Elite Screens ezFrame Plus Series User manual

Rev.041014-JA www.elitescreens.com 1
ezFrame Plus Series
Fixed&Frame&Projection&Screen&
User’s&Guide&
Hardware and Parts List
1. Frame Parts x 6 pcs (4 top/bottom horizontal frame pcs + 2 side vertical frame pcs)
2. Tension Rods x 6 pcs (4 top/bottom rods + 2 side rods)
3. Screen Material x 1 pc
4. Center joints x 2 pcs
5. Elbow Joints x 4 pcs
6. Wall brackets x 2 – 3 pcs (depending on model/size)
7. M5x50 wood screws x 6 pcs
8. Hollow wall anchor x 6 pcs
9. M5x15 screws x 16 pcs
10. Center Support Bar x 1 – 2 pcs (depending on model/size)
11. Support joiner x 2 – 4 pcs (depending on model/size)
12. Fix Plates x 60 – 180 pcs (depending on model/size)
Note: Please make sure all parts are included in your package before proceeding to assemble your Elite
Screens fixed frame projection screen.
FRAME ASSEMBLY
1. Insert the center joint connector into to one of the 1/2 horizontal frames and fasten it with two M5x15 screws.
bevel connection
½Horizontal Frame
M5×15 screws

Rev.041014-JA www.elitescreens.com 2
Push
Push
Short frame
Short frame
2. Insert the other 1/2 horizontal frame piece to the center joint connector and fasten it with two M5x15 screws.
Repeat steps 1 and 2 for assembling the second horizontal frame.
Note: a. 2 long frames should be assembled for a screen.
b. Do not tighten the screws completely until all frame pieces have been assembled correctly.
3. Insert both elbow joint connectors into the long horizontal frame and then fasten it with two M5x15 screws (see
Fig.1).Then insert the vertical short frames and fasten them with screws (fig.1.2)
&
bevel connection
½Long Frame
Push
Horizontal Long Frame
M5×15 screws
M5×15 screws
M5×15 screws
Screw
( fig.3)
(Fig.1.1)
Push Push
Joint
Long frame
( fig.1)
(Fig.1.2)

Rev.041014-JA www.elitescreens.com 3
Push
Push
( fig.2)
Insert the exposed ends of the joint connectors
into the short (vertical) frame and align the four
corners so that they meet at perfect right angles
Tension Rod (Horizontal) x 4
Tension Rod (Vertical) x 2
4. Join&all&four&frame&parts&together&following&the&steps&shown&below.&!"#$%&'&
(((()*+,-(./,0(122,345,67(85,12,(892/(2#395+10,*925:(+/,(+;*(,062(*<(+/,(5*0$(<=13,2%&
Attaching the screen material to the frame
1. Unroll the screen material and lay it down on a clean surface. Then insert the tension rods separately into the
edges of all four corners of the material (see fig.3)
M5×15 screws
(Fig. 3)
Screen Material
Screen Material
push
push
push
push
Tension&Rod&(Horizontal)&x&4&
push
push
Tension&Rod&(Vertical)&x&2&
Screw
( fig.3)

Rev.041014-JA www.elitescreens.com 4
2. Make sure that the material and frame are both lying face down on a clean, dry, and non-abrasive surface.
3. Center the material inside the frame.
Please note the material will be noticeably smaller than the frame, as the material must be stretched to create a
sufficient amount of tension for perfect material flatness.
4. Attach the fix plates
(1) Begin by securing the four corners in the following order A→B→C→D(Fig.4)
(2) Insert the fix plates as shown on Fig. 5. Fix plate ①is approximately 10 cm away from the frame’s corner
and fix plate ②is approximately 5cm away.
&
&
&
&
&
&
&
&
&
&
(3) Stretch the material to the corner and insert the screen material’s edge into the groove of the frame. While one
hand holds the material in place, the other hand snaps in the push plate (Fig.6-Fig.7).
&
(4) Place a fix plate in the center of each side in the following order E→F→G→H. (Fig.8)
.
(Fig. 6)
A
B
C
D
(Fig. 4)
E
F
G
H
(Fig. 5)
(Fig.8)
Insert push plate in
Tension Rod
(Fig. 7)
Schematic Cross section of the Frame
Plate

