EKOM DK50 2V/110 User manual

DK50
User manual
EN
Benutzerhandbuch
DE
N
Návod na použitie
SK
Руководство пользователя
RU

COMPRESSOR
KOMPRESSOR
КОМПРЕССОР
KOMPRESOR
DK50
EKOM spol. s r. o.
Priemyselná 5031/18
SK-921 01 Piešťany
Slovak Republic
tel.: [phone]
fax: [phone]
www.ekom.sk
email: eko[email protected]
DATE OF LAST REVISION
DATUM DER LETZTEN ÜBERARBEITUNG
ДАТА ПОСЛЕДНЕЙ РЕДАКЦИИ
DÁTUM POSLEDNEJ REVÍZIE
06/2020
NP-DK50 simple s DE-4_06-
2020
112000198-000

CONTENTS ........................................................................................ 5
INHALT............................................................................................... 30
ОГЛАВЛЕНИЕ ................................................................................... 55
OBSAH............................................................................................... 80

DK50
06/2020 - 5 - NP-DK50 simple s DE-4_06-2020
CONTENTS
IMPORTANT INFORMATION..................................................................................................6
1. CONFORMITY WITH THE REQUIREMENTS OF EUROPEAN UNION DIRECTIVES.6
2. INTENDED USE...........................................................................................................6
3. CONTRAINDICATIONS AND SIDE-EFFECTS.............................................................6
4. WARNINGS AND SYMBOLS .......................................................................................6
5. WARNINGS..................................................................................................................7
6. STORAGE AND TRANSPORT.....................................................................................9
7. TECHNICAL DATA.....................................................................................................10
8. PRODUCT DESCRIPTION.........................................................................................14
9. FUNCTION.................................................................................................................14
10. PNEUMATIC DIAGRAM.............................................................................................16
INSTALLATION.....................................................................................................................17
11. CONDITIONS FOR USE ............................................................................................17
12. PLACEMENT OF THE COMPRESSOR .....................................................................18
13. PNEUMATIC CONNECTIONS ...................................................................................20
14. ELECTRICAL CONNECTION.....................................................................................20
15. CONNECTION DIAGRAM..........................................................................................21
OPERATION..........................................................................................................................22
16. COMMISSIONING......................................................................................................22
17. SWITCHING THE COMPRESSOR ON ......................................................................23
MAINTENANCE.....................................................................................................................23
18. DEVICE MAINTENANCE ...........................................................................................23
TROUBLESHOOTING...........................................................................................................28
19. REPAIR SERVICE......................................................................................................29
20. STORAGE..................................................................................................................29
21. DISPOSING OF THE DEVICE....................................................................................29
ANNEX ................................................................................................................................105
22. INSTALLATION RECORD........................................................................................105

DK50
NP-DK50 simple s DE-4_06-2020 - 6 - 06/2020
IMPORTANT INFORMATION
1. CONFORMITY WITH THE REQUIREMENTS OF EUROPEAN UNION DIRECTIVES
This product conforms to the requirements of the Medical Device Directive (93/42/EEC), and is
safe for the intended use if all safety instructions are followed.
2. INTENDED USE
Compressor is the source of clean, oil-free compressed air used to drive dental devices and
equipment.
Compressed air supplied by the compressor is unsuitable for use with artificial
lung ventilation devices without further filtration.
Any other use of the product beyond its intended use is considered an incorrect use. The
manufacturer is not liable for any damages or injuries resulting from the incorrect use.
3. CONTRAINDICATIONS AND SIDE-EFFECTS
There are no contraindications or side-effects known.
4. WARNINGS AND SYMBOLS
The following symbols are used in the user manual, device and its packaging to denote important
details and information:
General warnings
Warning
Danger, electric shock hazard
Read the operating instructions
Refer to instruction manual
CE-marking
Compressor is controlled automatically and may start without warning
Caution! Hot surface
Ground connection
Terminal for ground connection
Fuse

