EKOM DK50-10 Series User manual

User manual
EN
DK50-10
Benutzerhandbuch
DE
Manuel de l’utilisateur
FR
Návod na
p
oužitie
SK
Р
у
ково
д
ство пользователя
RU
Návod k
p
oužití
CS
Instrukcja obsługi
PL

08/2017 - 1 - NP-DK50-1_08-2017-MD
CONTENTS................................. 2
INHALT....................................... 30
SOMMAIRE................................ 58
СОДЕРЖАНИЕ.......................... 86
SPIS TREŚCI.............................. 114
OBSAH………............................. 142
OBSAH………............................. 170
Ed. - 1

DK50-10
NP-DK50-1_08-2017-MD - 2 - 08/2017
CONTENTS
IMPORTANT INFORMATION .................................................................................................................3
1.CE MARKING ............................................................................................................................3
2.WARNINGS ................................................................................................................................3
3.WARNINGS AND SYMBOLS .....................................................................................................4
4.STORAGE AND TRANSPORT................................................................................................... 5
5.TECHNICAL DATA .....................................................................................................................6
6.PRODUCT DESCRIPTION.........................................................................................................9
7.PRODUCT FUNCTIONALITY................................................................................................... 11
8.PNEUMATIC SCHEMATIC....................................................................................................... 15
OPERATION..........................................................................................................................................16
9.SWITCHING THE COMPRESS OR ON...................................................................................16
INSTALLATION.....................................................................................................................................17
10.CONDITIONS FOR USE ..........................................................................................................17
11.PLACEMENT OF THE COMPRESSOR................................................................................... 18
12.PNEUMATIC CONNECTIONS .................................................................................................19
13.ELECTRICAL CONNECTIONS ................................................................................................19
14.CONNECTION SCHEMATIC.................................................................................................... 20
15.COMMISSIONING ....................................................................................................................22
16.SWITCHING THE COMPRESSOR ON.................................................................................... 22
17.COMPRESSOR SHUT-DOWN................................................................................................. 22
MAINTENANCE ....................................................................................................................................23
18.EQUIPMENT MAINTENANCE .................................................................................................23
TROUBLESHOOTING ..........................................................................................................................28
19.REPAIR SERVICE.................................................................................................................... 29
20.STORAGE.................................................................................................................................29
21.DISPOSING OF THE APPLIANCE...........................................................................................29
ANNEX ................................................................................................................................................198
22.INSTALLATION RECORD...................................................................................................... 198

DK50-10
08/2017 - 3 - NP-DK50-1_08-2017-MD
IMPORTANT INFORMATION
1. CE MARKING
Products labeled with the CE mark of compliance meet the safety guidelines (93/42/EEC) of the European
Union.
2. WARNINGS
The product is designed and manufactured to be safe for the user and its surrounding environment when
used in the defined manner. Keep the following warnings in mind. This keeps risks to a minimum.
2.1. General warnings
The user manual aids in correct installation, operation and maintenance of the product. It is included with
the product and must be kept close to it at all times. Careful review of this manual will provide the
information necessary for correct operation of the product.
Original packaging should be kept for the return of the equipment. Only the original packaging ensures
protection of the equipment during transport. If it is necessary to return the product during the warranty
period, the manufacturer is not liable for damages caused by improper packaging.
This warranty does not cover damages originating from the use of accessories or consumables other
than those specified or suggested by the manufacturer.
The manufacturer only guarantees the safety, reliability and function of the equipment if:
- installation, new settings, changes, expansion and repairs are performed by the manufacturer or a
service provider authorized by the manufacturer.
- the product is used pursuant to the user manual.
The user manual corresponds to the configuration of the product and its compliance with applicable
safety and technical standards at the time of its printing. The manufacturer reserves all rights for the
protection of its configuration, methods and names.
Translation of the user manual is performed in accordance with the best available knowledge. The
Slovak version is to be used in the event of any uncertainties.
2.2. General safety warnings
The manufacturer designed and manufactured the product to mitigate all risks when used correctly. Please
note the following safety measures to mitigate residual risks.
Use and operation of the product must comply with all local codes and regulations. The operator and
user are responsible for following all appropriate regulations in the interests of performing work safely.
Only the use of original parts guarantees the safety of operating personnel and flawless operation of the
product itself. Only accessories and parts mentioned in the technical documentation or expressly
approved by the manufacturer may be used.
The operator must ensure the equipment is functioning correctly and safely before every use.
The user must fully understand the operation of the equipment.
Do not use the product in explosive environments.
The user must inform the supplier immediately if any problem occurs during use of the equipment.

