Electric Motorized Projection Screen
Spectrum Series
User’s Guide

2
Rev.010312-AS
www.elitescreens.com [e-mail]
Make sure to read this user’s guide and follow the procedure below.
Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra Black
Top Drop in the roller. Please be aware o this as it will void your warranty with Elite Screens. Unapproved
changes or modi ications (except or cutting the power cord or hardwire installations) to this unit are
prohibited and will void your warranty. For more in ormation, please contact our Technical Support
Department at [phone] Ext. 604.
•Please retain this user’s guide for future reference.
•To avoid damaging the unit, do not use with any unauthorized accessories not
recommended by the manufacturer.
•Handle the unit carefully during transportation to avoid any damages.
•To ensure safe and reliable operation, direct connection to a properly grounded power
source is advised.
•The power outlet supplying power to the unit should be close to the unit and easily
accessible.
•Do not install the unit on uneven or inclined surfaces.
•Do not put heavy objects on the power cord and position it properly to avoid creating a
trip obstacle.
•ever overload the power cord to prevent an electric shock or fire due to a loose
contact or a short circuit.
•There are not user serviceable parts in this unit. Do not attempt to disassemble this unit
by yourself. o one except authorized technicians can open and make repairs to this
unit.
•Make sure the power source this unit is connected to has a continuous power flow.
•If there is need to use an extension cord, make sure the cord has an equal rating as the
appliance to avoid overheat.
•Do not handle the power plug when your hands are wet or your feet are in contact with
water.
Do not use this unit under the following circumstances.
•Disconnect the power cord under the conditions of heavy rain, wind, thunder or
lightning.
•Avoid direct Sunshine, rain shower and moisture.
•Keep away from fire sources and high temperature to prevent this device from
overheating.
•Cut off the power supply first before transportation or maintenance.
•Fully disconnect from the power supply when the unit is not in use for a long period of
time, as should be done with any other electric household appliance.
•To avoid possible injury and/or an electric shock, do not attempt to use the screen if
there is obvious damage or if there are any evident broken parts.
Important Safety & Warning Precautions

3
Rev.010312-AS
www.elitescreens.com [e-mail]
Due to various installation environments, the instructions provided in this user’s guide are for
reference only. Please consult a professional installation company for further installation and
safety advice. The installer must insure that proper mounting hardware is used to provide
adequate strength suitable for the installation. lite Screens is not liable for any faulty
installations.
The Screen’s Top Black Drop is already set to its maximum drop distance. There is NO extra top black
drop in the roller. Please be aware of this as it will void the limitation of your warranty.
Individual modifications to this product are prohibited and will void the warranty with the
manufacturer. Please contact Elite Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
owever, there is no guarantee that the interference will not occur on a particular installation. If this
equipment causes harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures.
Reorient or relocate the receiving antenna of the device which may be casing the interference.
Increase the separation between the screen and the device’s receiver.
onnect the equipment into a different power outlet other than the device.
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with
foreign particles such as dust, sawdust, and/or liquids.
Regardless of the mounting method, the screen should be securely supported so that the vibration or
pulling on the viewing surface will not cause the casing to become loose or fall. The installer must insure
that the fasteners used are of adequate strength and suitable for the installation location.
Installation Warning
Pre
-
Installation
NOTE

4
Rev.010312-AS
www.elitescreens.com [e-mail]
Please make sure all accessories below are included before proceeding.
Red+ Green-
A. B. C.
Infrared Remote 3 Way Wall Switch 12 Volt Trigger
D. E. F. G.
AAA Batteries Bubble Level Radio Frequency Remote Infrared Eye Receiver
(Not Included) (Not Included)
Accessories for Spectrum Series

