EKOM DK50-10 Z User manual

DK50-10
05/2019 - 1 - NP-DK50-10-7_05-2019-MD
CONTENTS
IMPORTANT INFORMATION................................................................................................................. 2
CONFORMITY WITH THE REQUIREMENTS OF EUROPEAN UNION DIRECTIVES ............ 2
INTENDED USE......................................................................................................................... 2
CONTRAINDICATIONS AND SIDE-EFFECTS.......................................................................... 2
WARNINGS AND SYMBOLS..................................................................................................... 2
WARNINGS................................................................................................................................ 3
STORAGE AND TRANSPORT .................................................................................................. 5
TECHNICAL DATA..................................................................................................................... 6
PRODUCT DESCRIPTION ...................................................................................................... 12
PRODUCT FUNCTIONALITY .................................................................................................. 13
PNEUMATIC DIAGRAM.......................................................................................................... 17
INSTALLATION .................................................................................................................................... 18
CONDITIONS FOR USE.......................................................................................................... 18
PLACEMENT OF THE COMPRESSOR .................................................................................. 19
PNEUMATIC CONNECTIONS................................................................................................. 20
ELECTRICAL CONNECTIONS................................................................................................ 20
CONNECTION DIAGRAM........................................................................................................ 22
OPERATION ......................................................................................................................................... 24
COMMISSIONING.................................................................................................................... 24
SWITCHING THE COMPRESSOR ON ................................................................................... 25
COMPRESSOR SHUT-DOWN ................................................................................................ 25
MAINTENANCE.................................................................................................................................... 26
DEVICE MAINTENANCE ......................................................................................................... 26
TROUBLESHOOTING.......................................................................................................................... 32
REPAIR SERVICE.................................................................................................................... 33
STORAGE ................................................................................................................................ 33
DISPOSAL OF THE DEVICE................................................................................................... 33
ANNEX ................................................................................................................................................ 232
INSTALLATION RECORD...................................................................................................... 232

DK50-10
NP-DK50-10-7_05-2019-MD - 2 - 05/2019
IMPORTANT INFORMATION
CONFORMITY WITH THE REQUIREMENTS OF EUROPEAN UNION DIRECTIVES
This product conforms to the requirements of the Medical Device Directive (93/42/EEC) and the
Machinery Directive (2006/42/EC), and is safe for the intended use if all safety instructions are
followed.
INTENDED USE
The compressor is used as a source of clean, oil-free compressed air to power dental unit,
instruments, and devices in laboratories where the parameters and properties of the compressed
air are suitable for the specific application.
Compressed air supplied by the compressor is unsuitable for use with artificial
lung ventilation devices without further filtration
Any other use of the product beyond its intended use is considered an incorrect use. The
manufacturer is not liable for any damages or injuries resulting from the incorrect use.
CONTRAINDICATIONS AND SIDE-EFFECTS
There are no contraindications or side-effects known.
WARNINGS AND SYMBOLS
The following symbols are used in the user manual, device and its packaging to denote important
details and information:
General warnings
Warning
Danger, electric shock hazard
Read the user manual!
CE-marking
Compressor is controlled automatically and may start without warning
Caution! Hot surface
Ground connection
Terminal for ground connection
Alternating current

