Duronic HV052 User manual

Creative Consumer Electronics
Mica Heater - HV052 / HV102
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

2

3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
5
21
35
49
63
Contents

4

5
English Manual

6

7
Contents
Features & Specications
Introduction
Remove Packaging
Installation of Wheels
Operation
Important Safeguards
Cleaning, Storage & Warning
Troubleshooting
8
9
10
11
12
14
16
17

8
Features & Specications
The Duronic HV102 and HV052 uses Mica Heating Element which is a
leading heating technology used for heaters. Our mode is not only oil free, but
offers more than a standard heater. It heats up within a minute, making it a
very cost effective heater. All our Mica heaters have carry handles and
wheels to make it a fantastic portable heater.
Full heat in 1 Minute
Two Power settings
Digital LED display
Temperature adjustable between 5-36°C
Remote control
18 hours auto-off timer
Tip-over and overheat protection
Quiet operation
No oil= No leakage
No dehumidifying
Power cord storage on front
Oil-Free Column Heater
Special Features
Specication
Item Power Voltage Rating Unit Size Unit Weight
HV102 2500W 220-240V,
50/60Hz
710(L)*232(W)*6 48(H )
mm
6.1kg
HV052 1500W 220-240V,
50/60Hz
525(L)”232(W)”6 48(H)mm 4.8kg

9
Unit Layout
1. Display screen
2. Button
3. Storage location of plug cord
4. Power switch
5. Foot base
6. Caster
7. Wheel
8. Body
9. Back Cover
Introduction

10
Removing Packaging
1. Take the heater and the packaging
out of the gift box .
2. Remove foam from both ends of the
heater. Remove the polybag which is
covering the heater and store away.
Keep any bags and foam away from
children.
3. Remove the front foot and wheels from
the foam packaging
4.Keep your packaging safe, as this is
part of the guarantee. It is also useful
for storing the heater when not in use.

11
Installation of Wheels and Wheels Mountings
Insert the wheels on the bottom rear of
the heater by slotting it into the wheel
holder. Similarly the foot will go on the
front of the heater.
1. Plug in power cord to a suitable
electrical outlet.
2. Locate the switch on side rear and
switch the heater on.
The heater will now go into standby
Operation

12
3. Press the button on the front display
panel. The screen will indicate the room
temperature and power indicator light. It
will start off on low settings.
4. Press to increase the power to
“High power setting”, press
to decrease the power to “Low power
setting”.
5. Press the ‘Temp’ button, then the room
temperature will be on the display screen,
the defaulted temperature is 25˚C.
There is 5-36˚C which can be set as you
desire. You can press to change
temperature, the settings will be effective
in 6 seconds.
The heater will remain on until the room
temperature increases to your desired
temperature. It will stop heating while at
the desired temperature, when the room
temperature is 2˚C less than the desired
temperature, it will start heating again.
This cycle will repeat to maintain the
desired room temperature.
Operation

13
6.The heater is equipped with a18-hours
automatic timer. To activate the timer,
press the “Timer” button and then press
( .& or ..,.. ) on the control panel or remote
control. This will increase or decrease the
heater operating time by one hour each
time. The screen will display the number
you have selected. Select a time for the
timer to turn off, and in 6 seconds the
timer will be activated.
If you need to turn off the timer, simply
press the” Timer” Button.
7. Covering Sensors.
Even though a warning label “DO NOT
COVER” has been placed on the unit,
some users accidentally cover the unit by
means of towels or blankets etc.
Therefore, a safety device has been
installed within the heater to detect
overheating. Once the unit overheats,
the power wilI be cut off. When the unit
temperature falls again, power will be
resumed .
a. Tip over protection .
If the heater is accidentally knocked over ,
it will switch off automatically .

14
Important Safeguards
The heater is hot when in use. To
avoid burns, do not let bare skin
touch the hot surface. Use the
handles when moving the heater.
Keep combustible materials, such
as curtains etc., and other
furnishings at least 3 feet (0.9m)
radius from the heater to avoid a
fire hazard.
Extreme caution is necessary when
any heater is used near children,
Do not leave children unattended
when this heater is ON. The heater
is not a toy.
Do not use the heater outdoors.
This heater is not intended for use
in bathrooms, laundry areas and
similar indoor locations. Never use
the heater near any forms of water.
Do not use the heater in areas
where gasoline, paint or flammable
liquids are used or stored.
Do not insert or allow any objects to
enter any ventilation or exhaust
opening as this may cause an
electric shock or fire, or damage
the heater.
To prevent a possible fire, do not
block air intakes or exhaust in any
manner. Do not operate this
appliance on a soft or uneven
surface as that can block the
openings.

15
Always unplug heater when not in
use. To disconnect the heater,
remove plug from outlet.
Please avoid using an extension lead
with this heater. All extension leads
have a maximum wattage allowance,
by using this heater with other
appliances the wattage allowance
may be exceeded and overheat the
plug and extension socket and result
in a fire risk.
Do not run cord under carpeting. Do
not cover cord with throw rugs,
runners, etc. Arrange tidily where is
cannot be tripped over.
Do not operate any heater with a
damaged cord or plug. If the supply
cord is damaged, it must be replaced
by a qualified person in order to avoid
hazard.
Connect to properly grounded outlets
only.
Use this heater only for the purpose
described in this manual. Any other
use not recommended by the
manufacturer may cause fire, electric
shock, or injury to persons. Do not
use this heater with a programmer,
timer or any other device that
switches the heater on automatically,
since a fire risk exists if the heater is
covered or positioned incorrectly.

16
Cleaning
Storage
Warning
1. Before cleaning, turn off the heater, unplug the power cord and allow the
heater to cool.
2. Do not immerse power cord, plug or heater in water or other liquid, or pour
water or other liquid over the heater.
3. Use a vacuum cleaner to remove dust and lint at the metal grill of the
heater. Wipe the heater with a dry cloth to remove dust and a damp cloth (not
wet) to clean off stains.
4. Do not use detergents, abrasive cleaning products or any kind of polishing
material on the body of the heater, as these can damage the nish.
Do not use this heater in the immediate
surroundings of a bath, a shower or a
swimming pool
The heater must not be located
immediately below a socket-outlet.
1. Store the heater in a cool dry location, preferably covered to present dust
and dirt. Use old packaging to repack the unit.
2. Unplug the heater and store the mains lead in the storage tidy at the front of
the heater. Ensure that the plug does not trail.
Any other servicing should be performed by an authorized service
representative.

17
Troubleshooting
Heater Not Warm
1. Check the heater is
operating or not
3. Check if any object
covering in front of
the heater?
2. Check the
temperature setting in
right position or not
4. On the lowest heat settings not all
panels heat up. This does not mean
that the heater is defect.
1. Check the power
cord is plugged
into the
electrical outlet
2. Check whether the
electricity or the main
fuse is working
4. Check that the heater if
it is on the Thermostat
Control Condition.
After storage or restarting the heater, the heater may smell slightly.
This is because the heater absorbs the air from the room, which
may contain cigarette smoke, cosmetic fumes and smells from
furniture or the walls. When the heater starts up again, it will emit
those smells, this is normal and after a short period of time the
smell will start to disappear.
3. Make sure the
power switch
at[ ON] position.
Heater is not Operating
There is a smell coming from the heater
Keep these instructions safe

18
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest or quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 years from the date of original purchase. If any defect arises due
to a faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions contained in
this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or
consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
7. Valid in the UK only
This product is tted with BS:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.

19
