Dynamite DYN1922 User manual

Ni-MH Glow Driver and Charger
Instruction Manual | Bedienungsanleitung | Manuel d’utilisation | Manuale di Istruzioni
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole
discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or
towerhobbies.com and click on the support or resources tab for this product.
MEANING OF SPECIAL LANGUAGE
The following terms are used throughout the product literature to indicate various levels of
potential harm when operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property
damage, collateral damage, and serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property
damage AND a possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property
damage AND a little or no possibility of injury.
WARNING: Read the ENTIRE instruction manual to become familiar with the features
of the product before operating. Failure to operate the product correctly can result in
damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this Product in a safe and responsible
manner could result in injury or damage to the product or other property. This product is not
intended for use by children without direct adult supervision. Do not use with incompatible
components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is
essential to read and follow all the instructions and warnings in the manual, prior to assembly,
setup or use, in order to operate correctly and avoid damage or serious injury.
Age Recommendation: Not for children under 14 years. This is not a toy.
SPECIFICATIONS
Glow Driver
Sub C 2600mAh Ni-MH battery cell
Short-circuit protection
Charge status LED
Ni-MH Charger
AC Input Voltage 100–240V AC (50–60Hz)
Charge Current 250mAh
Operating Temperature 0º C to + 50º C
Charging Mode Ni-MH
GLOW DRIVER BATTERY INSTRUCTIONS
Turn the meter cap counterclockwise to remove and replace the battery.
OPERATING INSTRUCTIONS
Operating your optional Charger with the Glow Driver
1. Attach the AC charger to the AC wall outlet. Make sure the plug is fully seated in the socket.
CAUTION: Always connect the charger to AC power before connecting a Glow Driver
to the charger, or damage to the charger and the battery can result.
2. Correctly connect the output end of the charger to the igniter end of the glow driver.
3. The light of the red LED on the charger indicates that the unit is charging.
4. After charging is complete, disconnect the charger from the AC power outlet then disconnect
the Glow Driver from the charger.
ESTIMATED CHARGE TIME
The charger can charge (at a 250mAh charge rate) the included Ni-MH battery (2600mAh) of
the glow igniter in approximately 10 hours if the battery is fully discharged. Initial charging will
take about 8.5 hours and recharging will require slightly less time, depending on the amount
the battery is discharged.
HEATING A GLOW PLUG
Connect the glow driver to a glow plug by depressing the spring loaded plunger, then releasing
the plunger when the end of the driver is on the glow plug’s hexagonal body.
When the meter pointer points to the green, the glow igniter is operating normally and the glow
plug is passing current.
When the meter pointer points to the red, the glow driver’s battery may be low and require
charging. If the battery is fully charged, the glow driver may be faulty or the glow plug has
failed. Replace faulty parts when needed.
We recommend always putting an insulating cap on the end of your driver during storage
to prevent accidental shorting or battery discharge through the electrical connection.
MULTI-PURPOSE NI-MH
(DYN1922)
WARNING: Failure to exercise caution while using this product and comply with the
following warnings could result in product malfunction, electrical issues, excessive
heat, FIRE, and ultimately injury and property damage.
• Read all safety precautions and literature prior to use of this product
• Never allow minors to charge battery packs
• Never drop charger or batteries
• Never attempt to charge damaged batteries
• Never attempt to charge a battery pack containing different types of batteries
• Never charge a battery if the cable has been pinched or shorted
• Never allow batteries or battery packs to come into contact with moisture at any time
• Never charge batteries in extremely hot or cold places (recommended between 50–80°F or
10–27°C) or place in direct sunlight
• Always disconnect the battery after charging, and let the charger cool between charges
• Always inspect a new battery before charging
• Always terminate all processes and contact Horizon Hobby if the product malfunctions
• Always keep batteries and charger away from any material that could be affected by heat
(such as ceramic and tile), as they can get hot
• Always end the charging process if the charger or battery becomes hot to the touch or starts
to change form (swell) during the charge process
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to national regulations.
SAFETY PRECAUTIONS AND WARNINGS
Scan the QR code and select the Manuals & Support quick link
from the product page for the most up-to-date information.

LIMITED WARRANTY
What this Warranty Covers
Horizon Hobby, Inc., (Horizon) warrants to the original purchaser that the product purchased (the
“Product”) will be free from defects in materials and workmanship at the date of purchase.