DK50-10
05/2019 - 3 - NP-DK50-10-7_05-2019-MD
Handling mark on package –FRAGILE
Handling mark on package –THIS SIDE UP
Handling mark on package –KEEP DRY
Handling mark on package –TEMPERATURE LIMITATIONS
Handling mark on package –LIMITED STACKING
Mark on package –RECYCLABLE MATERIAL
Manufacturer
WARNINGS
The product is designed and manufactured to be safe for the user and the surrounding environment
when used in the defined manner. Keep the following warnings in mind.
General warnings
READ THE USER MANUAL CAREFULLY BEFORE USING THE DEVICE AND KEEP IT FOR
FUTURE USE!
The user manual supports the correct installation, operation and maintenance of the product.
Careful review of this manual will provide the information necessary for the correct operation of
the product for its intended use.
Original packaging should be retained for the return of the device. Only the original packaging
ensures protection of the device during transport. If it is necessary to return the product during
the warranty period, the manufacturer is not liable for damages caused by improper packaging.
This warranty does not cover damages originating from the use of accessories other than those
specified or recommended by the manufacturer.
The manufacturer only guarantees the safety, reliability and function of the device if:
installation, new settings, changes, expansion, and repairs are performed by the
manufacturer or an organisation authorised by the manufacturer.
the product is used pursuant to the user manual.
The user manual corresponds to the configuration of the product and its compliance with the
applicable safety and technical standards at the time of printing. The manufacturer reserves all
rights for the protection of its configuration, methods and names.
Translation of the user manual is performed in accordance with the best available knowledge.
The Slovak version is to be used in the event of any uncertainties.

DK50-10
NP-DK50-10-7_05-2019-MD - 4 - 05/2019
General safety warnings
The manufacturer designed and manufactured the product to minimise all risks when used correctly
for the intended use. The manufacturer considers it its obligation to lay down the following general
safety precautions.
Use and operation of the product must comply with all laws and local regulations valid in the
place of use. The operator and user are responsible for following all the appropriate regulations
in the interests of performing work safely.
Only the use of original parts guarantees the safety of operating personnel and the flawless
operation of the product itself. Only the accessories and parts mentioned in the technical
documentation or expressly approved by the manufacturer should be used.
The operator must ensure that the device is functioning correctly and safely before every use.
The user must be familiar with the operation of the device.
Do not use the product in environments with a risk of explosion.
The user must inform the supplier immediately if any problem directly related to the operation of
the device occurs.
Safety warnings on protection from electric current
The device must only be connected to a properly installed, earthed socket.
Before the product is plugged in, ensure that the mains voltage and frequency stated on the
product are in compliance with the values of the mains.
Prior to putting the device into operation check for any damage to the connected pneumatic lines
and electrical wiring. Replace damaged pneumatic lines and electrical wirings immediately.
Immediately disconnect the product from the mains (remove power cord from the socket) in
hazardous situations or in the case of a technical malfunction.
During all repairs and maintenance, ensure that:
-the mains plug is removed from the power socket
-pressure is vented from the air tank and pipes
The product shall only be installed by a qualified technician.

DK50-10
05/2019 - 5 - NP-DK50-10-7_05-2019-MD


STORAGE AND TRANSPORT
The compressor is shipped from the factory in a transport packaging. This protects the device from
damage during transport.
The original compressor packaging must be used for transport whenever possible.
Transport the compressor in an upright position, always secured with transport
fixation.
Protect the compressor from moisture, dirt and extreme temperatures during transport
and storage. Store the compressor in its original packaging in a warm, dry, and dust-free
area. Do not store near any chemical substances.
Keep the packaging material, if possible. If not, please dispose of the packaging material
in an environmentally-friendly way. Packaging cardboard can be recycled with old paper.
The compressor may only be transported when all air pressure has been vented.
Before moving or transporting the compressor, release all air pressure from the
tank and hoses and drain condensate from the air tank.
Storing or shipping the equipment in any conditions other than those specified
below is prohibited.
Ambient conditions for storage and transport
Products may only be stored and transported in vehicles that are free of any traces of volatile
chemicals under the following conditions:
Temperature: –25°C to +55°C, 24 h at up to +70°C
Relative humidity: 10% to 90% (non-condensing)

