EdilKamin IDROPELLBOX 30 Quick start guide

Installation, use and maintenance page 2
IDROPELLBOX 30
WOOD PELLET BOILER-FIREPLACE

2
ENGLISH
The undersigned EDILKAMIN S.p.A., with registered office in
Via Vincenzo Monti 47 - 20123 Milan (Italy) - Tax ID Code and
VAT number 00192220192
Hereby declares, under its sole responsibility, that:
the wood pellet boiler-fireplace mentioned below are
conforming with EU Regulation 305/2011 and harmonised
EU standard EN 14785:2006
WOOD PELLET BOILER-FIREPLACE, bearing the
EDILKAMIN trademark, models
IDROPELLBOX 30
SERIAL NO.: Rating plate reference
IDROPELLBOX 30: Performance declaration (DoP - EK no.
168)
Moreover, the company hereby declares that:
the wood pellet boiler-fireplace IDROPELLBOX 30
comply with the requirements in the following European
Directives:
2014/35/EC - Low Voltage Directive
2014/30/EC - Electromagnetic Compatibility Directive
Introduction and readers of this manual 3
Safety information 4
Dimensions 5
Technical data 6
Unpacking 7
Fume outlet direction 9
Water circuit installation 10
Terminal board 12
Installation 13
Introduction about use 20
Maintenance 35
Troubleshooting 48
CONTENTS
USER/INSTALLER
The original language of this manual is Italian

3
ENGLISH
USER/INSTALLER
Dear Sir/Madam
We thank you for and congratulate you on choosing our
product. Before using it, we ask you to read this manual
carefully, in order for you to be able to make the most of all
its functions in total safety.
This manual is an integral part of the product. We ask you
to keep it for the entire lifetime of the product. If you lose it,
you can request a copy from your dealer or download it from
www.edilkamin.com
Readers of this manual
This manual is addressed to:
• those who will use the product at home (“USER”);
• the technician who will install the product (“INSTALLER”)
The target person of each page is indicated in a band at the
bottom of the page (USER or INSTALLER).
General information
After unpacking the product, check the condition and
completeness of the contents.
In the event of error, immediately contact the retailer where
the purchase was made, providing them with a copy of the
warranty booklet and the sales receipt.
The appliance must be installed and operated in compliance
with local and national law and European regulations. For the
installation, and for anything not specifically indicated in the
manual, observe local regulations.
The diagrams provided in this manual are for illustration
purposes only: they do not always strictly refer to your
specific model, and are not binding in any way.
MEANING OF SYMBOLS
In some parts of the manual the following symbols are
used:
INFORMATION:
failure to comply with these requirements
will compromise product use.
PLEASE NOTE:
carefully read and understand the
message in question, since failure to
follow the instructions in it could cause
serious damage to the product and put
the safety of those using it at risk.
OPERATING SEQUENCE:
follow the instructions for the operations
described.
Identification of the product and warranty.
The product is uniquely identified by a number, the
“counterfoil”, which is indicated on the warranty certificate.
Please keep:
• the warranty certificate accompanying the product
• the purchase receipt given to you by the retailer
• the declaration of conformity given to you by the installer.
The warranty conditions are given in the warranty certificate
accompanying the product.
First ignition (commissioning), in Italy, by an
authorised technician is required by UNI 10683, and is
recommended in all countries to ensure best results from
the product.
This consists of:
• checking the installation documents (declaration of
conformity) and the quality of the installation itself
• calibrating the product to suit its actual application
• providing explanations to the end user and issuing
the complementary documentation (first ignition -
commissioning certificate)
Having the appliance commissioned properly ensures that it
will operate to best effect and in complete safety.
Commissioning is required for activation of the Edilkamin
manufacturer warranty. The warranty is only valid in the
country where the product was bought.
If the appliance is not commissioned by an authorised
technician, Edilkamin will not provide warranty service. See
the warranty booklet for details. The above terms do not
affect the dealer's legal responsibility for the legal warranty.
The warranty, however, covers only demonstrable
manufacturing defects and not, for instance, problems
resulting from improper installation or calibration.