DK50-10
NP-DK50-1_08-2017-MD - 4 - 08/2017
2.3. Electrical system safety warnings
The equipment may only be connected to a properly installed socket connected to earth (grounded).
Before the product is plugged in, make sure that the mains voltage and frequency stated on the product
are the same as the power mains.
Check for any damage to the connected compressed air system and electrical circuit before use.
Replace damaged pneumatic and electrical conductors immediately.
Immediately disconnect the product from the mains (remove the power cord from the socket) in
hazardous situations or when a technical malfunction occurs.
Ensure the following during any maintenance and repairs:
- the mains plug is pulled out from the power socket
- pressure is vented from the compressed air lines and the air tank
Only a qualified technician may install the product.
3. WARNINGS AND SYMBOLS
The following labels and symbols are used in the user manual and on the equipment and its packaging to
indicate important details and information:
Information, instructions and cautions for the prevention of damage to health or
materials
Caution! Dangerous electric voltage
Read the user manual!
CE mark of compliance
Caution! Hot surface
Compressor is remote-controlled and may start without warning
Earth (ground) connection
Terminal for ground connection
Fuse
Alternating current
Handling mark on package – FRAGILE
Handling mark on package – THIS SIDE UP
Handling mark on package – KEEP DRY
Handling mark on package – TEMPERATURE LIMITATIONS
Handling mark on package – LIMITED STACKING
Mark on package – RECYCLABLE MATERIAL

DK50-10
08/2017 - 5 - NP-DK50-1_08-2017-MD


4. STORAGE AND TRANSPORT
The compressor is shipped in cardboard that protects the appliance from damage during transport.
Caution! For transport, always use the original packaging and secure the compressor in
the upright position.
Protect the compressor from humidity and extreme temperatures during transport and storage. A
compressor in its original packaging can be stored in a warm, dry and dust-free area. Do not
store near any chemical substances.
Keep packaging material if possible. If not, please dispose of the packaging material in an
environmentally friendly way and recycle if possible.
Caution! Before moving or transporting the compressor, release all the air pressure from
the tank and hoses and drain the condensed water.
Ambient conditions for storage and transport
Products may only be stored and transported in vehicles that are free of any traces of volatile chemicals
under the following conditions:
Temperature: –25°C to +55°C, 24 h at up to +70°C
Relative humidity: 10% to 90% (non-condensing)

DK50-10
NP-DK50-1_08-2017-MD - 6 - 08/2017
5. TECHNICAL DATA
Compressors are designed for dry and ventilated indoor environments with the following conditions:
Temperature : +5°C až +40°C,
Max. relative humidity.: 70%,
Max. absolute humidity. 15 g/m3
Tab.1
5 – 7 bar DK50-10 Z DK50-10 S DK50-10 Z/M
DK50-10 S/M
Nominal voltage / frequency (*) V / Hz 230 / 50/60
115 / 60
230 / 50/60
115 / 60
230 / 50/60
115 / 60
230 / 50/60
115 / 60
Output
at 5 bar Lit.min-1 75 / 85 85
75 / 85
85
58 / 68
68
58 / 68
68
Working pressure (**) bar 5.0 – 7.0 5.0 – 7.0 5.0 – 7.0 5.0 – 7.0
Output with KJF-1
at 5 bar Lit.min-1 75 / 85
85
75 / 85
85 - -
Max. current A 3.8 / 4.8
9.5
3.8 / 4.8
9.5
4.1 / 5.1
10
4.1 / 5.1
10
Motor output kW 0.55 0.55 0.55 0.55
Air tank volume Lit. 10 10 10 10
Air quality – filtration m - - 0.3 0.3
Maximum operating pressure of
safety valve bar 8.0 8.0 8.0 8.0
Noise level at 5 bar LpfA [dB] 65 / 66.5
66.5
49.5 / 51
51
67 / 68.5
68.5
51.5 / 53
53
Operating mode 100% - S 1 100% - S 1 100% - S 1 100% - S 1
PDP - drying performance at 7
bar - - +3°C +3°C
Time to fill air tank from 0 to 6
bar s 50 / 44
44
50 / 44
44
70/60
60
70/60
60
Dimensions (net) w x d x h mm 485x350x553 580x440x655 544x350x553 649x440x655
Net weight kg 38 (***) 53 (***) 44 61
Configuration per
EN 60601-1 Type B, class I.
Notices:
(*) When ordering, state the version of compressor
(**) Range of pressure: consult with contractor
(***) Weight of compressors with a KJF1 unit _add 3 kg
(****) The permitted operating pressure of the safety valve can also be set to another value, e.g. 9 bar /
the setting shall be specified in the order.

