Duronic Mica HV180 User manual

Mica Heater - HV180
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

2

3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
Instrukcja obsługi. Polski
5
16
27
38
49
60
Contents

4

5
English Manual

6
The Duronic HV180 uses a Mica heating element, which is a leading technology
in the world of heating. Our model is oil-free and offers more much more than a
standard heater.
The HV180 heats up within one minute, making it a very cost-effective and
energy-efcient heater.
Equipped with a long handle, moving and relocating this portable heater from one
place to another is easy to do.
Special Features
• Heats up in 1 minute
• Two power settings
• Cover sensor (overheat protection)
• Tip-over protection
• Anti-frost
• Lightweight portable design
• Quiet operation
• Oil-free
• Does not dehumidify
• Power cable storage on the side
• IP24 rated: dust-proof and splash-proof
Features and Specications
Model
Number Power Voltage Dimensions Weight
HV180 1800W 220-240V,
50/60Hz
495(L)x150(W)
x550(H)mm 4.5kg

7
1. Handle
2. Power indicator
3. Temperature control dial
4. Power control dial
5. Front cover
6. Cable storage hook
7. Power cable with plug
8. Top cover
9. Rear cover
10. Protective mesh
11. Legs
1
9
11
8
10
5
2
3
4
6
7

8
PLEASE READ THIS MANUAL CAREFULLY AND RETAIN FOR FUTURE
REFERENCE
• This appliance is for indoor/household use only. Do not use outdoors.
• This heater is not designed for commercial or industrial use; it is solely for
household use only.
• Ensure that the voltage is the same as indicated on the rating label of the
heater.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• Some parts of this product can become very hot and cause burns. Do not
touch the front of the heater, the protective grill or vent whilst it is in use.
• Particular attention has to be given where children and vulnerable people are
present.
• If either the appliance or power cable is damaged, return the heater to
Duronic for service or repair by a professional technician.
• Never open and repair the machine yourself. Do not modify the machine in
any way that is not described in the instructions for use.
• Always operate the appliance on a dry, smooth, even and stable surface. Do
not use on long pile carpet or deep pile rugs.
• Always ensure that your hands are dry before operating or adjusting any
switch on the product or touching the plug and socket.
• Cleaning should be done as per instructions in this manual. Do not immerse
the heater in water or any other liquid.
• Do not insert or allow any foreign object to enter any intake or outlet
openings, as this may cause an electric shock, re or damage to the
appliance.
Safety Instructions

9
• Keep the appliance and cable away from sources of heat, sharp objects or
anything that might cause damage.
•To avoid overheating, do not cover the heater. To prevent a possible re
hazard, do not block the air intakes or the outlet in any way.
• Ensure the appliance is always switched off before connecting it to the mains
power supply.
• This appliance is not intended to be operated using an external timer or
separate remote-control system.
• Do not plug the heater into an extension lead or multi-plug power adapter
as the heater is too powerful for it. Using an extension lead or adapter with
this heater is a re hazard and may cause damage to the heater or the user.
Always plug a heater directly into a mains socket.
• Switch off the power supply and unplug the appliance whenever it is not in
use, before cleaning it or carrying out any maintenance.
• Ensure the heater is positioned at a minimum distance of 1 metre from any
wall or objects.
• This heater must not be located immediately below a plug socket.
• To disconnect the appliance, switch it off, and then remove the plug from the
socket.
• Do not pull the cable to unplug it.
•Do not operate the heater in areas where petrol, paint or other ammable
liquids are used or stored.
• Do not touch the hot surfaces.
• Do not leave this appliance unattended when it is in use.
•The most common cause of overheating is deposits of dust or uff in the
appliance. Ensure these deposits are removed regularly by disconnecting the
appliance and then vacuum cleaning the air vents and grills.
•Place the cable in such a way that it is not in any high trafc area to avoid it
being tripped over or stood on.

10
1. Position the heater carefully upside down.
2. Attach one leg at a time. Position the rst leg onto the base and align with the
screw holes in the bottom of the heater.Insert two screws into the base of the
leg and tighten them up xing the leg in place securely.
Repeat the same steps to attach the second leg.
Assembly Instructions
• Before cleaning, turn off the heater. Unplug the power cable and allow the
heater to cool down.
• Do not put the heater away until it has cooled down completely. Store the
heater in cool dry location when not in use.
• This product is only suitable for well insulated spaces or occasional use.
• Remember, portable electric heaters are designed for spot heating, or as a
supplementary heat source. They are not intended to be main sources of
heat.

