Elite Screens Kestrel Tab-Tension 2 CLR User manual

Model Number
Nominal
Diagonal
Aspect
Ratio
Screen
Material
Gain
Case
Length
(A)
Viewable
Width
(A1)
Screen
Width
(A2)
Top Cover
Length
(A3)
Distance
between
right end
to fabric
(A4)
Distance
between
left end to
fabric
(A5)
Overall
Height
(B)
Viewable
Height
(B1)
Fabric
Height
(B2)
Bottom
Black
Border
(B3)
Screen
Height
(B4)
Net
Weight
Gross
Weight
Lbs Lbs
FTE101UH2-CLR 101" 16:9 CLR® 3 0.8 97.2 88.0 88.9 97.0 3.8 3.4 65.4 49.5 51.7 8.0 59.7 103.4 10.8 10.2 57.3 70.6
FTE101XH2-CLR 101" 16:9 CLR® 3 0.8 97.2 88.0 88.9 97.0 3.8 3.4 65.4 49.5 51.7 8.0 59.7 103.4 10.8 10.2 57.3 70.6
FTE121UH2-CLR 121" 16:9 CLR® 3 0.8 114.7 105.5 106.0 114.5 3.6 3.2 78.6 60.9 73.0 12.0 73.0 120.7 10.8 10.2 66.1 77.6
FTE121XH2-CLR 121" 16:9 CLR® 3 0.8 114.7 105.5 106.0 114.5 3.6 3.2 78.6 60.9 73.0 12.0 73.0 120.7 10.8 10.2 66.1 77.6
Kgs Kgs
FTE101UH2-CLR 101" 16:9 CLR® 3 0.8 2469 2236 2257 2464 96 87 1660 1258 1314 203 1517 2625 275 260 26.0 32.0
FTE101XH2-CLR 101" 16:9 CLR® 3 0.8 2469 2236 2257 2464 96 87 1660 1258 1314 203 1517 2625 275 260 26.0 32.0
FTE121UH2-CLR 121" 16:9 CLR® 3 0.8 2912 2679 2693 2907 92 81 1996 1548 1853 305 1853 3065 275 260 30.0 35.2
FTE121XH2-CLR 121" 16:9 CLR® 3 0.8 2912 2679 2693 2907 92 81 1996 1548 1853 305 1853 3065 275 260 30.0 35.2
Note: Data Error may be +/- 1"
Kestrel Tab-Tension 2 CLR ®Dimensions Table
Packing Dims
(LxWxH)
Unit: inch
Unit: mm
The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture modification. Although a
manufacturer may offer product advice, it may be taken or disregarded at the integrator’s discretion. Elite Screens will not be held responsible or be otherwise liable for faulty installations.
6.1"
4.8"
5.6"
5"
4.3"
Unit of Measure:
mm / inch
3/7/2022 www.elitescreens.com FTE-CLR

• StarBright CLR® (Ceiling Light Rejecting) material absorbs up to 95% of overhead lighting
• 100x contrast enhancement over standard matte white screens under ambient light
• Multi-layered optical micro-structures filter out ambient light for superior image brightness
• Black absorbent layer improves black levels in bright and dark room environments
• Reflective layer concentrates projected light back to viewer’s field of vision and negates
light scatter
• Ultra-wide viewing angle allows viewers to see a clear and bright image from any position
• Special lenticular surface provides superb color fidelity, contrast and black/white dynamic
range
• Black backing eliminates light penetration to avoid picture degradation
• Available in the following diagonal sizes: 101” and 121” in 16:9 aspect ratio
• Elegant moisture resistant black or white aluminum housing options to fit any room décor.
• Rises and lowers using “scissor-backed” industry grade cross spring risers
• Specially designed for tabletop/bottom placed ultra-short throw projectors
• Project from within a short distance without shadowing the picture
• Includes Infrared (IR) and Radio Frequency (RF) handheld remote controls
• Wireless 12v trigger included – Synchronizes operation with projector’s power cycle
• Up/Stop/Down toggle switch for manual operation
• Plug & Play ready, no hardwired installation required
• 2-Year / 3-Year ENR-G Manufacturer's Warranty by Elite Screens, an ISO9001
manufacturer since 2004
The Kestrel Tab-Tension 2 CLR® is an electric floor-rising projector screen with Ceiling Light Rejecting® technology to
combat the washout effect from overhead lighting in bright room environments.
The StarBright CLR® material is configured in a tab-tensioned format to ensure a taut, flat, and ripple-free projection
surface suitable for ultra-short throw projectors. It is the ideal non-invasive solution for environments where wall or ceiling
installations are impractical. Available in either a black or white housing to fit any room décor.
www.elitescreens.com[email protected]