4
ENGLISH
SAFETY INFORMATION
• The product is not designed for use by
people, including children, with limited
physical, sensory and mental abilities.
• The appliance is not designed for cooking
purposes.
• The appliance is designed to burn wood
pellets from category A1 in the UNI EN
ISO 17225-2 standard, in the amounts
and manner described in this manual.
• The appliance is designed for indoor
use and in areas with normal humidity
conditions.
• Keep the product in a dry place out of the
weather.
• For the legal and company warranties,
refer to the warranty certificate inside the
product: specifically, neither Edilkamin nor
the retailer are liable for damage resulting
from incorrect installation or maintenance.
Safety risks may be caused by:
• installation in non-suitable settings, in
particular those that are subject to fire
risks. DO NOT INSTALL THE PRODUCT
IN AREAS SUBJECT TO THE RISK OF
FIRE.
• contact with fire and hot parts (e.g. glass
panel and pipes). DO NOT TOUCH HOT
PARTS and, when the stove is switched
off and still hot, always wear the glove
supplied.
• contact with live electrical equipment
(internal). DO NOT ACCESS THE
INTERNAL ELECTRICAL EQUIPMENT
WHILE THE APPLIANCE IS POWERED
ON. Electrocution hazard.
• use of improper ignition aids (e.g.
alcohol). DO NOT IGNITE OR BOOST
THE FLAME WITH FLUID SPRAYS OR
A FLAME TORCH. Serious risk of burns,
damage and injury.
• use of fuel other than wood pellets. DO
NOT BURN WASTE MATTER, PLASTIC
OR OTHER MATERIALS THAN WOOD
PELLETS IN THE COMBUSTION
CHAMBER. The product may become
soiled, the flue may catch fire, and
environmental damage may ensue.
• cleaning the combustion chamber when
hot. DO NOT CLEAN THE HEARTH WITH
A VACUUM CLEANER WHILE IT IS HOT.
You could damage the vacuum-cleaner
and risk the emission of smoke in the
room.
• cleaning the smoke duct with cleaning
products. DO NOT CLEAN THE PRODUCT
WITH FLAMMABLE PRODUCTS. Risk of
fire or blowback.
• cleaning the glass pane while hot or
with unsuitable cleaning products. DO
NOT CLEAN HOT GLASS WITH WATER.
ONLY USE RECOMMENDED GLASS
CLEANING PRODUCTS. Risk of cracking
and permanent, irreparable damage to
the glass.
• the storage of flammable materials at
a distance which is less than the safe
distances listed in this manual. DO NOT
PLACE LAUNDRY ON THE APPLIANCE.
DO NOT PLACE DRYING RACKS WITHIN
THE SAFETY CLEARANCE. Keep
flammable fluids away from the appliance.
Fire hazard.
• blocking the aeration vents and air
intakes in the room. DO NOT BLOCK
THE AERATION VENTS OR FLUE. Risk
of smoke returning into the room with
consequent damage and injury.
• use of the product as a support or ladder.
DO NOT CLIMB ONTO THE PRODUCT
OR USE IT AS A SUPPORT. Risk of
damage and injury.
• use of the stove with the combustion
chamber open. DO NOT USE THE
PRODUCT WITH ITS DOOR OPEN.
• incandescent material projected from the
open door. DO NOT throw incandescent
material outside the appliance. Fire
hazard.
• use of water in case of fire. CALL THE
AUTHORITIES if a fire breaks out.
• never operate the product without water in
the circuit.
• running it dry can damage it.
If you have doubts, please do not take any
action, but contact the retailer or the installer.
For reasonsofsafety,read theuser instructions
included in this manual.
USER/INSTALLER

5
ENGLISH
USER/INSTALLER
DIMENSIONS
IDROPELLBOX 30
33 462
143
37
13,5
9,5 8,97
60
76
95
Ø 10 cm
smoke outlet
Cold H2O
1/2” fitting heating return 3/4”
fitting
heating delivery
3/4” fitting
Ø 10 cm
smoke outlet

