Edimax BR-6428nS V5 User manual

BR-6428nS V5
User Manual
12-2018 / v1.0

CONTENTS
I. Product Information.............................................................................. 1
I-1. Package Contents ..........................................................................................................1
I-2. LED Status ......................................................................................................................2
I-3. Back Panel......................................................................................................................3
II. Installation............................................................................................ 5
II-1. Wi-Fi Router Mode ........................................................................................................8
II-2. WISP Mode ..................................................................................................................11
II-3. Universal Repeater Mode............................................................................................14
II-4. Access Point Mode.......................................................................................................17
II-5. WPS Setup....................................................................................................................20
II-6. Reset to Factory Default Settings ................................................................................20
III. Browser Based Configuration Interface.................................................21
III-1. Login.............................................................................................................................21
III-2. Main Menu ..................................................................................................................23
III-2-1. Commonly used web elements ...................................................................................24
III-2-2. Setup Wizard................................................................................................................25
III-2-3. Status ...........................................................................................................................27
III-2-3-1. System Status...............................................................................................................28
III-2-3-2. LAN Status....................................................................................................................28
III-2-3-3. Wireless Status ............................................................................................................29
III-2-3-4. WAN Status..................................................................................................................30
III-3. Network .......................................................................................................................30
III-3-1. WAN Settings ...............................................................................................................31
III-3-1-5. WAN Settings- L2TP .....................................................................................................35
III-3-2. WAN Speed..................................................................................................................36
IV. Appendix .............................................................................................64
IV-1. Configuring your IP address.........................................................................................64
IV-1-1. How to check that your computer uses a dynamic IP address ...................................65
IV-1-1-1. Windows 7 ...................................................................................................................65
IV-1-1-2. Windows 8 ...................................................................................................................69
IV-1-1-3. Windows 10 .................................................................................................................73
IV-1-1-4. Mac OS.........................................................................................................................75
IV-1-2. How to modify the IP address of your computer ........................................................77
IV-1-2-1. Windows 7 ...................................................................................................................77
IV-1-2-2. Windows 8 ...................................................................................................................80
IV-1-2-3. Windows 10 .................................................................................................................84

IV-1-2-4. Mac ..............................................................................................................................86
IV-1-3. How to Find Your Network Security Key .....................................................................88
IV-1-3-1. Windows 7 & 8.............................................................................................................88
IV-1-3-2. Windows 10 .................................................................................................................91
IV-1-3-3. Mac ..............................................................................................................................92
IV-1-4. How to Find Your Router’s IP Address.........................................................................95
IV-1-4-1. Windows 7 ...................................................................................................................95
IV-1-4-2. Windows 8 ...................................................................................................................97
IV-1-4-3. Window 10...................................................................................................................99
IV-1-4-4. Mac ............................................................................................................................100
IV-2. Connecting to a Wi-Fi network..................................................................................102
IV-3. Troubleshooting.........................................................................................................103
Step 1: Right-click the Network icon and select Properties. .............................................................105
Step 2: Select Manage Wireless Networks........................................................................................105
Step 3: Select the wireless network and click Remove network.......................................................105

1
I. Product Information
I-1. Package Contents
Before you start using this product, please check if there is anything missing in
the package, and contact your dealer to claim the missing item(s):
BR-6428nS V5
(5dBi Antenna x 2)
Power Adapter
Ethernet Cable
Quick Installation Guide
CD-ROM

2
I-2. LED Status
LED
LED Colors
LED Status
Description
WPS
Green
On
Negotiation is in progress through Wi-Fi Protected
Setup.
Quick Flashing
Reset factory settings
Slow Flashing
WPS in progress
Off
WPS is disabled or connected.
PWR
Green
On
Device is on.
Quick Flashing
Reset factory settings
Slow Flashing
Firmware upgrade in process
Off
Device is off.
WAN
Green
On
WAN port connected.
Flashing
WAN activity.
Off
WAN port not connected.
WLAN
Blue
On
Wi-Fi wireless activity (transferring/receiving data).
Quick Flashing
Reset factory settings
Off
Wi-Fi not active.
LAN
Green
On
Ethernet port is connected to a network device.
Flashing
LAN activity.
Off
Ethernet port is not connected to a network device.

3
I-3. Back Panel
10/100Mbps
WAN Port
10/100 Mbps
LAN Ports 1–4
WPS/Reset Button
Power Port
BR 6428nS V5 Fixed 5dBi Antenna x 2

4
I-4. Safety Information
In order to ensure the safe operation of the device and its users, please read
and act in accordance with the following safety instructions.
1. The device is designed for indoor use only; do not place it outdoors.
2. Do not place the device in or near hot/humid places, such as a kitchen or
bathroom.
3. Do not pull any connected cable with force; carefully disconnect it from the
BR-6428nS V5.
4. Handle the device with care. Accidental damage will void the warranty of
the device.
5. The device contains small parts which are a danger to small children under
3 years old. Please keep the device out of reach of children.
6. Do not place the device on paper, cloth, dust, corrosive liquids or other
flammable materials. The device may become hot during use.
7. There are no user-serviceable parts inside the device. If you experience
problems with the device, please contact your dealer of purchase and ask
for help.
8. The device is an electrical device and as such, if it becomes wet for any
reason, do not attempt to touch it without switching the power supply off.
Contact an experienced electrical technician for further help.
9. Plug this product directly into a wall socket (100-240V~, 50/60Hz). Do not
use an extension cord between this product and the AC power source.
10.The Operating temperature is 0℃~40℃(32℉~104℉). The Storage
temperature is -40℃~70℃(-40℉~158℉).