Rev. V121421DT www.elitescreens.com 1
Kestrel Tab-Tension 2 CLR® Series
Floor Rising Ceiling/Ambient Light Rejecting (CLR®/ALR)
Tab-Tensioned Motorized Screen
User’s Guide
IMPORTANT SAFEGUARDS
Read these instructions carefully and retain them for future use. If this product is passed to a third party,
then these instructions must be included.
Caution:
The screen’s Black Bottom Drop is already set to its maximum drop distance. There is NO extra
Black Bottom Drop in the roller. Please be aware of this as it will void your warranty with Elite
Screens®. Unapproved changes or modifications (except for cutting the power cord for hardwire
installations) to this unit are prohibited and will void your warranty.
•To avoid damaging the unit, do not use with any unauthorized accessories not recommended by
the manufacturer.
•Handle the unit carefully during transportation to avoid any damages.
•To ensure safe and reliable operation, direct connection to a properly grounded power source is
advised.
•The power outlet supplying power to the unit should be close to the unit and easily accessible.
•Do not install the unit on uneven or inclined surfaces.
•Do not put heavy objects on the power cord and position it properly to avoid creating a trip
obstacle.
•Never overload the power cord to prevent an electric shock or fire due to a loose contact or a
short circuit.
•There are not user serviceable parts in this unit. Do not attempt to disassemble this unit by
yourself. No one except authorized technicians can open and make repairs to this unit.
•Make sure the power source this unit is connected to has a continuous power flow.
•If there is need to use an extension cord, make sure the cord has an equal rating as the
appliance to avoid overheat.
•Do not handle the power plug when your hands are wet, or your feet are in contact with water.

User’s Guide Kestrel Tab-Tension 2 CLR® Series
Rev. V121421DT www.elitescreens.com 2
Do not use this unit under the following circumstances.
•Disconnect the power cord under the conditions of heavy rain, wind, thunder, or lightning.
•Avoid direct Sunshine, rain shower and moisture.
•Keep away from fire sources and high temperature to prevent this device from overheating.
•Cut off the power supply first before transportation or maintenance.
•Fully disconnect from the power supply when the unit is not in use for a long period of time, as
should be done with any other electric household appliance.
•To avoid possible injury and/or an electric shock, do not attempt to use the screen if there is
obvious damage or if there are any evident broken parts.
•Keep hands clear from the closing panels.
•Keep away from children when screen is in operation.
WARNING
Individual modifications to this product are prohibited and will void the manufacturer’s warranty. Please
contact the Elite Screens® Customer Service Team with any questions.
SCREEN MAINTAINANCE
Dust, dirt, and scratches on the projection screen surface will affect the quality and performance of the
projection image. For optimal results we advise to pay attention to the following instructions.
1) The screen surface has a horizontal structure. DO NOT wipe the screen up and down or in a circular
motion.
Wipe very gently when needed from left to right only.
2) Please clean the dust on the screen surface with a soft brush or microfiber cloth (rough towel or cloth
may damage the screen’s surface).
3) Gently wipe the screen with a lightly moistened microfiber cloth with mild soap diluted in water.
Notes：
The following precautions should be always followed to avoid damaging the material,
which is not covered under warranty.
▪NEVER touch the screen material with your bare hands as it will leave oily fingerprints which
are permanent and not removable. Use cotton gloves when handling the material.
▪NEVER scratch the material, as it will leave permanent markings on the screen’s surface.
▪NEVER point to the screen material with a fingertip or other sharp objects to prevent damage
to the material.
▪NEVER use acetone, benzene, alcohol, and any other organic solvents to clean the screen
material. Using such chemicals will permanently damage the screen.

User’s Guide Kestrel Tab-Tension 2 CLR® Series
Rev. V121421DT www.elitescreens.com 3
FCC Regulatory Compliance
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device is susceptible to receiving
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.

