Elkay Swirlflo EDFPB114FPC Installation manual

98008C (REV. B - 4/06)
EDFPB114FP
1
Installation/Care/Use Manual
EDFPB114FPC
Swirlflo®Freeze Resistant Fountain
IMPORTANT! INSTALLER PLEASE NOTE.
THEGROUNDINGOFELECTRICALEQUIPMENTSUCHASTELEPHONE,COMPUTERS,ETC.TOWATER
LINESISACOMMONPROCEDURE.THIS GROUNDING MAYBE INTHE BUILDINGORMAYOCCURAWAY
FROMTHEBUILDING.THISGROUNDINGCANCAUSEELECTRICALFEEDBACKINTOAFOUNTAIN,CREAT-
INGAN ELECTROLYSISWHICHCAUSESAMETALLICTASTE ORANINCREASEINTHEMETALCONTENT
OFTHE WATER.THIS CONDITION ISAVOIDABLEBYUSINGTHE PROPER MATERIALSASINDICATED.
ANYDRAIN FITTINGS PROVIDED BYTHEINSTALLERSHOULDBEMADEOFPLASTICTOELECTRICALLY
ISOLATETHEFOUNTAINFROMTHEBUILDINGPLUMBINGSYSTEM.
IMPORTANT
ALLSERVICETOBE PERFORMED BYANAUTHORIZEDSERVICEPERSON
FIG. 1
NOTE: WATER FLOW
DIRECTION
BUILDING WATER
INLET
SERVICESTOP
(NOT FURNISHED)
1/4" O.D. TUBE
WATER INLET
TO COOLER
3/8" O.D. UNPLATED
COPPER TUBE CONNECT
COLD WATER SUPPLY
TUBE IS
SECURED
IN POSITION
SIMPLY PUSH IN
TUBE TO ATTACH PUSH IN COLLET TO RELEASE TUBE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
FIG. 2
OPERATION OF QUICK CONNECT FITTINGS
Toassureyouinstallthismodeleasilyandcorrectly,PLEASEREADTHESESIMPLEIN-
STRUCTIONSBEFORESTARTINGTHEINSTALLATION.CHECKYOURINSTALLATION
FORCOMPLIANCEWITHPLUMBING,ELECTRICALANDOTHERAPPLICABLECODES.
Afterinstallation,leavetheseinstructionswiththebuildingownerforfuturereference. This
FreezeResistantFountainisshippedintwoseparatecartons.Thesecondcartoncontains
theFreezeResistantPackageLKFRB1thatisinstalledonaninteriorheatedwall.Referto
theFreezeResistantPackagefortherough-indimensionsforinstallation.
Installer

EDFPB114FP
98008C (REV. B - 4/06) 2
16" 406mm
33 15/16" 863mm
1 5/8" 41mm
5" 127mm
6" 152mm 25 3/8" 645mm
1/2" 13mm
28 3/4" 730mm
29 1/4" 743mm
8" 203mm 3/4"
19mm
FINISHED FLOOR
B
A18 3/8"
467mm
3/8" (10mm) DIA HOLES (4) FOR SECURING MOUNTING PLATE TO STUDS
27" 686mm
ADA REQUIREMENT 13 3/8"
339mm
2 5/8" 66mm
3 5/8" 91mm
12" 305mm
MAX. WALL THICKNESS
FIG. 3
EDFPB114FPC ROUGH-IN
LEGEND: A= 7/8" (22mm) DIA. HOLE FOR WATER SUPPLY TUBE B = 1-3/4" (44mm) DIA. HOLE FOR WASTE LINE *Note: All dimensions are taken from the finished floor on the side of the wall that the fountain is installed on.
7 1/4" 184mm
12" 305mm
MAX. WALL THICKNESS