DK50
06/2020 - 7 - NP-DK50 simple s DE-4_06-2020
Condensate drain
Handling mark on package –FRAGILE
Handling mark on package –THIS SIDE UP
Handling mark on package –KEEP DRY
Handling mark on package –TEMPERATURE LIMITATIONS
Handling mark on package –LIMITED STACKING
Mark on package –RECYCLABLE MATERIAL
Manufacturer
5. WARNINGS
The product is designed and manufactured to be safe for the user and the surrounding
environment when used in the defined manner. Keep the following warnings in mind.
5.1. General warnings
READTHE USER MANUAL CAREFULLY BEFORE USING THE DEVICE AND KEEPIT FOR
FUTURE USE!
The user manual supports the correct installation, operation and maintenance of the product.
Careful review of this manual will provide the information necessary for the correct operation of
the product for its intended use.
Original packaging should be retained for the return of the device. Only the original packaging
ensures protection of the device during transport. If it is necessary to return the product during
the warranty period, the manufacturer is not liable for damages caused by improper packaging.
This warranty does not cover damages originating from the use of accessories other than those
specified or recommended by the manufacturer.
The manufacturer only guarantees the safety, reliability and function of the device if:
installation, new settings, changes, expansion, and repairs are performed by the
manufacturer or an organisation authorised by the manufacturer.
the product is used pursuant to the user manual.
The user manual corresponds to the configuration of the product and its compliance with the
applicable safety and technical standards at the time of printing. The manufacturer reserves all
rights for the protection of its configuration, methods and names.
This user manual is the original instructions. Translation is performed in accordance with the
best available knowledge.

DK50
NP-DK50 simple s DE-4_06-2020 - 8 - 06/2020
5.2. General safety warnings
The manufacturer designed and manufactured the product to minimise all risks when used
correctly for the intended use. The manufacturer considers it its obligation to lay down the following
general safety precautions.
Use and operation of the product must comply with all laws and local regulations valid in the
place of use. The operator and user are responsible for following all the appropriate regulations
in the interests of performing work safely.
Only the use of original parts guarantees the safety of operating personnel and the flawless
operation of the product itself. Only the accessories and parts mentioned in the technical
documentation or expressly approved by the manufacturer should be used.
The operator must ensure that the device is functioning correctly and safely before every use.
The user must be familiar with the operation of the device.
Do not use the product in environments with a risk of explosion.
The user must inform the supplier immediately if any problem directly related to the operation of
the device occurs.
5.3. Safety warnings on protection from electric current
The device must only be connected to a properly installed, earthed socket.
Before the product is plugged in, ensure that the mains voltage and frequency stated on the
product are in compliance with thevalues of the mains.
Prior to putting the device into operation check for any damage to the connected pneumatic
lines and electrical wiring. Replace damaged pneumatic lines and electrical wiringsimmediately.
Immediately disconnect the product from the mains (remove power cord from the socket) in
hazardous situations or in the case of a technical malfunction.
During all repairs and maintenance, ensure that:
the mains plug is removed from the power socket
pressure is vented from the air tank and pipes
The product shall only be installed by a qualified technician.

DK50
06/2020 - 9 - NP-DK50 simple s DE-4_06-2020
6. STORAGE AND TRANSPORT
The compressor is shipped from the factory in a transport packaging. This protects the device from
damage during transport.
The original compressor packaging must be used for transport whenever
possible. Transport the compressor in an upright position, always secured with
transport fixation.
Protect the compressor from moisture, dirt and extreme temperatures during transport
and storage. Store the compressor in its original packaging in a warm, dry, and dust-
free area. Do not store near any chemical substances.
Keep the packaging material, if possible. If not, please dispose of the packaging
material in an environmentally-friendly way. Packaging cardboard can be recycled with
old paper.
The compressor may only be transported when all air pressure has been vented.
Before moving or transporting the compressor, release all air pressure from the
tank and hoses and drain condensate from the air tank.
Storing or shipping the equipment in any conditions other than those specified
below is prohibited.
Ambient conditions for storage and transport
Products may only be stored and transported in vehicles that are free of any traces of volatile
chemicals under the following conditions:
Temperature: –25°C to +55°C, 24 h at up to +70°C
Relative humidity: 10% to 90% (non-condensing)