5
Rev.010312-AS
www.elitescreens.com [e-mail]
3
-
way Wall switch
UP
Stop
D
o
wn
5-12 Volt Trigger Cable
Control System for Spectrum Series
1. 5-12V Trigger: The built-in 5-12V trigger input
allows your screen to synchronize its drop & rise
with the projector’s power cycle. The screen
deploys when the projector powers up and will
retract when the projector powers down. The 5-12
volt adaptor connects to your projector’s trigger
output via a separate cable that may or may not
be provided by the manufacturer of the projector.
The trigger feature will not work without an
output cable from the projector, but it can be
tested by connecting the Red (+) and Green (-)
cable to a 9-volt battery.
3
-
prong power cable
RJ
-
45 input for 5
-
12V Trigger
Red: DC 12 +
Green: 0 V -
2.
3
-
Way Wal
l Switch:
The 3
-
way wall
switch is a wall mount control box with
an up/stop/down button and plugs
directly into the screen’s RJ-45 input.
3. IR “Eye” Receiver:
(Not Included)
The IR “Eye”
Receiver plugs directly into the screen’s RJ-45 input to
present a low profile line-of-sight control option for your
IR remote control even in a recessed ceiling installation.
IR “Eye” Receiver
4. IR Remote ontrol:
The Infrared
functions by direct line of sight contact
with a beam range of 30 feet.
5. RF Remote ontrol:
(Not Included)
The radio waves eliminate the need for a
direct line of sight with a range of 150 feet.

6
Rev.010312-AS
www.elitescreens.com [e-mail]
Optional installation method using a chain to h
ang the screen from the ceiling
Please consult a professional installer. Elite Screens is not liable for any faulty installations.
1. Select the installation location for your screen. Ensure that it is within reasona le proximity from your
power source.
2. For est support of your screen, it is ideal to secure your screen into the studs of your house’s internal
framework. If studs are not availa le, use hollow anchors for mounting your wall screws into drywall. If
you’re installing in a concrete structure, use concrete olts to secure your screen.
Always consult a professional installer or hardware professional to ensure that the proper screws and/or
hardware are eing used.
3. Ensure that oth rackets are in perfect level alignment with one another. Use wall/ceiling wood screws
to secure to the wood studs. Use hollow anchors if mounting in drywall.
4. The screen casing is designed to accept the wall screws directly. If not using the Optional L-Brackets
http://shop.elitescreens.com/accessories.aspx, e sure to position the washer etween the head of the
wall-screw and the anchor slots on the screen’s casing.
5. Using a tape measure, mark the keyholes that are located at the ack of the screen’s casing end cap.
6. After marking the area and predrilled hole, insert the screw and have at least 1/8” from the wall to mount
the screen. (See example in Figure 1.)
7. Figure 2 will show you an optional installation using chains (not included).
Installation Instructions
Fig. 1
Fig. 2

7
Rev.010312-AS
www.elitescreens.com [e-mail]
For additional information, please contact Elite Screens at [e-mail]
1. If your screen does not move, please check the power supply. The screen will understandably
not move without power.
2. Make sure the power cord is firmly plugged to the power outlet.
3. Make sure that all cable connections are secure.
4. If the screen works well with the line switch but not with the remote control, please make sure
the remote controls have fresh batteries. Change the batteries every 6 months to ensure proper
operation of the remotes.
1. Q: Why does my screen no longer function?
A: Make sure your wall plug has power and that the screen is properly plugged. The fuse on the
screen will also need to be checked. Please contact [e-mail] for the
location. The tubular motor in this screen is equipped with a thermal relay. This feature will
automatically shut off the screen in the event of the motor becoming too hot. This will prevent
the motor from overheating. If you should experience this, please let the screen’s temperature
decrease for 10-15 min. before usage.
2. Q: ow is the screen material cleaned?
A: The screen material can be cleaned with mild soap and water.
3. Q: What type of batteries do the remote controls require?
A: The IR and RF remote controls use AAA alkaline batteries.
4. Q: Can you manually pull down the screen?
A: No, manually pulling down the screen will damage the electronic motor rolling system and
void your warranty.
5. Q: How could I setup my Screens IR receiver to work with my learning remote control system
Do you have any IR codes I can use to achieve this?
A: Our IR remote controls have been evaluated and entered in to the databases of some
Universal remote control manufacturers. Please contact the manufacturer of your remote to
inquire about your remotes ability to function with ours. If they have not evaluated our remote
control then the following list of Binary codes will be used for most remote setups.
For Spectrum, VMAX2 (Plus), ome2 and CineTension 2 Series
Up: 1111 0000 0001
Stop: 1111 0000 0010
Down: 1111 0000 0100
Troubleshooting & FAQ’S