DK50-10
NP-DK50-10-7_05-2019-MD - 6 - 05/2019
TECHNICAL DATA
Compressors are designed for dry and ventilated indoor environments with the following conditions:
Temperature : +5°C to +40°C,
Max. relative humidity.: 70%,
Max. absolute humidity. 15 g/m3
Tab.1
5 –7 bar
DK50-10 Z
DK50-10 S
DK50-10 Z/M
DK50-10 S/M
Nominal voltage /
frequency (*)
V / Hz
230 /
50/60
115 /
60
230 /
50/60
115 /
60
230 /
50/60
115 /
60
230 /
50/60
115 /
60
Performance at 5 bar
Lit.min-1
75/85
85
75/85
85
58/68
68
58/68
68
Working pressure (**)
bar
5.0 –7.0
5.0 –7.0
5.0 –7.0
5.0 –7.0
Max. current
A
3.8/4.8
8.9
3.8/4.8
8.9
4.1/5.1
9.1
4.1/5.1
9.1
Motor power
kW
0.55
0.55
0.55
0.55
Air tank volume
Lit.
10
10
10
10
Air quality –filtration
m
-
-
0.3
0.3
Maximum operating
pressure of safety valve
bar
8.0
8.0
8.0
8.0
Noise level at 5 bar
LpfA
[dB]
≤64/≤66
≤66
≤46/≤49
≤49
≤65/≤67
≤67
≤49/≤52
≤52
Duty cycle
100%
100%
100%
100%
PDP - drying
performance at 7 bar
-
-
+3°C
+3°C
Time to fill air tank from
0 to 6 bar
s
50/44
44
50/44
44
70/60
60
70/60
60
Dimensions (net)
w x d x h
mm
485x350x553
580x440x655
544x350x553
649x440x655
Net weight (***)
kg
38
53
44
61
Classification under EN 60601-1
Class I.
Notes:
(*) When ordering, state the version of the compressor
(**) For other range of pressure:consult with the supplier
(***) Information about the weight is for informative purposes only and applies to the product without any
additional accessories.

DK50-10
05/2019 - 7 - NP-DK50-10-7_05-2019-MD
Tab. 2
6 –8 bar
DK50-10 Z
DK50-10 S
DK50-10 Z/M
DK50-10 S/M
Nominal voltage /
frequency (*)
V / Hz
230 /
50/60
115 /
60
230 /
50/60
115 /
60
230 /
50/60
115 /
60
230 /
50/60
115 /
60
Performance
at 6 bar
Lit.min-1
70/80
80
70/80
80
60/70
70
60/70
70
Working pressure (**)
bar
6.0 –8.0
6.0 –8.0
6.0 –8.0
6.0 –8.0
Max. current
A
3.9/4.9
9
3.9/4.9
9
4.1/5.1
9.2
4.1/5.1
9.2
Motor power
kW
0.55
0.55
0.55
0.55
Air tank volume
Lit.
10
10
10
10
Air quality –filtration
m
-
-
0.3
0.3
Maximum operating
pressure of safety valve
bar
12.0
12.0
12.0
12.0
Noise level at 5 bar
LpfA [dB]
≤64/≤66
≤66
≤46/≤49
≤49
≤65/≤67
≤67
≤49/≤52
≤52
Duty cycle
100%
100%
100%
100%
PDP drying performance
at 7 bar
-
-
+3°C
+3°C
Time to fill air tank from 0
to 7 bar
s
60/51
51
60/51
51
72/61
61
72/61
61
Dimensions (net)
w x d x h
mm
485x350x553
580x440x655
544x350x553
649x440x655
Net weight (***)
kg
38
53
44
61
Classification under EN 60601-1
Class I.
Notes:
(*) When ordering, state the version of the compressor
(**) For other range of pressure:consult with the supplier
(***) Information about the weight is for informative purposes only and applies to the product without any
additional accessories.

