Duronic HV051 User manual

Creative Consumer Electronics
Mica Heater - HV051 / HV101
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

2

3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
5
21
35
49
63
Contents

4

5
English Manual

6

7
Contents
Features & Specications
Introduction
Remove Packaging
Installation of Wheels
Operation
Important Safeguards
Cleaning, Storage & Warning
Trouble-shooting
8
9
10
11
12
14
16
17

8
Features & Specications
The Duronic HV101 and HV051 use a “Mica Heating Element” which is a
leading technology in heating. Our mode is not only oil free, but also offers
more than a standard oil heater. It heats up within a minute hence making it a
very cost effective heater. All our Mica heaters have easy carry handles and
wheels to make it a fantastic portable heater.
Full heat in 1 Minute
Three Power settings
Covering sensor (overheat protection) and Tip over protection
On/Off switch with light indicator
Temperature setting indicator
Comfortable zone
Anti -frost
Light weight
Quiet operation
No oil =No leakage
No dehumidifying
Power cord storage on front
Oil-Free Column Heater
Special Features
Specication
Item Power Voltage Rating Unit Size Unit Weight
HV101 2500W 220-240V,
50/60Hz
710(L)*232(W)*648(H )mm 6.1kg
HV051 1500W 220-240V,
50/60Hz
525(L)”232(W)”648(H)mm 4.8kg

9
Unit Layout
1. Built-in handle
2. I ON/OFF Switch
3. I I ON/OFF Switch
4. Temperature Control Knob
5. Storage location for cord
6. Stand
7. Wheel
8. Right panel

10
Removing the Packaging
1. Take the heater and the packaging
out of the box .
2. Remove the foam from both ends of
the heater. Remove the polybag
which is covering the heater and
store away. Keep any bags and foam
away from children.
3. Remove the front foot and wheels
from the foam packaging
4. Keep your packaging safe, as this is
part of the guarantee. It is also useful
for storing the heater when not in use.

11
Installation of the wheels and the base
Insert the wheels and the base onto
the bottom of the heater by slotting
them into the gaps.

12
Operation
PLEASE READ THE
INSTRUCTIONS INFULL
BEFORE USING THIS
HEATER.
1.Check that the unit is at:
- [OFF] position (Fig. 1 ).
-The Temperature Control
Knob is at [OFF] position
(Fig. 2).
- Also the power at Low Heat
Position (Fig. 3)
2.Plug in the power cord to a
suitable electrical outlet.
(Rated not less than 10 AMP)
3.Press the ON/OFF switch to
[ON] position.
At this moment, its light
indicator is on.
4. Turn the temperature control knob to
your desired temperature. The light
indicator and heater will turn on until the
room has reached the desired
temperature. It will then automatically
turn off until the room temperature drops.
The heater will then turn on again so that
the desired room temperature is
maintained. According to personal needs
you can adjust the temperature control
knob to increase or decrease the room
temperature.

13
5. Then press the Power switch to:[ I ]
Heating power setting I [II] Heating power
setting II HV101
[ I ] 1500W, [ II ] 1 ooow,
[ I ]& [ II ] 2500W HV051
[I] 1000W, [II] 500 W,[ I ]& [ II ] 1500W
6. For a pleasant temperature
there is an area indicated on the
Temperature Control Knob which is
known as the “Comfortable Zone”.
7. Anti-Frost Function
This function will keep the surrounding
temperature above freezing point. To
do this, simply plug in the power cord,
and turn the Temperature control knob
to the “Snowflake” position.
a. Covering Sensors
Even though a warning label “DO NOT
COVER” has been placed on the unit,
some users may accidentally cover the
unit with towels or blankets etc.
Therefore, a safety device has been
installed within the heater to detect
overheating. Once the unit overheats,
power will be cut off. When the unit
temperature falls again, power will be
resumed.
8. Tip over protection.
If the heater is accidentally knocked over,
it will switch off automatically.