Rev.041014-JA www.elitescreens.com 5
Black backing for AcousticPro models
This procedure only applies to AcousticPro models. Disregard this section if your Fixed Frame does not include an acoustically
transparent screen material. The purpose of the black backing material is to block out any light penetration that may reflect off
of anything mounted behind the screen, which can cause distortion to the projected image.
(
(
(5) Put the next set of fix plates ②in the
middle between fix plate ①# and the
corner. (Fig.9)
(6) Then put the next set of fix plates
③between ①and ②and the corner.
(Fig.10)
(7) Lastly, put the next set of fix
plates (4) as shown in Fig.11
(8) Repeat steps 5-7 to for the rest of
the sides to complete attaching the
screen material (Fig.12)
Interval markings reveal the best points for inserting the fix plates
(Fig. 13). The prongs on the fix plates insert to the lip on the back
of the frame creating a friction hold that will firmly keep the
material and black backing in place (Fig. 14-15). After the
material has been installed, the backing will lie over the back of
the white (Acoustic) material and then be held in place by the
Velcro on the fix plates (Fig 16).
&
&
&
(Fig. 13)
(Fig. 15)
(Fig. 14)
(Fig. 16)
(Fig.9)
(Fig.10)
(Fig.11)
(Fig.12)
The black backing is held in place by the Velcro that is on the fix plates.
Black backing
Fix plates secure the Acoustic material and the black backing behind it.

Rev.041014-JA www.elitescreens.com 6
Center Support Bard
1. Insert the support joiner into each end of the center support bar to complete assembly.
support joiner
Center support bar
2. Insert the Center Support Bar into the upper top groove on the back of the frame (not the one where the fix
plate inserts) with the bottom end near the approximate center point as shown in Fig. 17 and rotate it in at an angle
so that both ends of the bar are in alignment with the groove.
3. Slide the top end of the bar into the top center point of the frame to complete the center support bar installation.
This will provide added stability to your frame and added tension to the material.
(
>02+1551+#*0
1. Locate your desired installation location with a stud finder (recommended) and mark the drill-hole area of
where the screen is to be installed.
2. Drill a hole with the proper bit size according to the wood screws included.
3. Line up the wall brackets with the drilled holes on the installation location and screw them in using a
Phillips screwdriver.
Note: Use use 3 top wall brackets on diagonal sizes 135” and above.
4. Position the fixed frame screen onto the top wall brackets as shown in (Fig. 19) and push down at the center
of the bottom frame to secure the installation.
5. The design of the wall brackets allows the frame to slide over them through its sides. This is an important
feature of the installation design as it allows your screen to be properly centered.
6. Using both hands finish the installation by pushing the lower portion of the fixed frame screen into the
lower bracket as shown in Fig 20.
Center&Support&Bars&
!"#$%(?@'(
push
Remove
Tension&Rod&
Center&Support&Bar&

Rev.041014-JA www.elitescreens.com 7
&
CAUTION
Please follow these instructions carefully to ensure proper maintenance and safety of your Fixed
Frame Screen
1.&When&hanging&the&screen&up,&please&make&sure&that&no&other&objects&such&as&power&switches,&outlets,&furniture,&
ladders,&windows,&etc.&occupy&the&space&designated&for&your&FixedOFrame&screen.&
&
2.&Regardless&if&the&screen&is&hung&on&or&installed&into&the&wall,&make&sure&that&the&proper&mounting&anchors&are&
used&and&that&the&weight&is&supported&appropriately&by&a&strong&and&structurally&sound&surface&just&as&any&large&
and&heavy&picture&frame&should.&(Please'consult'a'home'improvement'specialist'for'the'best'advice'on'installation)'
&
3.&Frame&parts&are&made&of&high&quality&velourOsurfaced&aluminum&and&should&be&handled&with&care.&
&
4.&When&not&in&use,&cover&over&the&screen&with&a&furniture&sheet&to&protect&it&from&dirt,&grime,&paint&or&any&other&
impurities.&
&
5.&When&cleaning,&use&a&damp&soft&cloth&with&warm&water&to&remove&any&marks&on&the&frame&or&screen&surface.& &
&
6.&Never&attempt&to&use&any&solutions,&chemicals&or&abrasive&cleaners&on&the&screen&surface.&
&
7.&In&order&to&avoid&damaging&the&screen,&avoid&touching&it&directly&with&your&fingers,&tools&or&any&other&sharp&or&
abrasive&objects.& &
&
8.&Spare&Parts&should&be&placed&out&of&reach&of&small&children&in&accordance&with&household&safety&guidelines.&
&
For&a&local&Elite&Screens&contact&or&Technical&Support,&please&visit&
www.elitescreens.com&
(Fig.&19)&
(Fig.20)&