DK50
NP-DK50 simple s DE-4_06-2020 - 10 - 06/2020
7. TECHNICAL DATA
Compressors are designed for dry and ventilated indoor environments with the following
conditions:
Temperature : +5°C to +40°C,
Max. relative humidity.: 70%,
Max. absolute humidity. 15 g/m3
TYPE
DK50
MODEL
standard
Output flow
50 L.min-1 ( 1.8 Cft. min-1 )
Voltage / Frequency /
Nominal current
V/Hz/A
230/50 / 2.8
Air filtration
m
-
Outlet connection
hose coupling
ø6
Sound level
dB(A)
53
Mode of operation
Continuous - S1
Separation of condensed water
Manual
Air tank capacity
4,7 L (1gall UK)
Pressure range
4,5 bar ( 65 psig ) –6 bar ( 87 psig)
Operating pressure of safety valve
7 bar ( 101.5 psig )
Adjustment of output air pressure
-
Dimensions of compressor
w x d x h
440 x 360 x 430 mm (17 x 14 x 17 in )
Dimensions of compressor
with weels
š x h x v
480 x 390 x 505 mm (19 x 15.5 x 19.5 in )
Net weight
30 kg ( 66 lbs )
Net weight of compressor with weels
31 kg ( 68.5 lbs )
Implementation according to
EN 60601-1, EN 12021
class I.
7.1. Free air delivery (FAD) correction due to elevation
FAD correction table
Elevation [mamsl]
0 - 1500
1501 - 2500
2501 - 3500
3501 - 4500
FAD [l/min]
FAD x 1
FAD x 0.8
FAD x 0.71
FAD x 0.60
FAD („Free Air Delivery“) output related to conditions:
Elevation: 0 MASL
Temperature : 20°C
Atmospheric pressure : 101325 Pa
Relative humidity : 0%

DK50
06/2020 - 11 - NP-DK50 simple s DE-4_06-2020
7.2. Electromagnetic compatibility declaration
Medical equipment needs special precautions regarding electromagnetic compatibility (EMC) and
needs to be installed and put into service according to the EMC information provided below.
Guidance and manufacturer's declaration - electromagnetic emissions
Pursuant to IEC 60601-1-2:2014 - Medical electrical equipment - Part 1-2: General requirements for
basic safety and essential performance - Collateral Standard: Electromagnetic disturbances
The equipment is intended for use in the electromagnetic environment specified below. The customer or the
user of the equipment should assure that it is used in such an environment.
Emissions test
Compliance
Electromagnetic environment - guidance
RF emissions CISPR 11
Group 1
The equipment uses RF energy only for its
internal functions. Therefore, the RF emissions
are very low and are not likely to cause any
interference in nearby electronic equipment.
RF emissions CISPR 11
Class B
The equipment is suitable for use in all
establishments, including domestic
establishments and those directly connected to
the public low voltage power supply
network that supplies buildings used for domestic
purposes.
Harmonic emissions IEC
61000-3-2
Class A
Voltage fluctuations/ flicker
emissions IEC 61000-3-3
The equipment is not likely
to cause any flicker, as the
current flow is approx.
constant after the start up.

DK50
NP-DK50 simple s DE-4_06-2020 - 12 - 06/2020
Guidance and manufacturer's declaration - electromagnetic immunity
Pursuant to IEC 60601-1-2:2014 - Medical electrical equipment - Part 1-2: General requirements for
basic safety and essential performance - Collateral Standard: Electromagnetic disturbances
The equipment is intended for use in the electromagnetic environment specified below. The customer or the
user of the equipment should assure that it is used in such an environment.
Immunity test
IEC 60601-1-2
test level
Compliance level
Electromagnetic environment -
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood, concrete
or ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply
lines
±1 kV for
input/output lines
±2 kV
100 kHz repetition
frequency
Applied to mains
connection
Mains power quality should be
that of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV differential
mode
±2 kV common
mode
±1 kV L-N
±2 kV L-PE; N-PE
Applied to mains
connection
Mains power quality should be that of a
typical commercial or hospital
environment.
Voltage dips,
short interruption,
and voltage
variations on
power
supply
input lines IEC
60601-4-11
UT=0%, 0,5 cycle
(at 0, 45, 90, 135,
180, 225, 270 and
315°)
UT=0%, 1 cycle
UT=70% 25/30
cycles (at 0°)
UT=0%, 250/300
cycles
UT=>95%, 0,5 cycle
(at 0, 45, 90, 135, 180,
225, 270 and 315°)
UT=>95%, 1 cycle
UT=70% (30% dipp UT),
25(50Hz)/30(60Hz)
cycles (at 0°)
UT=>95%,
250(50Hz)/300(60Hz)
cycle
Mains power quality should be
that of a typical commercial or hospital
environment.
The device stops and restarts
automatically at each dip. In this case
does not occur unacceptable pressure
drop.
Power frequency
(50/60 Hz)
IEC 61000-4-8
N/A
N/A
The equipment does not contain
magnetically sensitive components or
circuits.
NOTE: UTis the A.C. mains voltage prior to application of the test level.

