DURAVIT SensoWash Starck f Plus User manual

4,71mm
2
4
5
6
1
3
Order.-Nr. 57352/20.06.1 ·We reserve the right to make technical improvements and enhance the appearance of the products shown.
Duravit AG
P.O. Box 240
Werderstr. 36
78132 Hornberg
Germany
Phone [phone]
Fax [phone]
[e-mail]
www.duravit.com
SensoWash
®
Starck f Plus
Operating instructions
Manual de instrucciones
Notice d’utilisation
Shower toilet unit
Accesorio para el WC con ducha
Abattant WC douche
Duravit USA, Inc.
2635 North Berkeley Lake Rd., Suite 100
Duluth, GA 30096
Toll Free 888-DURAVIT
Phone [phone]
Fax [phone]
[email protected]vit.com
www.duravit.us

www.sensowash.us
20
22
24
26 27
21
7
10
12
14
19
9
11
13
15
16
17
18
8
23
25
4,71mm 148 mm
146 mm135 mm


EN
Contents
. Brief overview............................................................................................
. Toilet unit .........................................................................................
. Remote control .................................................................................
. App...................................................................................................
. Functional area ................................................................................
. Descaling connection ........................................................................
. Description of symbols...............................................................................
. For your safety...........................................................................................
. Normal use .......................................................................................
. Safety instructions............................................................................
. Basic product information ........................................................................
. About this manual...........................................................................
. Operation........................................................................................
. LED indication ................................................................................
. Energy saving and water efficiency.................................................
. Initial operation .......................................................................................
Switch SensoWash® on/off ...................................................................
Download app......................................................................................
Pairing app..........................................................................................
Change batteries .................................................................................
. Operating.................................................................................................
Open/close lid......................................................................................
Activate/deactivate Rearwash..............................................................
Activate/deactivate Ladywash..............................................................
Activate/deactivate warm air dryer .....................................................
Adjust spray wand position..................................................................
Adjust water spray intensity ................................................................
Adjust water temperature ...................................................................
Set user profile....................................................................................
Activate user profile.............................................................................
Activate/deactivate odor extraction .....................................................
. Cleaning and care.....................................................................................
Cleaning recommendations .................................................................
Manual cleaning mode (spray wand and nozzle) .................................
Self-cleaning (spray wand and nozzle)................................................
Holiday mode.......................................................................................


EN
Descaling.............................................................................................
. Disposal ...................................................................................................
. Troubleshooting support..........................................................................
. Technical data .........................................................................................


EN
. Toilet unit
1Seat sensor
2Auto opening lid
3Seat heating
4Night light
5Power/status indication (LED)
6Bluetooth
. Remote control
7User profile 1
8User profile 2
9User profile 3
10 User profile 4
11 Rearwash
12 Ladywash
13 Odor extraction
14 Warm air dryer
15 Water temperature
16 Water spray intensity
17 Spray wand position
18 Open/close lid
19 Stop
. App
20 Menu
21 Add/delete device
22 Ladywash
23 Warm air dryer
24 Rearwash
25 Odor extraction
26 Open/close lid
27 Stop
. Brief overview


EN
. Functional area
. Descaling connection
Odor extraction Spray wand
Warm air dryer
Spray nozzle
Night light
Descaling connection


EN
. Description of symbols
The following warning signs warn you of dangerous situations and
their severity:
Indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, may result in
minor or moderate injury.
NOTICE Addresses practices not related to physical injury.
The following symbols are used:
Hints and tips are provided here.
> This is a prompt requesting your input.
Functions/settings controlled on seat unit.
Functions/settings controlled via remote control.
Functions/settings controlled via app.
DANGER
CAUTION


EN
. For your safety
To ensure that you will enjoy your SensoWash®, read these operating
instructions carefully, particularly the safety instructions.
Keep the operating instructions in a safe place and in the case of a
change in ownership, ensure they are given to the new owner.
These operating instructions correspond to the device’s state of
technology at the time of printing. Duravit reserves the right to
make changes in terms of further development.
. Normal use
SensoWash®is a shower toilet with spray attachment for Rearwash
and Ladywash cleansing functions and additional comfort features.
Its use is limited exclusively to enclosed spaces.
Any other usage will be deemed as not corresponding with normal
usage. Duravit undertakes no liability for abnormal usage.
. Safety instructions
Read and observe the following safety instructions carefully!
Requirements for the user
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
> Children should be supervised to ensure that they do not play with
the appliance.
WARNING Damage to health caused by electric shock and/
or product damage
> The product must be grounded. Compare with the mounting
instructions.
Only use the device when it is fully functional.
> Make sure that the power cord is not damaged.
> The power cord must not become jammed or pinched.
> Keep the power cord away from hot surfaces and sharp edges.


