Teile-Nr./ Part-No.:
0791 867703
Printed in Federal Republic of Germany
Ausgabe/Edition:
01. 2006
Blatt: 3 von 4
Sheett from
1. General information
1.1 Mounting kit
The complete kit for mounting and adjusting the reflected light barrier with the order number
0867 590074 consists of the following components:
light barrier 9815 920023 head cover 0667 105164
holder 0867 490030 washer 1001 009243
reflecting foil 9815 920024 oval head screw 9204 201657
fastening clamp 9840 120025 cable tie 9840 121001
washer 9330 000087
Caution: Risk of injury !
Switchthemainswitchoff!
Mount the kit only with the sewing machine switched off.
2. Assembly
–Remove the head cover.
–Mount new head cover 0667 105164.
–Screw light barrier 1on holder 2with the oval
head screws 3.
–Place the connecting cable in the strain relief of
the holder.
–Screw holder 2with light barrier on the head
cover with two oval head screws and washers.
–Guide the connecting cable through clamp 4
and screw it on the head cover with oval head
screw and washer.
–Guide the cable to the cable duct at the back
side of the sewing head and fix it with two cable
ties.
–Connect plug 6to the printed circuit board of the
sewing head (see illustration).
–Stick on reflecting foils 5(see illustration).
A = for stitch length £5mm
B = for stitch length ³5mm
Anbauanleitung Reflexlichtschranke
Instructions for fitting the reflecting light barrier
Bausatz / Kit 0867 590074
2
1
43
16 mm
16 mm
Stichlänge
<5mm >5mm
AB
5
6