DK50-10
NP-DK50-10-7_05-2019-MD - 8 - 05/2019
Tab. 3
8 –10 bar
DK50-10 Z
DK50-10 S
DK50-10 Z/M
DK50-10 S/M
Nominal voltage /
frequency (*)
V / Hz
230 /
50/60
115 /
60
230 /
50/60
115 /
60
230 /
50/60
115 /
60
230 /
50/60
115 /
60
Performance
at 8 bar
Lit.min-1
60/70
70
60/70
70
50/60
60
50/60
60
Working pressure (**)
bar
8.0 –10.0
8.0 –10.0
8.0 –10.0
8.0 –10.0
Max. current
A
4.1/5.1
9.2
4.1/5.1
9.2
4.3/5.3
9.4
4.4/5.4
9.4
Motor power
kW
0.55
0.55
0.55
0.55
Air tank volume
Lit.
10
10
10
10
Air quality –filtration
m
-
-
0.3
0.3
Maximum operating
pressure of safety
valve
bar
12.0
12.0
12.0
12.0
Noise level at 5 bar
LpfA
[dB]
≤64/≤66
≤66
≤46/≤49
≤49
≤65/≤67
≤67
≤49/≤52
≤52
Duty cycle
100%
100%
100%
100%
PDP drying
performance at 7 bar
-
-
+3°C
+3°C
Time to fill air tank from
0 to 9 bar
s
85/75
75
85/75
75
96/82
82
96/82
82
Dimensions (net)
w x d x h
mm
485x350x553
580x440x655
544x350x553
649x440x655
Net weight (***)
kg
38
53
44
61
Classification under EN 60601-1
Class I.
Notes:
(*) When ordering, state the version of the compressor
(**) For other range of pressure:consult with the supplier
(***) Information about the weight is for informative purposes only and applies to the product without any
additional accessories.

DK50-10
05/2019 - 9 - NP-DK50-10-7_05-2019-MD
Free air delivery (FAD) correction due to elevation
FAD correction table
Elevation [mamsl]
0 - 1500
1501 - 2500
2501 - 3500
3501 - 4500
FAD [l/min]
FAD x 1
FAD x 0.8
FAD x 0.71
FAD x 0.60
FAD („Free Air Delivery“) output related to conditions:
Elevation: 0 MASL Temperature : 20°C
Atmospheric pressure : 101325 Pa Relative humidity : 0%
Electromagnetic compatibility declaration
Medical equipment needs special precautions regarding electromagnetic compatibility (EMC) and
needs to be installed and put into service according to the EMC information provided below.
Guidance and manufacturer's declaration - electromagnetic emissions
Pursuant to IEC 60601-1-2:2014 - Medical electrical equipment - Part 1-2: General requirements for
basic safety and essential performance - Collateral Standard: Electromagnetic disturbances
The equipment is intended for use in the electromagnetic environment specified below. The customer or
the user of the equipment should assure that it is used in such an environment.
Emissions test
Compliance
Electromagnetic environment - guidance
RF emissions CISPR 11
Group 1
The equipment uses RF energy only for its
internal functions. Therefore, the RF emissions
are very low and are not likely to cause any
interference in nearby electronic equipment.
RF emissions CISPR 11
Class B
The equipment is suitable for use in all
establishments, including domestic
establishments and those directly connected to
the public low voltage power supply
network that supplies buildings used for
domestic purposes.
Harmonic emissions IEC
61000-3-2
Class A
Voltage fluctuations/
flicker emissions IEC
61000-3-3
The equipment is not
likely to cause any flicker,
as the current flow is
approx. constant after the
start up.

