Echo LC-56V1A User manual

X7508310900
© 5/23 ECHO Incorporated
Operator’s
Manual
LC-56V1A
CHARGER
Read and understand all provided literature before use. Failure
to do so could result in serious injury.
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
Note: This product complies with CAN ICES-003(B) / NMB-003(B)
Intertek
EP5026361
ENERGY
PERFORMANCE
VERIFIED
RENDIMIENTO
ENERGÉTICO
VERIFICADO
RENDEMENT
ÉNERGÉTIQUE
VÉRIFIÉ

TABLE OF CONTENTS LC-56V1A
2 X7508310900
© 5/23 ECHO Incorporated
TABLE OF CONTENTS
Table of Contents ........................................................................................ 2
Introduction ................................................................................................. 3
Servicing Information .................................................................................. 3
Parts and Serial Number...................................................................... 3
Service................................................................................................. 4
ECHO Consumer Product Support ...................................................... 4
Product Registration ............................................................................ 4
Additional Literature............................................................................. 4
Safety.......................................................................................................... 5
For safe use of your product................................................................ 5
Important Safety Warnings ................................................................. 6
Description .................................................................................................. 8
Operation .................................................................................................. 10
Charging ............................................................................................ 10
Examine the Charger......................................................................... 12
Maintenance ............................................................................................. 12
Maintenance and Care ...................................................................... 12
Troubleshooting ........................................................................................ 13
Storage ..................................................................................................... 13
Storage After Use .............................................................................. 13
Specifications............................................................................................ 13
Warranty.................................................................................................... 14
Product Registration.................................................................................. 15

LC-56V1A INTRODUCTION
X7508310900 3
© 5/23 ECHO Incorporated
INTRODUCTION
Specifications, descriptions, and illustrative material in this literature are as
accurate as possible. Specifications are subject to change without notice.
Illustrations might include optional equipment and accessories, and might
not include all standard equipment. Your equipment might appear slightly
different than pictured equipment.
Read and understand all provided literature.
Literature contains specifications and
information for safety, operation,
maintenance, storage, and assembly
specific to this product. Scan QR codes for
more information.
For additional literature, including safety manuals where applicable, or
questions regarding terms used in this manual, visit:
https://www.echo-usa.com/manuals
OR
https://www.shindaiwa-usa.com/manuals
SERVICING INFORMATION
Parts and Serial Number
Genuine ECHO parts and
assemblies for your ECHO
products are available only from an
Authorized ECHO Dealer. When
you do need to buy parts, always
have the model number and serial
number of the unit with you. For
future reference write them in the
space provided below.
Model No. _____________________ Serial No. ____________________

SERVICING INFORMATION LC-56V1A
4 X7508310900
© 5/23 ECHO Incorporated
Service
Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the
Authorized ECHO Service Dealer nearest you, ask your retailer or call:
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.
ECHO Consumer Product Support
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer
Product Support Department at 1-800-432-ECHO (3246) from 8:00 a.m. to
5:00 p.m. (Central Standard Time) Monday through Friday. Before calling,
please know the model and serial number of your unit.
Product Registration
Register your ECHO equipment online at www.echo-usa.com or by filling
out the product registration sheet included in this manual. Registering your
product confirms warranty coverage and provides a direct link to ECHO if
we find it necessary to contact you.
Additional Literature
In addition to finding information online, information is available from your
Authorized ECHO Service Dealer, or by contacting ECHO Incorporated,
400 Oakwood Road, Lake Zurich, IL 60047, 1-800-432-ECHO (3246).

LC-56V1A SAFETY
X7508310900 5
© 5/23 ECHO Incorporated
SAFETY
For safe use of your product
Be careful to read this section before using your product.
• The precautions described in this section contain important safety
information. Please observe them carefully.
• You must also read the precautions that appear in the body of the manual
itself.
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which might lead to minor
or moderate personal injury if not avoided.
The enclosed message provides information necessary for the
protection of the unit.
Note: This enclosed message provides tips for use, care and
maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.