EN
Do NOT use the product if it is not working properly.
> Disconnect from the power supply immediately. Close the stop
valve to interrupt the water supply. Contact [e-mail].
> Avoid malfunctions and damage to the product as a result of
improper use.
CAUTION Health damage and potential product damage!
> Supply the device with cold drinking water from the main water
system.
> The new hose-sets supplied with the appliance are to be used and
old hose-sets should not be reused.
> The product itself does not have electrical leakage protection
function, it must be installed in circuit where there is leakage
protection device installed.
> Means for disconnection must be incorporated in the fixed wiring
in accordance with the wiring rules and having a contact
separation in all poles that provide full disconnection under
overvoltage category III conditions.
> DO NOT sit, stand or lean on the lid.
> DO NOT connect any waste water, grey water, industrial water, sea
water or other untreated or semi-treated water.
> Do NOT detach seat and lid for any purpose.
> DO NOT damage the surface of seat. If the surface of the seat is
damage, contact [email protected]om.
> DO NOT open and close seat with excessive force.
> Open and close the lid via remote control and app only. Do not open
and close the lid manually.
> If the SensoWash®is moved from a cold location to a warm
location, condensation may form. Leave the unit switched off for a
few hours.
> DO NOT install the SensoWash®in rooms where there is a danger
of frost. The room temperature must not be less than 4 °C (39 °F).
> DO NOT place open fire sources, candles, cigarettes, or similar, on
the SensoWash®.
> DO NOT expose the SensoWash®directly to water or sunlight.
> DO NOT climb on or stand on the product.
> DO NOT place any heavy objects on the lid.
> DO NOT deliberately soil, spray or block the spray wand.


EN
Repairs must only be carried out by a person with the necessary
expertise and qualification.
> DO NOT carry out modifications, tamper with, install additional
equipment or attempt to repair the SensoWash®.
> If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
> Repairs must be carried out by qualified electricians or technicians.
> Improperly performed repairs can lead to accidents, damage and
malfunctions.
> DO NOT use attachments not recommended by Duravit.
Use of batteries
Risk of fatal injury if swallowed/Chemical burn
hazard
This product contains coin/button cell batteries. Do not ingest
battery! If the cell battery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
> DO NOT ingest battery, Chemical Burn Hazard.
> Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the product and
keep it away from children.
> If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
Damage to health caused by leaking battery acid
> Avoid contact with skin, eyes and mucous membranes if battery
acid has leaked.
> In case of contact with the acid, flush the affected areas with large
amounts of clean water and consult a doctor immediately.
> DO NOT expose the batteries to extreme conditions: avoid contact
with hot surfaces or direct sunlight. Otherwise there is a risk of
leakage.
> The cells shall be disposed of properly, including keeping them
away from children. Even used cells may cause injury.
WARNING
CAUTION


EN
NOTICE Product and/or property damage
> Batteries may not be recharged, reactivated by other means,
dismantled or exposed to fire.
> The supply terminals are not to be short-circuited.
> Always remove empty batteries from the remote control
immediately. They may leak and cause damage.
> DO NOT insert new and old batteries together in the remote control.
> Different types of batteries are not to be mixed.
> Clean the battery and contacts before inserting the battery.
> Batteries are to be inserted with the right polarity.
> Remove the batteries if you do not use the remote control for an
extended period.
IMPORTANT SAFEGUARDS
When using electrical products, especially when children are pre-
sent, basic safety precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING
DANGER
To reduce the risk of electrocution!
> Do not use while bathing.
> Do not place or store product where it can fall or be pulled into a
tub or sink.
> Do not place in or drop into water or other liquid.
> Do not reach for a product that has fallen into water. Unplug
immediately.
WARNING To reduce the risk of burns, electrocution, fire,
or injury to persons!
> Close supervision is necessary when this product is used by, on,
or near children or invalids.
> Use this product only for its intended use as described in this
manual. Do not use attachments not recommended by the
manufacturer.