DK50-10
NP-DK50-10-7_05-2019-MD - 10 - 05/2019
Guidance and manufacturer's declaration - electromagnetic immunity
Pursuant to IEC 60601-1-2:2014 - Medical electrical equipment - Part 1-2: General requirements for
basic safety and essential performance - Collateral Standard: Electromagnetic disturbances
The equipment is intended for use in the electromagnetic environment specified below. The customer or
the user of the equipment should assure that it is used in such an environment.
Immunity test
IEC 60601-1-2
test level
Compliance level
Electromagnetic environment -
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood, concrete
or ceramic tile. If floors are covered
with synthetic material, the relative
humidity should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply
lines
±1 kV for
input/output lines
±2 kV
100 kHz repetition
frequency
Applied to mains
connection
Mains power quality should be
that of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV differential
mode
±2 kV common
mode
±1 kV L-N
±2 kV L-PE; N-PE
Applied to mains
connection
Mains power quality should be that of
a typical commercial or hospital
environment.
Voltage dips,
short interruption,
and voltage
variations on
power
supply
input lines IEC
60601-4-11
UT=0%, 0,5 cycle
(at 0, 45, 90, 135,
180, 225, 270
and 315°)
UT=0%, 1 cycle
UT=70% 25/30
cycles (at 0°)
UT=0%, 250/300
cycles
UT=>95%, 0,5 cycle
(at 0, 45, 90, 135, 180,
225, 270 and 315°)
UT=>95%, 1 cycle
UT=70% (30% dipp
UT),
25(50Hz)/30(60Hz)
cycles (at 0°)
UT=>95%,
250(50Hz)/300(60Hz)
cycle
Mains power quality should be
that of a typical commercial or hospital
environment.
The device stops and restarts
automatically at each dip. In this case
does not occur unacceptable pressure
drop.
Power frequency
(50/60 Hz)
IEC 61000-4-8
N/A
N/A
The equipment does not contain
magnetically sensitive components or
circuits.
NOTE: UTis the A.C. mains voltage prior to application of the test level.

DK50-10
05/2019 - 11 - NP-DK50-10-7_05-2019-MD
Guidance and manufacturer's declaration - electromagnetic immunity
Pursuant to IEC 60601-1-2:2014 - Medical electrical equipment - Part 1-2: General requirements for
basic safety and essential performance - Collateral Standard: Electromagnetic disturbances
The equipment is intended for use in the electromagnetic environment specified below. The customer or
the user of the equipment should assure that it is used in such an environment.
Immunity test
IEC 60601-1-2
test level
Compliance level
Electromagnetic environment - guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
Proximity fields
from RF wireless
communications
equipment
IEC 61000-4-3
3 Vrms
150 kHz to 80MHz
3 V/m
80 MHz to 2,7
GHz
9 to 28 V/m
15 specific
frequencies
(380 to 5800 MHz)
3 Vrms
3 V/m
9 to 28 V/m
15 specific
frequencies
(380 to 5800
MHz)
Portable and mobile RF communications
equipment should be used no closer to any
part of the equipment, including cables,
than the recommended separation distance
calculated from the equation applicable to
the frequency of the transmitter.
Recommended separation distance
d=1,2√ P
d=1,2√ P, 80 MHz to 800 MHz
d=2,3√ P, 800 MHz to 2,7 GHz
where P is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and d is the recommended separation dis-
tance in metres (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey a, should be less than the
compliance level in each frequency range b.
Interference may occur in the vicinity of
equipment marked with the following
symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an
electromagnetic site survey should be considered. If the measured field strength in the location in which
the equipment is used exceeds the applicable RF compliance level above, the equipment should be
observed to verify normal operation. If abnormal performance is observed, additional measures may be
necessary, such as re-orienting or relocating the equipment.
bOver the frequency range 150 kHz to 80 kHz, field strengths should be less than 3 V/m.

DK50-10
NP-DK50-10-7_05-2019-MD - 12 - 05/2019
DK50-10 Z
DK50-10 Z/M
DK50-10 S
DK50-10 S/M
PRODUCT DESCRIPTION
Variants
Compressor models are designed in the following variants:
DK50-10 Z - a base-mounted compressor for stand-alone installation in a given room
DK50-10 Z/M - a base-mounted compressor with an air dryer
DK50-10 S - a compressor in a cabinet with effective soundproofing for in-office installations
DK50-10 S/M - a compressor in a cabinet with an air dryer
Accessories
Accessories not included in the standard order must be ordered separately!
8.2.1. Automatic condensate drain
The automatic condensate drain (AOK) automatically drains condensate from the compressor’s air
tank based on a pre-set time interval. The condensate drain (AOK) is a suitable accessory for
compressor models without dryers.
8.2.2. Regulator set
Compressors may be equipped with a regulator set on the compressed air outlet if specified. The
regulator sets are suitable accessories for all the compressors specified above.
Type
Use
Kit article no.
REG10
DK50-10Z, DK50-10Z/M
447000001-042
Type
Use
Kit article no.
AOK 10
DK50-10Z
447000001-046