6
ENGLISH
The above data is for guidance only and was measured during certification by a notified body.
EDILKAMIN s.p.a. reserves the right to modify the product without notification in the interests of improvement.
TECHNICAL DATA as per EN 14785
IDROPELLBOX 30
Nominal power Reduced power
Available power 27 8,3 kW
Heat output to water 22 5,6
Efficiency 90,4 94,3 %
CO emissions at 13% O20,013 0,018 %
Smoke temperature 142 82 °C
Fuel consumption * 6,2 1,8 kg/h
Tank capacity 60 kg
Recommended draught 10 13 Pa
Autonomy 10 33 ore
Water content 50 l
Maximum operating pressure 2 bar
Maximum operating temperature 90 °C
Heatable volume ** 705 m3
Smoke outlet diameter (male) 100 mm
Air intake diameter (male) 50 mm
Weight with packaging 220 kg
TECHNICAL DATA FOR SIZING THE FLUE
which must in any case satisfy the requirements of this sheet and the installation instructions for the product
Nominal power
IDROPELLBOX 30
Smoke temperature at outlet 170 °C
Minimum draw 0,01 Pa
Smoke flow rate 2,4 g/s
TECHNICAL DATA
USER/INSTALLER
** The heatable volume is calculated based on the assumption of a heating demand of 33 Kcal/m³ hour.
*A calorific value of 4.8 kW/Kg has been used to calculate consumption.
ELECTRICAL SPECIFICATIONS
Power supply 230 Vac +/- 10% 50 Hz
Mean power absorbed (reduced power
- nominal) 40 - 140 W
Power absorbed in stand by 5 W
Power absorption during ignition 300 W
Remote control frequency (provided) 2,4 GHz
Protection Fusibile 4 AT, 250 Vac 5x20

7
ENGLISH
USER/INSTALLER
UNPACKING
PREPARATION AND UNPACKING
The packaging materials are neither toxic nor noxious
and do not require special disposal.
The user is responsible for storing, disposing of and
recycling them in a regulatory fashion.
Always move the stove vertically with
suitable equipment and in compliance with
safety regulations.
Do not turn the package over, and handle
all parts requiring installation with care.
Package materials such as plastic and
films my be dangerous for children.
Suffocation hazard.
Keep packages away from children.
PACKAGING
In the stove you will find:
• remote control,
• warranty certificate,
• glove,
• desiccant salts,
• this manual,
• power cable,
• detachable handle to activate the cleaning
brushes.
TO REMOVE THE PRODUCT FROM THE PALLET
remove the four brackets (screwed on): 2 at the front and 2 at the rear
brackets
brackets

8
ENGLISH
UNPACKING
casters
USER/INSTALLER
SHIFTING THE PRODUCT
The fireplace is equipped with four casters for facilitating its handling.
Lower the feet by turning them to use the wheels.
After positioning the fireplace, reposition the feet.
The feet are used to distance the fireplace from the floor and to level the hearth.
Handling should be done using
wheels only
Do not move the product if
weight is laying on feet and not
on wheels
The feet are used to distance the fireplace from the floor and to level the hearth.

9
ENGLISH
FUME OUTLET DIRECTION
The product has a rear fume discharge outlet but is also configured to have it on the upper side.
To orient the outlet upwards; (please note that the pellet loading hatch cannot be used from the side)
• Remove the 4 screws fastening the smoke outlet flange;
• Remove the screws fastening the upper cap;
• Invert their position and fasten the components back on.
INSTALLER
screws

10
ENGLISH
WATER CIRCUIT INSTALLATION
HYDRAULIC CONNECTIONS
Idropellbox 30 has an incorporated hydraulic kit.
It includes:
• a circulator pump;
• a safety valve;
• an 8-litre expansion vessel.
If the expansion tank is incorporated in the product, this
does NOT ensure adequate protection against thermal
expansion caused by water in the entire system.
Therefore, installers should assess whether an
additional expansion tank is needed, depending on the
type of system.
The hydraulic connections depend on the type of system.
However, there are a few “general rules”:
• The hydraulic system must operate at a pressure
between 1 and 1.5–2 bars at running temperature
(hot) in a closed vessel circuit.
• DO NOT install the product on a primary system with
an open expansion tank.
• The return temperature of water must be higher
than at least 50–55 °C to prevent condensate from
forming.
• The material used in the circuit must be capable of
withstanding possible overheating.
• The installer must decide whether or not to use
conditioners depending on the type of water and
system. In Italy, refer to the UNI 8065 standard
(Water treatment in heating systems for civil use).
VENT
During normal operations the vent
is automatic. During installation, the
technician must check the functionality of
the automatic vent and assess whether a
manual vent needs to be installed.
INSTALLER
PRESSURE GAUGE
The product reads the water pressure electronically.
You can read the water pressure on the remote control
display.
An analogue pressure gauge is also fitted on the right-
hand side of the product, near the filling valve.
pressure gauge
G 1/2” M
safety valve
G 3/4” M
system return
G 3/4” M boiler
delivery pipe
G 1/2” M
expansion vessel system return
snap-on fitting
Wilo pump para iPWM 7m
clip + O-ring available water delivery
pressure transducer HUBA 505.915 8,5-30 V dc
automatic vent
expansion valve G1/2” fitting
pressure gauge socket cap mounted
3-bar valve with threaded fitting G 1/2”
increased drain cock
G 3/4” M
system delivery
measurements in mm