5
II. Installation
1.Plug the included power adapter into the device’s 5V DC power port and
the other end into an electrical socket.
2.Ensure that the power LED is lit. If not, the device is not properly
connected.
3.Use a Wi-Fi device (e.g. computer, tablet, smartphone) to search for a Wi-Fi
network with the SSID “edimax.setup” and connect to it.
iOS 4 or Android 4 and above are required for setup on a
smartphone or tablet.

6
4.Open a web browser and if you do not automatically arrive at the log in
screen shown below, enter the URL http://192.168.2.1 and begin the setup
process.
If you cannot access http://192.168.2.1, please make sure your
computer is set to use a dynamic IP address. Refer to IV-1.
Configuring your IP address for more information.
5.Enter new password, confirmed and click “NEXT’ to continue.

7
6.Select the mode for your BR-6428nS V5 and click “NEXT”to continue.
Wi-Fi Router
The device connects to your modem and
enables Internet (wireless and Ethernet)
access on your network devices.
WISP Mode
The device connects wirelessly to your
Wireless Internet Service Provider and
provides 2.4GHz and/or 5GHz Internet
(wireless and Ethernet) access for your
network devices.
Universal Repeater
The device will act as a wireless range
extender that will help you to extend your
Wi-Fi network. The device acts as a client and
AP at the same time. It its client function to
connect to a root AP, and uses its AP function
to service wireless clients within its coverage.
Access Point
The device connects to an existing router via
Ethernet cable and provides Internet (wireless
and Ethernet) access for your network
devices.
Follow the appropriate instructions for your operating mode:

8
II-1. Wi-Fi Router Mode
1. Connect the blue WAN port of your BR-6428nS V5 to the LAN port of your
modem using an Ethernet cable, and then log on to http://192.168.2.1.
2. Select “Router”mode and click “NEXT”.
3. You can select “Dynamic IP”, “Static IP”, and “PPPOE”mode.

9
4. Confirm the configuration details for your wireless network, then click
“NEXT” to continue.
5. Please click “Save” to reboot the device and activate the configuration.

10
6. Please wait a moment until the BR-6428nS V5 is ready.
7.When the setup is complete. Please close the browser window.
8.The BR-6428nS V5 is working and ready for use. You can now connect to
the device’s new SSID. Please refer to IV-2. Connecting to a Wi-Fi network
if you require more guidance.

11
II-2. WISP Mode
1.Please ensure your BR-6478nS V5 is within Wi-Fi range of your WISP
network. Log on to http://192.168.2.1 to configure your device.
2.Select WISP mode and click “NEXT”.
3.Click “Site Survey” to scan the wireless signals and connect to desired
device.

12
4.A summary of your wireless configuration will be displayed, as shown
below. Check that all of the details are correct and then click “NEXT” to
proceed.
5.Please click “Save” to reboot the device and activate the configuration.

13
6.Please wait a moment until the BR-6428nS V5 is ready.
7.When the setup is complete, please close the browser window.
8.The BR-6428nS V5 is working and ready for use. You can now connect to
the device’s new SSID. Please refer to IV-2. Connecting to a Wi-Fi network
if you require more guidance.

14
II-3. Universal Repeater Mode
1. Please ensure your BR-6428nS V5 is within Wi-Fi range of your existing
wireless router. Log on to http://192.168.2.1 to configure your device.
2. Select Repeater Mode and click “NEXT”.
If the Wi-Fi network you wish to connect to does not appear, try
clicking “Refresh”.

15
3. The device will search for nearby wireless networks to connect to. If you
cannot find the access point you wish to connect to, click “Site Survey” to
refresh the list of wireless networks. Select the wireless network you wish
to connect to, and click “NEXT” to continue.
4. A summary of your wireless configuration will be displayed, as shown
below. Check that all of the details are correct and then click “NEXT” to
proceed. Click on Support Wireless Roaming to display the existing wireless
configuration.
The device will use the same wireless password/security key as
the existing wireless network.

16
5.Please click “Save”to reboot the device and activate the configuration.
6.Please wait a moment until the BR-6428nS V5 is ready.
7.When the setup is complete. Please close the browser window.
8.The BR-6428nS V5 is working and ready for use. You can now connect to
the device’s new SSID. Please refer to IV-2. Connecting to a Wi-Fi network
if you require more guidance.

17
II-4. Access Point Mode
1. Connect the yellow LAN port of your BR-6428nS V5 to the LAN port of
your existing router using an Ethernet cable, and then log on to
http://192.168.2.1.
2. Select “AP” mode and click “NEXT”.
3. Confirm the configuration details for your wireless network, then click
“NEXT” to continue.