DK50-10
05/2019 - 13 - NP-DK50-10-7_05-2019-MD
8.2.3. Filters set
Compressors may be equipped with a filters set on the compressed air outlet if specified. The set of
filters may be equipped with a pressure regulator. Filters set are suitable accessories for all the
compressors specified above.
NOTE : If a higher level of air filtration is required, this specification must be agreed on with the
supplier and made clear in the order.
Type
Use
Level of filtration
(µm)
Pressure regulator
Kit article no.
FS 20FR
DK50-10Z
5
yes
447000001-043
FS 20M
5+ 0.3
no
447000001-044
FS 20MR
5+ 0.3
yes
447000001-071
FS 20S
5+ 0.3 + 0.01
no
447000001-045
FS 20SR
5+ 0.3 + 0.01
yes
447000001-072
FS 21S
DK50-10Z/M
0.3 + 0.01
no
447000001-075
FS 21SR
0.3 + 0.01
yes
447000001-076
8.2.4. Condensation and filtration unit (KJF)
The compressor may be additionally fitted with a condensation and filtration unit (KJF-1 or KJFR-1).
The KJF-1 or KJFR-1 ensure that the compressed air from the air tank is cooled in the cooler and
the condensate is captured in the filter and automatically separated from the pneumatic distribution
system. The compressed air is filtered at the same time.
PRODUCT FUNCTIONALITY
Compressor (Fig. 1)
The air pump (1) draws in atmospheric air through an inlet filter (8) and compresses it through a
non-return valve (3) into an air tank (2) from which the device draws compressed air. If the pressure
in the air tank drops to the switch-on pressure, the pressure switch (4) turns on the compressor and
the compressor supplies compressed air into the air tank until it reaches the switch-off pressure,
when the compressor switches off. The pressure hose is vented through the relief solenoid valve
(13) once the air pump is shut off. The safety valve (5) prevents the pressure in the air tank from
rising above the maximum allowed value. The drain valve (7) drains condensate from the air tank.
Compressed, oil-free filtered air is stored in the air tank ready for use.
Condensate must be drained from the air tank at regular intervals (see Chapter 19.1).
Compressor with membrane dryer (Fig. 2)
The air pump (1) draws in atmospheric air through an inlet filter (8) and compresses it, feeding it
through the coolers (14) and the filter (15) into the dryer (9) and the dry, clean air is then fed through
the non-return valve (3) into the air tank (2). A part of the air is released from the dryer with the
captured moisture, which is manifested as a light air stream along the body of the dryer (9).
Condensate from the filter is automatically drained at regular intervals into the collecting bottle via
the condensate drain solenoid valve (16). The dryer ensures continuous drying of the compressed
Type
Use
Level of filtration
(µm)
Pressure
regulator
Kit article no.
KJF-1
DK50-10Z
5
no
450001011-001
KJFR-1
yes
450001011-002

DK50-10
NP-DK50-10-7_05-2019-MD - 14 - 05/2019
air. The drain valve (7) drains condensate from the air tank when drying performance is checked.
Compressed, oil-free filtered air is stored in the air tank ready for use.
The pressure vessel does not need to be drained.
Compressor cabinet
The soundproof cabinet provides compact covering of the compressor, allowing sufficient exchange
of cooling air. With its design It can be placed in a dentist’s office as a part of furniture. The fan
under the air pump of a compressor provides cooling of compressor and it is in operation at the
same time with an engine of the compressor. After prolonged use the temperature in the cabinet
may rise above 40°C, causing the cooling fan blower to automatically turn on. After cooling the
cabinet area down to 32°C the fan blower turns off automatically.
Make sure that nothing impedes the free flow of air under and around the
compressor. Never cover the hot air outlet on the top back side of the cabinet.
If placing the compressor on a soft floor such as carpet, create spacefor ventilation
between the base and floor or the cabinet and floor, e.g. underpin the footings with
hard pads.
The 8-10 bar compressor model is equipped with an hour counter (Fig. 3).
Fig. 1 - DK50-10 Z - Compressor
Description for Figures 1-3
1. Air pump
2. Air tank
3. Non-return valve
4. Pressure switch
5. Safety valve
6. Pressure gauge
7. Drain valve
8. Inlet filter
9. Dryer
10. -
11. -
12. -
13. Solenoid valve
14. Dryer cooler
15. Filter
16. Condensate drain
solenoid valve
17. Compressed air outlet
18. Circuit breaker switch
19. Bottle
20. Magnetic holder
21. Fan
22. Switch
23. Hour counter
24. Socket
25. Cabinet fan