EN
> Never operate this product if it has a damaged cord or plug, if it
is not working properly, if it has been dropped or damaged, or
dropped into water. Return the product to a service center for
examination and repair.
> Keep the cord away from heated surfaces.
> Never block the air openings of the product or place it on a soft
surface, such as a bed or couch, where the air openings may be
blocked.
> Keep the air openings free of lint, hair, and the like.
> Never use while sleeping or drowsy.
> Never drop or insert any object into any opening or hose.
> Do not use outdoors or operate where aerosol (spray) products
are being used or where oxygen is being administered.
> Connect this product to a properly grounded outlet only (For cord-
connected models only). See Grounding Instructions.
> Unplug this product before filling. Fill (reservoir) with water only
unless otherwise specified by manufacturer. Do not overfill (or
specify filling instructions).
SAVE THESE INSTRUCTIONS
For all grounded, cord connected products:
GROUNDING INSTRUCTIONS
This product should be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. This product is equipped with a
cord having a grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and grounded.
Improper use of the grounding plug can result in
a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not
connect the grounding wire to either flat blade terminal. The wire
with insulation having an outer surface that is green with or without
yellow stripes is the grounding wire.
DANGER


EN
Check with a qualified electrician or serviceman if the grounding
instructions are not completely understood, or if in doubt as to
whether the product is properly grounded.
This product is for use on a nominal 120 V circuit, and has a
grounding plug that looks like the plug illustrated in sketch A in
Figure 75.1. A temporary adapter, which looks like the adapter
illustrated in sketches B and C, may be used to connect this plug to
a 2-pole receptacle as shown in sketch B if a properly grounded
outlet is not available. The temporary adapter should be used only
until a properly grounded outlet (sketch A) can be installed by a
qualified electrician. The green colored rigid ear, lug, and the like
extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover. Whenever the
adapter is used, it must be held in place by the screw.
For units converted into a permanently connected device:
GROUNDING INSTRUCTIONS
This product should be connected to a grounded, metallic,
permanent wiring system, or an equipment-grounding
conductor should be run with the circuit conductors and connected
to the equipment grounding terminal or lead on the product.
FFC Compliance statement
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
(A)
(B)
(C)
Grounding pin
Grounded
outlet
Grounded
outlet box
Tab for
grounding screw
Metal screw
Adapter


EN
WARNING
Changes or modification not expressly approved by the party
responsible for compliance could void the user‘s authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
Industry Canada (IC) Compliance Statement
This device complies with Industry Canada’s licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including inter-
ference that may cause undesired operation of the device.


EN
Functions and Settings
The full range of functions is available whether the product is operated via remote
control or app. Functions are set according to default settings
(Table: Default settings). Download app to make adjustments on the extended
setting range ( Ch. 5: Download app).
Controlled via
basic range extended range
On/off SensoWash® • - -
Bluetooth (connect app) • - -
Open/close lid
(electromotive)
- • •
Auto opening lid - - •
Auto closing lid - - •
Rearwash - • •
Ladywash - • •
Comfortwash - - •
Warm air dryer - • •
Warm air dryer temperature - - •
Spray wand position - • •
Water spray intensity - • •
. Basic product information
. About this manual
This manual contains safety and general product information and information on how to
operate SensoWash® via remote control (basic setting range).
> See Quick Guide in app ( App: Menu - Device Guide - Quick Guide 20 ) for
information on the full range of setting options available for this product.
. Operation
SensoWash® is operated via remote control (basic setting range) and/or app (extended
setting range).
A number of settings can be adjusted via app only ( Table: Functions and settings).
> Download app to adjust the full range of setting options available for this product
(Ch. 5: Download app).


