Eaton xEffect User manual

Chapter 2.1.1. – 1
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Symbol Description
Eaton standard. Suitable for outdoor installation (distribution boxes for outdoor installation and
building sites) up to -25° C.
Conditionally surge-current proof (>250 A, 8/20 µs) for general application.
RCD sensitive to pulsating DC for application where residual pulsating DC may occur. Non-selec-
tive, instantaneous. Protects only against special forms of residual pulsating DC which have not
been smoothed.
Type B: All-current sensitive RCD switchgear for applications where DC fault currents may occur.
Non-selective, non-delayed. Protection against all kinds of fault currents.
Type B+: All-current sensitive RCD switchgear for applications where DC fault currents may occur.
Non-selective, non-delayed. Protection against all kinds of fault currents. Also meets the require-
ments of the VDE 0664-400 standard (formerly known as VDE V 0664-110) and therefore provides
enhanced fire safety.
RCD of type G (min 10 ms time delay) surge current-proof up to 3 kA. For system components
where protection against unwanted tripping is compulsory to avoid personal injury and damage to
property (§ 12.1.6 of ÖVE/ÖNORM E 8001-1). Also for systems involving long lines and high line
capacity. Some versions are sensitive to pulsating DC. Some versions are available in all-current
sensitive design.
RCD of type S (selective, min 40 ms time delay) surge current-proof up to 5 kA. Mainly used as
main switch according to ÖVE/ÖNORM E 8001-1 § 12.1.5, as well as in combination with surge
arresters.This is the only RCD suitable for series connection with other types if the rated tripping
current of the downstream RCD does not exceed one third of the rated tripping current of the
device of type S. Some versions are sensitive to pulsating DC. Some versions are available in all-
current sensitive design.
"X-ray-proof", for avoiding unwanted tripping caused by x-ray devices.
"Frequency converter-proof", for avoiding unwanted tripping caused by frequency converters,
speed-controlled drives, etc.
Residual Current Devices - General Data
Short description of the most important RCD types:
"umrichterfest"
S
G
ÖVE E 8601
“röntgenfest”

Chapter 2.1.1. – 2
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Tripping Characteristics (IEC/EN 61008)
§ 6.1.1 of ÖVE/ÖNORM E 8001-1/A1 deals with additional pro-
tection and provides essentially the following:
In circuits with sockets up to 16 A with fault current/residual current
protection by protective earthing, protective multiple earthing or
residual current devices (RCDs), additional residual current protection
devices with a rated tripping current of 0.03 A must be installed.
This means when using RCDs for fault current/residual current
protection two RCDs must be connected in series.
Testing:
RCDs with tripping time delay (Types -G and -S) may be function test-
ed with conventional testing equipment which must be set according
to the instructions for operation of the testing device. Due to reasons
inherent in the measuring process, the tripping time determined in
this way may be longer than expected in accordance with the specifi-
cations of the manufacturer of the measuring instrument.
However, the device is ok if the result of measurement is within the
time range specified by the manufacturer of the measuring instru-
ment.
Tripping characteristics, tripping time range and selectivity of instantaneous,
surge current-proof "G" and surge current-proof - selective "S" residual cur-
rent devices.
Tripping time t
Tripping time range type S
Residual tripping current
surge current.-
proof - selective
surge current-
proof
conditionally
surge current-
proof
Tripping time range type G
Tripping time range limit values
Tripping time range non-delayed
Area of unwanted tripping

