Dyson Micro 1.5kg User manual

User manual
SV12 JN.00000 PN.000000-00-00
00.00.00 VERSION NO.01
In the box
Getting started
Charging your machine
Caring for your floors
Emptying your bin
Cleaning your bin
Washing your filter
Washing your brush bar
Cleaning your tools
Clearing blockages
Looking after your machine

In the box
Vacuum cleaner
ChargerWand
Combi-crevice tool
Micro Fluffy™cleaner head
Charges your vacuum with
or without a dock.
Worktop tool
Engineered for cleaning kitchen
worktops, tables and hard surfaces.
Two tools in one – narrow nozzle and
brush, for quick switching between
cleaning and dusting tasks.
Light pipe crevice tool
Crevice tool with LED lights lets you
reach into dark, narrow spaces and
see where you’re cleaning.
Soft woven nylon and anti-static carbon
fibre filaments remove dust from hard
floors. Smaller than a standard Fluffy™
cleaner head - with a low profile to
reach under furniture.
Mini motorised tool
Motorised brush bar, concentrated
in a smaller head to remove
stubborn dirt from mattresses,
upholstery and stairs.
Wand clip
Some tools may not be included.
You can buy additional tools at www.dyson.com.
Clips to your vacuum's
wand to hold tools.

Power button
Press the Power button
once for comfortable,
continuous cleaning.
Getting started
Press the button to change
power modes.
Micro Fluffy™cleaner head
Power modes
Eco mode
Max mode
Soft woven nylon and anti-static carbon
fibre filaments remove dust from hard
floors. Smaller than a standard Fluffy™
cleaner head - with a low profile to
reach under furniture.
The optimum balance of
power and run time
Delivers maximum power.
For intensive cleaning of
ground-in dirt.

Charging your machine
For the best experience, we recommend fully charging your machine, and
any additional batteries, as soon as you open the box and after every clean.
The LED light on the end of the handle will flash when the power is running
low and you need to put your battery on to charge.
Connect the charger directly to the charging point on the base of the
handle of your machine. You can also connect to your dock as shown in the
installation instructions supplied with your dock.
The LED light on the end of the handle will pulse with a blue LED light when
charging, and the light will go out when fully charged.
It can take up to four hours to fully charge your battery. Your battery has
been designed to be left on charge.
Your machine won’t operate or charge if the ambient temperature is below
5°C (41°F). This is designed to protect both the motor and battery.
You can help prolong the battery life by leaving your machine to cool down
before recharging.
Caring for your floors
Check that the underside of the cleaner head or tool is clean and free from
any objects that may cause damage.
Before vacuuming your flooring, rugs, and carpets, check the manufacturer’s
recommended cleaning instructions.
This machine is designed for use on hard floors. The brush bar on your
machine can damage certain flooring. Some rug materials may fuzz if a
rotating brush bar is used when vacuuming. If this happens, we recommend
vacuuming without the motorised floor tool and consulting with your flooring
manufacturer.

Emptying your bin
Empty your bin as soon as the dirt reaches the MAX mark.
You may need to clean the filter more often if you use your machine with a full bin.
Cleaning your bin
Release the dirt
To remove the bin for emptying:
Minimise dust contact
Reassemble your machine
Remove your wand
Don’t put any part of your machine in a dishwasher or use detergents,
polishes or air fresheners.
Hold your vacuum over a bin.
Push the red bin release button, taking care not to press the power button.
The bottom of the bin will open and the shroud will slide down inside the bin,
wiping away any dirt.
If the bin doesn’t open, check the bin release button is pushed down fully.
If the bin doesn't empty fully, remove the bin and empty the dirt.
Press the red button located on the bin runner to release the bin and slide
your bin off the runner.
Cover your bin tightly in a dust proof bag while you empty. Remove the bin
carefully, seal the bag tightly and dispose.
If you have removed your bin, slide it back on to the runner. Make sure that
the bin and lid are both securely in position.
Push the bin base upwards until the bin and lid both click into place.
Reconnect the wand.
Press the red wand release button, on the top of the wand, and pull the wand
away from the bin.
2
1
1
clik
clik
2
2
1
1
clik
clik
2
2
1
1
clik
clik
2
2
1
2
1
1
clik
clik
2
2
1
1
clik
clik
2
2
1
1
clik
clik
2
2
1
1
clik
clik
2
2
1
1
clik
clik
2
2
1
1
clik
clik
2
2
1
1
clik
clik
2
Replace your bin
Clean your bin
If it is necessary to clean your bin, empty it as shown in the ‘Emptying your
bin’ section.
Press the red button located on the bin runner to release the bin and slide
your bin off the runner.
Only clean your bin with a damp cloth.
Make sure that the bin and seals are completely dry before replacing.
Insert the spine on to the bin runner.
Close your bin by pushing the bin base upwards until the bin and bin base
click into place.