11
ENGLISH
INSTALLER
WATER CIRCUIT INSTALLATION
Fig. 1:
A B
Fig. 2:
RKA RKC
Fig. 3a: Fig. 3b:
H max
H
H min
Hs
Q
Hs
1
/
2
H max
H
H min
Hs
Q
PUMP SPECIFICATIONS
The pump has no adjustment devices.
Adjustments are made via the micro
processor on the boiler stove: “begin” at the lowest speed and make adjustments based on the progression of the
water temperature. Below is the descriptions for the LED signals.
leds
LEDS MEANING CAUSE SOLUTION
Steady green Pump running Normal operation
Flashing green light Pump in stand-by mode Normal operation
Steady red LED
Stall Pump stalled
Contact the TAC
Contact/winding Defective winding
Flashing red LED
Under-/over-voltage Supply voltage too low/high Check the supply
voltage/contact the TAC
Excessively high module
temperature
Motor board temperature too
high
Flashing red/green light
Turbine-based operation
The pump is not powered but
the hydraulic system is fed by
other sources Check the network voltage/
water pressure and
environmental
conditions/contact the TAC
Dry operation Air in the pump
Overload The motor runs with difficulty

12
ENGLISH
TERMINAL BOARD
INSTALLER
No.
POLES POSSIBLE CONNECTIONS NOTES
1/2 NTC probe/room thermostat Non-standard supplied
3/4 Home automation input. This input receives all
home automation contacts
5/6 /7
External solenoid valve, external boiler permissive,
remote alarm, any device that manages a potential-
free contact
Configuration in system/technical menu
5=black - normally open (NA)
6=red - normally closed (NC)
7=white - common
8/9/10 Electrical connection for booster/secondary pump
“8=brown / live
9=blue / neutral
10=yellow-green / earth”
The poles are numbered on the product as described below:
TERMINAL BOARD
Sul lato sinistro (tolto il coperchio protettivo avvitato A
terminal board is mounted just above the electronic
board, on the left-hand side (remove the protective
cover fastened with two screws).
The terminal board includes low and high voltage.
Examples of possible connection configurations are
shown below.

13
ENGLISH
INSTALLATION
INSTALLER
NOTE
To load the pellets and perform maintenance, there must
be at least two doors on the left-hand and right-hand
sides (170x55 cm).
See following page.
You can load from either the right or left. You can decide
during the installation phase.
Warning:
if the fume outlet points upwards, you can only load from
the right-hand side.
REMARKS ON INSTALLATION
Note that:
• installation must be carried out by authorised
technical personnel;
• The appliance must be installed and operated
in compliance with local and national law and
European regulations. The applicable Italian
standard is UNI 10683;
• If installed in a condominium, the appliance must
be approved by the administrator.
We give some general instructions below, however
these do not obviate the need to comply with local
regulations and do not imply any liability as regards
the installer's work.
Checking the suitability of the installation
space
• The room must have a volume of at least 30 m3.
• The floor must be able to bear the weight of the
product and its accessories.
• Level the product (the product is provided with
adjustable feet).
• The appliance may not be installed in a bedroom,
bathroom or in the same room as other equipment
which draws air for combustion from the room
itself, or in any area with an explosive atmosphere.
Any extraction fans operating in the same room or
area as the product, may affect its draw.
• In Italy, check the compatibility pursuant to UNI
10683 and UNI 7129 in the presence of gas fired
products.

14
ENGLISH
INSTALLATION
INSTALLER
Distance from flammable wall not requested (0 cm).
If the air vent is not connected to the outside, leave 4 cm.
“Insert the aeration grilles and side openings (55x170 cm doors) to be able to load the pellets
into the tank, view the pressure gauge, for easier access to the ignition button, maintenance, etc.
The measurements and positions are expressed in cm in the figure below.”
2222
64
Minimum depth
120
Minimum width
FRONT VIEWLH SIDE VIEW
Ventilation
(min. 350 cm2)
Ventilation
(min. 350 cm2)
(1) add insu-
lating material
A1 between
the thermo-
fireplace and
the cladding
aeration grille
(min. cross-section 640 cm2)
Pellet loading and
maintenance door
Pellet loading and
maintenance door
170 170
35
15 15
20 20
55 555 55 5
62
(1)
(1)
RH SIDE VIEW

15
ENGLISH
INSTALLATION
INSTALLER
Protection from heat and safety clearances
The surfaces of the building that are adjacent to the
product must be protected against overheating.
The insulation to be used will depend on the type of
surface in question.
The appliance must be installed in accordance with
the following safety instructions:
- no flammable materials may be kept closer than 10
cm to the sides and back
- no flammable materials may be kept within 80 cm
from the front of the appliance.
If connected to a wooden or otherwise flammable wall,
the flue must be insulated appropriately.
If installed on a flammable or combustible floor, or
which is not capable of bearing its load, use steel or
glass plates under the stove to distribute the load.