98008C (REV. B - 4/06)
EDFPB114FP
3
FIG. 4
CABLESHEATHADJUSTMENT
To Increase FreePlay
ToReduce Free Play
18
12,13
20 7
INSTALLATION INSTRUCTIONS
1. Wall should already be framed for the fountain using the positioning dimensions shown in Fig. 3. Shown
dimensions pertain to installation location (framing must support up to 300 lbs. weight). These dimensions are required
for compliance with ANSI Standard A117.1/ADA requirements.
2. The freeze resistant package must be mounted on an interior wall in a heated area. The room temperature of the
interior heated area must be 50° F (10° C) or higher. The freeze resistant package may be surface or recessed mounted.
If recess mounted the surface of the cover must be flush with the interior wall surface. The package is furnished with
screws for mounting the cover to the box. If the box is recess mounted, do not fasten the top and bottom of the cover to
the box. Use the holes on the front only.
3. To assemble the operating cable to the sleeve inside the fountain arm you will need to remove cap screw (Item 18, See
Fig. 4) and then remove Push Button and Pin (Items 12 & 13, See Fig. 4). Remove screw (Item 20, See Fig. 4) and you
will now be able to remove the Sleeve (Item 7, See Fig. 4) to get access to the adjustment nuts for additional adjustability.
(Fountain should be mounted to exterior wall) Create a loop in the cable and thread the free end of the cable through the
wall into the freeze resistant box. The adjustment nuts should be in the middle of threaded area on the operating cable.
See Fig. 4.
4. Connect free end of operating cable to the valve-operating bracket. The end of the cables must be recessed into the
indents on the pivot brackets.
5. Remove cable free play by adjusting the jam nuts on the ends of the operating cable. See Fig. 4.
6. Connect water line from fountain bubbler into freeze resistant box. The connection to the box uses a quick connect
water fitting. Position the water line, in the fountain, to drain back into interior mounted box. Any water left standing, in the
exterior line, can freeze. To insure positive draining of the bubbler supply tube, excess length should be trimmed off and
discarded.
7. Connect drain and water supply lines to the freeze resistant fountain. Inline strainer must be used on the inlet water
line.
START UP
1. Turn on building water supply and check all connections for leaks. Repair as required.
2. Stream height is factory set at 35 PSI. If stream height needs to be changed adjust the regulator in the freeze resistant
package. Clockwise adjustment raises stream height, counter clockwise adjustment will lower stream.
3. Adjust operating cable as required. Cable system should have a minimal amount of free play to allow for proper valve
operation. If the system is too tight the valve will stay in the on position creating constant water flow. Too much free play
will result in non-operation of the valve with the push-buttons.
4. Note: Water from the drain back tube in the freeze resistant package will continue to run while the valve is actuated.
5. After cable system is adjusted properly, stuff flexible insulation into any openings between the outside wall and the
interior box.
6. Recheck all connections. If all connections are leak free replace cover(s) on the freeze resistant box(es) and
fountain(s).

EDFPB114FP
98008C (REV. B - 4/06) 4
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
ELKAY MANUFACTURING COMPANY• 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484
FIG. 6
NOTE:
When installing replacement bubbler and
pedestal, tighten nut (Item 5) only to hold
parts snug in position. Do Not Over-
tighten.
Basin
SEE FIG. 5
3
2
FIG. 5
PARTSLIST
ITEMNO. PARTNO. DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
56073C
40322C
56011C
55997C
75580C
15027C
15025C
28474C
28473C
45767C
28343C
45848C
45821C
56163C
45769C
45768C
56092C
75669C
70817C
111008343890
70432C
75560C
Bubbler Assy
Orifice Assy
Housing Assembly
Pedestal
Bubbler Locknut
Brkt - Swirlflow
Assy - Sleeve/Button Swirlflo
Basin - Swirlflow
Lower Shell
Fountain Body
CoverPlate
Button - Push Swirlflo
Pin - Push Button Swirlflo FP
Gasket - Drain
Assy - Drain/Tailpipe
Drain - Plug 1-1/2
Poly Tubing (Cut To Length)
Cap Screw - #6-32 x 1.25"
Fttng - Elbow 1/4 x 1/4
Screw - #10-24 x .62 HHSM
Screw - #8-32 x .38 THTC
Screw - 5/16-18 x 1.00 HHMS
17,19 15
11, 21
9
514
8
16
5
4
1
10
13 18
12 20 7
6
22
20