Washing your filter
Wash your filter at least once a month to maintain the best performance.
Make sure the filter is completely dry before refitting.
Twist off your filter
Wash your filter
Shake and dry
Refit your filter
Don’t put any part of your machine in a dishwasher or use detergents,
polishes or air fresheners.
Turn your filter anti-clockwise and pull it away from your machine.
Before washing your filter, tap it gently over a bin to remove any loose dust
and debris.
Wash the outside of the filter, rubbing with your fingers to remove the dirt.
Carefully rinse the inside filter, without allowing water to fill the filter.
Repeat these steps until the water runs clear.
Empty the filter and shake firmly to remove excess water.
Keep shaking until there’s no water coming from the filter.
Place your filter end up, as shown.
Leave your filter to dry for at least 24 hours in a well-ventilated, warm place.
Don’t dry your filter in a tumble dryer, microwave or near a naked flame.
Important: your filter must be completely dry before you put it back into the
machine. Your machine could be damaged if used with a damp filter.
To refit your filter, slide it onto the handle and turn it clockwise until it clicks
into place.
Your filter may need more frequent washing if you vacuum fine dust,
use Max mode frequently or use with the bin full.

To maintain optimum performance, check and wash the brush bar regularly.
Washing your brush bar
Remove brush bar
Wash and dry brush bar
Replace your brush bars
Don’t put any part of your machine in a dishwasher or use detergents,
polishes or air fresheners.
Press the cleaner head release button to remove it from the wand.
Pull the brush bar off the end cap and put the end cap to one side, don’t
wash it.
Hold your brush bar under cold tap water and gently rub to remove any lint
or dirt. Keep washing until the water runs clear.
Stand the brush bar upright and leave for at least 24 hours to dry.
Make sure your brush bar is completely dry before refitting.
Reattach the end cap to the brush bar and slide it back into the cleaner head.
Rotate the end cap until it clips securely back into position.
The cleaner head housing is not washable and should only be wiped over
with a damp lint-free cloth.
2
3
1
2
1
2
3
1
2
1
2
3
1
2
1

Cleaning your tools
Don’t put any part of your machine in a dishwasher or use detergents,
polishes or air fresheners.
Wipe with a damp, lint-free cloth, without touching the connector end.
Make sure your tools are completely dry before using.
Combi-crevice tool Worktop tool Light pipe crevice tool Mini motorised tool

Clearing blockages
If your machine detects a blockage, the motor will pulse six times. You won’t
be able to use your machine until the blockage has been cleared.
If you try to use your machine when the motor is pulsing, it will automatically
cut out.
Leave your machine to cool down before looking for blockages and, for your
safety, take care not to touch the power button.
Disconnect your machine from the charger before looking for blockages.
Be careful not to touch the trigger and be aware of sharp objects.
Leave your machine to cool down before looking for blockages.
Don't use your machine when looking for blockages as this could cause injury.

Looking after your machine
To always get the best performance from your machine, it’s important to
clean it regularly and check for blockages.
Look after your machine
Look after your battery
Your serial numbers
You can register your machine using the serial number found on the bottom
of your machine.
If your machine is dusty, wipe with a damp lint-free cloth.
Check for blockages in the cleaner head, tools and main body of your machine.
Wash your filter regularly and leave to dry completely.
Don’t use detergents or polishes to clean your machine.
To get the best performance and life from your battery, use Eco mode.
Your machine won’t operate or charge if the ambient temperature is below
5°C(41°F). This is designed to protect both the motor and battery.
You can find your serial numbers on your machine, battery and charger.
Use your serial number to register.