8
Rev.010312-AS
www.elitescreens.com [e-mail]
*Me surement dimensions re intended s reference only nd subject to ch nge without notice. Note: D t Error m y be ±1"
Spectrum Series Dimension Table

9
Rev.010312-AS
www.elitescreens.com [e-mail]
•Two (2) Year parts and labor warranty from defects in workmanship from purchase date as
follows (except for refurbished units as specified below).
•Three (3) Year parts and labor warranty from defects in workmanship for GEMR (Government,
Educational, Military, & Religious) purchases of new product only.
•Refurbished Units carry a 90-DAY parts and labor warranty.
•Each party will be responsible for one way shipping during the warranty period.
•A RMA (Return Merchandise Authorization) number must be issued in order to process a
replacement or to authorize a return for warranty repair. Elite Screens will, at its sole option
replace or repair the defective unit with a replacement *(see exceptions below) after the
defective unit or parts have been received. Once the product is received, Elite Screens will send
out a replacement *unit to the customer by ground service (subject to inventory availability).
•Do Not Return Any Unauthorized Items to Elite Screens, as they will be refused and returned
at your expense. The RMA Number must be included on the outside label of your shipping
box. Our warehouse is not authorized to accept returns without an RMA number on the
shipping label.
•RMA Numbers are valid for 45 days from the date issued.
•Missing Parts must be reported within 7 days of receipt. If reported after 7 days, the customer
will be responsible for shipping and handling fees. If reported after 30 days of receipt, the
customer will be responsible for cost of parts and shipping & handling fees.
*A New or refurbished replacement will be send out to the customer depending on the type of
purchase (new or refurbished) and based on stock availability.
North America only U.S. and anada
For Warranty and Service requests, please submit an RMA/Service Form at:
www.elitescreens.com/warrantysupportform
Please visit this link for full Warranty information:
www.elitescreens.com/warranty
For Customer Service and Technical questions, please contact Elite Screens at:
Telephone: [phone] [e-mail]
Fax: [phone] [e-mail]
REMEMBER TO REGISTER YOUR PRODUCT AT:
WWW.ELITESCREENS.COM
Warranty Policy

10
Rev.010312-AS
www.elitescreens.com [e-mail]
US & Canada Tech Support & Warranty Claim
Please contact us at ser[email protected]om or call [phone] #3 or fax [phone]
Europe Tech Support & Warranty Claim
Please contact us at ser[email protected] or call [phone]
Asia Tech Support & Warranty Claim
Please contact us at ser[email protected]om.cn or call [phone]
Taiwan Tech Support & Warranty Claim
Please contact us at ser[email protected]om.tw or call +866+2+8990-1999
America: Europe:
Elite Screens Inc Elite Screens Europe
16410 Manning Way Lübecker Straße 1
Cerritos, CA 90703 USA 22087 amburg, Germany
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
[email protected] [email protected]
www.elitescreens.com www.elitescreens.eu
Asia: Elite Screens France S.A.S
Elite Screens China Corp. 11, Allée William Penn
Longxi Duimianling Industry Zone 92150 Surenes, rance
Longcheng Longgang District, Tel: [phone]
ShenZhen GuangDong, China ax: [phone]
Tel: [phone] [e-mail]
ax: [phone] www.elitescreens.com/fr
[e-mail]
www.elitescreens.com.cn
Japan:
Taiwan: Elite Screens Japan Corp.
Elite Screens Taiwan Corp. 467-2-606 Tsuruma, Machida-shi,
4 ., No. 42-1 Wuguan Rd. Wugu Township Taipei Tokyo, 194-0004 Japan
County 248, Taiwan (Wugu Industrial Park) Tel: [phone]
Taiwan (R.O.C) ax: + 81(0)42-706-9130
Tel: +886+2+8990-1999 [e-mail]
ax: +886+2+8990+1366 www.elitescreens.jp
[e-mail]
www.elitscreens.com.tw
Latin America ontact:
[email protected]
East Asia ontact:
[email protected]
India ontact:
[email protected]
Contact Information