Chapter 2.1.1. – 3
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Hints for the application of our frequency converter-proof RCDs:
Frequency converters are used in a wide variety of systems and equip-
ment requiring variable speed, such as lifts, escalators, conveyor
belts, and large washing machines. Using them for such purposes in
circuits with conventional residual current devices causes frequent
problems with unwanted tripping.
The technical root cause of this phenomenon is the following: Fast
switching operations involving high voltages cause high interference
levels which propagate through the lines on the one hand, and in the
form of interfering radiation on the other. In order to eliminate this
problem, a mains-side filter (also referred to as input filter or EMC-fil-
ter) is connected between the RCD and frequency converter. The anti-
interference capacitors in the filters produce discharge currents
against earth which may cause unwanted tripping of the RCD due to
the apparent residual currents. Connecting a filter on the output side
between frequency converter and 3-phase AC motor results in the
same behaviour.
Due to the currents flowing off through the filters (designated IF), the sum of
currents through the RCD is not exactly zero, which causes unwanted tripping.
This sample tripping characteristic of a 100 mA RCD and a 300 mA
RCD shows the following: In the frequency range around 50 Hz, the
RCDs trip as required (50 - 100 % of the indicated IΔn).
In the range shown hatched in the diagram, i. e. from approx. 100 to
300 Hz, unwanted tripping occurs frequently due to the use of fre-
quency converters. Frequency converter-proof residual current
devices are much less sensitive in this frequency range than in the 50
- 60 Hz range, which leads to an enormous increase in the reliability of
systems.
Therefore, we recommend to use frequency converter-proof RCDs!
These special residual current devices can be recognised by an extension
of the type designation ("-U").They meet the requirements of compatibil-
ity between RCDs and frequency converters with respect to unwanted
tripping.
These are NOT AC/DC-sensitive RCDs of type B !!!
Our RCDs of type "-U" are characterised by SENSITIVITY TO RESIDUAL
PULSATING DC and SELECTIVITY or SHORT-TIME DELAY .
GS
Tripping characteristic
Protective Measures
In Austria, the ÖVE Decision EN 219 is applicable.
Under this standard
• frequency converters must be equipped with current limiting
devices in order to ensure disconnection in cause of faults or over-
load, and
• the installer of a system is obliged to make sure that additional
equipotential bonding is provided (additional inclusion of all metal
components, such as frequency converters, mains filters, motor fil-
ters, etc. into the existing equipotential bonding), in order to ensure
that the permissible touch voltage of 50 V AC or 120 V DC is not
exceeded. (In ÖVE/ÖNORM E 8001-1 the term "touch voltage" has
been omitted.There is only a fault voltage limit of 65 V AC or 120 V
DC which must not be exceeded).
In Germany, VDE 0100 is applicable, in Switzerland SEV 1000.
In case of application in any other country than those mentioned
take into account national rules and recommendations.
The following rules for the application of RCDs of type" -U" are only applicable in those cases where an RCD of type "-B" is not explicitly demanded in the
instructions of the manufacturer of the frequency converter.
How can you make sure that the required protective measures are in place when using RCDs type “-U” and frequency converters in one system?
Mains
RCD
RCD
Mains-side filter
Mains-side filter
Frequency converter
Frequency converter
Screened motor line
Mains side filter
Motor
Motor
Frequency converter
interference range
(approx. 100 - 300 Hz)

Residual Current Devices
• Line voltage independent RCCB for fault or additional protection with addi-
tional digital features.
• System Monitoring: Preventive information / warning before the RCD trips
in case of leakage currents
– Integrated auxiliary contact
– Local Indication
• New level of accuracy -> reduced unwanted tripping
• No monthly test required
• Comprehensive range of accessories
• Real contact position indicator
• Fault current tripping indicator
• Automatic re-setting possible
• Transparent designation plate
Chapter 2.2.1. – 1
EATON CORPORATION xxxxx+xxxx-xxxxEN
SG49712
Residual Current Devices FRCdM Digital

