Eachine EX3 User manual

Farther.Faster.Clearer
Quick Start
EX3

Aircraft
*Please turn to User Manual for detailed information of flight environment requirements.
1. Brushless motor
2. Undercarriage
3. Propeller
4. Camera
5. Ultrasonic sensor
6. Lights
7. Vision positioning lens
8. Battery
9. Front light
10. Rear light
11. Power switch
①
③
④⑤⑦
⑧
⑥
⑨
②
10
11
1

Gimbal trimmer
Remote Controller
A
BA
B
Short-press to take photos; Long-press
to take videos.
Photo/Video
One-key RTH
One-key unlock
High/Low speed switch
(short-press); Light switch
(long-press)
Short-press to enter into RTH procedure;
Press again to exit RTH.
Short-press to unlock; Long-press to
lock.
Short-press to switch High/Low speed;
Long-press to turn on/off the LED lights.
1. Power switch
2. One-key RTH
3. Left stick
4. Right stick
5. Photo/Video
6. One-key unlock
7. Mobile phone holder
8. Antenna
9. Hand stick
10. LCD display
11. One-key takeoff/One-key
landing
12. High/Low speed switch
(short-press); Light switch
(long-press)
13. Gimbal trimmer
14. Gesture/GPS mode switch
One-key takeoff/One-key landing
Short-press to switch one-key takeoff or
one-key landing.
Gesture/GPS mode switch
OFF - Gesture Mode;
ON - GPS Mode.
⑥
⑧
⑨①
②
③
④
⑤
⑦
10
11 12 13
14
The camera can be rotated by 90 degrees.
90°
2

LCD screen display
The icon is on during the RTH procedure
and will be off once RTH procedure canceled.
Return to Home (RTH) Icon
Aircraft battery level
Distance against Home Point
GPS mode
Satellite amount
It indicates current aircraft battery level.
It indicates current aircraft flying distance
against recorded Home Point.
Once the GPS signal amount is over 7,
Home Point will be recorded at the location
where the aircraft takes off.
Remote controller throttle mode
It indicates current throttle mode.
Throttle mode is set at Mode 2 by
default.
Remote controller
battery level
GPS mode
Satellite
amount
Altitude against
Home Point
Photo/Video
Return to Home
(RTH) icon
Aircraft battery
level
Remote controller
throttle mode
Distance against
Home Point
Signal strength
High/Low speed
mode
It indicates the signal strength that the
remote controller receives from the aircraft.
Altitude against Home Point
It indicates aircraft current altitude
against Home Point.
High/Low speed mode
Signal strength
It indicates remote controller current
battery level.
Remote controller battery level
Flashing once to take photos; Keep
flashing to take videos.
Photo/Video
LOW - Low Speed;
HIGH - High Speed.
ON - GPS Mode;
OFF - Gesture Mode.
3

Download the software “X-DRONE” APP
Prepare your EX3
Preparation before Use
Flight Preparation
Install 2*AA batteries into the
remote controller.
Install the aircraft battery.
Unfold the rear arms. Unfold the front arms. Insert the TF Card
(TF Card is not included).
● For Apple IOS system, please turn to Apple store, search “X-DRONE” or scan the QR code to
download the software.
● For Android system, please scan the “Google play” QR code or search “X-DRONE” in “Google play”
to download the software.
AA
AA
4
ANDROID APP ON
Available on the
App Store

Unlock the aircraft
Flight
Short-press the unlock button.
Signal connection
Keep pressing the unlock button and turn
on the remote controller.
Power on the aircraft by pressing the
switch on the aircraft for 3 seconds.
Compass calibration
Connect your mobile device with EX3
Step 1. Rotate the EX3 360 degrees for
3 circles horizontally.
Step 2. Rotate the EX3 360 degrees for
3 circles vertically.
Tap “X-DRONE” AppConnect WIFI
Setting
Wi-Fi
drone****
5

Control the aircraft
Throttle mode is set at Mode 2 by default. Left stick determines the aircraft’s altitude and orientation;
Right stick control the function of each stick movement.
Mode 1 is opposite to Mode 2. That’s to say, in Mode 1, right stick determines the aircraft’s altitude
and orientation, left stick control the function of each stick movement.
Left stick Right stick
Left stick Right stick
A
s
c
e
n
t
D
e
s
c
e
n
t
A
s
c
e
n
t
D
e
s
c
e
n
t
R
i
g
h
t
w
a
r
d
f
l
i
g
h
t
L
e
f
t
w
a
r
d
f
l
i
g
h
t
T
u
r
n
r
i
g
h
t
T
u
r
n
l
e
f
t
R
i
g
h
t
w
a
r
d
f
l
i
g
h
t
L
e
f
t
w
a
r
d
f
l
i
g
h
t
T
u
r
n
r
i
g
h
t
T
u
r
n
l
e
f
t
F
o
r
w
a
r
d
B
a
c
k
w
a
r
d
F
o
r
w
a
r
d
B
a
c
k
w
a
r
d
Change the throttle mode
Keep pressing the unlock button and turn
on the remote controller.
Keep pressing the RTH button for 3
seconds to change the throttle mode.
6

X-DRONE
Charge the Aircraft Battery
Turn off the remote controller and aircraft
Long-press the unlock button and turn off
the remote controller.
Power off your aircraft by pressing
the switch for 3 seconds.
USB
●The aircraft needs to be full charged before every flight;
● Please use Eachine charging device for this aircraft;
● Full Charging time takes about 270 minutes.