EN
Functions and Settings
Controlled via
basic range extended range
Water temperature - • •
Odor extraction - • •
User profile - • -
Seat heating - - •
Seat heating temperature - - •
Energy saving (seat heating) - - •
Night light - - •
Confirmation tone - - •
Holiday mode - - •
Manual cleaning mode - - •
Self-cleaning - - •
Descaling - - •
Reset default setting - - •
Table: Functions and settings
Default Settings
setting range default setting
Auto opening lid on/off off
Auto closing lid on/off off
Comfortwash on/off on
Warm air dryer temperature off/low/medium/high medium
Spray wand position front 1, 2, 3, 4, 5 back 3
Water spray intensity low/medium/high medium
Water temperature off/low/medium/high medium
Seat heating on/off on
Seat heating temperature low/medium/high medium
Energy saving mode on/off off
Night light off/auto/on auto
Confirmation tone on/off off
Table: Default settings


EN
. LED indication
Power button
Red light Indicates stand-by mode.
Switch SensoWash® on to activate seat unit
(Ch. 5: Switch SensoWash® on/off).
Green light Indicates on mode.
Energy saving mode is off.
Orange light Indicates on mode.
Energy saving mode is on.
Flashing Malfunction.
Deactivate seat unit, close stop valve, contact
[email protected]om ( Ch. 9: Troubleshooting).
Bluetooth button
Blue light Bluetooth is available or connected.
Off Bluetooth is not available.
Flashing Device is in pairing mode ( Ch. 5: Pairing app).
Table: LED indication (seat unit)
. Energy saving and water efficiency
In order to minimize the cost of natural resources, SensoWash®includes an instant
heating system and an Auto Stop feature for all washing and drying functions. To save
energy in the everyday usage of the product, it is possible to adjust the following
settings:
> Energy saving mode (seat heating)
Deactivates seat heating for a specific period of time (e. g. during daytime, while at
work) and automatically reactivates seat heating after that time ( App: Menu -
Settings - Seat 20 ).
> Holiday mode
If you do not use SensoWash® for two weeks or above, deactivate the product
(Ch. 7: Holiday mode) ( App: Menu - Care - Holiday mode 20 ).


EN
. Initial operation
Switch SensoWash® on/off
SensoWash® can be switched on/off via the side control button. Requirement:
SensoWash®must be connected to the main power supply.
Download app
Search for “SensoWash“ in Play Store (Android) or App Store (iOS).
Pairing app
SensoWash®is connected to the app via bluetooth. SensoWash®and bluetooth have
to be switched on ( 5and 6) to establish the connection. Follow step-by-step
instructions in app to connect app to the product.
> Green LED: seat
ready to use.
> Red LED: seat
not ready to use
(standby).
> Press button
shown to switch
seat on or off.
2
1


EN
Change batteries
Insert batteries into the remote control.
. Operating
Use this QR-Code to see a video of the operating functions
or visit www.duravit.com/vid_sensowash_starck_f
Open/close lid
The SensoWash®lid opens/closes automatically when a person approaches/leaves the
toilet. Alternatively open/close lid via remote control or app.
NOTICE Damage of seat and lid!
Lid can be damaged if it is opened/closed manually.
> Open and close lid via remote control or app only.
> Do not open and close the lid manually.
> Do NOT open and close seat with excessive force.
1
M2x4
4
> Attach screw.
> Insert batteries
(CR2450).
> Remove screw
and open
battery
compartment.
> Close battery
compartment.
CR 2450
+
3V
CR 2450
+
3V
2
CR 2450
+
3V
CR 2450
+
3V
1
2
3


EN
Open/close lid
Auto opening (activate/deactivate)
Auto closing (activate/deactivate)
Activate/deactivate Rearwash
Gentle and safe rear cleansing.
SensoWash®automatically cleans the retracted spray wand when the seat sensor is
activated and also before and after washing functions are used.
Rearwash (activate/deactivate)
Adjust spray wand position, adjust water spray intensity, adjust
water temperature
Comfortwash (activate/deactivate)
> Press icon
shown to open
or close lid.
34
1
> Rearwash is
active, the spray
wand extracts
slowly.
34
1
> Press icon shown
to activate
Rearwash.
> Press stop to end
or after 2 min.
auto stop.
2
34
3
