Elkay Soft Sides ERFPD8C Installation manual

97869C (Rev. L - 03/23)
ERFP8C_C
Installation/Care/Use Manual
Soft Sides®Refrigerated Fountains
To assure you install this model easily and correctly, PLEASE READ
THESE SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLA-
TION. CHECK YOUR INSTALLATION FOR COMPLIANCE WITH PLUMB-
ING, ELECTRICAL AND OTHER APPLICABLE CODES. After installation,
leave these instructions inside the fountain for future reference.
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
FIG. 2FIG. 1
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER
LINES IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY
FROM THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREAT-
ING AN ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT
OF THE WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY
DRAIN FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE
THE FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
IMPORTANT! INSTALLER PLEASE NOTE.
Installer
NOTE: WATER FLOW
DIRECTION
BUILDING WATER
INLET
SERVICE STOP
(NOT FURNISHED)
1/4" O.D. TUBE
WATER INLET
TO COOLER
3/8" O.D. UNPLATED COP-
PER TUBE CONNECT
COLD WATER SUPPLY
FIG. 3
FIG. 4
13
2
6
3 4
5
147
NOTE: WHEN INSTALLING REPLACEMENT BUBBLER,
TIGHTEN NUT ONLY TO HOLD PARTS SNUG IN
POSITION. DO NOT OVER TIGHTEN.
20
ERFPD8C
PAGE 1

97869C (Rev. L - 03/23)
ERFP8C_C
PAGE 2
WALL LINE
9-3/8"
(238mm)
8-1/8"
(206mm)
3-1/8"
(79mm)
1-1/8"
(29mm)
3-13/16"
(97mm)
12-1/8"
(308mm)
19-3/4"
(502mm)
3-13/16"
(97mm)
20-3/8"
(518mm)
20-7/16"
(519mm)
33-1/2"
(851mm)
27"
(686mm)
ADA
REQUIREMENT
18"
(457mm)
12"
(305mm)
MIN.
DEPTH
BACK WALL LINE
3-1/2"
(89mm)
4-1/2"
(114mm)
1-1/8"
(29mm)
11"
(279mm)
FINISHED FLOOR
31-1/4"
(794mm)
18-3/4"
(476mm)
1-1/4" (32mm)
TRAP FURNISHED
2-1/2"
(64mm)
ELECTRICAL
INLET
3/8" O.D. COPPER TUBE
WATER INLET ON CHILLER
SHUT OFF VALVE BY OTHERS
1/4" O.D. TUBE CONNECT
(CHILLER WATER OUTLET)
15-1/16"
(382mm)
2-15/16"
(75mm)
34-7/8"
(886mm)
FILTER LOCATION (OPTIONAL)
ERFPM8K
FIG. 5