16
ENGLISH
FLUE SYSTEM(Smoke duct, flue and
chimney pot)
This chapter has been drawn up pursuant to European
standards EN 13384, EN 1443, EN 1856 and EN 1457.
The installer must observe both these and any other
local regulations.
This manual does not in any way substitute such
regulations.
The product must be connected to a flue system which
ensures that the smoke produced by combustion is
discharged in complete safety.
Before positioning the appliance, the installer must
check that the flue is suitable.
SMOKE DUCT, FLUE
The smoke duct (which connects the smoke outlet of
the combustion chamber with the flue) and the flue
itself must, among other regulatory requirements:
• receive the smoke from a single product (outlets
from multiple appliances may not be conveyed
into a single flue)
• be routed vertically for the most part
• have no downwards sloping sections
• preferably have a circular internal cross section, or
with a ratio of the sides of less than 1.5
• terminate at roof level with a proper chimney pot:
the flue may not discharge directly onto the wall
or into an enclosed space, even if the space in
question is open to the sky
• be made of material with rated fire reaction class
A1 as per UNI EN 13501 or analogous national
regulations
• be certified, with a chimney plate if metal
• be of uniform cross section or vary in cross section
only immediately after the outlet, not at some mid
point of its length
THE SMOKE DUCT
Further to the general prescriptions for the smoke duct
and flue, the smoke duct:
• may not be made of flexible metal material
• must be insulated, if routed through unheated
areas or outdoors
• must not be routed through rooms where the
installation of combustion heat generators is
prohibited, where there is risk of fire, or which
cannot be inspected
• must enable the recovery of soot and be open for
inspection
• must have at most 1 bend with a maximum angle
of 90°
• if there is a horizontal section, it must be a single
one with a maximum length of no more than 3
metres, depending on the draw. Note, in any case,
that long sections promote the accumulation of
dirt and are harder to keep clean.
INSTALLER
INSTALLATION

17
ENGLISH
THE FLUE:
Further to the general prescriptions, the flue must
• only be used to discharge smoke
• be correctly sized to satisfy the requirements of
smoke discharge (EN 13384-1)
• must preferably be insulated, in steel with a circular
internal section. If rectangular, the corners must
have a radius of not less than 20 mm, with a ratio
of the internal dimensions of <1.5
• must normally be at least 1.5 metres in vertical
length
• must have a constant cross section
• must be waterproof and thermally insulated to
ensure a good draw
• must preferable have a collection chamber for
non-combusted matter and condensation.
• if pre-existing, it must be cleaned to prevent any
fire hazard
• in general, we recommend fitting a tube inside the
existing masonry chimney if its diameter is greater
than 150 mm. This recommendation is purely for
guidance; the installer must assess wile installing,
after the calculation of the draw.
INTUBATED SYSTEM:
Further to the general prescriptions, the intubated
system must:
• operate in negative pressure
• be open to inspection
• be compliant with local regulations.
THE CHIMNEY POT must:
• be wind-proof
• have an internal cross section equivalent to that of
the flue and a smoke outlet at least double that of
the interior of the flue
• extend beyond the back flow zone (in Italy, refer to
UNI 10683 point 6.5.8.)
• allow for maintenance of the chimney
For dual flues (which should be spaced at least 2 m
apart), the chimney pot receiving the smoke from the
solid fuel appliance or that from the higher storey, must
be at least 50 cm higher than the other
AIR INTAKE FOR COMBUSTION
In general, we suggest two ways to ensure a proper
flow of combustion air. Air must come from the outside*
It is also important to ensure a change of heating air
and glass cleaning air etc.
Indirect air intake
The boiler stove takes air from the outside through the
hole on the rear.
Install an air outlet at floor level with an effective sur-
face area (net of the mesh or other protections) of at
least 100 cm2.
To prevent draughts, we recommend installing the
intake behind the product or behind a radiator.
Installing it in front of the appliance will create
unpleasant draughts.
Direct air intake**
Install an air intake of effective area (net of the mesh or
other protective equipment) at least equal to that of the
air intake at the back of the product.
Connect the air intake to the appliance's air intake with
a tube (which may also be of the hose type). Increase
the diameter of the pipe if it is not smooth: assess its
pressure drops.
We recommend not exceeding a length of 1 m,
considering the draw of the flue. You should also
consider increasing the diameter of the pipe.
*The air may be drawn from an adjacent room only if:
• the flow is taken from permanent and unobstructed
openings communicating with the outdoors
• the air pressure in the adjacent room is never
lower than that of the outdoor pressure
• the adjacent room is not a garage. subject to fire
hazard, a bathroom or bedroom
• the adjacent room is not a shared room in the
condominium
In Italy, UNI 10683 provides that ventilation is sufficient
even if a pressure difference between the outdoors
and indoors of no more than 4 PA is guaranteed (UNI
EN 13384-1). The installer who issues the declaration
of conformity is responsible for ensuring these
conditions.
**The direct connection of the air intake does not
make the product airtight. It is therefore necessary also
to ensure recovery of the air taken in the room by the
product (i.e. for the glass cleaning)
INSTALLER
INSTALLATION

