EdgeStar AP410HS User manual

Installation
Installing the exhaust hose
In order to be used effectively, the exhaust hose must be mounted to the back of the
unit.
1. Make sure the rectangular vent connector is fitted to one end of the exhaust hose
and fit the round adapter to the other end.
2. Insert the rectangular vent connector into the exhaust port on the back of the unit.
1

Window installation
This portable air conditioner ships with a foam window kit for temporary mounting in
standard windows.
1. Punch the circular cut-out out of the foam window kit. Insert the round adaptor
into the cut-out. Open the window and place the foam window kit in it, with the
circle cut-out near where you are going to place the portable air conditioner.
If the window is oriented horizontally, place the foam window kit horizontally. If
the window is oriented vertically, place the foam window kit vertically. Gauge the
size of the window. The foam window kit can be cut to fit into the window if the
kit is too long.
2. Once you have properly sized the window kit for the window, close the window
tightly onto the window kit. If necessary, use the included adhesive tape to help
keep the window kit in the proper position.
3. Position the portable air conditioner near the window, extend the exhaust hose as
far as you need to, and place the end of the exhaust hose into the round adapter.
2

Wall installation (permanent mounting)
Key for the above diagram:
1. Exhaust port
2. Vent connector
3. Exhaust hose
4. Round adapter
1. Drill a 5 1/8” diameter (approx.) hole through the wall. For safety and to avoid
cutting into structural support beams or electrical wires, please have a qualified
technician drill this hole.
2. Insert the round adapter into the hole (from inside the room) and mark the screw
hole positions on the wall
3. Remove the round adapter from the wall and drill four screw holes in the
positions marked.
4. Replace the round adapter into the wall and screw it into place.
5. Move the portable air conditioner into place near the wall and insert the exhaust
hose into the round adapter. Twist the exhaust hose into the adapter in a clockwise
direction.
6. When not in use, remove the exhaust hose from the round adapter and place the
round adapter cap over the hole.
3