Chapter 2.2.1. – 2
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Residual Current Devices FRCdM type G/A
Surge current-proof 3 kA, sensitive to residual pulsating DC, type G/A (ÖVE E 8601)
4-pole
25/0.03 FRCdM-25/4/003-G/A 168646 1/30
25/0.3 FRCdM-25/4/03-G/A 168647 1/30
40/0.03 FRCdM-40/4/003-G/A 168648 1/30
40/0.3 FRCdM-40/4/03-G/A 168649 1/30
63/0.03 FRCdM-63/4/003-G/A 168650 1/30
63/0.3 FRCdM-63/4/03-G/A 168651 1/30
80/0.03 FRCdM-80/4/003-G/A 168634 1/30
80/0.3 FRCdM-80/4/03-G/A 168635 1/30
SG49712
In/IΔnType Article No. Units
(A) Designation per
package
Residual Current Devices FRCdM type R
Surge current-proof 3 kA, X-ray application, type R
4-pole
63/0.03 FRCdM-63/4/003-R 168636 1/30
SG49712
In/IΔnType Article No. Units
(A) Designation per
package
Residual Current Devices FRCdM type S/A
Selective + surge current-proof typ. 5 kA, sensitive to residual pulsating DC, type S/A
4-pole
40/0.3 FRCdM-40/4/03-S/A 168637 1/30
63/0.3 FRCdM-63/4/03-S/A 168638 1/30
80/0.3 FRCdM-80/4/03-S/A 168639 1/30
SG49712
In/IΔnType Article No. Units
(A) Designation per
package
Residual Current Devices FRCdM type U
Selective + surge current-proof typ. 5 kA, frequency converter-proof, type U
4-pole
40/0.03 *) FRCdM-40/4/003-U 168643 1/30
40/0.3 FRCdM-40/4/03-U 168644 1/30
63/0.03 *) FRCdM-63/4/003-U 168640 1/30
63/0.3 FRCdM-63/4/03-U 168641 1/30
80/0.3 FRCdM-80/4/03-U 168642 1/30
*) Short time delayed + surge current-proof 3 kA
SG49712
In/IΔnType Article No. Units
(A) Designation per
package

Chapter 2.2.1. – 3
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Specifications | Residual Current Devices FRCdM
Description
Accessories:
Auxiliary switch for subsequent installation to the left Z-HK 248432
Tripping signal contact for subsequent installation to the right Z-NHK 248434
Automatic restarting device Z-FW/LP 248296
Z-FW-LPD 265244
Remote control Z-FW-MO 284730
Pre-mounted sets Z-FW-LP/MO 290171
Z-FW-LPD/MO 290172
Remote testing module Z-FW/003 248298
Z-FW/010 248299
Z-FW/030 248300
Sealing cover set Z-RC/AK-4TE 101062
Switching interlock IS/SPE-1TE 101911
• Residual current devices
• Shape compatible with and suitable for standard busbar connec-
tion to other devices of the xEffect-series
• Twin-purpose terminal (lift/open-mouthed) above and below
• Busbar positioning optionally above or below
• Free terminal space despite installed busbar
• Universal tripping signal switch, also suitable for FAZ, FRBmM-1N
can be mounted subsequently
• Auxiliary switch Z-HK can be mounted subsequently
• Contact position indicator red - green
• Tripping indicator white - blue
• Additional Safety
- possibility to seal
- possibility to lock in ON and OFF position
• Delayed types suitable for being used with standard fluorescent
tubes with or without electronical ballast (30mA-RCD: 30 units per
phase conductor, 100mA-RCD: 90 units per phase conductor).
Notes: Depending of the fluorescent lamp ballast manufacturer
partly more possible. Symmetrical allocation of the fluorescent
lamp ballasts on all phases favourably. Shifting references of the
fluorescent lamp ballast manufacturer consider.
• The device functions irrespective of the position of installation
• Tripping is line voltage-independent. Consequently, the RCD is suit-
able for “fault current/residual current protection” and “additional
protection” within the meaning of the applicable installation rules.
• Mains connection at either side
• The 4-pole device can also be used for 3-pole connection:
See connection possibilities.
• The 4-pole device can also be used for 2-pole connection:
See connection possibilities.
• The test key “T” must be pressed every year.The system operator
must be informed of this obligation and his responsibility in a way
that can be proven.The yearly test interval is only valid for residen-
tial and similar applications. Under all other conditions (e.g. damp-
ly or dusty environment), it's recommended to test in shorter inter-
vals (e.g. monthly). A test is further needed if red and yellow LED
are on together.
• Pressing the test key “T” serves the only purpose of function test-
ing the residual current device (RCD).This test does not make
earthing resistance measurement (RE), or proper checking of the
earth conductor condition redundant, which must be performed
separately.
• Functioning
-The green LED becomes active at 0-30% IΔn
-The yellow LED becomes active at 30-50% IΔn
-The red LED becomes active at >50% IΔn
• Potential-free relay (NO contact, in parallel with the yellow LED, up
to 1 A ohmic load / 230 V~) for external prewarning function.
Bistabile, means the warning stays on also when the breaker trips,
until reset.
• Type -A: Protects against special forms of residual pulsating DC
which have have not been smoothed.
• Type -G: High reliability against unwanted tripping. Compulsory
for any circuit where personal injury or damage to property may
occur in case of unwanted tripping (ÖVE/ÖNORM E 8001-1 § 12.1.6).
• Type -G/A: Additionally protects against special forms of residual
pulsating DC which have not been smoothed.
• Type -R:To aviod unwanted tripping due to X-ray devices.
• Type -S: Selective residual current device sensitive to AC, type -S.
Compulsory for systems with surge arresters downstream of the
RCD (ÖVE/ÖNORM E 8001-1 § 12.1.5).
• Type -S/A: Additionally protects against special forms of residual
pulsating pulsating DC which have not been smoothed.
• Type -U: Suitable for speed-controlled drives with frequency con-
verters in household, trade, and industry.
Unwanted tripping is avoided thanks to a tripping characteristic
designed particularly for frequency converters.
See also explanation “Frequency Converter-Proof RCDs - What for?”.
Application according to ÖVE/ÖNORM E 8001-1 and Decision
EN 219 (1989), VDE 0100, SEV 1000.