SAFETY LC-56V1A
6 X7508310900
© 5/23 ECHO Incorporated
Important Safety Warnings
1. SAVE THESE INSTRUCTIONS - DANGER: TO REDUCE RISK OF
FIRE OR ELECTRICAL SHOCK CAREFULLY OBEY THESE
INSTRUCTIONS.
2. Confirm available voltage before using charger. Connect the charger
only to 120V AC and 60Hz outlets.
• If the above power requirements are not available, a voltage converter
must be used. Refer to your local country requirements before
purchasing a voltage converter.
• Any damage caused by charging with other than 120V AC and 60Hz
will void the warranty.
• Even when using the correct specified power requirements noted
above, this charger is equipped with an A-type plug. If a different type
plug is required for connection to an electrical outlet, it is the owner’s
responsibility to select the appropriate plug adapter, otherwise the
warranty may be voided.
3. Do not operate charger in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
4. Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of
electric shock.
5. Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
6. Do not connect the charger to a portable generator. Portable
generators can have spikes in voltage which can result in fire or
explosion of the charger and/or the battery.
7. DO NOT probe the charger with conductive materials.
8. DO NOT allow liquid inside the charger.
9. DO NOT try to use the charger for any other purpose than what is
presented in this manual.
10. Unplug the charger before cleaning and when there is no battery in the
charger.
11. Do not try to connect two chargers together.
12. Do not use the charger in the circumstances that the output polarity
does not match the load polarity.

LC-56V1A SAFETY
X7508310900 7
© 5/23 ECHO Incorporated
13. For indoor use only.
14. Keep away from children.
15. The cover may under no circumstances be opened. If the cover is
damaged, then the charger may no longer be used.
16. Do not recharge non-rechargeable batteries.
17. Before using battery charger, read all instructions and cautionary
markings on battery charger, battery, and product using battery.
18. CAUTION – To reduce risk of injury, charge only with ECHO
eFORCE™ 56V battery series. Other types of batteries may burst
causing personal injury and damage.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instructions, may cause
harmful interference to radio or television reception. The reception
can be determined by turning the equipment off and on. The user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.

DESCRIPTION LC-56V1A
8 X7508310900
© 5/23 ECHO Incorporated
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible
and that you understand and follow the instructions on it. If a decal cannot
be read, a new one can be ordered from your ECHO dealer. Safety label is
for example only. Your label my appear slightly different.
1
1
2
2
34
4
5

LC-56V1A DESCRIPTION
X7508310900 9
© 5/23 ECHO Incorporated
CHARGER TERMS
• BATTERY TERMINAL GROOVES - Electrical connection between
battery and charger.
• CHARGE INDICATION PANEL - Indicates Charging Status.
1. CHARGER ADAPTER
2. CHARGER CUP
3. CHARGE INDICATION PANEL
4. ELECTRICAL CORD
5. BATTERY TERMINAL GROOVES

OPERATION LC-56V1A
10 X7508310900
© 5/23 ECHO Incorporated
OPERATION
(1) Assumes the battery is just off the charger or stored at the temperature
range noted for charger usage (39° F (4°C)) - 104°F (40°C)).
(2) Hot batteries in high ambient temperatures require longer charge times.
(3) To maximize life of batteries being stored more than 3 months, ECHO
recommends batteries being stored at 3 green lights on the battery capacity
indicator (BCI) and at room temperature.
Note: Long term storage of batteries in conditions or charge levels
on the battery capacity indicator (BCI) other than noted
above could degrade the performance and runtime of the
battery.
Charging
Before use, charge battery fully to assure maximum unit run time.
This battery does not have battery memory and does not need
periodic full discharge cycles to prolong life.
Charging Procedure
1. Plug charger adapter (A) into AC power outlet.
2. Insert battery (B) into charger (C).
Recommended Ambient Temperatures:
Charging Usage/Discharge Storage
Low High Low High Low High
Product
(1) Not Applicable 32°F (0°C) 113°F (45°C) 32°F (0°C) 113°F (45°C)
Battery
(2)(3) 39°F (4°C) 104°F (40°C) 32°F (0°C) 113°F (45°C) 32°F (0°C) 113°F (45°C)
Charger 39°F (4°C) 104°F (40°C) Not Applicable 32°F (0°C) 113°F (45°C)