11
When not in use:
Check that the power switch dial is turned OFF [0]
(Fig 1) and the temperature control dial is turned
OFF (Fig 2).
Switching on the Heater:
To turn the heater on, rotate the power dial to your
preferred power level:
[ I ] Setting 1: 900W
[ II ] Setting 2: 1800W
Please read these instructions in full before using this heater and retain for future
reference.
Fig 1
Low Power
Setting
Fig 2
High Power
Setting
Operating Instructions
Connecting the Power:
Plug the power cable into a suitable mains socket (rated not less than 10 AMP).
Once plugged in and the socket is switched on, the light indicator will turn on.
Setting the Temperature:
Select the temperature you prefer and the heater will
heat the room to the chosen temperature and then turn
off automatically.
When the indoor temperature drops below the set
temperature, the heater will start to work again
emitting heat until the indoor temperature reaches the
desired temperature once again. This cycle will repeat to maintain your chosen
temperature. The temperature can be adjusted by simply turning the temperature
control dial to the temperature you want.

12
Anti-Frost Function:
This function will keep the surrounding
temperature above ‘freezing point’. To activate
this function, simply plug in the power cable
and turn the temperature control dial to the
snowake position.
Overheat Protection
A warning label saying “DO NOT COVER” has
been placed on the heater to warn against
putting anything on top of the heater. Despite
this, it has been known that some users still
accidently cover the heater with a towel or
blanket etc. Therefore, there is an inbuilt safety
device within the heater to protect against over
heating.
If the heater overheats, the power will be cut
off automatically.
When the heater detects that the temperature
has dropped again, the power will swtich back
on.
Tip-Over Protection:
If the heater is accidently knocked over, it will
switch off automatically.
Operating Instructions (continued)

13
• Before cleaning, turn off the heater. Unplug the power cable and allow the
heater to cool down.
• Do not immerse the power cord, plug or the heater itself into water or any
liquid. Do not pour water or any liquid over the heater.
• To clean the heater safely, use a vacuum cleaner to remove any dust and lint
on the grill/mesh cover. Wipe the heater with a dry cloth to remove any extra
dust and a damp (well wrung) cloth to clean off any stains.
• Do not use detergents, abrasive cleaning products or any kind of
polishing material on the body of the heater as this can damage the nish.
• Unplug the heater and wind up the power cable onto the cable storage hook.
• Store the heater in a cool dry place.
Cover to prevent dust and dirt building up on the machine.
Old packaging is ideal for using as a cover.
•Any other maintenance or servicing should be performed by a qualiied
person or by the manufacturer.
• Do not use this heater in the immediate surroundings of a bath, a shower or a
swimming pool.
• The heater must not be located immediately below a socket-outlet.
Cleaning
Storage
Warning

14
Heater does not heat up:
Troubleshooting
1. Check if the heater is
working or not.
1. Check the power cable
is plugged into the
mains socket.
2. Check if the temperature
setting is in the right
position.
2. Check if electricity or the main fuse
is working or not.
3. Check if there is any
object covering the front
of the heater.
3. Make sure the power
switch is at “I” or “II”
position.
4. The heater does not function when
one set of elements are not working.
4. Check if the
temperature control dial
is in a working position.
Heater is not operating:
Smell comes out from the heater:
After storing or restarting the heater, some smell may be released.
This can be because the heater absorbed the air in the room, which may contain
cigarette, smoke, cosmetic smells, household chemical frangrances or any other
surrounding pollutants.
Be assured, when the heater starts up again it will release these smells but after a
short time the smell will disappear.

15
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest of quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give a very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 year from the date of original purchase. If any defect arises due
to faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions
contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect,
inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work,
under the guarantee
7. Valid in the UK only
This product is tted with CE:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.
Follow Us

16
Manuel d’utilisation en français

17
Le HV180 de Duronic utilise un élément chauffant en Mica, qui
Le HV180 chauffe en une minute, ce qui en fait un appareil de chauffage
économique et économe en énergie.
Equipé d'une longue poignée, il est facile de déplacer ce radiateur portable d'un
endroit à un autre.
Caractéristiques spéciales
•
est une
technologie de pointe dans le monde du chauffage. Notre modèle est sans
huile et offre bien plus qu'un appareil de chauffage standard.
Chauffe en 1 minute
•Deux réglages de puissance
•Capteur de couverture (protection anti-surchauffe)
•Protection anti-chute
•Anti-gel
• portable légerDesign
•Fonctionnement silencieux
•Sans
•
huile
Ne
•
déshumidifie pas
Enroule-câble sur le côté
•Certifié IP24 : résistant à la poussière et aux éclaboussures
Caractéristiques et Spécifications
Modèle Puissance Voltage Dimensions Poids
HV180 1800W 220-240V,
50/60Hz
495 x 150 x 550
mm 4.5 kg