18
ENGLISH
CHECKING THE ELECTRICAL
CONNECTIONS (the power socket must be
located in an easily-accessible position)
The product is supplied with an electrical power cord
for connection to a 230V 50 Hz socket, preferably one
equipped with a trip switch.
Variations in voltage of more than 10% can compromise
its operation.
The electrical system must be compliant; check the
operation of the earth in particular.
Edilkamin is not responsible for malfunctions resulting
from an improperly earthed system.
The power line must be of adequate section for the
power of the appliance.
The power cable must not come into contact with the
flue or other hot parts of the stove.
Power up the product by setting its switch from 0 to 1.
There is one 4 A fuse on the socket with switch located
at the rear of the product.
We recommend mounting an on/off switch in an
accessible point.
INSTALLER
switch
fuse housing power supply
INSTALLATION

19
ENGLISH
INSTALLER
Facings, gather hood and vents
Face the product only after having
completed the following steps:
• connection of the product to the
smoke outlet and air intake;
• inspection of the product when hot;
• check to verify whether the product
is levelled.
The installer must implement all the installation good
practices and take all the necessary precautions
against overheating and fire.
In particular:
• if a plinth is constructed beneath the hearth level,
it must include a suitable slot for the passage of
recirculation air from the room;
• if the Air Diffuser Kit is installed, it must be possible
to inspect or replace the fans;
• wooden parts must be protected with fireproof
panels, which must not be placed against one
another but spaced at least 1 cm apart to enable air
to flow and prevent heat build-up. The gather hood
can be made with fireproof panels, plasterboard
or gypsum slabs; during construction, the hot air
ducting kit must be mounted as described above.
The interior of the gather hood should be aerated
by exploiting the flow of air coming from below (the
space between the door and mantel) which convective
currents will cause to exit from the grille on top,
thus allowing heat recovery and preventing undue
overheating.
In addition to that mentioned above, take into account
the regulations in force in the relevant country
concerning “insulation, finishes, facings and safety
recommendations”.
INSTALLATION

20
ENGLISH
LOADING THE PELLETS INTO THE TANK
Load the pellets from the right-hand or left-hand hatch,
as decided during the installation phase.
USER
FIRST IGNITION (COMMISSIONING)
PHASES
• Make sure you have read and understood this
manual.
• Remove all flammable materials from the appliance
(manuals, labels, etc.). In particular remove any
labels from the glass.
• Make sure that the technician performs the first
ignition and the first loading of the pellet tank.
Refer to the “Various Menus” chapter, paragraph
“pellet loading”.
FUEL
Use UNI EN ISO 17225-2 category A1 wood pellets
or similar regulatory products with the following
characteristics.
diameter 6 mm
length 3-4 cm
humidity <10 %
For reasons of safety and environmental compatibility,
DO NOT burn plastic, painted wood, coal, bark or
other such materials in the stove.
Do not use the stove as an incinerator.
On first ignition, there may be a slight
smell of paint, which will disappear in a
short time.
VENT
During normal operations the vent is
automatic. The need for a manual vent for
the system can only be assessed by the
technician during commissioning.
Caution
Using fuels other than those specified can
damage the appliance
USER INSTRUCTIONS