DK50-10
08/2017 - 7 - NP-DK50-1_08-2017-MD
Tab. 2
6 – 8 bar DK50-10 Z DK50-10 S DK50-10 Z/M
DK50-10 S/M
Nominal voltage / frequency (*) V / Hz 230 / 50/60
115 / 60
230 / 50/60
115 / 60
230 / 50/60
115 / 60
230 / 50/60
115 / 60
Output
at 6 bar Lit.min-1 70 / 80 80
70 / 80
80
60 / 70
70
60 / 70
70
Working pressure (**) bar 6.0 – 8.0 6.0 – 8.0 6.0 – 8.0 6.0 – 8.0
Output with KJF-1
at 6 bar Lit.min-1 70 / 80
80
70 / 80
80 - -
Max. current A 3.9 / 4.9
9.8
3.9 / 4.9
9.8
4.1 / 5.1
10.2
4.1 / 5.1
10.2
Motor output kW 0.55 0.55 0.55 0.55
Air tank volume 10 10 10 10
Air quality – filtration m - - 0.3 0.3
Maximum operating pressure of
safety valve bar 12.0 12.0 12.0 12.0
Noise level at 5 bar LpfA [dB] 65 / 66.5
66.5
49.5 / 51
51
67 / 68.5
68.5
51.5 / 53
53
Operating mode 100% - S 1 100% - S 1 100% - S 1 100% - S 1
PDP drying performance at 7
bar - -
+3°C +3°C
Time to fill air tank from 0 to 7
bar s 60 / 51 51
60/51
51
72/61
61
72/61
61
Dimensions (net) w x d x h mm 485x350x553 580x440x655 544x350x553 649x440x655
Net weight kg 38 (***) 53 (***) 44 61
Configuration per
EN 60601-1
Type B, class I.
Notices:
(*) When ordering, state the version of compressor
(**) Range of pressure: consult with contractor
(***) Weight of compressors with a KJF1 unit _add 3 kg
(****) The permitted operating pressure of the safety valve can also be set to another value, e.g. 9 bar /
the setting shall be specified in the order.

DK50-10
NP-DK50-1_08-2017-MD - 8 - 08/2017
Tab. 3
8 – 10 bar DK50-10 Z DK50-10 S DK50-10 Z/M
DK50-10 S/M
Nominal voltage / frequency (*) V / Hz 230 / 50/60
115 / 60
230 / 50/60
115 / 60
230 / 50/60
115 / 60
230 / 50/60
115 / 60
Output
at 8 bar Lit.min-1 60 / 70 70
60 / 70
70
50 / 60
60
50 / 60
60
Working pressure (**) bar 8.0 – 10.0 8.0 – 10.0 8.0 – 10.0 8.0 – 10.0
Output with KJF-1
at 8 bar Lit.min-1 60 / 70
70
60 / 70
70 - -
Max. current A 4.1 / 5.1
10.2
4.1 / 5.1
10.2
4. / 5.3
10.5
4.4 / 5.4
10.5
Motor output kW 0.55 0.55 0.55 0.55
Air tank volume 10 10 10 10
Air quality – filtration m - - 0.3 0.3
Maximum operating pressure of
safety valve bar 12.0 12.0 12.0 12.0
Noise level at 5 bar LpfA [dB] 65 / 66.5
66.5
49.5 / 51
51
67 / 68.5
68.5
51.5 / 53
53
Operating mode 100% - S 1 100% - S 1 100% - S 1 100% - S 1
PDP drying performance at 7
bar - -
+3°C +3°C
Time to fill air tank from 0 to 9
bar s 85/75 75
85/75
75
96/82
82
96/82
82
Dimensions (net) w x d x h mm 485x350x553 580x440x655 544x350x553 649x440x655
Net weight kg 38 (***) 53 (***) 44 61
Configuration per
EN 60601-1
Type B, class I.
Notices:
(*) When ordering, state the version of compressor
(**) Range of pressure: consult with contractor
(***) Weight of compressors with a KJF1 unit _add 3 kg
(****) The permitted operating pressure of the safety valve can also be set to another value, e.g. 9 bar /
the setting shall be specified in the order.

