Elinz DCSIMPLE User manual

User Manual
Product Introduction
1）USB 2）Bracket Mounting Hole 3）OK
4）Up Button 5）Down Button 6）Power
7）Lens 8）LED 9）Display
10）SD Card Slot 11）Microphone 12）Reset
Description of Function Keys:
1）USB
USB data interface, (1) Storage; (2) PC Camera
2）Bracket Mounting Hole
Connect the car bracket mounting screw holes;
3）OK

Video and take pictures to confirm button, the camera mode, short press this key to start recording
again press stop recording; camera mode Short Press to take pictures;
4）UP Button
Used for upward movement in menu
5）Down Button
Used for downward movement in menu
6）Power
You can turn up the camcorder by long pressing the button. You’ll turn off the camcorder in the same
way.
7）Lens
Used to capture videos and photographs
8）LED
Indicative LED
9）Display
2.0inch camera display screen
10）Slot SD Card Slot
Used to receive the micro SD when inserted
11）Microphone
Used to record sound around the camcorder
12）Reset
Restarts the camcorder if necessary
Special Function Description：
G-sensor
Setting of the G-Sensor intensity.G-Sensor will start up emergency recording in response to shocks.
Park mode
With the function activated the camcorder shall start up recording whenever sensing shocks.it is necessary
to deactivate the camcorder by means of the automatic turn-off function upon power-off condition.
Screen Saver
Setting of the automatic screen deactivation.
REC/photo operation specifications
Power on/off

Press the power button , the blue indicator light lights up at boot time
Again press the power button is turned off, the blue light goes out
Note: The recording instrument will be prompted to low battery voltage automatic shutdown when battery
is low
REC mode
Short press key, switch to video mode, the upper left corner of the screen displays a video icon;
Short press button to start the camera, the video icon will appear flashing red dot, indicating the video
work
Photo mode
Short press key, switch to camera mode, the upper-left corner of the screen displays the camera icon;
Short press key camera, take pictures of the screen flashes once said camera to complete.
Video / photo playback
Short press key, switch to playback mode, the upper-left corner of the screen to display the playback
icon
Short press key up to select the file;
Short press key down to select the file;
Short press button to play the selected video files;
Menu setting
Long press key to enter the video settings state, then the "video icon" field is a yellow background；
Again long press key，switch to setting mode, the "Settings icon" field a yellow background,，short
press key, key to exit the setting.
Bring up the settings, short press key，you can set the sub key up and down select switch,，
short press key to enter set sub key.
Short press to quit menu setting.

Time setting
Long press key to enter the set state ，though button to select the date and time options,short
press key enter ,key in Year / Month / Day / Minutes / Seconds between each other to switch
though adjust the required value，press confirm the modification
USB mode
Connect DVR with computer by USB Cable, car DVR will automatically show USB menu ,there are 2
modes available :
Storage : In this mode we can access video files and photo files
PC Camera:In this mode, the model can be used as pc cam
Battery instruction
Battery indication image：
Full battery slightly low battery low battery battery empty
There are three methods to charge, the red indicator light up when charging, the entire charging time is
about 180 minutes, and the red indicator light automatically off when charging completed.
1. Use power adapter to charge
2. Use PC-USB to charge
3. Use vehicle power to charge
Remark: when appear crash because of improper operation, use the pin to hit “reset” hole to restart.
Products specifications
Features
2.0inch Video Camera
G-sensor
Off, 2G, 4G, 8G
LCD screen size
2.0inch Screen
Resolution
FHD 1920*1080, HD 1280*720, VGA 640*480
Lens
120 degree
Motion Detection
Off, On

Loop Recording
Off,1 Minutes,5 Minutes,8 Minutes
Camera
12M, 10M, 8M, 5M, 3M, 2MHD, 1.3M, VGA
Date Stamp
Off, On
Quality
Fine,Normal,Economy
Sharpness
High,Normal,Soft
White Balance
Auto,Day light,Cloudy,Tungsten,Fluorescent
Anti-Shaking
Off,On
Auto power off
Support auto ignition boot, turn off shutdown
Quick Review
Off,2 Seconds,5 Seconds
Date/Time
Support (YY/MM/DD)
Photo format
JPEG
Memory card
TF (max 32GB)
MIC
Support
Current frequency
50HZ/60HZ
USB function
1：Storage
2：PC Cam
Power interface
5V 1A
Battery
Built-in 400mAh
Trouble shooting:
For problems in normal operating situation ,please try these methods below:
Can’t take photo and recording
Check the if the TF card has enough space or locked
Automatically stop when recording
Use the compatible high-speed TF card with SDHC because of big HD video data, the high-speed TF
card have identifying of C4 and C6
Appear “files error” when replay photo or video
Uncompleted files because of TF card storage error, please use formatting function to format your TF
card
Unclear video
Check if there are any dirt or fingerprint; and use lens paper to clear the camera len.

Color is not perfect in cloudy day and outdoor light
Set the “white balance” function to automatic
Cross stripe interference in image
Because of wrong “light frequency”, please set it to 50Hz or 60Hz according to the local power supply
frequency
Crash
Restart by pressing shortly on” RESET” hole after crash