DK50
06/2020 - 13 - NP-DK50 simple s DE-4_06-2020
Guidance and manufacturer's declaration - electromagnetic immunity
Pursuant to IEC 60601-1-2:2014 - Medical electrical equipment - Part 1-2: General requirements for
basic safety and essential performance - Collateral Standard: Electromagnetic disturbances
The equipment is intended for use in the electromagnetic environment specified below. The customer or the
user of the equipment should assure that it is used in such an environment.
Immunity test
IEC 60601-1-2 test
level
Compliance level
Electromagnetic environment - guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
Proximity fields
from RF wireless
communications
equipment
IEC 61000-4-3
3 Vrms
150 kHz to 80MHz
3 V/m
80 MHz to 2,7 GHz
9 to 28 V/m
15 specific
frequencies
(380 to 5800 MHz)
3 Vrms
3 V/m
9 to 28 V/m
15 specific
frequencies
(380 to 5800 MHz)
Portable and mobile RF communications
equipment should be used no closer to any
part of the equipment, including cables, than
the recommended separation distance
calculated from the equation applicable to
the frequency of the transmitter.
Recommended separation distance
d=1,2√ P
d=1,2√ P, 80 MHz to 800 MHz
d=2,3√ P, 800 MHz to 2,7 GHz
where P is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and d is the recommended separation dis-
tance in metres (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey a, should be less than the compliance
level in each frequency range b. Interference
may occur in the vicinity of equipment
marked with the following symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast
cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to
fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field
strength in the location in which the equipment is used exceeds the applicable RF compliance level
above, the equipment should be observed to verify normal operation. If abnormal performance is
observed, additional measures may be necessary, such as re-orienting or relocating the
equipment.
bOver the frequency range 150 kHz to 80 kHz, field strengths should be less than 3 V/m.

DK50
NP-DK50 simple s DE-4_06-2020 - 14 - 06/2020
8. PRODUCT DESCRIPTION
8.1. Prevedenia
Compressor models are designed in the following variants:
Dental compressor DK50
oil-free compressor embedded on a base covered with a compact
housing with an efficient noise suppression.
Upon customer request the compressor is provided with rubber feet or casters (2 with brakes (22) in
front and 2 without brakes (23) in the back).
Without additional filtration equipment, the compressed air from a compressor is
not suitable for the operation of breathing devices or similar equipment.
he compressor is not equipped with an emergency power supply.
9. FUNCTION
(Fig.1)
The compressor (1) draws in air through a filter and compresses it through a check valve (3) into
an air tank (2). The connected apparatus draws the compressed air from the air tank until the
pressure drops to a default preset level on the air-pressure switch (4) switching the compressor on.
The compressor again compresses air into the nozzle until the maximum pressure is reached and
the compressor switches off. Safety valve (5) prevents the pressure in air chamber from rising
above the maximal allowed value. The drain valve (8) releases the condensate from the air
nozzle.
The soundproof box is compact yet allows sufficient exchange of cooling air. Fan (6) provides for
the compressor cooling. After a prolonged operation of a compressor, temperature in the casing
can rise above 40°C, at that time the ventilator shall be in operation also after the compressor is
switched off after the space within the casing is cooled down under ca 32°C. Fastener (14)
ensures the power cord and its possible release from the connector (10).
Make sure that nothing impedes the free flow of air under and around the
compressor. Never cover the hot air outlet on the top back side of the cabinet .
If placing the compressor on a soft floor such as carpet, create space for
ventilation between the base and floor or the cabinet and floor, e.g. underpin the
footings with hard pads .