Chapter 2.2.1. – 4
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Connection diagram
4-pole
Technical Data
FRCdM
Electrical
Design according to IEC/EN 61008
Type G and G/A acc. to ÖVE E 8601
Current test marks as printed onto the device
Tripping instantaneous
Type G , R 10 ms delay
Type S 40 ms delay - with selective disconnecting function
Type U (only 30 mA) 10 ms delay
Type U (except 30 mA) 40 ms delay - with selective disconnecting function
Rated voltage Un240/415 V AC, 50Hz
Operation voltage electronic 50 – 264V AC
Operation voltage test circuit 196 – 264V AC
Rated tripping current IΔn30, 300 mA
Sensitivity AC and pulsating DC
Rated insulation voltage Ui440 V
Rated impulse withstand voltage Uimp 4 kV (1.2/50µs)
Rated short circuit capacity Icn 10 kA
Peak withstand current
Type G, G/A, R, U (30mA) 3 kA (8/20 µs) surge current proof
Type S/A, U (except 30mA) typ. 5 kA (8/20 µs) selective + surge current proof
Electrical isolation > 4 mm contact space
Maximum back-up fuse Short circuit and overload protection
In= 16-63A 63 A gG/gL
In= 80A 80 A gG/gL
In= 100A 100 A gG/gL
Endurance
electrical components ≥4,000 operating cycles
mechanical components ≥20,000 operating cycles
Mechanical
Frame size 45 mm
Device height 80 mm
Device width 70 mm (4MU)
Mounting quick fastening with 2 lock-in positions on DIN rail IEC/EN 60715
Degree of protection, built-in IP40
Degree of protection in moisture-proof enclosure IP54
Upper and lower terminals open mouthed/lift terminals
Terminal protection finger and hand touch safe, BGV A3, ÖVE-EN 6
Terminal capacity 1.5 - 35 mm2single wire
2 x 16 mm2multi wire
Terminal screw M5 (Pozidriv PZ2)
Terminal capacity warning contact(s) 0.25-1.5 mm2(plug in terminals)
Terminal torque 2 - 2.4 Nm
Busbar thickness 0.8 - 2 mm
Tripping temperature -25°C to +40°C
Storage- and transport temperature -35°C to +60°C
Resistance to climatic conditions 25-55°C/90-95% relative humidity acc. to IEC 60068-2
Contact position indicator red / green
Tripping indicator white / blue