User’s Guide Kestrel Tab-Tension 2 CLR® Series
Rev. V121421DT www.elitescreens.com 4
PARTS IDENTIFICATION
Note: Please always store the screen flat horizontally. Never store the screen in a vertical
position as it will permanently damage the screen’s structure, shift the material, and cause
wrinkles/folds which will void the warranty.
CLR® Material
Bottom black masking
border
Power terminal /
Power switch
Tab/Strings
Cross-rising spring
scissor mechanism
Case/Housing
Closing Panel/Lid
Feet
Front of screen
Back of screen

User’s Guide Kestrel Tab-Tension 2 CLR® Series
Rev. V121421DT www.elitescreens.com 5
Kestrel Tab-Tension 2 CLR® Series | Controls and Accessories
A. Radio Frequency
(RF) Remote control
B. Infrared (IR)
Remote Control
C. IR extended
receiver
D. Radio Frequency
(RF) USB wireless
trigger
* E. Micro USB
Charging Cable
Installed inside housing
near circuit board box
*Included with rechargeable remote version only
SCREEN OPERATION
Electric Current: Depending on your region, the screen will operate in either 110v or 220v voltage.
1. After ensuring the power outlet & screen are compatible (voltage), plug the power cord into the power
outlet.
2. Once the screen has power, you’ll be able to control it using any of the 4 methods described below.
4 ways to control your Kestrel Tab-Tension 2 CLR® Screen
1. Manual Operation Switch: The left side of the screen's housing includes a UP/STOP/DOWN
switch to raise, lower and stop the screen without the use of the RF/IR remote.
2. RF Remote Control (Item A): The RF (A) remote is best used when the screen is concealed or when
long distance control is required. The RF technology therefore is more versatile as it does not require
line of sight to operate the screen.
3. IR Remote Control (Item B) and IR Eye Receiver
(Item C): The IR remote (B) requires a direct line
of sight through the screen’s IR receiver. Place the IR Eye Receiver (C) in a suitable location free from
obstruction. Then point the IR remote to the IR Eye receiver to operate the screen.
※ IR Eye Receiver has been installed inside the housing on left side (power terminal side)
Stop
Down
Up

User’s Guide Kestrel Tab-Tension 2 CLR® Series
Rev. V121421DT www.elitescreens.com 6
4. USB RF wireless trigger (Item D): The RF wireless trigger (D) can synchronize your projector’s
power cycle to the screen’s UP/DOWN operation.
※ The trigger has been synchronized to your electric screen.
a. Connect the RF wireless trigger into the projector’s USB port.
b. Make sure to enable this feature if needed in your projector’s menu settings.
c. Power ON the projector. The screen should raise (up) the screen automatically.
d. Power OFF the projector. The screen should descend (down) the screen automatically.
NOTE
➢When powering off the projector, assure it is completely powered off (ex. fan off), then the
screen will retract automatically.
➢If the motorized screen does not automatically drop or retract, repeat the process from step one.
Remote control battery operated and charging instructions:
Note: One or the other type included not both types.
Rechargeable version
Charge the RF or IR remote by plugging the Micro USB
Charging cable (Item E) into any USB power source and
into the left side of your RF or IR Remote Control. While
charging, you will see a solid red light above the touch
sensitive buttons. For your convenience, you may use the
remote while it charges. Note: The red light may dim while
charging.
Battery version
Follow the steps below to replace the CR232 button cell batteries (2x required) on the remote control.
a. Unscrew the back cover of the remote control.
b. PUSH UP to remove the back cover.
c. Replace the old batteries with new batteries.
d. Put the back cover on the remote control secure with screw.
e. Check the operation of the remote control to verify screen responds to the commands.
Front cover
Screw hole
Back cover
CR232 Button
Cell battery
Charging port

User’s Guide Kestrel Tab-Tension 2 CLR® Series
Rev. V121421DT www.elitescreens.com 7
Notice to Installer:
PROPER PROJECTOR PLACEMENT
The StarBright CLR®is exclusively for tabletop/bottom mounted ultra-short throw projectors.
See illustrations below for limits and criteria.
1) Tabletop mounted ultra-short
throw projection illustration
IMPROPER PROJECTOR PLACEMENT
Overhead placement or a standard
throw projector will make the image
very dark on account of the screen’s
absorbent layer deflecting light that
is not aligned with its reflective angle.
1) Ceiling mounted Ultra-short
throw projector illustration
2) Ceiling mounted Short and
Standard throw Projector Illustration
Note:
Images are not up to scale and are for
illustrations purposes only

User’s Guide Kestrel Tab-Tension 2 CLR® Series
Rev. V121421DT www.elitescreens.com 8
ANTI-PINCH SAFETY FEATURE
Prevent injury or damage to the screen when an object interferes with the screen’s descend during its
operation. The screen is equipped with an anti-pinch safety feature which prevents the closing panel/lid
to stop when it detects an object
For more information, technical support or your local Elite Screens®
contact, please visit http://www.elitescreens.com/