DK50-10
05/2019 - 15 - NP-DK50-10-7_05-2019-MD
Fig. 2 - DK50-10Z/M- Compressor with dryer

DK50-10
NP-DK50-10-7_05-2019-MD - 16 - 05/2019
Fig. 3 -Compressor DK50-10 S/M (8-10bar)

DK50-10
05/2019 - 17 - NP-DK50-10-7_05-2019-MD
78
9
4
6
3
12
5
10
11
14
13
15
16
3
12
3
12
78
9
4
6
5
10
11
PNEUMATIC DIAGRAM
DK50-10 Z, DK50-10 S
DK50-10 Z/M, DK50-10 S/M
Legend for compressed air diagram
1. Inlet filter
2. Air pump motor
3. Fan
4. Relief valve
5. Noise silencer
6. Non-return valve
7. Pressure gauge
8. Pressure switch
9. Safety valve
10. Air tank
11. Drain valve
12. Cooler
13. Coalescence filter
14. Membrane dryer
15. Condensate drain bottle
16. Condensate drain solenoid valve

DK50-10
NP-DK50-10-7_05-2019-MD - 18 - 05/2019
INSTALLATION
CONDITIONS FOR USE
Compressors may only be installed and operating in dry, well-ventilated and clean environments
with environmental parameters that meet the requirements specified in Chapter 7, Technical data.
The compressor must be installed so that it is accessible at all times for operating and
maintenance. Please ensure that the label on the device is readily accessible.
The compressor must stand on a flat, sufficiently stable base (be aware of the weight of the
compressor, see Chapter 7, Technical data).
Compressors may not be operated outdoors or in otherwise wet or damp environments. Do not
use the compressor in the presence of explosive gases, dust or flammable liquids.
Before connecting the compressor to medical equipment, the supplier must confirm that it meets
all requirements for its use. Refer to the technical data of the product for this purpose. When a
unit is to be built-in, classification and evaluation of compatibility must be done by the manufacturer
or supplier of the product to be used.
Any other use or use outside this framework is not considered as intended use. The manufacturer
is not responsible for any damages arising from such use. The operator/user assumes all risks.
Only a qualified professional may install the compressor and place it into operation
for the first time. This professional is obliged to train operating staff as to the use
and maintenance of the device. Installation and training of all operators shall be
confirmed by the installer’s signature on the certificate of installation.
Prior to installation, ensure that the compressor is free of all transport packaging
and stabilizers to avoid any risk of damage to the product.
Parts of the air pump may be hot and reach hazardous temperatures during
compressor operation and may pose a contact risk for operators or materials. Burn
or fire hazard! Caution! Hot surface!
Ambient operating conditions
Temperature: +5°C to +40°C,
Max. relative humidity: 70%,
Max. absolute humidity: 15 g/m3.

DK50-10
05/2019 - 19 - NP-DK50-10-7_05-2019-MD
Fig. 5
Fig. 4
PLACEMENT OF THE COMPRESSOR
The device shall only be installed by a qualified professional.
Unwrap the compressor from the packaging.
Handling and releasing the compressor
Position the compressor at the site of future operation (Fig. 4)
Remove the transport securing elements/bolts from the air pumps. (Fig. 5)
Remove all devices used to secure the air pump once the compressor set has been
installed and mounted at the site of final installation!