Dimensions (mm)
Chapter 2.2.1. – 5
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Local Indication RCCB
Status indication LED red / yellow / green
Permanent light green Normal operation
Permanent light yellow The measured residual current is bigger than 30% of the nominal trip-
ping value.
Permanent light red The measured residual current is bigger than 50% of the nominal trip-
ping value.
Flashing yellow/red Check the device with test key. If the LEDs are still flashing check the
direction of connection (supply side / load side).
Remote Indication
Potential-free auxiliary switch for use in control circuits, insulated from main circuit of the switch gear according to IEC/EN60664.
0.25A ohmic load / 240V AC, terminal capacity: 0.25 - 1.5 mm2.
Correct connection
3+N
(240/415V)
3-phase load without N
(240V AC AC Phase-Phase)
1+N (240V)
3-phase load without N
(415V AC Phase-Phase)
Electronic works within 50-264V AC !
- Disconnect load side of the switch gear, if you make a insulation test of the installation!

Chapter 2.2.1. – 6
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
• Line-voltage independent, all-current sensitive RCCB for fault or additional
protection with additional digital features
• System Monitoring: Preventive information / warning before the RCD trips
in case of leakage currents
– Integrated auxiliary contact
– Local Indication through 3 LEDs
• B+ types also meet the requirements of superior fire-protection systems
according to VDE 0664-400 (formerly known as VDE V 0664-110)
• 4-pole types can also be used as 2-pole devices for photovoltaic applica-
tions
• New level of accuracy -> reduced unwanted tripping
• No monthly test required
• Comprehensive range of accessories
• Real contact position indicator
• Fault current tripping indicator
• Automatic re-setting possible
• Transparent designation plate
SG49812
Residual Current Devices FRCdM Type B, B+ and Bfq Digital

Chapter 2.2.1. – 7
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Residual Current Devices FRCdM type G/B
Surge current-proof 3 kA, AC-DC sensitive, type G/B (ÖVE E 8601)
4-pole
25/0.03 FRCdM-25/4/003-G/B 167892 1/30
25/0.3 FRCdM-25/4/03-G/B 167896 1/30
40/0.03 FRCdM-40/4/003-G/B 167893 1/30
40/0.3 FRCdM-40/4/03-G/B 167897 1/30
63/0.03 FRCdM-63/4/003-G/B 167894 1/30
63/0.3 FRCdM-63/4/03-G/B 167898 1/30
SG49812
In/IΔnType Article No. Units
(A) Designation per
package
Residual Current Devices FRCdMTyp S/B
Selective + surge current-proof 5 kA, type S/B
4-pole
25/0.3 FRCdM-25/4/03-S/B 167900 1/30
40/0.3 FRCdM-40/4/03-S/B 167901 1/30
63/0.3 FRCdM-63/4/03-S/B 167902 1/30
SG49812
In/IΔnType Article No. Units
(A) Designation per
package
Residual Current Devices FRCdMTyp G/B+
Surge current-proof 3 kA, type G/B+ (ÖVE E 8601)
4-pole
25/0.03 FRCdM-25/4/003-G/B+ 167880 1/30
25/0.3 FRCdM-25/4/03-G/B+ 167884 1/30
40/0.03 FRCdM-40/4/003-G/B+ 167881 1/30
40/0.3 FRCdM-40/4/03-G/B+ 167885 1/30
63/0.03 FRCdM-63/4/003-G/B+ 167882 1/30
63/0.3 FRCdM-63/4/03-G/B+ 167886 1/30
SG49812
In/IΔnType Article No. Units
(A) Designation per
package
Residual Current Devices FRCdMTyp S/B+
Selective + surge current-proof 5 kA, type S/B+
4-pole
25/0.3 FRCdM-25/4/03-S/B+ 167888 1/30
40/0.3 FRCdM-40/4/03-S/B+ 167889 1/30
63/0.3 FRCdM-63/4/03-S/B+ 167890 1/30
SG49812
In/IΔnType Article No. Units
(A) Designation per
package