14
Important Safeguards
The heater is hot when in use. To
avoid burns, do not let bare skin
touch the hot surface. Use the
handles when moving the heater.
Keep combustible materials, such
as curtains etc., and other
furnishings at least 3 feet (0.9m)
radius from the heater to avoid a
re hazard.
Extreme caution is necessary when
any heater is used near children,
Do not leave children unattended
when this heater is ON. The heater
is not a toy.
Do not use the heater outdoors.
This heater is not intended for use
in bathrooms, laundry areas and
similar indoor locations. Never use
the heater near any forms of water.
Do not use the heater in areas
where gasoline, paint or ammable
liquids are used or stored.
Do not insert or allow any objects to
enter any ventilation or exhaust
opening as this may cause an
electric shock or re, or damage
the heater.
To prevent a possible re, do not
block air intakes or exhaust in any
manner.
Do not operate this appliance on a
soft or uneven surface as that can
block the openings.

15
Always unplug the heater when not in
use. To disconnect the heater,
remove plug from outlet.
Please avoid using an extension lead
with this heater. All extension leads
have a maximum wattage allowance,
and by using this heater with other
appliances the wattage allowance
may be exceeded and overheat the
plug and extension socket and result
in a fire risk.
Do not run the cord under carpeting.
Do not cover the cord with throw rugs,
runners, etc. Arrange the cord tidily
where is cannot be tripped over. Do
not operate any heater with a
damaged cord or plug. If the supply
cord is damaged, it must be replaced
by a qualified person in order to avoid
hazard.
Connect to properly grounded outlets
only.
Use this heater only for the purpose
as described in this manual. Any other
use not recommended by the
manufacturer may cause fire, electric
shock, or injury to persons. Do not
use this heater with a programmer,
timer or any other device that
switches the heater on automatically,
since a fire risk exists if the heater is
covered or positioned incorrectly.

16
Cleaning
Storage
Warning
1. Before cleaning turn off the heater, unplug the power cord and allow the
heater to cool.
2. Do not immerse the power cord, plug or heater in water or other liquids, or
pour water or other liquids over the heater.
3. Use a vacuum cleaner to remove dust and lint from the metal grill of the
heater. Wipe the heater with a dry cloth to remove dust and a damp cloth (not
wet) to clean off stains.
4. Do not use detergents, abrasive cleaning products or any kind of polishing
material on the body of the heater as these can damage the nish.
Do not use this heater in the immediate
surroundings of a bath, a shower or a
swimming pool
The heater must not be located
immediately below a socket-outlet.
1. Store the heater in a cool dry location, preferably covered to prevent dust
and dirt building up in the heater. Use old packaging to repack the unit.
2. Unplug the heater and store the mains lead in the storage tidy at the front of
the heater. Ensure that the plug does not trail.
Any other servicing should be performed by an authorized service
representative.

17
Troubleshooting
Heater is not warm
1. Check the heater is
plugged in.
3. Check that the
heater is not
covered.
2. Check that the
temperature setting is
in right position.
4. On the lowest heat settings
not all panels heat up. This
does not mean that the
heater is defect.
1. Check the power
cord is plugged
into the
electrical outlet
2. Check whether the
electricity or the main
fuse is working
4. Check that heater
is on the Thermostat
Control Condition.
After storage or restarting the heater, the heater may smell slightly.
This is because the heater absorbs the air from the room,
which may contain cigarette smoke, cosmetic fumes and smells
from furniture or the walls etc. When the heater starts up again,
it will emit those smells, this is normal and after a short period
of time the smell will start to disappear.
3. Make sure the
power switch is
at the [ON]
position.
Heater is not operating
There is a smell coming from the heater
Keep these instructions safe

18
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest or quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 years from the date of original purchase. If any defect arises due
to a faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions contained in
this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or
consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
7. Valid in the UK only
This product is tted with BS:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.

19