LC-56V1A OPERATION
X7508310900 11
© 5/23 ECHO Incorporated
This is a diagnostic charger. The charger LED will illuminate to
communicate the current battery status. LED representations are as follows:
Solid Red Light:
1. Remove battery from charger. Assure battery is within appropriate
temperature range (see table).
2. When battery is within appropriate temperature range, insert battery
into charger. If LED remains solid red, battery is being slowly charged
because of low voltage condition. Allow battery to continue charging.
Blinking Red Light:
1. Remove battery from charger for one minute.
Battery Status / Condition LED Appearance
Battery is Charging.
Battery is fully charged.
Battery is outside charging temperature range (either
too high or too low), OR is being slowly charged
because of low voltage condition. (See below.)
Battery might be defective. (See below.)
A
B
C
Green Blinking
Green Solid
Red Solid
Red Blinking

MAINTENANCE LC-56V1A
12 X7508310900
© 5/23 ECHO Incorporated
2. Re-insert battery into charger. If LED shows any status other than
blinking red, battery is good. If LED blinks red, remove battery from
charger and unplug charger from outlet.
3. Wait one minute, then plug charger back into outlet and put battery
back into charger. If LED shows any status other than blinking red,
battery is good. If LED blinks red, battery is defective and must be
replaced.
Examine the Charger
If the battery does not charge correctly:
1. Test outlet by plugging a different appliance into it.
2. Assure that charger contacts are not short-circuited.
3. If the charger is not located within normal room temperature, move
charger and battery to a location that conforms with temperatures listed
in table. .
If charging is attempted in an environment that’s too hot or too
cold, charger LED will turn red. Remove battery and allow
temperature to regulate for approximately 30 minutes.
MAINTENANCE
Maintenance and Care
• Clean housing and the plastic components with a dry and soft cloth.

LC-56V1A TROUBLESHOOTING
X7508310900 13
© 5/23 ECHO Incorporated
TROUBLESHOOTING
STORAGE
Storage After Use
1. Remove battery from charger.
2. Disconnect charger from power supply.
3. Store in a dry, dust-free place, out of the reach of children.
SPECIFICATIONS
Problem Possible Cause Solution
Charger doesn’t work.
Charger shows blinking red
LED.
Battery of charger is
defective or there is a
bad connection
between the battery
and charger.
Remove and reinsert the
battery into the charger.
Try charging a different
battery.
Unplug the charger and
wait until the LED goes
out, then reconnect the
plug to the power supply.
Charger doesn’t work.
Charger shows solid red
LED.
Battery is outside
charging temperature
range, or charger is
charging battery slowly
due to low voltage.
Allow the battery to
reach normal
temperature. Charging
will begin when the
battery returns to an
acceptable temperature
range.
MODEL LC-56V1A
Voltage 56V
Input 120V ~ 50/60HZ,1.5A Max
Output 56V DC 1A