DK50-10
08/2017 - 9 - NP-DK50-1_08-2017-MD
DK50-10 Z
DK50-10 Z/M DK50-10 S DK50-10 S/M
5.1. Free air delivery (FAD) correction due to elevation
FAD correction table
FAD output related to conditions:
Elevation: 0 MASL Temperature : 20°C
Atmospheric pressure : 101325 Pa Relative humidity : 0%
6. PRODUCT DESCRIPTION
6.1. Model variations and their uses
The compressor is used as a source of clean, oil-free compressed air to power dental equipment,
instruments and devices in laboratories where the parameters and properties of the compressed air are
suitable to the specific application.
Compressed air supplied by the compressor is unsuitable for use with artificial lung
ventilation devices without further filtration
Any use of the equipment outside the framework defined herein is considered inappropriate use. The
manufacturer is not liable for any damages or injury occurring as a result of inappropriate use.
6.2. Description
Compressor models are designed for the following uses:
DK50-10 Z compressor - a base-mounted compressor for stand-alone installation in a given space
DK50-10 Z/K compressor - a base-mounted compressor with a condensate and filtration unit (KJF1)
DK50-10 Z/M compressor - a base-mounted compressor with an air dryer
DK50-10 S compressor - an enclosed compressor with effective noise dampening for in-office installations
DK50-10 S/K compressor - an enclosed compressor with a condensate and filtration unit (KJF1)
DK50-10 S/M compressor - an enclosed compressor with an air dryer
Elevation [mamsl] 0 - 1500 1501 - 2500 2501 - 3500 3501 - 4500
FAD [l/min] FAD x 1 FAD x 0.8 FAD x 0.71 FAD x 0.60

DK50-10
NP-DK50-1_08-2017-MD - 10 - 08/2017
6.3. Accessories
Accessories not included in the standard order must be ordered separately!
6.3.1 Automatic condensate drain
The automatic condensate drain (AOK) automatically drains condensate from the compressor’s air tank
based on a pre-set time interval. The condensate drain (AOK) is a suitable accessory for compressor
models without dryers.
6.3.2 Set of filters
Compressors may be equipped with a set of filters on the compressed air outlet if specified. The set of filters
may be equipped with a pressure regulator. Sets of filters are suitable accessories for all the compressors
specified above.
NOTE : If a higher level of air filtration is required, this specification must be agreed upon with the supplier
and made clear in the order.
6.3.3 Condensation and filtration unit (KJF)
The compressor may additionally be fitted with a condensation and filtration unit (KJF-1 or KJFR-1). The
KJF-1 or KJFR-1 ensure that the compressed air from the air tank is cooled in the cooler and the
condensate is captured in the filter and automatically separated from the compressed air circuit. The
compressed air is filtered at the same time.
SET OF
FILTERS
Level of filtration Pressure regulator Kit article no.
- Yes 604013245-000
5µm 604013233-000
0,3µm No 604013234-000
0,01µm 604013235-000
Condensation and
filtration unit Level of filtration Pressure
regulator Kit article no.
KJF-1 5µm No 450001011-001
KJFR-1 Yes 450001011-002