What is Not Covered
This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to
acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use,
installation, operation or maintenance, (iii) modification of or to any part of the Product, (iv)
attempted service by anyone other than a Horizon Hobby authorized service center, (v) Product
not purchased from an authorized Horizon dealer, (vi) Product not compliant with applicable
technical regulations, or (vii) use that violates any applicable laws, rules, or regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON MAKES NO OTHER WARRANTY
OR REPRESENTATION, AND HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE PURCHASER
ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY
MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE.
Purchaser’s Remedy
Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon will,
at its option, either (i) service, or (ii) replace, any Product determined by Horizon to be defective.
Horizon reserves the right to inspect any and all Product(s) involved in a warranty claim. Service
or replacement decisions are at the sole discretion of Horizon. Proof of purchase is required for
all warranty claims. SERVICE OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY.
Limitation of Liability
HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY,
REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT,
NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the liability
of Horizon exceed the individual price of the Product on which liability is asserted. As Horizon
has no control over use, setup, final assembly, modification or misuse, no liability shall be
assumed nor accepted for any resulting damage or injury. By the act of use, setup or assembly,
the user accepts all resulting liability. If you as the purchaser or user are not prepared to accept
the liability associated with the use of the Product, purchaser is advised to return the Product
immediately in new and unused condition to the place of purchase.
Law
These terms are governed by Illinois law (without regard to conflict of law principals). This
warranty gives you specific legal rights, and you may also have other rights which vary from state
to state. Horizon reserves the right to change or modify this warranty at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services
Your local hobby store and/or place of purchase cannot provide warranty support or service.
Once assembly, setup or use of the Product has been started, you must contact your local
distributor or Horizon directly. This will enable Horizon to better answer your questions and
service you in the event that you may need any assistance. For questions or assistance, please
visit our website at www.horizonhobby.com, submit a Product Support Inquiry, or call the toll
free telephone number referenced in the Warranty and Service Contact Information section to
speak with a Product Support representative.
Inspection or Services
If this Product needs to be inspected or serviced and is compliant in the country you live and use
the Product in, please use the Horizon Online Service Request submission process found on our
website or call Horizon to obtain a Return Merchandise Authorization (RMA) number. Pack the
Product securely using a shipping carton. Please note that original boxes may be included, but are
not designed to withstand the rigors of shipping without additional protection. Ship via a carrier
that provides tracking and insurance for lost or damaged parcels, as Horizon is not responsible for
merchandise until it arrives and is accepted at our facility. An Online Service Request is available
at http://www.horizonhobby.com/content/service-center_render-service-center. If you do not
have internet access, please contact Horizon Product Support to obtain a RMA number along
with instructions for submitting your product for service. When calling Horizon, you will be asked
to provide your complete name, street address, email address and phone number where you can
be reached during business hours. When sending product into Horizon, please include your RMA
number, a list of the included items, and a brief summary of the problem. A copy of your original
sales receipt must be included for warranty consideration. Be sure your name, address, and RMA
number are clearly written on the outside of the shipping carton.
NOTICE: Do not ship LiPo batteries to Horizon. If you have any issue with a LiPo battery,
please contact the appropriate Horizon Product Support office.
Warranty Requirements
For Warranty consideration, you must include your original sales receipt verifying the proof-of-
purchase date. Provided warranty conditions have been met, your Product will be serviced or
replaced free of charge. Service or replacement decisions are at the sole discretion of Horizon.
Non-Warranty Service
Should your service not be covered by warranty, service will be completed and payment will
be required without notification or estimate of the expense unless the expense exceeds 50%
of the retail purchase cost. By submitting the item for service you are agreeing to payment
of the service without notification. Service estimates are available upon request. You must
include this request with your item submitted for service. Non-warranty service estimates will
be billed a minimum of ½ hour of labor. In addition you will be billed for return freight. Horizon
accepts money orders and cashier’s checks, as well as Visa, MasterCard, American Express,
and Discover cards. By submitting any item to Horizon for service, you are agreeing to Horizon’s
Terms and Conditions found on our website http://www.horizonhobby.com/content/service-
center_render-service-center.
ATTENTION: Horizon service is limited to Product compliant in the country of use and
ownership. If received, a non-compliant Product will not be serviced. Further, the sender will
be responsible for arranging return shipment of the un-serviced Product, through a carrier of
the sender’s choice and at the sender’s expense. Horizon will hold non-compliant Product for a
period of 60 days from notification, after which it will be discarded.