WARRANTY LC-56V1A
14 X7508310900
© 5/23 ECHO Incorporated
WARRANTY
WARRANTY
Limited Warranty Statement for ECHO 56 Volt
Handheld Products and Walk Behind Mowers
sold
in USA and Canada
ECHO Incorporated warrants
to the original retail purchaser
that this ECHO brand 56 Volt outdoor product is free from de-
fects in material and workmanship and agrees to repair or re-
place, at ECHO Incorporated’s discretion, any defective prod-
uct free of charge within these time periods from the date of
purchase:
If the product is for homeowner use:
• Units and Bare Tool – 5 Years
• Battery or charger – 2 years
If the product is for commercial use:
• Units and Bare Tool – 2 years
• Battery or charger – 2 years
If the product is for rental use: 90 days for all units, batter-
ies, and chargers.
Cutting attachments such as, but not limited to, bars,
chains, sprockets, blades, tines, belts, PowerBroomTM and
nylon trimmer heads for homeowner or non-income pro-
ducing use will be covered for failures due to defects in
material or workmanship for a period of 60 days from origi-
nal product purchase date and 30 days for commercial /
rental use. Any misuse from contact with concrete, rocks,
or other structures is not covered by this warranty.
This warranty extends to the original retail purchaser only and
commences on the date of the original retail purchase.
Any part of this product found in the reasonable judgment of
ECHO Incorporated, to be defective in material or workmanship
will be repaired or replaced without charge for parts and labor
by an authorized ECHO dealer. Units, repair parts and acces-
sories
replaced under this warranty are warranted only for the
balance of the original warranty period.
The product, including any defective part, must be returned to
an authorized ECHO dealer within the warranty period. The ex-
pense of delivering the product to the service center for war-
ranty work and the expense of returning it back to the owner
after repair or replacement will be paid by the owner. ECHO
Incorporated’s, responsibility in respect to claims is limited to
making the required repairs or replacements
and no claim of
breach of warranty shall be cause for cancellation or rescission
of the contract of sale of any ECHO brand 56 Volt outdoor prod-
uct. Proof of purchase will be required by the dealer to substan-
tiate any warranty claim. All warranty work must
be performed
by an authorized ECHO dealer.
This warranty does not cover any units, battery or charger
that
has been subject to misuse, neglect, negligence, or accident,
or that has been operated in any way contrary to the operating
instructions as specified in the Operator’s Manual. This war-
ranty does not cover normal deterioration due to the use or ex-
posure, and any repairs made necessary by normal wear, im-
proper maintenance, improper lubrication, improper storage,
dirt, abrasives, impact, moisture, water, rain, snow, rust, corro-
sion, varnish, or other similar conditions.
This warranty does not cover damage to chargers or batteries
by improper charging voltage and batteries that have been ex-
posed to temperatures beyond those specified in the Opera-
tor’s Manual, batteries that have not been properly charged or
batteries that have reached their useful life.
This warranty does not apply to any
damage to the product that
is the result of improper maintenance or to any product that has
been altered or modified. The warranty does not extend to re-
pairs made necessary by normal wear or by the use
of parts or
accessories which are either incompatible with the ECHO
brand 56 Volt outdoor product or adversely affect its operation,
performance, or durability. In addition, this warranty does not
cover wear to normal items such as, but not limited to:
Wear items –
Bump Knobs, Outer Spools, Cutting Lines, Inner
Reels, Felt Washers, Hitch Pins, Mulching Blades, Blower
Fans, Blower and Vacuum Tubes, Vacuum Bag and Straps,
Guide Bars, Saw Chains, Grass Catch B
ag, Hedge Trimmer
Blades, and Wheels
ECHO Incorporated,
reserves the right to change or improve
the design of this product without assuming any obligation to
modify any product previously manufactured.
All implied warranties are limited in duration to the stated war-
ranty period. Accordingly, any such implied warranties includ-
ing merchantability, fitness for a particular purpose, or other-
wise, are disclaimed in their
entirety after the expiration of the
appropriate
five-year, two-year, one-year, 90-day, 60-
day, or
30-day warranty period.
ECHO Incorporated’s
obligation under
this warranty is strictly and
exclusively limited to the repair or re-
placement
of defective parts. ECHO Incorporated, does not as-
sume or
authorize anyone to assume for them any other obliga-
tion. Some states do not allow limitations
on how long an implied
warranty lasts, so the above limitation may not apply to you.
ECHO Incorporated, assumes no responsibility for incidental, con-
sequential,
or other damages including, but not limited to, ex-
pense of returning the product to an authorized dealer
for
ECHO brand 56 Volt outdoor products and expense of deliver-
ing it back to the owner, mechanic’s travel time, telephone
charges, rental of a like product during the time warranty ser-
vice is being performed, travel, loss or damage to
personal prop-
erty, loss of revenue, loss of use
of the product, loss of time, or
inconvenience. Some states do not allow the exclusion or limi-
tation of incidental or conse
quential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
This warranty applies to all ECHO brand 56 Volt outdoor prod-
ucts
manufactured by or for ECHO Incorporated, and sold in
the United States and Canada.
To locate your nearest authorized ECHO dealer, visit
www.ECHO-usa.com or dial 1-800-432-ECHO (3246).
–––
99922205724
11/2022

LC-56V1A PRODUCT REGISTRATION
X7508310900 15
© 5/23 ECHO Incorporated
PRODUCT REGISTRATION
Thank you for choosing ECHO Power Equipment
Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to
register your new product on-line. It's FAST and EASY! NOTE: your
information will never be sold or misused by ECHO, Incorporated.
Registering your purchase enables us to contact you in the unlikely event of
a service update or product recall, and verifies your ownership for warranty
consideration.
If you do not have access to the Internet, you can complete the form below
and mail to:
ECHO Incorporated, Product Registration, PO Box 1139,
Lake Zurich, IL 60047.

PRODUCT REGISTRATION LC-56V1A
16 X7508310900
© 5/23 ECHO Incorporated
ECHO Incorporated