DK50-10
08/2017 - 11 - NP-DK50-1_08-2017-MD
7. PRODUCT FUNCTIONALITY
Compressor (Fig. 1)
The compressor aggregate (1) draws in air through an inlet filter (8) and compresses it through a check
valve (3) into an air tank (2) from which the appliance draws compressed air. If the pressure in the air tank
drops to the switching pressure, the pressure switch (4) turns on the compressor and the compressor
supplies compressed air to the air tank until it reaches the switch off pressure, at which time the compressor
switches off. The pressure hose is vented through the relief solenoid valve (13) once the compressor unit is
shut off. The safety valve (5) prevents the pressure in the air tank from rising above the maximum allowed
value. The drain valve (7) drains condensate from the air tank. Compressed, oil-free filtered air is stored in
the air tank ready for use.
Condensate must be drained from the air tank at regular intervals (see Chapter 18).
Compressor with membrane dryer. (Fig. 3)
The compressor aggregate (1) draws in air through an inlet filter (8) and compresses it, feeding it to the
cooler (14) through the filter (15) to the dryer (9) and the dry, clean air is then fed through the check valve
(3) into the air tank (2). A portion of the air bypasses the dryer with the captured moisture, which is
manifested as a gentle stream of air along the body of the dryer (9). Condensate from the filter is
automatically drained at regular intervals into the vessel via the condensate drain solenoid valve (16). The
dryer ensures continuous drying of the compressed air. The drain valve (7) drains condensate from the air
tank when drying performance is checked. Compressed, oil-free filtered air is stored in the air tank ready for
use.
The compressor with dryer requires no operator. The pressure vessel does not need to be drained.
Compressor with condensate and filtration unit (Fig. 2)
The compressor aggregate (1) draws in air through an inlet filter (8) and compresses it through a check
valve (3) into an air tank (2). Compressed air from the air tank flows through a cooler (10) that cools the
compressed air. The condensed moisture is trapped in the filter (11) and automatically separates as
condensate (12) into the vessel. Compressed, oil-free filtered air is ready for use.
Condensate must be drained from the air tank at regular intervals (see Chapter 18).
Compressor enclosure
The soundproof enclosure is compact and allows sufficient cooling air exchange. The design makes it
suitable for in-office installations in a way that blends in with other furniture. The fan under the compressor
aggregate ensures sufficient cooling for the compressor and runs with the compressor motor or when the
temperature switch is activated at temperatures above 40 °C.
Make sure that nothing impedes the free flow of air under and around the compressor.
Never cover the hot air outlet on the top back side of the case.
If placing the compressor on a soft floor such as carpet, create space for ventilation
between the base and floor or the box and floor, e.g. underpin the footings with hard
pads.
The 10 bar compressor model is equipped with an hour meter (Fig. 4).

DK50-10
NP-DK50-1_08-2017-MD - 12 - 08/2017
Fig. 1 - DK50-10 Z - Compressor
Fig. 2 – DK50-10 Z/K - Compressor with KJF1 condensate and filtration unit
Description for Figures 1-4
1. Compressor aggregate
2. Air tank
3. Check valve
4. Pressure switch
5. Safety valve
6. Pressure gauge
7. Drain valve
8. Inlet filter
9. Dryer
10. Pipe cooler
11. Filter
12. Condensate outlet
13. Solenoid valve
14. Dryer cooler
15. Filter
16. Valve with timer
17. Compressed air outlet
18. Breaker switch
19. Vessel
20. Magnetic bracket
21. Fan
22. Switch
23. Hour Meter
24. Connector
25. Box fan

DK50-10
08/2017 - 13 - NP-DK50-1_08-2017-MD
Fig. 3 - DK50-10 Z/M - Compressor with dryer

DK50-10
NP-DK50-1_08-2017-MD - 14 - 08/2017
Fig. 4 - Compressor DK50-10 S/M - 10bar

DK50-10
08/2017 - 15 - NP-DK50-1_08-2017-MD
78
9
4
6
3
12
5
10
11
14
13
15
16
3
12
3
12
78
9
4
6
5
10
11
8. PNEUMATIC SCHEMATIC
DK50-10Z, DK50-10S
DK50-10Z/M, DK50-10S/M
Legend for compressed air schematics
1. Inlet filter
2. Compressor
3. Fan
4. Relief valve
5. Noise muffler
6. Check valve
7. Pressure gauge
8. Pressure switch
9. Safety valve
10. Air tank
11. Drain valve
12. Cooler
13. Coalescence filter
14. Membrane dryer
15. Condensate tank
16. Condensate drain solenoid valve