Chapter 2.2.1. – 8
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Residual Current Devices FRCdMTyp G/Bfq
Surge current-proof 3 kA, AC-DC sensitive, type G/Bfq (ÖVE E 8601)
4-pole
25/0.3 FRCdM-25/4/03-G/Bfq 167904 1/30
40/0.3 FRCdM-40/4/03-G/Bfq 167905 1/30
63/0.3 FRCdM-63/4/03-G/Bfq 167906 1/30
SG49812
In/IΔnType Article No. Units
(A) Designation per
package
Residual Current Devices FRCdMTyp S/Bfq
Selective + surge current-proof 5 kA, type S/Bfq
4-pole
25/0.3 FRCdM-25/4/03-S/Bfq 167908 1/30
40/0.3 FRCdM-40/4/03-S/Bfq 167909 1/30
63/0.3 FRCdM-63/4/03-S/Bfq 167910 1/30
SG49812
In/IΔnType Article No. Units
(A) Designation per
package

Chapter 2.2.1. – 9
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Specifications | Residual Current Devices FRCdM - digital, Type B and B+
Description
• Residual current devices, all-current sensitive
• Shape compatible with and suitable for standard busbar connec-
tion to other devices of the xEffect-series
• Twin-purpose terminal (lift/open-mouthed) above and below
• Busbar positioning optionally above or below
• Free terminal space despite installed busbar
• Universal tripping signal switch, also suitable for FAZ, FRBmM-1N
can be mounted subsequently
• Auxiliary switch Z-HK can be mounted subsequently
• Contact position indicator red - green
• Tripping indicator white - blue
• Additional Safety
- possibility to seal
- possibility to lock in ON and OFF position
• Delayed types (G, S) suitable for being used with standard fluores-
cent tubes with or without electronical ballast (30mA-RCD: 30 units
per phase conductor, 100mA-RCD: 90 units per phase conductor).
Notes: Depending of the fluorescent lamp ballast manufacturer
partly more possible. Symmetrical allocation of the fluorescent
lamp ballasts on all phases favourably. Shifting references of the
fluorescent lamp ballast manufacturer consider.
• The device functions irrespective of the position of installation
• Tripping is line voltage-independent. Consequently, the RCD is suit-
able for “fault current/residual current protection” and “additional
protection” within the meaning of the applicable installation rules.
• The 4-pole device can also be used for 3-pole connection:
See connection possibilities.
• The 4-pole device can also be used for 2-pole connection:
See connection possibilities.
• The test key “T” must be pressed every year.The system operator
must be informed of this obligation and his responsibility in a way
that can be proven.The yearly test interval is only valid for residen-
tial and similar applications. Under all other conditions (e.g. damp-
ly or dusty environment), it's recommended to test in shorter inter-
vals (e.g. monthly). A test is further needed if red and yellow LED
are flashing alternately.
• Pressing the test key “T” serves the only purpose of function test-
ing the residual current device (RCD).This test does not make
earthing resistance measurement (RE), or proper checking of the
earth conductor condition redundant, which must be performed
separately.
• Functioning
-The green LED becomes active at 0-30% IΔn
-The yellow LED becomes active at 30-50% IΔn
-The red LED becomes active at >50% IΔn
• Potential-free auxiliary switch for use in control circuits, insulated
from main circuit of the switch gear according to IEC/EN60664
(0.25A ohmic load / 240V AC) in parallel with the yellow LED, for
external prewarning function. Bistabile, means the warning stays
on also when the breaker trips, until reset.
• Type -G/B and G/B+: High reliability against unwanted tripping.
Compulsory for any circuit where personal injury or damage to
property may occur in case of unwanted tripping (ÖVE/ÖNORM
E 8001-1 § 12.1.6).
Protection against all types of fault currents.
• Type -S/B and S/B+: Selective residual current device.
Protection against all types of fault currents.
• Type -S/Bfq: Suitable for speed-controlled drives with frequency
converters inhousehold, trade, and industry.Unwanted tripping is
avoided thanks to a tripping characteristic designedparticularly for
frequency converters.
Protection against all types of fault currents.
Accessories:
Auxiliary switch for subsequent installation to the left Z-HK 248432
Tripping signal contact for subsequent installation to the right Z-NHK 248434
Automatic restarting device Z-FW/LP 248296
Z-FW-LPD 265244
Remote control Z-FW-MO 284730
Pre-mounted sets Z-FW-LP/MO 290171
Z-FW-LPD/MO 290172
Remote testing module Z-FW/001 248297
Z-FW/003 248298
Z-FW/010 248299
Z-FW/030 248300
Z-FW/050 248301
Sealing cover set Z-RC/AK-4TE 101062
Switching interlock IS/SPE-1TE 101911

