Elite Screens C User manual

Manual Pull-Down Screen
Elite Manual Series
-TYPE C-
USER’S GUIDE
MATTE WHITE
Rev. 1.3

Pre-installation
1. Carefully unpack the screen
2. Always handle the screen in a leveled position on a clean surface.
Installation
Flush Wall Mounting
1. Using a tape measure, mark the keyholes that are located at the back of the
screen’s case end cap. 2. After marking the area and predrilled hole, insert the
screw and leave about 1/8” of an inch from the wall to mount the screen. Fig. 1
Fig. 1
Ceiling Mounting (additional hardware required)
Optional installation using a chain to hang the screen from the ceiling
Rev. 1.3

Loops
Fig. 2
2. You can also hang the screen on a ceiling by using a chain with s-hooks (not included)
and hang it by the two loops located on each end of the case as shown on Fig. 2.
“L” Bracket diagram
Find the studs on
your wall or use
drywall anchors to
install L brackets to
the desired location.
Top of “L” bracket from top view
6-3/4”
Height
1” Width 6-3/4” Length
Rev. 1.3

“L” Bracket accessories
“L” Brackets Installation
Wood/Dry Wall installation: Use “B”
wood screws provided for installation on
wood studs on wall. Or use “E” hollow wall
anchors provided in conjunction with the
wood screws for dry wall installation as
shown on Fig. 3.
Hang from your screen’s
loops located on the end
caps using the hooks
(A) provided with the L
bracket kit.
Fig. 3
Masonry/Cement wall installation:
Use “D” bolts provided for installing
your screen on a cement wall as shown
on Fig. 4.
Fig. 4 Hang from your screen’s
loops located on the end
caps using the hooks
(A) provided with the L
bracket kit.
Rev. 1.3

SCREEN OPERATION
Note: Always pull the screen down in a 90-degree vertical angle and do not allow the
screen to touch the screen case when the screen comes down to avoid damaging the
screen material.
1. Pull the screen down from the rope or from the handle only in a 90-degree angle.
Do not attempt to pull the screen down by the surface or touch the screen, as it
will damage the screen and void the warranty. Fig. 5
Fi
g
. 5
Note: An internal auto-lock mechanism system will cause the screen to stop and lock
on the position on intervals.
2. If you want to the screen to retract back, simply pull down the screen down more
than 2 inches and retract the screen back by quickly and smoothly releasing it up
gently. Fig. 6 (Always release in a 90-degree angle and do not let go until the
screen is entirely inside the case)
Fig. 6
Note: Improperly bringing the screen up/down will damage the screen material or
rolling system.
Maintenance
Clean matte white screen material with a soft cloth and mild soap with water.
When not in use, retract screen in it’s housing to keep the surface clean
Rev. 1.3

NOTE:
Regardless of mounting method, screen should be securely
supported so that vibration or even abusive pulling on the viewing
surface will not cause case to work loose or fall. Installer must insure
that fasteners used are of adequate strength and suitable for the
mounting surface chosen.
Fill this in!!
For the convenience of service, record the following information in the space below.
The serial number can be located on the packaging box or on an end cap.
Screen Model:
Serial Number:
Date of Purchase:
Dealer / Reseller Purchased from:
Tel: [phone]
www.elitescreens.com
[email protected]
Rev. 1.3
