DXV Keefe D35104780 User manual

- 1 -
INSTALLATION INSTRUCTIONS
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
SAVE FOR FUTURE USE
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
M965482 Rev. 1.5 (5/17)
Model D35104780
Keefe®
Personal Hand Shower
Plumbers' Putty or Caulking
Drill Adjustable Wrench
Flat Blade Screwdriver
Teon Tape
Level
10'
Tape Measure
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: [phone]
www.DXV.com
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: [phone]
www.DXV.ca
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.

- 2 - M965482 Rev. 1.5 (5/17)
12INSTALL WALL BRACKETS
• The ADJUSTABLE SHOWER BAR (1) works best if secured to a
wall stud or cross brace within the wall, using the MOUNTING
SCREWS (2).
• If the ADJUSTABLE SHOWER BAR (1) is to be installed on
a tile or plaster wall the ANCHORS (3) and SCREWS (2)
should be used.
• Determine desired height and location (optional) of the
ADJUSTABLE SHOWER BAR (1) and mark the center line
location of the upper MOUNTING BRACKET (4). Using a level
and tape measure mark the lower center line for the other
MOUNTING BRACKET (4). The distance between the center
lines of the two MOUNTING BRACKETS (4) is 23-3/8" (594 mm).
Note: This dimension is important and must be maintained.
• For installations on drywall or tiled walls: Use MOUNTING
BRACKETS (4) as template and mark the location of the three
mounting holes. Drill three 1/4" dia. holes a minimum of 1-3/4"
deep. Insert the three ANCHORS (3) ush with face of the
nished wall.
• With a screw driver secure the MOUNTING BRACKETS (4)
to the wall with MOUNTING SCREWS (2).
• Supply to WALL SUPPLY (1) is 1/2" (13 mm) NPT.
See rough-in above for detailed information.
• Install RUBBER SEAL (2) onto WALL SUPPLY (1).
• Apply sealant or teon tape to threads of 1/2"
(13 mm) NPT supply nipple. Thread WALL
SUPPLY (1) onto supply nipple making a water tight
seal. WALL SUPPLY (1) with RUBBER SEAL (2)
should be tight against nished wall.
INSTALL WALL SUPPLY
CAUTION Turn off hot and cold water
supplies before beginning.
1/2" NPT
APPLY SEALANT
1
2
ROUGHING-IN DIMENSIONS:
• For reference
23-3/8"
(593 mm)
25-1/2"
(647mm)
2-9/16"
(65.9 mm)
7-1/4"
(185 mm)
7/8"
(22 mm)
8-3/4"
(222 mm)
WALL SUPPLY
WITH BUILT IN
BACK FLOW
PREVENTER
1/2”
(13 mm)
1-7/16"
(37 mm)
1-1/16"
(27 mm)
1/2
N.P.T.
48" - 60" (1219 - 1524 mm)
OPTIONAL
TO FINISHED FLOOR
RUBBER GASKET
FINISHED
WALL
FINISHED
WALL
1/2 NPSM HOSE
CONNECTION
59"
(1499 mm)

- 3 -
23-3/8"
(594 mm)
2
3
4
FINISHED
WALL
23-3/8"
(593mm)
1
C/L
C/L
9
11
10
6
8
7
3
4
5
5
C/L
LEVEL
2
M965482 Rev. 1.5 (5/17)
3
4
INSTALL ADJUSTABLE SHOWER BAR
5TEST INSTALLED HAND SHOWER
• Lift HAND SHOWER (1) from
HOLDER (2) and direct spray
into tub. Turn hand shower
valve on to check HAND
SHOWER (1) for proper
operation and hose
connections for leaks.
• Use KNOB (3) on HOLDER (2)
to adjust HAND SHOWER (1)
height on slide bar.
• I nstall SEAL (6) into COUPLING NUT (7).
Connect COUPLING NUT (7) to WALL
SUPPLY NIPPLE (8) and tighten.
• INSTALL second SEAL (9) into
SPRAY HOSE END (10) and connect
HAND SHOWER (11) to SPRAY
HOSE END (10). Hand tighten.
INSTALL HOSE AND HAND SHOWER
• Install the ADJUSTABLE SHOWER BAR (1)
onto the MOUNTING BRACKETS (4).
Push ADJUSTABLE SHOWER BAR (1)
ush against nished wall.
• If the ADJUSTABLE SHOWER BAR (1)
is aligned and level, tighten the upper and
lower SET SCREWS (5) with Hex Wrench
supplied to secure ADJUSTABLE SHOWER
BAR (1) to the nished wall.
1
3
2

- 4 - M965482 Rev. 1.5 (5/17)
Replace the “YYY” with
appropriate finish code
POLISHED CHROME 100
BRUSHED NICKEL 144
MODEL NUMBER
D35104780
Keefe®
Personal Hand Shower
D35104781.XXX
HAND SHOWER
H960440.XXX
HOSE & SEALS
M964561-YYY0A
HAND SHOWER BRACKET
M964565-0070A
MOUNTING KIT
M964546-0070A
SET SCREW
D35700035.XXX
WALL ELBOW