Chapter 2.2.1. – 10
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Connection diagram
4-pole
Last
Load
Netz
Mains
Technical Data
FRCdM Type B and B+
Electrical
Design according to Types B and Bfq acc. to IEC/EN 61008, IEC/EN 62423
B+Type acc. to VDE 0664-400, formerly known as VDE V 0664-110
Type G/B and G/B+ additional acc. to ÖVE E 8601
Current test marks as printed onto the device
Tripping
Type G 10 ms delay
Type S 40 ms delay - with selective disconnecting function
Rated voltage Un240/415 V AC, 50 Hz
Operation voltage electronic 50 – 254V AC
Voltage range test circuit 184 - 440V AV (300mA) / 184 - 264V AV (30mA)
Rated tripping current IΔn30, 300 mA
Sensitivity Alternating, pulsed and direct currents
Rated insulation voltage Ui440 V
Rated impulse withstand voltage Uimp 4 kV (1.2/50µs)
Rated short circuit capacity Icn 10 kA
Peak withstand current
Type G/B, G/B+ and G/Bfq 3 kA (8/20 µs) surge current proof
Type S/B, S/B+ and S/Bfq typ. 5 kA (8/20 µs) selective + surge current proof
Electrical isolation > 4 mm contact space
Maximum back-up fuse Short circuit and overload protection
In= 16-63A 63 A gG/gL
In= 80A 80 A gG/gL
Endurance
electrical components ≥4,000 operating cycles
mechanical components ≥20,000 operating cycles
Mechanical
Frame size 45 mm
Device height 80 mm
Device width 70 mm (4MU)
Mounting quick fastening with 2 lock-in positions on DIN rail IEC/EN 60715
Degree of protection, built-in IP40
Degree of protection in moisture-proof enclosure IP54
Upper and lower terminals open mouthed/lift terminals
Terminal protection finger and hand touch safe, BGV A3, ÖVE-EN 6
Terminal capacity 1.5 - 35 mm2single wire
2 x 16 mm2multi wire
Terminal screw M5 (Pozidriv PZ2)
Terminal capacity warning contact 0.25-1.5 mm2(plug in terminals)
Terminal torque 2 - 2.4 Nm
Busbar thickness 0.8 - 2 mm
Tripping temperature -25°C to +40°C
Storage- and transport temperature -35°C to +60°C
Resistance to climatic conditions 25-55°C/90-95% relative humidity acc. to IEC 60068-2
Contact position indicator red / green
Tripping indicator white / blue

Chapter 2.2.1. – 11
EATON CORPORATION xxxxx+xxxx-xxxxEN
Residual Current Devices
Dimensions (mm)
Local Indication RCCB
Status indication LED red / yellow / green
Permanent light green Normal operation
Permanent light yellow The measured residual current is bigger than 30% of the nominal trip-
ping value.
Permanent light red The measured residual current is bigger than 50% of the nominal trip-
ping value.
Flashing yellow/red Check the device with test key. If the LEDs are still flashing check the
direction of connection (supply side / load side).
Remote Indication
Potential-free auxiliary switch for use in control circuits, insulated from main circuit of the switch gear according to IEC/EN60664.
0.25A ohmic load / 240V AC, terminal capacity: 0.25 - 1.5 mm2.
Correct connection
2-pole
(240V)
Netzseite
Lastseite
3+N
(240/415V)
Netzseite
Lastseite
3-phase application
(30mA 184-264V)
(300mA 184-415V)
Netzseite
Lastseite
Test button works within 184-264V (30mA) bzw. 184-440V (300mA)!
- Disconnect load side of the switch gear, if you make a insulation test of the installation!
- Please take care of supply side and load side!
Load side
Supply
side
Load side
Supply side
Load side
Supply
side
4-pole
(240/415V)
Load side
Supply side