18
1. Poignée
2. de puissanceIndicateur
3.
4.
Cadran de contrôle de température
5.
Cadran de contrôle de puissance
Capot
6.
avant
Crochet de rangement du câble
7. Câble d'alimentation
8. Capot supérieur
9. Capot arrière
10. Grille de protection
11. Pieds
1
9
11
8
10
5
2
3
4
6
7

19
VEUILLEZ LIRE CE MANUEL ATTENTIVEMENT ET LE CONSERVER.
• Cet appareil est conçu pour un usage intérieur. Ne l'utilisez pas à l'extérieur.
• Ce radiateur n'est pas conçu pour un usage commercial ou industriel; il
est uniquement conçu pour un usage domestique.
• Assurez-vous que la tension est la même que celle indiquée sur la
plaque signalétique de l'appareil de chauffage.
.
• Ce produit n'est pas conçu pour être utilisé par des personnes (y compris des
enfants) dont les capacités physiques, sensorielles ou mentales sont limitées ou
qui manquent de savoir et d'expérience, à moins qu'elles ne soient supervisées
ou qu'elles aient reçu les
•
instructions nécessaires à l'utilisation de cet appareil
par la personne responsable de leur sécurité.
Certains éléments de cet appareil peuvent devenir très chauds et
provoquer des brûlures. Ne touchez pas l'avant de l'appareil, la grille de
protection ou la ventilation, lorsqu'il est en cours d'utilisation.
•
•
Une attention particulière doit être donnée là où les enfants et personnes
vulnérables sont présentes.
Si l'appareil ou le câble d'alimentation est endommagé, veuillez
contacter Duronic ou faites réparer par un technicien professionnel.
• N'essayez jamais d'ouvrir et de réparer l'appareil vous-même. Ne modifiez pas
l'appareil d'une façon qui n'est
•
pas décrite dans les instructions d'utilisation.
Utilisez toujours l'appareil sur une surface sèche, lisse, plate et stable.
N'utilisez pas l'appareil sur des tapis à poils longs ou à poils épais.
• Assurez-vous toujours que vos mains sont sèches avant d'actionner ou de
régler un interrupteur sur l'appareil ou de toucher le câble ou la prise.
• Le nettoyage doit être réalisé conformément aux instructions de ce
manuel. N'immergez pas le radiateur dans l'eau ou tout autre liquide.
• N’insérez ou ne laissez aucun objet pénétrer dans les ouvertures
d’entrée ou de sortie de la ventilation, car cela pourrait provoquer
un choc électrique, un incendie ou endommager l’appareil.
de sécuritéInstructions

20
• pointus
ou de tout objet qui pourrait endommager l'appareil.
Gardez l'appareil et le câble à l'écart des sources de chaleur, d'objets
• Pour éviter la surchauffe, ne couvrez pas le radiateur. Pour éviter un possible
risque d’incendie, ne bloquez pas les conduits d’entrée et de sortie d’air de
quelque manière.
• Vérifiez que l'appareil est toujours éteint avant de le brancher sur une prise
secteur.
• Cet appareil n'est pas conçu pour être utilisé avec un minuteur
externe ou un système de contrôle à distance.
• Ne branchez pas le radiateur sur une rallonge ou une multiprise, car le
radiateur est trop puissant pour cela. L’utilisation d’une rallonge ou une
multiprise avec ce radiateur présente un risque d’incendie et peut
endommager l’appareil ou blesser l’utilisateur. Branchez toujours un chauffage
directement sur une prise de courant.
• Eteignez l'appareil et débranchez-le lorsque vous ne l'utilisez pas, avant
de le nettoyer ou bien avant d'effectuer un entretien.
• Assurez-vous que le radiateur est placé à une distance minimale d'1
mètre de
•
tout mur ou objet.
•
Cet appareil de chauffage ne doit pas être situé juste en dessous d'une prise
de courant.
•
Pour débrancher l'appareil, éteignez-le, puis retirez la fiche de la prise.
Ne débranchez jamais la prise en tirant sur le câble.
• N’utilisez pas le radiateur dans un endroit où du pétrole, de la peinture
ou tout autre produit inflammable sont utilisés ou rangés.
• Ne touchez pas les surfaces chaudes.
•
•
Ne laissez pas cet appareil sans surveillance lorsqu'il est en cours d'utilisation.
La cause de surchauffe la plus commune est le dépôt de poussières et
peluches dans l'appareil. Assurez-vous que ces dépôts soient
régulièrement
•
retirés en débranchant l'appareil puis en passant l'aspirateur
dans les aérations et grilles.
Placez le câble de manière à ce qu’il ne puisse pas être piétiné ou que l’on
ne puisse pas trébucher dessus.
