sible for compliance could void the user‘s authority to operate the
equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference
by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
Industry Canada (IC) Compliance Statement
This device complies with Industry Canada’s licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including inter-
ference that may cause undesired operation of the device.
12
EN

. Basic product information
. About this manual
This manual contains safety and general product information and information on how to
operate SensoWash® via remote control (basic setting range).
> See Quick Guide in app ( Menu - Device Guide - Quick Guide 22 ) for information
on the full range of setting options available for this product.
. Operation
SensoWash® is operated via remote control (basic setting range) and / or app (extended
setting range). The flushing function can also be operated via a side control button on
the seat unit itself.
A number of settings can be adjusted via app only ( Table : Functions and settings).
> Download app to adjust the full range of setting options available for this
product ( Ch. 5: Download app).
Operating Options
The full range of functions is available whether the product is opera-
ted via remote control or app. Functions are set according to default settings
(Table : Default settings). Download app to make adjustments on the extended
setting range ( Ch. 5: Download app).
Controlled via
basic range extended range
On / off SensoWash® • - -
Bluetooth (connect app) • - -
Full flush • • •
Open / close lid
(electromotive)
- • •
Auto opening lid - - •
Auto closing lid - - •
Eco flush - • •
Auto flush - - •
Pre-flush - - •
Rearwash - • •
13
EN

Operating Options
Controlled via
basic range extended range
Ladywash - • •
Comfortwash - - •
Warm air dryer - • •
Warm air dryer temperature - - •
Spray wand position - • •
Water spray intensity - • •
Water temperature - • •
Odor extraction - • •
Auto odor extraction - - •
Odor extraction follow-up
time
- - •
User profile - • -
Seat heating - - •
Seat heating temperature - - •
Energy saving (seat heating) - - •
Night light - - •
Confirmation tone - - •
Holiday mode - - •
Manual cleaning mode - - •
Self-cleaning - - •
Descaling - - •
Reset default setting - - •
Table 1: Functions and settings
14
EN

Default Settings
setting range default setting
Full flush - ~4.4 L per flush (Lpf)
(~1.16 gallon per flush
(gpf))
Eco flush - ~3.1 L per flush (Lpf)
(~0.82 gallon per flush
(gpf))
Auto flush on / off on
Auto opening lid on / off off
Auto closing lid on / off off
Pre-flush on / off on
Comfortwash on / off on
Warm air dryer temperature off / low / medium /
high medium
Spray wand position front 1, 2, 3, 4, 5 back 3
Water spray intensity low / medium / high medium
Water temperature off / low / medium /
high medium
Auto odor extraction on / off off
Odor extraction follow-up time off / 1 min. / 3 min. 1 min.
Seat heating on / off on
Seat heating temperature low / medium / high medium
Energy saving mode on / off off
Night light off / auto / on auto
Confirmation tone on / off off
Table 2: Default settings
15
EN

. LED indication
Power button
Red light Indicates stand-by mode.
Switch SensoWash® on to activate seat unit
(Ch. 5: Switch SensoWash® on / off).
Green light Indicates on mode.
Energy saving mode is off.
Orange light Indicates on mode.
Energy saving mode is on.
Flashing Malfunction.
Deactivate seat unit, close stop valve, contact
[email protected]om ( Ch. 9: Troubleshooting).
Bluetooth button
Blue light Bluetooth is available or connected.
Off Bluetooth is not available.
Flashing Device is in pairing mode ( Ch. 5: Pairing app).
Table 3: LED indication (seat unit)
16
EN