DK50-10
NP-DK50-1_08-2017-MD - 16 - 08/2017
Fig.5



OPERATION
In case of emergency, disconnect the compressor from the mains (pull out the mains
plug).
The compressor has hot surfaces.
Burns or fire may result if contact is made.
During prolonged operation of the compressor, the temperature in the box may increase
to over 40°C. At this point the cooling fan automatically switches on. After cooling the
space to under 32°C, the ventilator switches off.
Automatic start: when pressure in the tank drops to the pressure switch’s lower limit
level, the compressor automatically switches on. The compressor automatically switches
off after reaching the pressure switch’s upper limit level.
The working pressure settings for the pressure switch set by the manufacturer cannot be changed.
Compressor operation at a working pressure below the switching pressure indicates high air usage by the
attached appliance (see the Malfunctions chapter)
Required drying performance can only be achieved when following the defined operating
conditions!
Drying performance will decline and the achieved dew point will drop if the dryer is
operated at any pressure below the minimum working pressure!
The dryer will suffer damage if operated at ambient temperatures above the maximum
working temperature!
9. SWITCHING THE COMPRESSOR ON
(Fig. 5)
Turn the compressor on at the pressure switch (2) by rotating the
main switch (3) to the “I” position. Check the position of the breaker
switch, it must be in the “I” position. If it is in the “0” position, turn
the switch to the “I” position (Fig.3 – position 18). The switch (Fig. 4
– position 22) in the case of DK50-10 S/M 10bar compressors is on
the front side of the enclosure; the indicator lights up green. The
compressor switches on and begins to fill the air tank until the
pressure reaches the switching pressure and the pressure switch
turns the compressor off. The compressor then operates in
automatic mode and is controlled by the on and off pressure
settings on the pressure switch based on compressed air usage.
This pressure may be monitored on the pressure gauge (5). A
tolerance of 10% is acceptable. The pressure in the air tank may
not exceed the permitted operating pressure.
Changing the switching pressures on the pressure
switch is prohibited on any compressor.
The pressure switch (2) has been set by the manufacturer and further setting of switching on and off
pressure may be carried out only by a qualified expert trained by the manufacturer.
Fi
g
. 8
3
25

DK50-10
08/2017 - 17 - NP-DK50-1_08-2017-MD

INSTALLATION
10. CONDITIONS FOR USE
Compressors may only be installed and operating in dry, well-ventilated and clean environments with
environmental parameters that meet the requirements specified in Chapter 5, Technical data. The
compressor must be installed so that it is accessible at all times for operating and maintenance. Please
ensure that the nameplate on the device is readily accessible.
The compressor must stand on a flat, sufficiently stable base (be aware of the weight of the compressor,
see Chapter 5, Technical data).
Compressors may not be operated outdoors or in otherwise wet or damp environments. Do not use the
compressor in the presence of explosive gases, dust or flammable liquids.
Before connecting the compressor to medical equipment, the supplier must confirm that it meets all
requirements for its use. Refer to the technical data of the product for this purpose. When a unit is to be
built-in, classification and evaluation of compatibility must be done by the manufacturer or supplier of the
product to be used.
Any use other than that described in this manual is not covered by the guarantee, and the manufacturer is
not liable for any damages that may result. The operator/user assumes all risk.
Only a qualified professional may install the compressor and place it into operation for
the first time. This professional is obliged to train operating staff as to the use and
maintenance of the equipment. Installation and training of all operators shall be confirmed
by the installer’s signature on the certificate of installation.
Prior to installation, ensure that the compressor is free of all transport packaging and
stabilizers to avoid any risk of damage to the product.
Caution! When in operation, the compressor is hot. Burns or fire may result if contact is
made by the operator or any flammable material.
Ambient operating conditions
Temperature: +5°C to +40°C,
Max. relative humidity: 70%,
Max. absolute humidity: 15 g/m3.

DK50-10
NP-DK50-1_08-2017-MD - 18 - 08/2017
Fig.7
Fig.6
11. PLACEMENT OF THE COMPRESSOR
The equipment shall only be installed by a qualified professional.
Unwrap the compressor from the packaging.
11.1. Handling and releasing the compressor
Position the compressor at the site of future operation (Fig. 6)
Remove the transport stabilisers from the aggregates. (Fig. 7)
Remove all devices used to secure the compressors once the compressor set has been installed
and mounted at the site of final installation!