DK50
06/2020 - 15 - NP-DK50 simple s DE-4_06-2020
Fig. 1: Compressor
Description for Figures::
1 Compressor motor
2 Air tank
3 Check valve
4 Pressure switch
5 Safety valve
6 Fan
7 Manometer
8 Drain valve
9 Pressurized air output
10 Connector
11 Switch
12 Caster
13 Baraked caster
14 Fastener of power cord
15 Equipotential (ground) pin
16 Compressor cover
17 Fuse housing with fuses

DK50
NP-DK50 simple s DE-4_06-2020 - 16 - 06/2020
10. PNEUMATIC DIAGRAM
DK50
Legend for compressed air diagram
1 Inlet filter
2 Compressor fan
3 Compressor
4 Check valve
5 Safety valve
6 Pressure switch
7 Air tank
8 Air tank pressure gauge
9 Drain valve

DK50
06/2020 - 17 - NP-DK50 simple s DE-4_06-2020
INSTALLATION
11. CONDITIONS FOR USE
Compressors may only be installed and operating in dry, well-ventilated and clean environments
with environmental parameters that meet the requirements specified in Chapter 7, Technical
data. The compressor must be installed so that it is accessible at all times for operating and
maintenance. Please ensure that the label on the device is readily accessible.
he compressor must stand on a flat, sufficiently stable base (be aware of the weight of the
compressor, see Chapter 7, Technical data).
Compressors may not be operated outdoors or in otherwise wet or damp environments. Do not
use the compressor in the presence of explosive gases, dust or flammable liquids.
Before connecting the compressor to medical equipment, the supplier must confirm that it meets
all requirements for its use. Refer to the technical data of the product for this purpose. When a
unit is to be built-in, classification and evaluation of compatibility must be done by the
manufacturer or supplier of the product to be used.
Any other use or use outside this framework is not considered as intended use. The
manufacturer is not responsible for any damages arising from such use. The operator/user
assumes all risks.
Only a qualified professional may install the compressor and place it into
operation for the first time. This professional is obliged to train operating staff as
to the use and maintenance of the device. Installation and training of all operators
shall be confirmed by the installer’s signature on the certificate of installation.
Ambient operating conditions
Temperature: +5°C to +40°C,
Max. relative humidity: 70%,
Max. absolute humidity: 15 g/m3.
Prior to installation, ensure that the compressor is free of all transport packaging
and stabilizers to avoid any risk of damage to the product.
Parts of the air pump may be hot and reach hazardous temperatures during
compressor operation and may pose a contact risk for operators or materials.
Burn or fire hazard! Caution! Hot surface!
Electric cord for connection to electric mains and air hoses may not be broken.
The power cord may not be exposed to pulling, pressure and excessive heat

DK50
NP-DK50 simple s DE-4_06-2020 - 18 - 06/2020
12. PLACEMENT OF THE COMPRESSOR
The device shall only be installed by a qualified professional.
Keep the fixation screws for possible later transport of the compressor.
Unwrap the compressor from the packaging.
12.1. Removal of transpor stabilizers
Unscrew four screws M6 from the bottom
part of the device marked with red warning
washer.
Fig. 2
Securing the casters
A compressor equipped with casters must
first be secured to prevent it from moving
before starting the compressor.
Lock the casters!
Fig. 3
Installing feet
Compressor models equipped with feet must
have the feet installed following the provided
illustration.
Fig. 4

DK50
06/2020 - 19 - NP-DK50 simple s DE-4_06-2020
12.2. Installation schematic
Compressor with feet
Compressor with casters

DK50
NP-DK50 simple s DE-4_06-2020 - 20 - 06/2020
13. PNEUMATIC CONNECTIONS
13.1. Connecting to the compressed air outlet
Dental compressor with
a compressed air outlet, OUT (9),
located in the front of the box.
Connect pressure hose for
connection to the relevant dental
device to coupling (9) –
pressurized air output.
Fig.5
14. ELECTRICAL CONNECTION
(Fig.1)
Keep the socket easily accessible to ensure that in an emergency the appliance can be safely
disconnected from the mains.
Connection to the power distribution box shall be protected with a locking element.
Connection of the ground connection (15) to other appliances must adhere to local electrical
regulations.
Fasten down the electrical cord through the holder (14).
The device is protected by fuses located in the fuse housing (17) beneath the cover of the main
switch.
Electrical cord may not contact the hot parts of a compressor. Insulation could be
damaged!
If any electrical cord or air hose is damaged it must be replaced immediately.
Plug the electrical cord into the mains.
The device is equipped with a grounded plug.
Make sure this connection complies with local electrical codes.
The mains voltage and frequency must comply with the data stated on the device
label.
Ensure the electrical cable does not touch hot compressor components. Risk of
electric shock!
9
