ekwb EK-FC R9 290X DCII Guide

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Released on 19th of February 2014. Revision 1.0
Installation and mounting manual for EK-FC R9-290X DCII
water block
This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at www.ekwb.com for updates. Before
installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.
Before you start using this product please follow these basic guidelines:
1. Please carefully read the manual before through before beginning with the installation process!
2. Please remove your motherboard from the computer to assure safest mounting process in order to prevent any possible damages to your CPU and/or motherboard’s circuit board (PCB).
3. The EK High Flow and EK-PSC type fittings require only a small amount of force to screw them firmly in place since the liquid seal is ensured by the rubber O-ring gaskets.
4. The use of corrosion inhibiting coolants is always recommended for any liquid cooling system.
STEP 1: GENERAL INFORMATION. Sample picture of ASUS Radeon R9 290X DCII graphics card
series graphics card.
STEP 2: PREPARING YOUR GRAPHIC CARD.
1. REMOVING STOCK COOLER: Remove four (4) encircled screws on
the back of the PCB:
STEP 2 cont.: PREPARING YOUR GRAPHIC CARD
1 cont... REMOVING STOCK COOLER. Remove the stock GPU HSF assembly. Remove two (2)
encircled screws attaching the metal plate to the circuit board as well as two (2) screws attaching the I/O
bracket to the HSF. All heat sink assembly screws should be removed.
2. CLEANING THE PCB. Carefully detach the original stock cooler
after removing all screws securing it to the board. Wipe off the
remains (by using non–abrasive cloth or qtip , as shown on sample
photo) of the original thermal compound until the components and
circuit board are completely clean. EKWB recommends the use of
denatured alcohol for removing TIM leftovers.
3. APPLYING THERMAL COMPOUND. Wipe off the remains
(by using non–abrasive cloth or q-tip ) of the original thermal
compound until the components and circuit board are
completely clean. Apply thermal compound: lightly coat AMD
GPU chip with enclosed EK-TIM Ectotherm thermal grease.
EKWB recommends to apply thermal grease in cross form for
best performance (see sample picture).
4. CUTTING THERMAL PADS. Your block
comes with thermal pads, some of which are
already pre-cut. Others have to be cut to smaller
chunks in order to cover all the VRM
components such as MOSFETs and drivers.
PLEASE REMOVE THE PROTECTIVE FOIL FROM
BOTH SIDES OF THE THERMAL PADS PRIOR TO
INSTALLATION.
Replacement thermal pads:
Thermal Pad D –0.5mm (RAM 16x),
Thermal Pad A –0.5 mm (100x16mm)
Thermal Pad A –1.0 mm (100x16mm)
STEP 3: INSTALLING THE WATER BLOCK
PLACING THERMAL PADS ON PCB. Place thermal pads on chips so that numbers on chips match size of thermal pads. EKWB made sure users have more than enough
pads to cover all surfaces that need to be covered to make block fully functional). EKWB recommends using small drops of electrically non-conductive (for example: EK-
TIM Ectotherm, Arctic Cooling MX-2 ™, MX-4 ™ or GELID GC-Extreme™) thermal grease on each phase regulator (that is being covered with thermal pad) in order to
even further improve the thermal performance of the EK-FC R9-290X DCII block.
1
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
1
2
1: Thermal pad D –0.5mm
(for memory IC):
2: Thermal pad A –0.5mm
(for VDD VRM):
1
1
1
1
1
1
1
1
2
3: Thermal pad A –1mm
(for main VRM/MOSFET):
3
2
2

All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use. Released on 19th of February 2014. Revision 1.0
2. PLACING THE BLOCK ON TO THE GRAPHICS CARD. Carefully position the water
block with preinstalled standoffs on to the graphics card. During this process please
make sure you align mounting holes on the PCB with holes on the water block (same
applies for other tops). Also pay attention not to use too much force by pressing the
block down to the PCB. Chip dies are prone to cracking.
3. ATTACHING THE BLOCK TO THE GRAPHIC CARD. Use a Philips screwdriver
screw with the enclosed M3x4 DIN 7985 screws. EKWB recommends users to start
tightening the screws around the GPU core and continue outwards.
STEP 4: CHECKING FOR CONTACTS
If necessary temporarily r emove the water block to check for uniform surface contact between the block and the components, pay special attention to the VRM section of the
graphics card. Check whether the water block makes contact with the intended integrated circuit. Then repeat sub-steps in previous section to re-attach the block. In case you
fail to obtain good contact, please check again that your thermal pad thickness or contact our support service at http://www.ekwb.com/support.
STEP 5: INSTALLATION OF FITTINGS AND TUBING
Screw in the two G1/4 threaded male fittings. Attach the liquid cooling tubes and connect the water-block(s) into the cooling circuit. EKWB recommends using EK-CSQ
fittings with the EK-FC R9-290X DCII series water blocks. To ensure that the tubes are securely attached to the barb/fittings, please use hose clamps or an appropriate
substitute.
You can use any opening as an inlet/outlet port.
CAUTION: In case of using connectors other than EK-CSQ or EK-PSC series compression fittings, take special attention to the length of the fittings’ male G1/4” thread. In case
the thread is longer than 5 mm please use the enclosed 1.8 mm nickel plated spacer!
5mm is the maximum allowed G1/4” thread length!
STEP 6: INSERTING THE CARD IN YOUR PC CASE
Carefully lift your graphics card with installed block and insert it in your PC’s motherboard PCI-express expansion slot. Please bear in mind that your graphics card is probably
heavier than when it was equipped with original heat sink fan assembly. One needs to be very careful when handling the graphics card. Avoid all un-needed manipulation of the
VGA/water block assembly that might damage your card or water block during final installation.
REQUIRED TOOLS:
scissors Philips head screwdriver
Screw M3x4 DIN 7985
EK-CSQ Fitting
Tubing
EK-Plug G1/4
Acetal Terminal
M3x4 DIN7985 screw
PVC washer
This applies only for Acetal top
version, which cover the entire
lenght of the PCB!