97869C (Rev. L - 03/23)
ERFP8C_C
ERFPD8C TUBE ROUTING
FIG. 6
TROUBLE SHOOTING AND MAINTENANCE
1. Orice Assy: Mineral deposits on orice can cause water ow to spurt or not regulate. Mineral deposits may be removed from
orice with a small round le not over 1/8" diameter or a small diameter wire.
CAUTION: Do not le or cut orice materials.
2. Stream Regulator: If orice is free of material deposits, regulate ow according to instruction 10 stated above.
3. Actuation of Quick Connect Water Fittings: Cooler is provided with lead-free connectors which utilize an o-ring water seal.
To remove tubing from the tting, relieve water pressure, push in on the gray collar while pulling on the tubing (See Figure 2). To
insert tubing, push tube straight into the tting until it reaches a positive stop, approximately 3/4".
INSTALLATION INSTRUCTIONS
1. Install remote chiller. Remove front panel of chiller. Remove and discard cardboard inner pack from between compressor and
side panel. Slide chiller onto the shelf and position it to the left within the guides on the shelf.
NOTE: Building construction must allow for adequate air ow on both sides, top, and back of chiller. See chiller instructions for
additional instructions.
2. Make water supply connections. Install a shut-o󰀨 valve and union connection to building water supply (valve and union not
provided). Turn on the water supply and ush the line thoroughly.
3. ERFP MODELS: Make connection between remote chiller and building supply line. Inlet port is marked on the chiller (1/4" O.D.
copper tube). Bend the copper tube (provided) at an appropriate length from chiller to opening in frame. Install the in-line strainer
(provided with chiller) by pushing it in until it reaches a positive stop, approximately 3/4" (19mm) on the marked chiller inlet port.
Connect building supply line to strainer. DO NOT SOLDER TUBES INSERTED INTO THE STRAINER AS DAMAGE TO THE
O-RINGS MAY RESULT. (See Figures 6 or 9).
4. Hang the upper panel on the mounting frame hanger. Align holes in the panel with the holes in the mounting frame. Be sure that
panel is engaged with hanger at top of frame before releasing it.
5. Install the fountain. Remove access cover plate on underside of fountains and save the screws. Mount the fountain to the
upper panel and the wall frame with (4) 5/16" x 3/4" (19mm) long bolts and nuts (provided). Tighten securely.
6. Remove elbow from end of p-trap and attach it to drain tube. Re-attach elbow to p-trap and cut waste tube to required length
using plumbing hardware and trap as a guide.
7. ERFP MODELS: Make connections between remote chiller outlet tube and fountain. Outlet port is marked on the chiller
(1/4" O.D. copper tube). Install a 1/4" x 1/4" union (provided) on the marked chiller outlet port. Insert the 1/4" poly tubing coming
from the fountain into the union. Turn on water supply and check for leaks. DO NOT SOLDER TUBES INSERTED INTO THE
UNIONS AS DAMAGE TO THE O-RINGS MAY RESULT. (See Figures 6 or 9).
8. These products are designed to operate on 20-105 PSIG supply line pressure. If inlet pressure is above 105 PSIG, a pressure
regulator must be installed in the supply line. Any damage caused by reason of connecting these products to supply line
pressures lower than 20 PSIG or higher than 105 PSIG is not covered by warranty.
9. Make electrical connections to the chiller. See chiller instructions.
10.Check stream height from bubbler. Stream height is factory set at 35 PSI. If supply pressure varies greatly from this, adjust the
screw on regulator item 6 by using a small screwdriver through the small hole in the push button item 3 (See Figure.3). Clockwise
adjustment will raise stream height and counter-clockwise will lower stream height. For best adjustment stream should hit basin
approximately 6 1/2" from the bubbler.
11. Mount lower panel. Loosen the (2) #10-24 x 5/8" (16mm) screws at frame bottom lip. Slide upper tongue of lower panel under
lower edge of already installed upper panel. Tighten previously loosened screws securely.
12. Replace bottom access panel to fountain basin using screws provided. Tighten securely.
PAGE 3
CHILLER
INLET
CHILLER
OUTLET
18
9
16 - TO
BUBBLER
16

97869C (Rev. L - 03/23)
ERFP8C_C
PAGE 4
REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
ELKAY MANUFACTURING COMPANY • 1333 BUTTERFIELD ROAD SUITE 200 DOWNERS GROVE, IL 60515 • 630.574.8484 • www.elkay.com
PART NO.
ITEM
NO.
PARTS LIST
Drain
Retaining Nut
Push Button
Push Button Sleeve
Regulator Holder
Regulator
Cap Screw
Screw - #10 - 24 X .50 PHTC
Strainer
Fountain Arm
Fountain Arm - (Glassller)
Bottom Cover Plate
Back Panel
Hex Nut
Regulator Mounting Bracket
Lower Panel
Poly Tubing (Cut To Length)
Tee - 1/4
Union - 1/4
Edge Trim - 2FT.
Kit-Bubbler
Screw - Mach 5/16-18 x 3/4
Nut - Hex 5/16-18
LK464
15005C
45662C
45663C
50986C
61313C
75672C
112627543890
55996C
28783C
27959C
55000665
26837C
40045C
28823C
26833C
56092C
70682C
70683C
56369C
97446C
111577243890
111577343890
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
NS
NS
DESCRIPTION
FIG. 8
10
SEE FIG. 4
SEE
FIG. 3
8, 11
15
1
12
FIG. 9
16 - TO
BUBBLER
16
18
CHILLER
INLET
9
CHILLER
OUTLET
ERFPD8C W/GLASSFILLER
16 - TO
GLASSFILLER
16
16
17
FIG. 7
19
