ekwb EK-FC570 GTX SE Series Manual

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Released on 17th of August, 2011. Revision 1.0
Installation and mounting manual for EK-FC570 GTX SE water block
This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at www.ekwaterblocks.com for updates.
Before installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box or our home page.
The barb hose fittings require only a small amount of force to screw them in; otherwise the high flow fittings might break. These fittings do not need to be tightened with much force because the
liquid seal is made using o-rings. The use of an algaecide and corrosion inhibitors is always recommended for any liquid cooling system.
STEP 1: GENERAL INFORMATION. Sample picture of GeForce 570 GTX HD graphics card (PCB NVA-P1263)
STEP 2: PREPARING YOUR GRAPHIC CARD.
1. REMOVING STOCK COOLER: Remove encircled screw on
the bracket (required only on certain models):
STEP 2 cont.: PREPARING YOUR GRAPHIC CARD
1 cont.. REMOVING STOCK COOLER. Remove all encircled screws. All heat sink assembly
screws should be removed. There are 17 screws on the back of the graphic card.
2. CLEANING THE PCB. Carefully detach the original heat sink after removing all
fasteners securing it to the board and bracket. Wipe off the remains (by using
non–abrasive cloth or Q-tip, as shown on sample photo) of the original thermal
compound until the components and circuit board are completely clean. EKWB
does not recommend using any liquids for removing paste.
3. APPLYING THERMAL COMPOUND. Apply thermal
compound: lightly coat nVidia GF110 GPU chip with for
example Arctic Cooling MX-2 ™or MX-4 ™ thermal
grease. EKWB recommends to apply thermal grease in
cross form for best performance (see sample picture).
4. CUTTING THERMAL PADS. Your block comes with thermal pads, some of which are already pre-cut. Others have
to be cut to smaller chunks in order to cover all the VRM components such as MOSFETs and inductors (chokes).
PLEASE REMOVE THE PROTECTIVE FOIL FROM BOTH SIDES OF THE THERMAL PADS PRIOR TO INSTALLATION.
STEP 3: INSTALLING WATER BLOCK
1. PLACING THERMAL PADS ON PCB. Place thermal pads on chips so that numbers on chips
match size of thermal pads. EKWB made sure users have more than enough pads to cover
all surfaces that need to be covered to make block fully functional). EK recommends using
small drops of electrically non-conductive (for example: Arctic Cooling MX-2 ™ or MX-4 ™)
thermal grease on each phase regulator (that is being covered with thermal pad) in order to
even further improve the thermal performance of the EK-FC570 GTX SE series water block.
2. PLACING GPU REINFORCE PLATE ON PCB. Place metal reinforce and washer on
PCB as shown on picture below and screw it in with enclosed M3x4 screws. Please
use encased PVC washers under each screw. Make sure you use fasten screws
equally and do not use too much force.
Orientation
of reinforcer
is important!
M3x4
screw
PVC washer
1
1
1
1
1
1
1
1
1
1
2
Thickness 1mm (for memory)
1
1
1
1
1
1
1
1
1
1
1
1
2
Thickness 0.5mm (for VRM MOSFETS and inductors (R30)
2
2
2
2
2
2
Washer

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Released on 17th of August, 2011. Revision 1.0
3. PLACING STANDOFFS ON BLOCK. Brass standoffs are obligatory in order to attach this
water block to the printed circuit board of the graphics card. Please use the enclosed key to
screw them to the copper base of the water block (pay attention not to scratch surface).
4. PLACING BLOCK TO GRAPHIC CARD. During this process please make sure you
align holes on PCB with holes on block. Also pay attention not to use too much
force by pressing block down to PCB. Chip dies are prone to cracking.
5. ATTACHING BLOCK TO GRAPHIC CARD. By using Philips screwdriver screw in
enclosed M3x4 DIN7985 screws. EKWB recommends start screwing the screws
around the GPU core and continue outwards.
STEP 4: CHECKING FOR CONTACTS
Temporarily r emove the water block to check for uniform surface contact between the block and the components. Note the pattern of contact on a piece of paper. Then repeat
substeps in previous section to reattach the block. In case you fail to obtain good contact, please check again your thermal pad thickness or contact our support
service.
STEP 5: SECURING I/O BRACKET
STEP 6: FITTING POSITIONING
Use one M3x6 screw, one PVC washer and one M3 nut to secure the I/O
(also known as PCI) bracket firmly to the circuit board. This will allow the
computer chassis to carry the weight of the waterblock thus reducing the
tension on the PCI-express slot. Tighten the screw with Philips screwdriver
while holding the M3 nut with your thumbs firmly.
Please use spacer only on copper base if you use fitting with G1/4 thread longer than 5mm (see
sample picture). Screw in the fittings and plugs (use spacers on copper base in case you have
fittings with G1/4 thread longer than 5mm). Use 6mm allen key to screw in and tighten new EK-
Plug G1/4. Attach the liquid cooling tubes and connect the water-block(s) into the cooling circuit.
EKWB recommends using EK-PSC fittings with the EK-FC570 GTX SE series water blocks. To ensure
that the tubes are securely attached to the barb/fittings, please use hose clamps or an appropriate
substitute. The use of an algaecide is always recommended for any liquid cooling system.
You can use any opening as an inlet/outlet port.
STEP 6: INSERTING CARD IN YOUR PC CASE
Carefully lift your card with installed block and insert it in your PC case. Please bear in mind that your card suddenly withstands extra weight thus again be very careful not to
bend it or cause any other unneeded moves that might damage your card or block during installation.
REQUIRED TOOLS AND MOUNTING SCREWS:
scissors philips screwdriver 13 ×screws M3x4 DIN7985 1 ×M3x6 DIN7985
1 ×M3 nut 14 ×PVC washers thermal grease
EK-PSC Fitting
Gasket/O-ring
M3x6 screw
PVC washer
M3 nut
Tightening the standoffs:
Use 9 enclosed PVC washers.
Standoff key
Brass M4-M3
3.9mm standoff
Standoff key
Use 9 screws M3x4
Plug with o-ring
HIGH FLOW FITTING
3mm spacer
Gasket/O-ring
High Flow
Fitting
